FRONT SUSPENSION 3C–7 Torsion Bar Torsion Bar and Associated Parts 410RS003 Legend (1) Adjust Bolt, End Piece and Seat (2) Height Control Arm Removal 1. Raise the vehicle and support the frame with suitable safety stands. 2. Apply the setting marks(1) to the adjust bolt and end piece, then remove adjust bolt, end piece and seat. 410RS004 |
