Infiniti QX80 (2018 year). Manual

3-30

Pre-driving checks and adjustments

CAUTION

. Do not store the main sun visor

before storing the extension sun
visor.

. Do not pull the extension sun visor

forcedly downward.

1. To block out glare from the front, swing

down the main sun visor

2. To block glare from the side, remove the

main sun visor from the center mount
and swing it to the side

3. Draw out the extension sun visor

from

the main sun visor to block from further
glare.

SPA2447

INSIDE MIRROR

Adjust the height and the angle of the inside
mirror to the desired position.

SPA2450-A

Automatic anti-glare type (if so
equipped)

The inside mirror is designed so that it
automatically changes reflection according
to the intensity of the headlights of the
following vehicle.
The anti-glare system will be automatically
turned on when the ignition switch is pushed
to the ON position.
When the anti-glare system is turned on, the
indicator light

will illuminate and excessive

glare from the headlights of the vehicle
behind you will be reduced.
Push the “

*” switch

to make the inside

rearview mirror operate normally. The in-

MIRRORS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

dicator light will turn off. Push the “I” switch

to turn the system on.

Do not allow any object to cover the sensors

or apply glass cleaner on them. Doing so

will reduce the sensitivity of the sensor,
resulting in improper operation.
For the HomeLink

Universal Transceiver

operation, see “HomeLink

Universal Trans-

ceiver (Type A)” (P.2-68).

Smart Rearview Mirror (if so
equipped)

WARNING

. Failure to follow the warnings and

instructions for proper use of the
Smart Rearview Mirror could result
in serious injury or death.

— The Smart Rearview Mirror is a

convenience feature but it is not a
substitute for proper vehicle op-
eration. The system has areas
where objects cannot be viewed.
Check the blind spot of the Smart
Rearview Mirror before vehicle
operation. The driver is always
responsible for safe driving.

— Do not disassemble or modify the

Smart Rearview Mirror, the cam-

era unit or wirings. If you do, it
may result in accidents or fire. In
case you notice smoke or smell
coming from the Smart Rearview
Mirror, stop using the system
immediately. It is recommended
that you see an INFINITI retailer
for servicing.

— Do not operate the Smart Rear-

view Mirror while driving. Doing
so can be a distraction and it could
lose control of your vehicle and
cause an accident or serious in-
jury.

— Do not gaze into the Smart Rear-

view Mirror display during driv-
ing. It may cause a distraction and
it could lose control of your vehi-
cle and cause an accident or
serious injury.

— Do not put a cigarette or flames

to the Smart Rearview Mirror, the
camera unit or wirings. It may
cause a fire.

. Be sure to adjust the Smart Rearview

Mirror before driving. Switch the
system to the conventional rearview
mirror mode and be properly seated
on the driver’s seat. Then adjust the
mirror so as to see the rear window

properly. Driving without adjusting
the mirror may cause difficulty in
watching the display at Smart Rear-
view Mirror mode (camera view
mode) due to the reflection from the
surface of the mirror.

. If the Smart Rearview Mirror mal-

functions, immediately switch the
system to the conventional rearview
mirror mode.

. When strong light (for example, sun-

light or high beams from following
vehicles) enters the camera, a light
beam or a glaring light may appear on
the monitor screen of the Smart
Rearview Mirror. In that case, switch
the system to the conventional rear-
view mirror mode appropriately.

. If dirt, rain or snow accumulates on

the exterior glass surface covering
the camera, the Smart Rearview
Mirror may not display objects
clearly. Use of the rear window
wiper/washer may improve visibility,
but if not, switch the Smart Rearview
Mirror to the conventional rearview
mirror mode until a time the glass
covering the camera can be cleaned.

Pre-driving checks and adjustments

3-31

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-32

Pre-driving checks and adjustments

JVP0515X

MENU button
Left button
Right button
Mode select lever
HomeLink

buttons (1-3)

Components:
Smart Rearview Mirror provides a clear
rearview from a camera located on the rear
of the vehicle. Smart Rearview Mirror has
two modes: conventional rearview mirror
mode and Smart Rearview Mirror mode
(camera view mode). You can switch these
two modes by the mode select lever

For the operation of the HomeLink

buttons

, see “HomeLink

Universal Transceiver

(Type B)” (P.2-72).

