6E–449
TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
D
Mis routed harness.
D
Rubbed through wire insulation.
D
Broken wire inside the insulation.
Check for the following conditions:
D
Poor connection at PCM-Inspect harness connectors
for backed out terminals, improper mating, broken
locks, improperly formed or damaged terminals, and
poor terminal to wire connection.
D
Damaged harness-Inspect the wiring harness for
damage. If the harness appears to be OK, observe the
moving connectors and wiring harnesses related to the
sensor.
A change in the display will indicate the location of
the fault. If DTC P1310 cannot be duplicated, the
information included in the Failure Records data
can be useful in determined vehicle mileage since
the DTC was last set.
If it is determined that the DTC occurs
intermittently, performing the DTC P1310
Diagnostic Chart may isolate the cause of the
fault.
