Jaguar S-Type. Manual - part 3
15
Quick Overview
R
Screen heaters and timed air recirculation
may be selected whilst in AUTO mode.
Selecting any other function will cancel
AUTO operation.
Recommended mode
• Select AUTO as the normal operating
mode.This will help prevent window
misting and odours from the climate
control system.
Dual temperature zones
With the DUAL button LED
illuminated, the system
provides separate temperature
control of the driver and front passenger
zones.
Press the button to de-select dual mode.
The temperature of the passenger zone
will automatically adjust to that of the
driver’s zone and the temperature of both
zones will be controlled by the driver’s
temperature control buttons.
Temperature selection
Press the red buttons to
increase temperature
and the blue buttons to
decrease temperature.
To quickly jump from HI or LO to a
mid-range temperature setting, press and
hold the AUTO button for a few seconds.
Air conditioning (A/C)
Air conditioning is an integral
part of the climate control
system, providing cooled and
dehumidified air for occupant comfort;
the dry airflow is also effective in
preventing misting of the windows.
Press the button to switch the air
conditioning system on or off. Air
conditioning is controlled automatically
when the vehicle is in AUTO mode.
De-selecting A/C will cancel AUTO mode.
External water deposits
• The air conditioning system removes
moisture from the air and deposits the
excess water beneath the vehicle.
Puddles may form, but this is normal
and no cause for concern.
Windshield defrost and demist
Press the DEF (defrost) button
to remove frost or heavy
misting from the windshield.
The rear screen and windshield heaters
will be activated.
To de-select defrost mode, press AUTO.
The rear screen and windshield heaters
will remain on.
Heated screen and door mirrors
The rear screen heater can be
switched on or off in any mode,
even when the climate control
system is off, but will only operate when
the engine is running.
Operating the DEF button will
automatically activate the front and rear
screen heaters.
The door mirror heaters are controlled by
the rear screen heater button.
