The followings are very important for the correct management and economic use of JAC vehicles, and
they shall be read carefully before use and maintenance.
Locations of chassis number and engine number
Please note down the chassis number and engine number, so as to give them
to the specified JAC maintenance stations in case of repair and maintenance.
Chassis number
The chassis number, which is VIN code number, is stamped on the outer side
of the right longeron end of the frame.
Engine number
The engine cylinder head is affixed with the engine tag, on which it is marked
with information about the engine, such as its model, serial number, nominal
horse power, rated engine speed, ex-works date, etc.
Location of the vehicle nameplate
The embossed number of VIN code for vehicle and Type II chassis is located
on the outer side of the right longeron of the frame as well as, on the back side
of the rear support of the rear leaf spring. Besides, an individual tablet of VIN
2
OWNER爷S MANUAL
JAC High end Light Trucks
code is attached on the dashboard near the right column.
Overload
Overloading will shorten vehicle's service life, but also bring about potential risk
to safe driving.
The loading mass must be limited to the specified range of the max. total mass
for vehicle, and the load distributions on the front and rear shafts shall not be
more than the carrying capacity of the vehicle shafts. Please refer to the techni鄄
cal specification sheet for the rated total mass value and shaft loading capacity.
3