JVP0489X

How to change the mode:
The mode can be switched when the ignition
switch is in the ON position.
. Pull the mode select lever

to switch to

the Smart Rearview Mirror mode (cam-
era view mode).

. Push the mode select lever to switch to

the conventional rearview mirror mode.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVP0506X

How to make settings of Smart Rearview
Mirror:
You can choose display settings of the Smart
Rearview Mirror such as brightness, camera
angle, textual indication ON or OFF and
language.
When the Smart Rearview Mirror mode is
on, setting menu can be selected by pushing
the MENU button

. Each time the MENU

button

is pushed, the setting menu will

change as follows:
MENU (initial screen)

?BRIGHTNESS ?

DOWN/UP

? ROTATION ? INDICATION

? DIMMING MIRROR ? LANGUAGE ?
MENU (initial screen)

NOTE:

. To switch the image quality adjustment

items with the MENU button

, push

the button within 5 seconds after
completing the adjustment of the pre-
vious item. If 5 seconds or more pass,
the monitor will return to MENU (initial
screen).

. When one of the HomeLink

buttons is

pushed, the monitor will display the
HomeLink

screen.

JVP0507X

BRIGHTNESS
The brightness of the display screen can be
adjusted.
. Push the left button

to dim the screen.

. Push the right button

to brighten the

screen.

Pre-driving checks and adjustments

3-33

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-34

Pre-driving checks and adjustments

JVP0508X

DOWN/UP
The vertical camera angle of the display
screen can be adjusted.
. Push the left button

to down the

camera angle.

. Push the right button

to up the camera

angle.

JVP0510X

ROTATION
The camera angle of the display screen can
be rotated.
. Push the left button

to rotate the

camera angle to the left.

. Push the right button

to rotate the

camera angle to the right.

JVP0511X

INDICATION
The textual indication can be turned on or
off on the Smart Rearview Mirror display
screen.
. Push the right button

to disable the

textual indication on the display screen.

. Push the left button

to enable the

textual indication on the display screen.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVP0514X

DIMMING MIRROR
The mirror is designed so that it automati-
cally changes reflection according to the
intensity of the headlights of the following
vehicle. You can enable or disable the
automatic anti-glare mode.
. Push the left button

to enable the

automatic anti-glare mode.

. Push the right button

to disable the

automatic anti-glare mode.

JVP0512X

LANGUAGE
The language of the textual indication can be
selected on the Smart Rearview Mirror
display screen.
Select the language by using the

button. You can select either English or
French. The language setting will be retained
even if the engine is restarted.

Smart Rearview Mirror system precautions:

NOTE:

. Long-term use of this system in stop-

ping engine may cause battery to be
discharged.

. Do not attach an antenna of wireless

device near the Smart Rearview Mirror.

Electric wave from wireless device may
cause disturbed image in Smart Rear-
view Mirror.

. Do not push buttons excessively or

operating the lever roughly may cause
a system failure or the Smart Rearview
Mirror itself to drop.

. Never turn the body of Smart Rearview

Mirror by 90° or more. It may damage
the Smart Rearview Mirror.

. Do not apply strong shocks to the body

of Smart Rearview Mirror. It may cause
a system failure.

. Do not apply heavy load to the camera

and camera-cover on the rear of the
vehicle. It may cause the camera to be
removed or may cause a system failure.

. If it is difficult to see the Smart Rearview

Mirror display screen because of a
strong external light, switch the mode
to the conventional rearview mirror
mode for better use.

. Close the sunshade (if so equipped)

when the Smart Rearview Mirror dis-
play screen is unclear due to strong
external light.

Pre-driving checks and adjustments

3-35

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-36

Pre-driving checks and adjustments

JVP0559X

Flicker image (example)

. When LED headlights are viewed on the

Smart Rearview Mirror display, the
images may flicker. This is normal.

. Due to diffused reflection from external

environment, images on the screen may
flicker. This is not a malfunction.

. A quick movement of a thing may not be

able to display on the camera view
screen. This is not a malfunction.

. Turn on the headlights at twilight or in a

tunnel, etc.

