SUN ROOF/CONVERTIBLE TOP 8I–5 Legend (1) Sunshade (3) Decoration Cover Removal 1. Remove the decoration cover. stopper screw and pull out the sunshade(6) until its 3. Remove the sun roof deflector. D Refer to the Sun Roof Deflector in this section. 4. Open the sun roof completely. out the sunshade up to the rail edge. 6. Remove the guide pin(4) in the sunshade through the notch(7) of guide rail(1) and then draw the sunshade 665RS008 Installation To install, follow the removal steps in the reverse order. |
