Mount the following, tightening the screws to the prescribed - supports (1 and 5) - ;alternator (2); - support (4) and compressor (3) DIAGRAM FOR FITTING BELT DRIVING Using a suitable tool (6), work in the direction of the arrow Using a suitable tool (3), work in the direction of the arrow Figure 84 Figure 85 Figure 86 The tighteners are automatic, so there are no 99255 99275 ENGINES F2BE0684A*B001 1. Alternator - 2. Water pump - 3. Crankshaft - 4. Compressor. 99276 Figure 87 ENGINE F2BE0687A*B101 1. Alternator - 2. Water pump - 3. Crankshaft. 99277 NOTE SECTION 3 - INDUSTRIAL APPLICATION 27 |
