Powertrain Interface Module – V6
Page 6E1–75
N O T E
The Tech 2 PIM Security Information Data List
typical display values are obtained from a
correctly operating vehicle under the following
conditions:
• ignition switched on,
• engine not running, and
• vehicle is stationary.
Tech 2 Parameter
Units Displayed
Typical Display Values
ICU / PIM Status
Yes / No
Yes
Security Code Programmed
Yes / No
Yes
Security Wait Time
Inactive / Active
Inactive
Security Wait Time
Inactive / 0:00:00
Inactive
Security Code Correct Enter
Yes / No
Yes
Security Code Reset Counter
0
0
12.2 PIM Reset Procedure
Do not perform the reset procedure within
sixty seconds of turning the ignition switch
on. Failure to comply may result in the PIM
failing to reset.
When a PIM has been installed into a vehicle, it is security linked to the immobiliser control unit (ICU) and engine control
module (ECM). Once this linking has been performed, the PIM cannot be installed in any other vehicle, unless the
security linking between the ICU and the ECM has been reset using the following procedure:
1
Prior to resetting the PIM, obtain the Security Code. For further information, refer to 12.1
Security and
Programming Information.
2
Connect Tech 2 to the data link connector (DLC) and turn the ignition switch on.
3
On Tech 2 select: Body / Powertrain Interface Module / Security / Reset PIM.
N O T E
When Tech 2 requests programming approval,
obtain TIS approval.
N O T E
If a Tech 2 screen displaying Security Wait Time
Active, Please Wait! appears after selecting the
Reset PIM option, an incorrect security code has
been previously entered. Refer to 12.1
Security and Programming Information for further
information.
4
When Tech 2 displays Enter Security Code, enter the security code, press the Enter key and then the Okay soft
key.
The engine will not start after the PIM has
been reset.
5
When Tech 2 displays Do you really want to Reset?, press the Reset soft key.
