7A–74 AUTOMATIC TRANSMISSION (4L30–E) Reverse Clutch Piston And Center Support Disassembled View 242RY001 Legend (1) Retaining Ring (9) Restrictor (10) Retainer Plate (11) Plug (12) Spring Disassembly 1. Install the J–23327 compressor tool on spring seat, then compress the spring seat. D Remove retaining ring (1). NOTE: Do not over–stress the springs and seat, as this D Remove the compressor tool. |
