6C-18  ENGINE FUEL (C24SE)

Special Tools



ILLUSTRATION

PART NO.

PART NAME











5–8840–2602–0

(J–39765)

Remover; fuel pump

retainer










Section 6D1 Engine Electrical ....................................................................................   2138

                                                                     PAGE

Section 6D2 Ignition System ....................................................................................... 2144

Section 6D3 Starting and Charging System................................................................  2149

SECTION 6D

Engine electrical

TABLE OF CONTENTS

C24SE MODEL

ENGINE 6D

ENGINE ELECTRICAL  6D1-1

SECTION 6D1

ENGINE ELECTRICAL

TABLE OF CONTENTS

PAGE

Battery .............................................................................................................................  6D1-  2

General Description...................................................................................................  6D1-  2

Service Precaution ....................................................................................................  6D1-  2

Diagnosis....................................................................................................................  6D1- 3

Battery Charging........................................................................................................  6D1-  4

Jump Starting.............................................................................................................  6D1- 4

Removal ......................................................................................................................  6D1- 6

Installation..................................................................................................................  6D1- 6

Main Data and Specifications ...................................................................................  6D1-  6



6D1-2  ENGINE ELECTRICAL





Battery

General Description

There are six battery fluid caps on top of the battery.
These are covered by a paper label.
The battery is completely sealed except for the six small vent
holes on the side. These vent holes permit the escape of small
amounts of gas generated by the battery.
This type of battery has the following advantages over
conventional batteries:
1.  There is no need to add water during the entire service life

of the battery.

2.  The battery protects itself against overcharging.



The battery will refuse to accept an extensive charge.

  (A conventional battery will accept an excessive charge,

resulting in gassing and loss of battery fluid.)

3.  The battery is much less vulnerable to self discharge than a

conventional type battery.








Service Precaution

CAUTION:
Always use the correct fastener in the proper location.
When you replace a fastener, use ONLY the exact part
number for that application. ISUZU will call out those
fasteners that require a replacement after removal. ISUZU
will also call out the fasteners that require thread lockers
or thread sealant. UNLESS OTHERWISE SPECIFIED, do
not use supplemental coatings (Paints, greases, or other
corrosion inhibitors) on threaded fasteners or fastener
joint interfaces. Generally, such coatings adversely affect
the fastener torque and the joint clamping force, and may
damage the fastener. When you install fasteners, use the
correct tightening sequence and specifications. Following
these instructions can help you avoid damage to parts
and systems.
