88
ELECTRIC/ELECTRONIC SYSTEM
D
AILY
Base - May 2004
Code
Function
Code
Function
Code
Function
25035
Switching on external lights
25003
Switching on fog lamps
25006
Switching on stop lights
25704
Total power takeoff engagement control
25104
Switching off Retarder with ABS on
25209
Loads cut-off during starting
25222
Thermal starter engagement enable
25223
Thermal starter fan control
25307
Climate control compressor engagement
25336
Engine cooling
25337
Climate control compressor disengagement
25340
Compressor on signal
25620
Fuel filter clogged signal
25705
Diagnostics enable
25810
Heated fuel filter circuit control
25811
Advance variator control (KSB)
25818
Heated windscreen switching on
25837
Electric fuel pump switching on
25858
EDC switching on
25926
Suspension raising enable
25927
Suspension lowering enable
25928
Rear-screen heating switching on
61002A
Anti-return from Trinary
61002B
Anti-return from TGC (bus)
66010
Timer for headlamp washer
!
Fuse 39 must be replaced with a 10A fuse if the following optionals are present on the vehicle at the same time:
- heated wing mirrors with heated driver's seat;
- heated wing mirrors with heated driver's and passenger's seat;
- heated wing mirrors with electric aiming with heated driver's seat;
- heated wing mirrors with electric aiming with heated driver's and passenger's seat.
Fuse 41(39 for F1A) must be replaced with a 15A fuse if the following optionals are present on the vehicle at the
same time:
- heated windscreen with heated rear-screen.
Fuse 55 must be replaced with a 15A fuse if both the seats are heated.
Fuse 70060 (40A) relating to the ABS, device is located in the engine compartment, near the control box.
For the F1A, plug preheat centre 25231is located on the engine compartment to the right of the EDC centre and
is powered by 60A fuse 70064.
The previous indications (fuses/remote control switches) can be changed. Should it occur, make reference to the indications
on the sticker label next to the fuses.
