When towing your vehicle, all jurisdictions
and local regulations for towing must be fol-
lowed. Incorrect towing equipment could
damage your vehicle. Towing instructions are
available from an INFINITI retailer. Local ser-
vice operators are generally familiar with the
applicable laws and procedures for towing.
To assure proper towing and to prevent ac-
cidental damage to your vehicle, INFINITI
recommends having a service operator tow
your vehicle. It is advisable to have the service
operator carefully read the following precau-
tions.

WARNING

•

Never ride in a vehicle that is being
towed.

•

Never get under your vehicle after it has
been lifted by a tow truck.

CAUTION

•

When towing, make sure that the trans-
mission, axles, steering system and
powertrain are in working condition. If
any of these conditions apply, dollies or
a flatbed tow truck must be used.

•

Always attach safety chains before
towing.

TOWING RECOMMENDED BY
INFINITI

INFINITI recommends towing your vehicle
based upon the type of drivetrain. Please re-
fer to the diagrams in this section to ensure
that your vehicle is properly towed.

NCE451

FWD (2WD) models

TOWING YOUR VEHICLE

6-14

In case of emergency

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Two-Wheel Drive (FWD) models

CAUTION

NEVER tow automatic transmission (DCT)
models with the front wheels on the
ground or with all four wheels on the
ground (forwards or backwards), as this
may cause serious and expensive damage
to the transmission. If it is necessary to tow
the vehicle with the rear wheels raised, al-
ways use towing dollies under the front
wheels.

Four-Wheel Drive (4WD) models

INFINITI recommends that towing dollies be
used under the front or rear wheels when
towing your vehicle or the vehicle be placed
on a flatbed tow truck as illustrated.

CAUTION

Never tow 4WD models with any of the
wheels on the ground. Doing so will cause
serious and expensive damage to the
drivetrain.

Vehicle recovery (freeing a stuck
vehicle)

WARNING

To avoid vehicle damage, serious personal
injury or death when recovering a stuck ve-
hicle:

•

Contact a professional towing service to
recover the vehicle if you have any ques-
tions regarding the recovery procedure.

•

Tow chains or cables must be attached
only to main structural members of the
vehicle.

•

Do not use the vehicle tie downs to tow
or free a stuck vehicle.

•

Only use devices specifically designed
for vehicle recovery and follow the
manufacturer's instructions.

•

Always pull the recovery device straight
out from the front of the vehicle. Never
pull at an angle.

•

Route recovery devices so they do not
touch any part of the vehicle except the
attachment point.

•

On vehicles with a push button ignition
switch: you must remove the start/stop

NCE450

4WD models

In case of emergency

6-15

-------------------------------------------------------------------------------------------------------------------------------------------------------------

button and use the key (see " Push-
button ignition switch (if equipped)" in
the "5. Starting and driving" section).
Otherwise the automatic transmission
may shift to position P (Park) when the
driver's or front passenger door are
opened, which could lead to damage to
the transmission.

If your vehicle is stuck in sand, snow, mud,
etc., use a tow strap or other device designed
specifically for vehicle recovery. Always fol-
low the manufacturer’s instructions for the
recovery device.

Rocking a stuck vehicle

WARNING

•

To avoid potential injury, stand clear of
a stuck vehicle.

•

Do not spin your tires at high speed. This
could cause them to explode and result
in serious injury. Parts of your vehicle
could also overheat and be damaged.

If your vehicle is stuck in sand, snow, mud,
etc., use the following procedure:

1. Turn off the Vehicle Dynamic Control

(VDC) system.

2. Make sure the area in front and behind the

vehicle is clear of obstructions.

3. Turn the steering wheel right and left to

clear an area around the front tires.

4. Slowly rock the vehicle forward and back-

ward.

•

Shift back and forth between R (Reverse)
and D (Drive).

•

Apply the accelerator as little as possible
to maintain the rocking motion.

•

Release the accelerator pedal before shift-
ing between R (Reverse) and D (Drive).

•

Do not spin the tires above 35 MPH (55
km/h).

5. If the vehicle cannot be freed after a few

tries, contact a professional towing ser-
vice to remove the vehicle.

6-16

In case of emergency

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In order to maintain the appearance of your
vehicle, it is important to take proper care of
it.

