Jaguar S-Type. Manual - part 4

19

Quick Overview

R

AUTOMATIC TRANSMISSION

Gearshift interlock

The ignition switch must be in position II
and the foot brake applied before the gear
selector can be moved from P (Park) to R
(Reverse). The lever can be moved into P
with the ignition switch off.

Gear selector

The gear selector lever is designed to
accommodate two different driving
techniques as follows:

Automatic selection: the right-hand side
of the selector gate.

Manual selection: the left-hand side of the
selector gate, to individually select 5th,
4th, 3rd or 2nd gear.

With the gear selector in D (Drive) and
Sports mode active, the transmission will
use 6th gear less at higher cruising
speeds.

Fuel consumption will be adversely
affected.

After selecting R (Reverse) or D (Drive)
from N (Neutral) or P (Park), wait briefly for
the transmission to engage before
accelerating.

Sport mode

Press the switch (arrowed) to select Sport
mode. A red indicator in the switch will
illuminate to indicate that Sport mode is
active. When Sport mode is selected, the
gear change points are modified to make
full use of the engine’s power.

JOL4707

20

Quick Overview

L

PARKBRAKE

Applying the parkbrake

• With the vehicle stationary, pull up the

parkbrake lever and then release. The
parkbrake red warning indicator in the
instrument pack will illuminate.

• The parkbrake will automatically apply

when the ignition key is removed from
the lock.

Releasing the parkbrake
• On manual transmission vehicles,

with the ignition switch in position II,
press down on the parkbrake lever.

• On automatic transmission vehicles,

with the ignition switch in position II,
apply the foot brake and press down
on the parkbrake lever.

• On automatic transmission vehicles, if

the vehicle is stationary with the
parkbrake applied and either D (Drive)
or R (Reverse) is selected, pressing
the accelerator pedal will
automatically release the parkbrake.

• The parkbrake will automatically

release when the gear selector is
moved from P (Park).

CRUISE (SPEED) CONTROL

Speed control

Speed control is the standard cruise
control system where the vehicle will
maintain a SET road speed until either
cruise control is cancelled or the brake
pedal is used.
The system is controlled via switches on
the steering wheel:

1. RESUME - to resume a set speed

retained in memory.

2. SET - to set the road speed to be

maintained, or increase or decrease
the speed in 2 km/h (1 mph) steps
when cruise control is operating.

3. CANCEL - cancels cruise control, but

retains the set speed in memory.

Brake pedal override
• Cruise control will automatically

disengage when the brake pedal is
pressed or when the vehicle speed
falls below 26 km/h (16 mph).

JOL4708

1

2

3

JOL4709

21

Quick Overview

R

ADAPTIVE CRUISE CONTROL
(ACC)

The Adaptive Cruise Control system is
designed to aid the driver in maintaining a
gap to the vehicle ahead, or to maintain a
set road speed if there is no slower
vehicle ahead. The system is controlled
via switches on the steering wheel:

1. RESUME - to resume a set speed

retained in memory.

2. SET - to set the road speed to be

maintained, or increase or decrease
the speed in 2 km/h (1 mph) steps
when cruise control is operating.

3. CANCEL - cancels cruise control but

retains the set speed in the memory.

4. GAP - increase or decrease the time

gap to the vehicle ahead.

The gap to the vehicle ahead can be
changed to one of four pre-defined
intervals and the current setting will be
displayed in the message center.

When a vehicle ahead enters the same
lane as you, or a slower vehicle is
encountered in the same lane, the road
speed will automatically be adjusted to
maintain the currently selected time gap.
The warning indicator will illuminate to
indicate that the vehicle is in ‘follow
mode’.
• Adaptive Cruise Control is not a

collision warning or avoidance
system. Additionally the system will
not detect:

• Stationary or slow moving vehicles

below 10 km/h (6 mph).

• Pedestrians or objects in the

roadway.

• Oncoming vehicles in the same lane.

V

I

V

V

I

I

I

V

1

2

3

JOL4710

4

22

Quick Overview

L

AUDIO SYSTEM KEY
FEATURES

General operation

Press the control knob A to switch on or
off and rotate to adjust the volume.

To adjust the sound settings, press the
MODE button B repeatedly, until the
required setting is displayed. Turn the
control knob A to adjust the level or rating.

After approximately five seconds, the
system will return to normal control mode.

Steering wheel controls

1. Press to mute the audio unit.

2. Press as required to increase or

decrease volume.

3. Press and release to cycle through

Radio, FM, AM, CD multichanger.

4. Press and release to cycle through

preset radio stations, the next CD
track.

Press and hold for at least two seconds to
cycle to the next strongest station or CD.

JOL4711

A

B

1

2

3

4

JOL4712
