12. Remove mounting nuts of the shock absorber from

the cab.

Remove the plastic cap.

Remove nuts and washers for fixing the piston
rod with an L-shaped wrench.

Remove the disc washer.

Caution:

Caution:

Caution:

Caution:

Pay attention not to damage the lower swing
arm ball joint for connecting the shock absorber
and the front suspension.

13. Lay down the lower swing arm assembly and

remove the helical spring.

14. Support the cross rail.

15. Remove the cross rail assembly.

① Remove the two bracket nuts and bolts
from the front suspension.

② Remove the four cross rail bolts.

Installation
1.

Reinstall the cross rail assembly.

Lift the cross rail, install the two bracket nuts
and bolts of the subframe relaxedly.

Reinstall the four cross rail bolts.

Tighten bracket nuts and bolts of the front
suspension.

1

2

2

1

FAX

FAX

FAX

FAX Front

Front

Front

Front Suspension

Suspension

Suspension

Suspension

-119

119

119

119 -

Removal

Removal

Removal

Removal and

and

and

and Installation

Installation

Installation

Installation of

of

of

of Subframe

Subframe

Subframe

Subframe (Continued)

(Continued)

(Continued)

(Continued)

2.

Reinstall the helical spring.

Ensure following operations:

Correctly prevent the shock insulator from
opening.

Correctly

combine

the

shock

insulator

connector.

Place the lower end of the helical spring into
the deepest place of the lower swing arm
groove.

3.

Remove the shock absorber.

4.

Lift the lower swing arm assembly and install the
shock absorber.

5.

Fix the shock absorber from the cab.

Reinstall the disc washer.

Support nuts and washers of the piston rod
with the L-shaped wrench.

Install nut caps.

6.

Reinstall the wheel hub assembly.

7.

Reconnect the brake hose onto the shock absorber.

8.

Install each end of the steering tie rod onto the
steering knuckle.
Fix castle nuts with a new cotter pin.

Caution:

Caution:

Caution:

Caution:

The convex side of the washer at the joint of the

front anti-roll bar should face the rubber shaft
sleeve.

9.

At the mounting position of the front anti-roll bar
link, connect it with the lower swing arm.

Caution:

Caution:

Caution:

Caution:

Make

sure

that

the

steering

wheel

is

in

straight-ahead position.

10. Then install tires and lower the vehicle.
11. Align clamped plates of the cross shaft with the

steering column and fix them with a new bolt.

12. Reconnect the negative cable of battery.

FAX

FAX

FAX

FAX Front

Front

Front

Front Suspension

Suspension

Suspension

Suspension

---- 120

120

120

120 ----

Disassembly

Disassembly

Disassembly

Disassembly and

and

and

and Assembly

Assembly

Assembly

Assembly of

of

of

of Subframe

Subframe

Subframe

Subframe

Disassembly
1.

Remove the two mounting bolts at the mounting
position of the front anti-roll bar.

2.

Remove the steering gear box.

3.

Remove the lower swing arm assembly.

Remove connecting bolts between the lower
swing arm and the subframe.

Remove feedthrough bolts and nuts between
the lower swing arm and the subframe.

4.

Remove the compression travel stop block.

FAX

FAX

FAX

FAX Front

Front

Front

Front Suspension

Suspension

Suspension

Suspension

-121

121

121

121 -

Removal

Removal

Removal

Removal and

and

and

and Installation

Installation

Installation

Installation of

of

of

of Subframe

Subframe

Subframe

Subframe (Continued)

(Continued)

(Continued)

(Continued)

Assembly
1.

Install the compression travel stop block.

2.

Reinstall the lower swing arm assembly.
Install feedthrough bolts and nuts between the
lower swing arm and the cross rail from the rear
side.

3.

Align and reinstall the lower swing arm assembly.

Tighten bolts between the front suspension
and the subframe.

Insert feedthrough bolts into the cross rail,
install and then tighten them.