To protect the paint surfaces, please wash
your vehicle as soon as you can:

•

After a rainfall, to prevent possible dam-
age from acid rain.

•

After driving on coastal roads.

•

When contaminants such as soot, bird
droppings, tree sap, metal particles or
bugs get on the paint surface.

•

When dust or mud builds up on the sur-
face.

Whenever possible, park your vehicle inside a
garage or in a covered area to minimize the
chances of damaging the paint surface of
your vehicle.

When it is necessary to park outside, park in a
shady area or protect the vehicle with a body
cover. Be careful not to scratch the paint
surface when putting on or removing the
body cover.

WASHING

Wash dirt off with a wet sponge and plenty
of water. Clean the vehicle thoroughly using a
mild soap, a special vehicle soap or general

purpose dishwashing liquid mixed with clean,
lukewarm (never hot) water.

CAUTION

•

Do not use car washes that use acid in
the detergent. Some car washes, espe-
cially brushless ones, use some acid for
cleaning. The acid may react with some
plastic vehicle components, causing
them to crack. This could affect their ap-
pearance, and also could cause them not
to function properly. Always check with
your car wash to confirm that acid is not
used.

•

Do not wash the vehicle with strong
household soap, strong chemical deter-
gents, gasoline or solvents.

•

Do not wash the vehicle in direct sun-
light or while the vehicle body is hot, as
the paint surface may become water-
spotted.

•

Avoid using tight-napped or rough
cloths, such as washing mitts. Care must
be taken when removing caked-on dirt
or other foreign substances so the paint
surface is not scratched or damaged.

Rinse the vehicle thoroughly with plenty of
clean water.

Inside edges, seams and folds on the doors,
hatches and hood are particularly vulnerable
to the effects of road salt. Therefore, these
areas must be cleaned regularly. Take care
that the drain holes in the lower edge of the
door are open. Spray water under the body
and in the wheel wells to loosen the dirt and
wash away road salt.

A damp chamois can be used to dry the ve-
hicle to avoid water spots.

WAXING

Regular waxing protects the paint surface
and helps maintain a new vehicle appear-
ance.

After waxing, polishing is recommended to
remove built-up residue and to avoid a
weathered appearance.

An INFINITI retailer can assist you in choos-
ing the appropriate waxing products.

•

Wax your vehicle only after a thorough
washing. Follow the instructions supplied
with the wax.

•

Do not use a wax containing any abra-
sives, cutting compounds or cleaners that
may damage the vehicle finish.

Machine compounding or aggressive polish-
ing on a base coat/clear coat paint finish may
dull the finish or leave swirl marks.

CLEANING EXTERIOR

7-2

Appearance and care

-------------------------------------------------------------------------------------------------------------------------------------------------------------

REMOVING SPOTS

Remove tar and oil spots, industrial dust, in-
sects, and tree sap as quickly as possible from
the paint surface to avoid lasting damage or
staining. Special cleaning products are avail-
able at an INFINITI retailer or any automotive
accessory store.

UNDERBODY

In areas where road salt is used in the winter,
it is necessary to clean the vehicle’s under-
body regularly in order to prevent dirt and salt
from building up and causing the acceleration
of corrosion on the underbody and suspen-
sion.

Before the winter and again in the spring, the
underseal must be checked and, if necessary,
re-treated.

GLASS

Use glass cleaner to remove smoke and dust
film from the glass surfaces. It is normal for
glass to become coated with a film after the
vehicle is parked in the hot sun. Glass cleaner
and a soft cloth will easily remove this film.

CAUTION

When cleaning the inside of the windows,
do not use sharp-edged tools, abrasive
cleaners or chlorine-based disinfectant
cleaners. They could damage the electrical
conductors, radio antenna elements or rear
window defroster elements.

WHEELS

•

Wash the wheels when washing the ve-
hicle to maintain their appearance.

•

Clean the inner side of the wheels when
the wheel is changed or the underside of
the vehicle is washed.

•

Do not use abrasive cleaners when wash-
ing the wheels.

•

Inspect wheel rims regularly for dents or
corrosion. This may cause loss of pressure
or damage the tire bead.

