6A3-144 ENGINE (4HF1 / 4HF1-2 / 4HE1-TC / 4HG1 / 4HG1-T) 54. Clutch Pressure Plate Assembly 1) Align the clutch pressure plate with the flywheel knock pin. 2) Tighten the pressure plate bolts to the specified torque in numerical order. Tighten: ⋅m (4.1 kg⋅m/30 lb⋅ft) 55. Cylinder Head Gasket Above works refer to “CYLINDER HEAD” section 57. Camshaft Bearing Lower Above works refer to “CAMSHAFT ASSEMBLY” 62. Rocker Arm Shaft Assembly Above works refer to “ROCKER ARM SHAFT AS- 63. Head Cover Gasket Above works refer to “CYLINDER HEAD” section 64. Cylinder Head Cover 1) Install the cylinder head cover. to the specified torque in the numerical order Tighten: ⋅m (1.8 kg⋅m/13 lb ⋅ft) Legend 1. Clutch pilot aligner Legend A. Knock pin N6A0351E N6A0352E N6A0383E |
