293

Radio

R

Auto Memory (A MEM)

The automatic memory function
programmes the nine strongest
stations on a selected waveband
to presets 1 to 9.

Note: These are additional to the preset
stations described earlier.

To activate this function, press and hold
A MEM button for at least two seconds.

The radio will be briefly muted while it
searches the waveband for the nine
strongest stations. When programming is
complete the radio will default to preset
number 1 and audio volume is restored.

If stations cannot be located for all preset
positions, those that are found will be
allocated positions commencing with
number 1, leaving the remainder not
programmed. The display will show
NO FM or NO AM if a selected preset are
is not programmed.

To switch between the A MEM preset
stations and your own presets, press and
immediately release the A MEM button.

A MEM with Radio Broadcast Data
System (RBDS) selected

If the A MEM function is operated while in
RBDS mode, the radio will be muted
briefly, while a search is made for the nine
strongest RBDS stations.

Radio Set Up

This function enables the radio to be set
to user operating preferences. By
selecting SET UP and using the preset
buttons, the owner or Jaguar Dealer can
adjust certain radio functions.

When in SET UP, pressing the relevant
preset button, as detailed below, will
display the facility selected and its state.
The state of that facility can be changed
by pressing the preset button again.

To enter SET UP: Press CD Eject and
BAND buttons simultaneously.

The display will show SET UP. The
following preferences can be selected or
changed in any order, within a 15 second
period. After 15 seconds the display will
clear and exit SET UP.

Preset 1

Press Preset 1 to enable
or disable RBDS
availability in the user’s
country.

Preset 2

Blank

Preset 3

Blank.

Preset 4

Blank.

Preset 5

Blank

Preset 6

FM volume high
(compensate for poor
signal strength).

Note: This feature is not
available in
North America, Australia
and Japan.

Preset 7

Blank.

Preset 8

Blank.

Preset 9

Blank.

Radio

294

L

Preset 10

During initial factory
installation, this is used
to set the radio to one of
the following regions:
Europe, USA, Australia
or Japan. Regional
settings determine the
correct frequency
increments required for
seeking stations,
automatic tuning etc.

Note: The regions are
preset at the factory.
Should you require a
regional change, consult
your Jaguar Dealer.

295

Radio

R

RADIO WITH TOUCH-SCREEN

On/Off control

Press the control knob to
switch the radio on, press
again to switch off.

Pressing the AUDIO button
can also turn on the radio.
When using the
touch-screen in other
operating modes, such as
Navigation, Television

(where fitted), Climate Control or any of
the setup screens, pressing the AUDIO
button will revert to the relevant audio
screen.

Volume control

Turn the control knob clockwise to
increase or counter-clockwise to
decrease volume, across a range of
settings (0 – 35) to be displayed during
and momentarily after adjustment.

When using the rotary control knob to
adjust volume the touch-screen will show
the above display to assist setting. The
pop-up volume control slide will
disappear from the display after
five seconds or can be removed by
touching it.

Any volume setting made whilst in audio,
telephone or navigation mode or
JaguarVoice, will be memorised for that
system.
Automatic Volume Control

This maintains radio volume at a level
sufficient to overcome road noise as
vehicle speed increases or decreases. To
activate AVC, press the MENU button,
followed by the VOLUME PRESET
button on the touch-screen. Once in the
volume preset screen, AVC level can be
adjusted (from OFF to 5) by repeatedly
pressing the + or – buttons adjacent to
the AVC volume indicator.

When AVC is ON, manual adjustment of
volume will override the AVC setting.

Volume preset adjustments

Volume for Telephone, JaguarVoice, TA
and Navigation can also be adjusted by
using the MENU button on the right of the
screen and selecting the volume preset
button as appropriate.

Radio

296

L

Audio setup

This function enables the radio to be set
to user operating preferences. By
selecting SETUP and using the buttons
on the touch-screen, the owner or Jaguar
Dealer can adjust certain radio functions.

When in SETUP, pressing the relevant
button will display the facility selected
and its state. The state of that facility can
be changed by pressing the button again.

To enter SETUP: Press Eject and BAND
buttons simultaneously.

The display will show AUDIO SETUP. The
preferences shown on the next page can
then be selected or changed in any order.
After 15 seconds the display will clear and
exit SETUP.

Market

During initial factory
installation, this is used
to set the radio to one of
the following regions:
Europe, Australia or
Japan. Regional settings
determine the correct
frequency increments
required for seeking
stations, automatic
tuning etc.

Note: The regions are
preset at the factory.
Should you require a
regional change, consult
your Jaguar Dealer.

RBDS/
RBDS

Press ON/OFF buttons
to enable or disable
RBDS, depending upon
RBDS availability in the
user’s country.

FM Volume

FM volume high or low
(compensate for poor
signal strength).

Note: This feature is not
available in Australia and
Japan.