•

INFINITI recommends that the road
wheels be waxed to protect against road
salt in areas where it is used during winter.

ALUMINUM ALLOY WHEELS

Wash the wheels regularly with a sponge
dampened in a mild soap solution, especially
during winter in areas where road salt is used.

The salt residue from road salt could discolor
the wheels if it is not washed off regularly.

CAUTION

Follow the directions below to avoid stain-
ing or discoloring the wheels:

•

Do not use a cleaner that uses strong
acid or alkali contents to clean the
wheels.

•

Do not apply wheel cleaners to the
wheels when they are hot. The wheel
temperature should be the same as am-
bient temperature.

•

Rinse the wheel to completely remove
the cleaner within 15 minutes after the
cleaner is applied.

CHROME PARTS

Clean all chrome parts regularly with a non-
abrasive chrome polish to maintain the finish.

TIRE DRESSINGS

INFINITI does not recommend the use of tire
dressings. Tire manufacturers apply a coating
to the tires to help reduce discoloration of the
rubber. If a tire dressing is applied to the tires,
it may react with the coating and form a
compound. This compound may come off the
tire while driving and stain the vehicle paint.

Appearance and care

7-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If you choose to use a tire dressing, take the
following precautions:

•

Use a water-based tire dressing. The coat-
ing on the tire dissolves more easily than
with an oil-based tire dressing.

•

Apply a light coat of tire dressing to help
prevent it from entering the tire tread/
grooves (where it would be difficult to re-
move).

•

Wipe off excess tire dressing using a dry
towel. Make sure the tire dressing is com-
pletely removed from the tire tread/
grooves.

•

Allow the tire dressing to dry as recom-
mended by tire dressing manufacturer.

Occasionally remove loose dust from the in-
terior trim, plastic parts and seats using a
vacuum cleaner or soft bristled brush. Wipe
the vinyl and leather surfaces with a clean,
soft cloth dampened in mild soap solution,
then wipe clean with a dry, soft cloth.

Regular care and cleaning is required in order
to maintain the appearance of the leather.

Before using any fabric protector, read the
manufacturer’s

recommendations.

Some

fabric protectors contain chemicals that may
stain or bleach the seat material.

Use a soft cloth dampened only with water to
clean the meter and gauge lens covers.

WARNING

Do not use water or acidic cleaners (hot
steam cleaners) on the seat. This can dam-
age the seat or occupant classification sen-
sor. This can also affect the operation of
the air bag system and result in serious per-
sonal injury.

CAUTION

•

Never use benzine, thinner or any similar
material on the interior surfaces or sur-
face damage may occur. Such damage is
not covered under the INFINITI war-
ranty.

•

Small dirt particles can be abrasive and
damaging to leather surfaces and should
be removed promptly. Do not use saddle
soap, car waxes, polishes, oils, cleaning
fluids,

solvents,

detergents

ammonia-based cleaners as they dam-
age the leather's natural finish.

•

Never use fabric protectors unless rec-
ommended by the manufacturer.

•

Do not use glass or plastic cleaner on
meter or gauge lens covers. It may dam-
age the lens covers.

AIR FRESHENERS

Most air fresheners use a solvent that could
affect the vehicle interior. If you use an air
freshener, take the following precautions:

•

Hanging-type air fresheners can cause
permanent discoloration when they con-
tact vehicle interior surfaces. Place the air
freshener in a location that allows it to

CLEANING INTERIOR

7-4

Appearance and care

-------------------------------------------------------------------------------------------------------------------------------------------------------------

hang free and not contact an interior sur-
face.

•

Liquid-type air fresheners typically clip on
the ventilators. These products can cause
immediate

damage

and

discoloration

when spilled on interior surfaces.

Carefully read and follow the manufacturer’s
instructions before using air fresheners.

FLOOR MATS (IF EQUIPPED)

WARNING

To avoid potential pedal interference that
may result in a collision, injury or death:

•

NEVER place a floor mat on top of an-
other floor mat in the driver front posi-
tion.

•

It is recommended you use only genuine
INFINITI floor mats specifically de-
signed for use in your vehicle model. For
additional information, it is recom-
mended you contact an INFINITI re-
tailer.

•

Properly position the mats in the floor-
well using the floor mat positioning aid.

