C36, component side C36, component side Pin 01
Pin 02
Is the resistance between 0 and 5.5 ohms? -> Yes An intermittent fault may be present in the wiring harness. Visually check for chaffed wires or other physical damage to the harness. If no fault is found in the circuit, suspect the following component(s): - Port de-activation solenoid connector - Port de-activation solenoid - ECM connector - ECM
-> No INSTALL a new port de-activation solenoid. Clear any DTCs, test the system for normal operation. G552277t8 : CHECK WHETHER THE SHORT CIRCUIT TO GROUND IS IN THE 1. Key off. 2. Disconnect the ECM connector, C100. 3. Key on, engine off. 4. Measure the resistance between: C36, harness side Battery
Pin 02
Negative terminal
Is the resistance greater than 100 Kohms? -> Yes An intermittent fault may be present in the wiring harness. Visually check for chaffed wires or other physical damage to the harness. If no fault is found in the circuit, suspect the following component(s): - ECM
-> No REPAIR the short circuit. For additional information, refer to the wiring diagrams. Clear any DTCs, test the system for normal operation. G552277t9 : CHECK WHETHER THE SHORT CIRCUIT TO POWER IS IN THE 1. Key off. 2. Disconnect the ECM connector, C100. 3. Key on, engine off. 4. Measure the resistance between: C36, harness side Battery
|
