Jaguar XJ (2008 year). Manual - part 5

Quick Start

AUDIO SYSTEM KEY
FEATURES

General operation

Press the control knob 1 to switch on or
off and rotate to adjust the volume.

To adjust the sound settings, press the
MODE button 2 repeatedly, until the
required setting is displayed. Turn the
control knob 1 to adjust the level or rating.

After approximately five seconds, the
system will return to normal control mode.

Steering wheel controls

1. Press to mute the audio unit.

2. Press, as required, to increase or

decrease volume.

3. Press and release to cycle through

Radio, FM, AM, CD, and CD
multichanger.

4. Press and release to cycle through

preset radio stations or to skip to the
next CD track.

Press and hold for at least two seconds to
cycle to the next strongest station or next
CD.

JAG0624

JOL4712

Quick Start

RADIO OPERATION

To switch on the radio
function, press the BAND
button. Pressing this button
repeatedly scrolls through

FM, MW wavebands and satellite or
digital stations (if fitted).

To search for a radio
station, press the Seek
arrow buttons.

Setting the radio presets

Once a radio station
has been tuned,
press and hold the
desired preset
button (or touch a
station position on

the touch-screen) until a beep is heard.
The preset is now stored.

A total of nine presets can be stored for
each waveband.

The radio presets can be
automatically set by using the
automatic memory function.

Press and hold the AMEM button for two
seconds. The radio will be briefly muted
while it searches the waveband for the
nine strongest stations.

To select the stored radio stations, press
or touch the required radio preset button
(1 to 9).

Activating TA (Traffic Announcements)

To activate this function, press
and release the TA button. With
TA activated, traffic

announcements will interrupt radio or CD
play.

To de-activate this feature, press and
release the TA button again.

CD OPERATION

Single CD player

If the radio or CD multichanger is
being used, pressing the CD
button will resume playing any

CD installed in the player mechanism.

When a CD is loaded into the aperture, it
will begin to load and play automatically.

Pressing the CD button, while in CD play
mode, will pause the current track. A
subsequent press of the CD button will
resume play mode.

To skip tracks, continually
press the Seek arrow
buttons to move back or

forward accordingly. Pressing and
holding these buttons will search through
the selected track.

When a disc is inserted, the CD
icon is displayed. Press the disc
eject button to eject the CD.

The display will show DISC EJECT and
the CD icon will be turned off.

Six discs can be loaded into the
multichanger unit, and a further single
disc in the audio console.

Quick Start

CD Multichanger

The CD multichanger is located in the
luggage compartment. To load a CD into
the multichanger:

1. Slide open the multichanger door;

press the Eject button and remove
the magazine. Close the door.

2. Pull a tray out from the magazine and

insert a CD (label side up). Slide the
tray into the magazine until a click is
heard.

3. Slide open the multichanger door and

ensure correct orientation, replace the
magazine. Make sure that the
magazine clicks into position.

CD selection

1. Press the CDC button to
select the CD multichanger
mode.

2. Press preset buttons 1 to 6 to select

the appropriate CD loaded in the
multichanger.

If a touch-screen is fitted to the
vehicle, disc selection can be made
by touching the relevant numbered
disc icon.

3. When playing a CD, press the CDC

button to pause play. Press again to
continue play.

Playing random tracks

To play random tracks from the
disc, press and release the MIX
button. To cancel, press the MIX

button again.

To play random tracks from all discs
loaded in the multichanger, press the MIX
button for two seconds. To cancel, press
and hold the MIX button.

Care point
Remember to close the multichanger
door. This will prevent dirt getting into
the unit and help reduce skipping.

JAG0625

Quick Start

TELEPHONE - BLUETOOTH®
SYSTEM

Jaguar approved mobile phones can
communicate with the vehicle’s inbuilt
telephone system. Please refer to the
Jaguar website for a list of approved
phones.

The following procedure demonstrates
how to connect the most popular brands
of mobile phone.

Pairing a handset to the vehicle

1. Turn the ignition switch to position II.

2. Press the telephone button on the

audio panel. Ensure that no mobile
phone is connected to the system.
The touch-screen will display the
message Discover Me. On non-touch
screen systems the message SIG****
or SIG***** will be displayed.

3. Prepare the handset for pairing to the

system.

See the telephone manufacturer’s
instructions for further details, or follow
the table below for generic commands.

When the handset has been successfully
paired to the system, the touch-screen
message changes to Registered
followed by the message Phone
Connected. On systems without a
touch-screen the audio system message
changes to SIG*.

If your phone is capable of sending the
signal strength and network operator’s
name, this information will be displayed
on the touch-screen. For systems without
touch-screen, the signal strength only will
be displayed.

Nokia

Motorola

Ericsson

Select menu

Select settings

Select connectivity

Select Bluetooth OR
Select Connectivity
then Bluetooth

Select Connection

Select Bluetooth

Select On

Select Bluetooth link

Select My Devices

Select Search for Audio
devices

Select Hands-free

With New Device
highlighted, select Add.
Press OK to confirm

After search select
Jaguar

Select Look for
devices

After search select Jaguar

Enter pass code 1313.
Press OK to confirm

After search select
Jaguar

Select Connect

No connection? Select
Bluetooth (Menu) then
Paired devices Jaguar

Permission to bond?
Select Yes and enter
pass code 1313

Enter pass code 1313 after
prompt

For best results when pairing your
handset to the system, ensure the
handset is fully charged.