. The Smart Rearview Mirror mode (cam-

era view mode) display is different from
the conventional rearview mirror. Ob-
jects in the display may differ from

actual distance. Do not solely rely on
the Smart Rearview Mirror. Always rely
on your own operation to avoid acci-
dents.

. If the brightness of the camera view

display is adjusted to excessive bright
level, it may cause an eyestrain in the
driving. Adjust the brightness properly.

. Use the rear window wiper when it rains.

If the camera view image is still unclear
when the rear window wiper is in
operation, check the deterioration of
the rear window wiper blade.

. When using the rear window wiper,

images on the screen may flicker. This
is not a malfunction.

. Defog the rear window with defroster

when rear window is fogged. Use the
conventional rearview mirror mode until
the rear window is fully defogged.

. The display of the Smart Rearview

Mirror may become hot. This is not a
malfunction.

. The color of an object in the distance or

in the dark may be difficult to be
recognized. This is not a malfunction.

System maintenance (Smart Rearview
Mirror):
. Always keep the mirror and camera area

of the rear window clean.

. Clean the mirror and the camera lens

with a dry soft cloth.

. When cleaning the camera area of the

rear window, use a soft cloth dampened
with water and a neutral detergent. Then
dry it with a dry soft cloth.

. If the image on the Smart Rearview

Mirror display screen is still unclear even
after cleaning the camera area of the
rear window, an oil film may be adhering
to the rear window glass. Clean the rear
window glass with an oil film remover.

. Never use alcohol, benzine, thinner, or

any similar material to clean the mirror or
camera lens. It will cause a discoloration,
deterioration or a system malfunction.

. Do not attach a sticker (including trans-

parent material) on the camera area of
the rear window.

OUTSIDE MIRRORS

WARNING

. Objects viewed in the outside mirror

on the passenger side are closer than
they appear. Be careful when moving
to the right. Using only this mirror
could cause an accident. Use the
inside mirror or glance over your
shoulder to properly judge distances

-------------------------------------------------------------------------------------------------------------------------------------------------------------

to other objects.

. Do not adjust the mirrors while

driving. You could lose control of
your vehicle and cause an accident.

SPA2739

Adjusting outside mirrors

The outside mirror control switch is located
on the driver’s door armrest.
The outside mirror will operate only when
the ignition switch is in the ACC or ON
position.
Move the switch right or left to select the
right or left side mirror

, then adjust using

the control switch

Defrosting outside mirrors

The outside mirrors will be heated when the
rear window defroster switch is operated.
(See “Rear window and outside mirror
defroster switch” (P.2-36).)

SPA2738

Power foldable outside mirrors

CAUTION

. Do not touch the mirrors while they

are moving. Your hand may be
pinched, and the mirror may malfunc-
tion.

. Do not drive with the mirrors stored.

You will be unable to see behind the
vehicle.

. If the mirrors were folded or unfolded

by hand, there is a chance that the
mirror will move forward or back-
ward during driving. If the mirrors

Pre-driving checks and adjustments

3-37

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-38

Pre-driving checks and adjustments

were folded or unfolded by hand, be
sure to adjust them again electrically
before driving.

The outside rearview mirror remote control
operates when the ignition switch is in the
ACC or ON position.
To fold the outside rearview mirrors, push
the outside rearview mirror folding switch to
the “CLOSE” position

. To unfold, push to

the “OPEN” position

If mirrors are manually operated or bumped,
the mirror body can become loose at the
pivot point. To correct electronic mirror
operation, cycle the mirrors by pushing
“CLOSE” until completely closed, then push
“OPEN” until the mirrors are in the open
position.

Reverse tilt-down feature

When backing up the vehicle, the right and
left outside mirrors will turn downward
automatically to provide better rear visibility.
1. Push the ignition switch to the ON

position.

2. Move the shift lever to the R (Reverse)

position.

3. Choose the right or left outside mirror by

operating the outside mirror control
switch.

4. The outside mirror surfaces move down-

ward.

When one of the following conditions has
occurred, the outside mirror surfaces will
return to their original positions.
. The shift lever is moved to any position

other than R (Reverse).

. The outside mirror control switch is set to

the center position.

. The ignition switch is placed in to the

OFF position.

