Self-lock handle
Tilting puller holder
self-lock handle
10
When the cabin tilts to a certain angle, the self -locking handle on the tilting
support will automatically locks in by the spring tension, and the handle will
support the cabin then.
Cabin lockup
With left hand holding firmly the tilting puller support, open the self-lock handle
upward and backward with right hand. The cabin will tilt downward by itself due
to the deadweight.
Attention: Keep your head and hands away from under the cabin when it is tilt鄄
ing downward by itself.
OWNER爷S MANUAL
JAC High end Light Trucks
When going down to a certain angle, the cabin will slow down. Hold the tilting
puller support and press it down with left hand, until the lock hook get engaged
in the hook limit support on the frame.
Then hold the operating handle with right hand and press it down, until the
safety hook securely locks the operating handle.
11
