Quick Start

Pedal adjustment

Turn the control to PEDALS and move the
control to adjust the fore/aft position of
the pedals.

Driver’s seat movement with starter
switch off

If the control is set to AUTO, the position
of the steering column and driver's seat
will automatically adjust to provide
greater clearance for exit and entry when:
• the key is in the ignition switch and the

driver’s door is opened;

• the ignition key is removed.

ELECTROCHROMATIC REAR
VIEW MIRROR

With the ignition switch on, the rear view
mirror will automatically darken in
proportion to the amount of glare
detected from the following vehicles'
headlamps. This feature is automatically
switched off when reverse gear is
selected.

WINDOWS AND DOOR
MIRRORS

Windows

The windows are fitted with a facility that
allows them to be fully opened or closed
with a single operation of the switch.
• To open the window, press the

respective window switch. Press the
switch again to stop the window from
fully opening.

• To close the window, pull the switch

up. Pull the switch again to stop the
window from fully closing.

E86306

JAG0611

Quick Start

Press button 1 to inhibit the operation of
the rear window switches and electric rear
seats (when fitted).

Door mirrors

To adjust the door mirrors, press the
mirror selector switch 2 left or right to
select the appropriate mirror. Use the
four-way switch to adjust the position.

Power fold mirrors

The mirrors can be folded towards the
door for better clearance/protection by
pressing button 3. Press the button again
to unfold the mirrors.

The mirrors will automatically unfold next
time the vehicle is unlocked with the
handset.

DRIVING POSITION MEMORY

Once you have adjusted the driver’s seat,
steering column, pedals and exterior
mirrors for your ideal driving position, the
vehicle can memorise these settings for
future use.

1. Insert the key into the starter switch

and leave in the OFF position.

2. Push the memory button M and a red

indicator in the switch will illuminate
for five seconds.

3. Whilst the indicator is illuminated,

press button 1, 2, or 3 to memorise
the current settings.

The indicator will extinguish and an
audible chime will sound to confirm that
the settings are memorised. Any existing
settings will be overwritten.

To recall a memorised driving position
press buttons 1, 2 or 3.

Reminder - Global closing
If a window has been left open when
leaving the vehicle, it can be closed by
pressing and holding the lock button
on the remote handset (this will also
close the sunroof).

Remote handset programming
With the key in the starter switch and
the M button illuminated, you can
program a remote handset to a
memory position by pressing any
button on the remote handset.

Quick Start

SEAT BELTS AND CHILD
RESTRAINTS

A warning indicator on the
instrument pack will illuminate
to alert you that the driver’s

and/or front passenger’s seat belt is
unbuckled. Dependent upon specification
this may be accompanied by an
intermittent chime.

Child Seats

It is important to remember that your
child’s weight, rather than age,
determines the type of seat that is
required.

Refer to Child Safety to determine the
correct seat for your child, see page 82.

Automatic Locking Reels (ALR)

All passenger seat belts have ALR fitted
for use with child seats.
• To engage: extend the belt to

maximum length to enable locking
mechanism.

• To disengage: unbuckle the belt and

allow the belt to fully retract.

OVERHEAD CONSOLE

Rear window blind

Press button 1 to raise the rear window
blind. Press the button again to lower the
blind.

Parking assist

Press button 2 to turn off the front and
rear parking sensors.

Sunroof

The sunroof is fitted with a facility that
allows it to be fully opened or closed with
a single operation of switch 3.

With ALR enabled, as the seat belt
retracts, it will automatically lock
preventing re-extension.
Ensure passengers do not fully extend
the restraints and inadvertently engage
this feature during normal use.

Parking assist care points
Sensors may activate on detection of
water, snow or ice on their surface.
This is entirely normal and regular
cleaning will aid performance.
Parking assist may sound if it detects a
signal operating at the same frequency
to that of the sensors (e.g.
motorcycles, airbrakes).

JAG0621

Quick Start

Garage door opener

The buttons 4 on the overhead console
can be programmed to transmit radio
frequencies that can operate external
devices, i.e. garage doors, entry gates,
security systems, etc.

For more information, see page 60.

CLIMATE CONTROL

These are the primary functions of the
climate control system:

For those vehicles fitted with
the touch-screen navigation
system, the advanced climate

control functions can be accessed by
pressing the Climate button.

AUTO (automatic) mode

Press to select automatic
operation of the climate
control system. The system

will adjust the heat output, blower speed,
air intake and airflow distribution to
maintain the selected temperature(s) and
reduce misting, without further
adjustments.

Screen heaters and timed air recirculation
may be selected whilst in AUTO mode.
Selecting any other function will cancel
AUTO operation.

Closing remotely
If the sunroof has been left open when
leaving the vehicle, it can be closed by
pressing and holding the lock button
on the remote handset.
