6A–33 ENGINE MECHANICAL (X22SE 2.2L) 6. Remove twenty fixing bolts from intake and exhaust camshaft bracket on the cylinder head, then remove 011RW015 CAUTION: f Do not damage camshaft lobe and journal. f Do not damage hydraulic lash adjuster(HLA) and 7. Remove oil seal from camshaft. Installation 1. Clean surface of camshaft bracket and HLA. bracket and HLA. 3. Install camshaft to cylinder head. shown in the illustration. f Exhaust: 1 to 5 from front f Intake: 6 to 10 from front. 014RW052 015RW014 |