Automatic anti-glare

The outside rearview mirrors are designed so
that its automatically change reflection
according to the intensity of the headlights
of the vehicle following you.
The anti-glare system will be automatically
turned on when you place the ignition switch
in the ON position.

SIC4448

VANITY MIRROR

To use the front vanity mirror, pull down the
sun visor and pull up the cover.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVP0250X

SET/memory switches

The automatic drive positioner system has
three features:
. Entry/exit function

. Memory storage

. Setting memory function

ENTRY/EXIT FUNCTION

This system is designed so that the driver’s
seat and steering column will automatically
move when the automatic transmission shift
lever is in the P (Park) position. This allows
the driver to get into and out of the driver’s
seat more easily.
The driver’s seat will slide backward and the
steering wheel will move up when the

driver’s door is opened with the ignition
switch in the LOCK position.
The driver’s seat and steering wheel will
return to the previous positions when the
ignition switch is pushed to the ACC posi-
tion.
The driver’s seat will not return to the
previous positions if the seat or steering
adjusting switch is operated when the seat is
at the exit position.

Cancel or activate entry/exit func-
tion

The shift lever must be in the P (Park)
position with the ignition switch in the OFF
position.
The entry/exit function can be activated or
canceled by pressing and holding the SET
switch for more than 10 seconds.
The entry/exit function can also be acti-
vated or canceled if the “Lift Steering Wheel
on Exit” key or “Slide Driver’s Seat Back on
Exit” key is turned to ON or OFF in the
Vehicle settings on the center display. (See
Infiniti InTouch Owner’s Manual.)

Initialize entry/exit function

If the battery cable is disconnected, or if the
fuse opens, the entry/exit function will not
work though this function was set on before.
In such a case, after connecting the battery

or replacing with a new fuse, open and close
the driver’s door more than two times after
the ignition switch is turned from the ON
position to the LOCK position. The entry/
exit function will be activated.

MEMORY STORAGE

Two positions for the driver’s seat, steering
column and outside mirrors can be stored in
the automatic drive positioner memory.
Follow these procedures to use the memory
system.
1. Move the shift lever to the P (Park)

position.

2. Adjust the driver’s seat, steering column

and outside mirrors to the desired posi-
tions by manually operating each adjust-
ing switch. For additional information,
see “Seats” (P.1-3) and “Tilt/telescopic
steering” (P.3-29) and “Outside mirrors”
(P.3-36).

3. Push the SET switch and, within 5

seconds, push the memory switch (1 or
2) fully for at least 1 second.
The indicator light for the pushed mem-
ory switch will stay on for approximately
5 seconds after pushing the switch.
When the memory is stored in the
memory switch (1 or 2), a buzzer will
sound.
If memory is stored in the same memory

Pre-driving checks and adjustments

3-39

AUTOMATIC DRIVE POSITIONER

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-40

Pre-driving checks and adjustments

switch, the previous memory will be
deleted.

Linking Intelligent Key to a stored
memory position

The Intelligent Key can be linked to a stored
memory position with the following proce-
dure.
1. Follow the steps for storing a memory

position.

2. While the indicator light for the memory

switch being set is illuminated for 5
seconds, push the

button on the

Intelligent Key. If the indicator light
blinks, the Intelligent Key is linked to
that memory setting.

Push the ignition switch to the OFF position,
and then push the

button on the

Intelligent Key. The driver’s seat, steering
wheel and outside mirrors will move to the
memorized position.

Confirming memory storage

. Push the ignition switch to the ON

position and push the SET switch. If the
main memory has not been stored, the
indicator light will come on for approxi-
mately 0.5 second. When the memory
has stored in position, the indicator light
will stay on for approximately 5 seconds.

. If the battery cable is disconnected, or if

the fuse opens, the memory will be
canceled. In this case, reset the desired
position using the previous procedure.

. If optional Intelligent Keys are added to

your vehicle, the memory storage proce-
dure to switch 1 or 2 and linking
Intelligent Key procedure to a stored
memory position should be performed
again for each Intelligent Key. For addi-
tional Intelligent Key information, see
“Keys” (P.3-2).

Selecting the memorized position

1. Move the shift lever to the P (Park)

position.