The use of genuine INFINITI floor mats can
extend the life of your vehicle carpet and
make it easier to clean the interior. Mats
should be maintained with regular cleaning
and replaced if they become excessively
worn.

Floor mat positioning aid

This vehicle includes a front floor mat bracket
to act as a floor mat positioning aid. INFINITI
floor mats have been specially designed for
your vehicle model.

Position the mat by placing the floor mat
bracket hook through the floor mat grommet
hole while centring the mat in the foot area.

Periodically check that the mats are properly
positioned.

SEAT BELTS

The seat belts can be cleaned by wiping them
with a sponge dampened in a mild soap solu-
tion.

SAI0039Z

Example

Appearance and care

7-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Allow the belts to dry completely in the shade
before using them. For additional informa-
tion, see "Seat belts" in the "1. Safety — seats,
seat belts and supplemental restraint system"
section.

WARNING

•

Do not allow wet seat belts to roll up in
the retractor.

•

NEVER use bleach, dye or chemical sol-
vents to clean the seat belts, since these
materials may severely weaken the seat
belt webbing.

CLEANING THE SEAT TRACKS

CAUTION

Periodically clean the seat tracks to pre-
vent reduction of ability to move the seats.
Clean periodically with a high-powered
vacuum cleaner. Dirt and debris may re-
duce the ability to adjust the seat. A wet
cleansing agent may be used if necessary.

GENUINE LEATHER SEAT
COVERS

Automotive leather is typically finished with
coatings which protect the surface from the
sun's damaging rays as well as making it re-
sistant to soiling. The finishes used in auto-
motive upholstery are unique; very different
to furniture, garment or shoe leathers.
Leather is extremely resilient and easy to
clean and maintain.

•

Before

cleaning

leather

upholstery,

vacuum it to remove dust.

•

To clean leather, simply use a soft and
lint-free cloth dampened with lukewarm
water and mild soap. Do not soak the
leather.

•

Use a gentle, circular motion. Do not run
the leather or apply extreme pressure
when cleaning.

•

Wipe the leather again with another clean,
slightly damp cloth to remove soap resi-
due. Dry with a soft cloth.

Leather should be cleaned whenever it be-
comes soiled. Dust and dirt may harm leather
if allowed to work into the finish.

Never use alcohol, cleaning solvents, oils,
varnishes or polishes on your leather, and
avoid using unknown products as they dam-
age the finish. Only use leather care agents
approved by INFINITI.

Steaming or ironing is not recommended as it
may damage the leather.

Leather is a natural product and has natural
surface properties such as unevenness in
structure, marks caused by injury, and subtle
color differences. These are characteristics of
leather and not material faults.

Leather cleaning kit (if equipped)

Spray onto the leather cleaning cloth, then
gently wipe the surface of leather. Use a dry
towel to absorb any excess moisture.

Please refer to the instruction manual pro-
vided with the leather cleaner kit.

Clean light-colored leather more frequently
because soiling on such surfaces is much
more visible.

You can obtain the leather cleaner kit from an
INFINITI retailer.

7-6

Appearance and care

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOST COMMON FACTORS
CONTRIBUTING TO VEHICLE
CORROSION

Most vehicle corrosion is caused by:

•

The accumulation of moisture-retaining
dirt and debris in body panel sections, cavi-
ties, and other areas.

•

Damage to the paint surface and other
protective coatings caused by gravel and
stone chips or minor traffic accidents.

ENVIRONMENTAL FACTORS
INFLUENCE THE RATE OF
CORROSION

Moisture

The accumulation of sand, dirt and water on
the inside floor of the vehicle can accelerate
corrosion. Wet floor carpet/floor mats will
not dry completely inside the vehicle. They
should be removed and completely dried to
avoid floor panel corrosion.

Relative humidity

Corrosion will be accelerated in areas of high
relative humidity, especially those areas
where the temperatures stay above freezing
and where atmospheric pollution exists and
road salt is used.

Temperature

High temperatures accelerate the rate of cor-
rosion to those parts which are not well ven-
tilated.

Air pollution

Industrial pollution, the presence of salt in the
air in coastal areas, or heavy road salt use
accelerates the corrosion process. Road salt
also accelerates the disintegration of paint
surfaces.

