7A2-28  DIAGNOSIS



PARTS LOCATION (4)


































DIAGNOSIS  7A2-29



CONNECTOR LIST

TCM

No. Connector

face  No. Connector

face

B-23

Green

Meter-A

C-56

(4JH1-TC)



ECM-A

B-24

Green

Meter-B

C-57

(4JH1-TC)



ECM-B

B-50

White

Power/3rd start switch

C-94

(6VE1)

(4JH1-TC)

Gray

TCM

B-54

White

J/B I2

C-95

(6VE1)

(4JH1-TC)

White

TCM

B-58

Black

Check connector

C-107

White

J/B E2

B-62

White

Ignition switch (IGSUB : G1)

C-109

Silver

Body-LH ; ground

B-63

White

Ignition switch (IGSUB : G2)

E-30

(4JH1-TC)

Gray

A/T speed sensor

B-64

Silver

Weld splice 1 (Illumination)

E-31

(4JH1-TC)

Gray

Turbine sensor

C-2

Silver

Engine room-RH ground

E-44

Gray

Vehicle speed sensor

C-44

White

Stop lamp switch

E-51

(4JH1-TC)

Black

Inhibiter switch

7A2-30  DIAGNOSIS





No. Connector

face  No. Connector

face

E-54

(4JH1-TC)

Black

A/T term ASM

P-10

Silver

Engine ground

H-4

(6VE1)

(4JH1-TC)

White

Engine ~ Engine room







H-6

White

Engine room ~ INST







H-7

White

Engine room ~ INST







H-22

(6VE1)

(4JH1-TC)

White

Engine ~ Engine room C







H-23

(6VE1)

(4JH1-TC)

White

Engine ~ Engine room B







P-1

Silver

Battery (+)







P-2

Silver

Relay & Fuse box







P-5

Silver

Battery (-)







P-6

Silver

Body earth (Ground)









DIAGNOSIS  7A2-31



DIAGNOSIS TROUBLE CODE TABLE



Flash Code

(P-Code)



CHECK TRANS Flash Pattern



Description

CHECK

TRANS

Warning









11 (P0722)



Vehicle Speed Sensor No Signal

ON

















12 (-)



Normal

-















13 (P0727)



ON





Engine Revolution Sensor No
Signal













14 (P0717)



Turbine Speed Sensor No Signal

ON

















15 (P0710)



ATF Temperature Sensor Failure

OFF

















16 (P0560)



System Voltage Failure

ON

















17 (P0705)



Inhibitor Switch Failure

ON

















22 (P1120)



Throttle Signal Failure

ON

















25 (P1875)



GND Return Circuit Failure

ON















26 (P1853)



ON





Low & Reverse Brake Pressure
Switch Failure













27 (P1858)



2-4 Brake Pressure Switch Failure

ON















28 (P1863)



ON





High Clutch Pressure Switch
Failure











31 (P0753)



ON





Low & Reverse Brake Duty
Solenoid Failure













32 (P0758)



2-4BrakeDutySolenoidFailure

ON















33 (P0763)



ON





High Clutch Duty Solenoid Failure
