BRAKES 5C-65
RTW75CSH002801
6. Clevis; Yoke
Assemble such that the distance from the rear of the vacuum
booster assembly to the center of the clevis yoke hole is within
the range of the reference values.
Distance mm
(in)
RHD
147.9 - 148.9 (5.823 - 5.862)
L
LHD
160.7 - 161.7 (6.327 - 6.366)
Upon assembling the clevis yoke, tighten the nut to the
specified torque.
Torque N
⋅m (kgf⋅m/lb⋅ft)
15 - 25 (1.5 - 2.5 / 11 - 18)
