Jaguar XJ (2008 year). Manual - part 6





25

Quick Start

R

Downloading phone book entries

1. Turn the ignition switch to position II

and make sure that the handset is
paired to the vehicle’s system.

2. Press the telephone button on the

audio panel or touch-screen
surround.

3. Switch off the ignition switch and wait

for your phone to disconnect from the
vehicle to allow the system to
complete the download process.

Making a call

1. Press and hold the SELECT switch on

the steering wheel control, or press
the call button on the audio panel.
Phone will be displayed.

2. Key in the phone number required on

the touch-screen or audio panel
keyboard.

3. Press the call button on the steering

wheel control, or on the audio panel.
Calling will be displayed.

4. To end the call, press the call button

on the steering wheel control, or on
the audio panel.

Receiving a call

To answer or end a call, press the call
button on the steering wheel control or on
the audio panel.

Mobile phone compatibility
There are a number of mobile phones
that have been tested to function
correctly with the Jaguar system,
however, not all mobile phones are
compatible. For the latest list of
compatible phones and software
versions, please refer to
www.ownerinfo.jaguar.com.
Alternatively consult your Jaguar
Dealer.

JOL4717

26

Filling Station Information

L

Filling Station Information

FUEL TYPE

Unleaded 95 RON.

FUEL FILLING

With the vehicle unlocked, press the fuel
flap release button on the knee bolster
switchpack, see page 178.

The filler flap is located on the right-hand
side of the vehicle.

Ensure that the fuel nozzle rests on the
filler neck when filling with fuel. After
refuelling, twist the filler cap clockwise
until it clicks and close the flap, which
automatically locks shut.

TIRE PRESSURES

Check pressures when the tires are cold,
see page 249. Deflating air from a warm
tire to the recommended pressure will
result in under-inflation which may be
dangerous.

!

WARNING:

When using tires other than those
recommended by Jaguar, do not
exceed the speed capacity
recommended by the tire
manufacturer.

USA

A tire information label/placard is visible
on the pillar behind the driver’s door (also
known as the B pillar).

The label/placard is shown on page 250.

JAG0626

JAG0598

JAG0798

27

Filling Station Information

R

Canada and Mexico

The tire pressures are shown on a label
affixed to the inside of the fuel filler flap.

For your convenience, you may wish to
record the tire pressures in the boxes
provided below. If you are unsure of the
correct pressures, please contact your
Jaguar Dealer.

HOOD RELEASE

Pull the release lever located below the
facia on the left-hand side of the vehicle,
see page 233.

Lift the hood slightly and push the safety
catch located under the centre of the front
edge of the hood, then lift the hood.

FRONT

Normal Driving

Laden/High Speed

REAR

Normal Driving

Laden/High Speed

28

Filling Station Information

L

UNDERHOOD TOP-UP

Recommended engine oil
See page 235.

An oil of 5W-30 viscosity to Jaguar
specification WSS M2C913 - B must be
used in all vehicles.

For top-up purposes only, where the
WSS M2C913 - B specification cannot be
found, ACEA A3/B3 or ACEA A1/B1
specification oils may be used.

Windshield/headlamp washer reservoir

See page 241.

Coolant system

See page 242.
