32 . Install the crankshaft sprocket.
33 .
CAUTION: Make sure the timing chain slack is on the tensioned side of the timing chain.
Install the left-hand primary timing chain.
Install the primary chain over the crankshaft sprocket and the intake sprocket.
34 . Install the left-hand primary timing chain tensioner guide.
Tighten to 12 Nm.
|