2. Use one of the following methods to

move the driver’s seat, the outside
mirrors and the steering wheel.

Push the memory switch (1 or 2) fully

for at least 1 second.

The driver’s seat, steering column and
outside mirrors will move to the memor-
ized position or to the exit position when
the entry/exit function is set to active
with the indicator light flashing, and then
the light will stay on for approximately 5
seconds.

SETTING MEMORY FUNCTION

The status of the following settings can be
linked to the Intelligent Key and the memor-
ized settings can be available for each
Intelligent Key.
. Air conditioner system

. Navigation system

. Audio system
To use the memory function, lock the doors
with the Intelligent Key that is linked to the
settings.
To enable the memorized settings:
1. Carry the Intelligent Key that is linked to

the settings, and unlock the doors by
pushing the driver’s door handle request
switch or “UNLOCK”

button on the

Intelligent Key.

2. Place the ignition switch in the ON

position. “Connection with the key has
been done” will be displayed on the
screen and the memorized settings are
available (only when a new Intelligent
Key is used).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SYSTEM OPERATION

The automatic drive positioner system will
not work or will stop operating under the
following conditions:
. When the vehicle speed is above 0 MPH

(0 km/h) or 4 MPH (7 km/h) for some
limited functions such linking an Intelli-
gent Key to the vehicle when the power
source is turned on from off or during the
Exit function.

. When any of the memory switches are

pushed while the automatic drive posi-
tioner is operating.

. When the adjusting switch for the dri-

ver’s seat and steering column is turned
on while the automatic drive positioner is
operating.

. When the seat has already been moved

to the memorized position.

. When no seat position is stored in the

memory switch.

. When the shift lever is moved from the P

(Park) position to any other position.

Pre-driving checks and adjustments

3-41

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4-2

Monitor, climate, audio, phone and voice recognition systems

Refer to the Infiniti InTouch

Owner’s

Manual that includes the following informa-
tion.
. Audio system

. Bluetooth

Hands-Free Phone system

. Infiniti InTouch

Apps

. Infiniti InTouch

Services

. SiriusXM Travel Link

. SiriusXM Traffic

. Navigation system

. Voice recognition

. Information and settings viewable on

Infiniti InTouch

WARNING

. Do not disassemble or modify this

system. If you do, it may result in
accidents, fire, or electric shock.

. Do not use this system if you notice

any abnormality, such as a frozen
screen or lack of sound. Continued
use of the system may result in
accident, fire or electric shock.

. In case you notice any foreign object

in the system hardware, spill liquid on
it, or notice smoke or smell coming
from it, stop using the system im-
mediately. It is recommended you
visit an INFINITI retailer for servi-
cing. Ignoring such conditions may
lead to accidents, fire, or electric
shock.

. Park the vehicle in a safe location and

apply the parking brake to view the
images on the front center display
screen.

Do not attempt to operate the system in
extreme temperature conditions [below
−4°F (−20°C) and above 158°F (70°C)].
Operating this system under these condi-
tions may result in system malfunctions.

INFINITI INTOUCH

OWNER’S MANUAL

SAFETY NOTE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVH1689X

1. CAMERA button
2. SETTING button

WARNING

Failure to follow the warnings and
instructions for the proper use of the
Around View

Monitor system could

result in serious injury or death.
. The Around View

Monitor is a

convenience feature and is not a
substitute for proper vehicle opera-
tion because it has areas where
objects cannot be viewed. The four
corners of the vehicle in particular,
are areas where objects do not al-
ways appear in the bird’s-eye, front,
or rear views. Always check your
surroundings to be sure that it is safe
to move before operating the vehicle.
Always operate the vehicle slowly.
Always look out the windows and
check mirrors to be sure that it is safe
to move.

. The driver is always responsible for

safety during parking and other
maneuvers.

CAUTION

Do not scratch the lens when cleaning
dirt or snow from the front of the
camera.

The Around View

Monitor system is de-

signed as an aid to the driver in situations
such as slot parking or parallel parking.

Monitor, climate, audio, phone and voice recognition systems

4-3

AROUND VIEW

MONITOR

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti QX80 (2018 year). Manual - part 13