TO PROTECT YOUR VEHICLE
FROM CORROSION

•

Wash and wax your vehicle often to keep
the vehicle clean.

•

Always check for minor damage to the
paint surface and repair it as soon as pos-
sible.

•

Keep drain holes in the lower edge of the
doors open to avoid water accumulation.

•

Check the underbody for accumulation of
sand, dirt or salt. If present, wash with
water as soon as possible.

CAUTION

•

NEVER remove dirt, sand or other de-
bris from the passenger compartment
by washing it out with a hose. Remove
dirt with a vacuum cleaner or broom.

•

Never allow water or other liquids to
come in contact with electronic compo-
nents inside the vehicle as this may dam-
age them.

Chemicals used for road surface deicing are
extremely corrosive. They accelerate corro-
sion and deterioration of underbody compo-
nents such as the exhaust system, fuel and
brake lines, brake cables, floor pan and fend-
ers.

In winter, the underbody must be cleaned
periodically.

For additional protection against rust and
corrosion, which may be required in some
areas, it is recommended that you visit an
INFINITI retailer.

CORROSION PROTECTION

Appearance and care

7-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When performing any inspection or mainte-
nance work on your vehicle, always take care
to prevent serious accidental injury to your-
self or damage to the vehicle. The following
are general precautions which should be
closely observed.

WARNING

•

Park the vehicle on a level surface, apply
the parking brake securely and block the
wheels to prevent the vehicle from mov-
ing. Press the P (Park) button.

•

Be sure the ignition switch is in the OFF
position when performing any parts re-
placement or repairs.

•

Do not work under the hood while the
engine is hot. Always turn off the engine
and wait until it cools down.

•

If you must work with the engine run-
ning, keep your hands, clothing, hair and
tools away from moving fans, belts and
any other moving parts.

•

It is advisable to secure or remove any
loose clothing and any jewelry, such as
rings, watches, etc. before working on
your vehicle.

•

If you must run the engine in an enclosed
space such as a garage, be sure there is

proper ventilation for exhaust gases to
escape.

•

Never get under the vehicle while it is
supported by a jack.

•

Keep smoking materials, flame and
sparks away from fuel and the battery.

•

Never connect or disconnect either the
battery or any transistorized compo-
nent connector while the ignition switch
is in the ON position.

•

On gasoline engine models with the
Multiport Fuel Injection system, the fuel
filter and fuel lines should be serviced by
an INFINITI retailer or qualified work-
shop because the fuel lines are under
high pressure even when the engine is
turned off.

•

Your vehicle is equipped with an auto-
matic engine cooling fan. It may come on
at any time without warning, even if the
ignition switch is in the OFF position
and the engine is not running. To avoid
injury, always disconnect the negative
battery cable before working near the
fan.

•

Always wear eye protection whenever
you work on your vehicle.

•

Never leave the engine or the transmis-
sion related component harness connec-
tor disconnected while the ignition
switch is in the ON position.

•

Avoid direct contact with used engine oil
and coolant. Improperly disposed engine
oil, engine coolant, and/or other vehicle
fluids can hurt the environment. Always
conform to local regulations for disposal
of vehicle fluids.

This “ 8. Do-it-yourself” section provides in-
structions regarding only those items which
are relatively easy for an owner to perform.

You should be aware that incomplete or im-
proper servicing may result in operating diffi-
culties or excessive emissions, and could af-
fect your warranty coverage. If in doubt
about any servicing, it is recommended you
have it done by an INFINITI retailer.

MAINTENANCE PRECAUTIONS

8-2

Do-it-yourself

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2.0L GASOLINE ENGINE

1. Engine coolant reservoir (P.8-3)
2. Engine oil dipstick (P.8-5)
3. Engine oil filler cap (P.8-5)
4. Brake fluid reservoir (P.8-7)
5. Engine air cleaner filter (P.8-13)

6. Battery (P.8-9)
7. Fuse box (P.8-17)
8. Window washer fluid reservoir (P.8-8)

WARNING

The engine cooling system is filled at the
factory with a high-quality, year-round,
antifreeze coolant solution. The antifreeze
solution contains rust and corrosion inhibi-
tors, therefore additional cooling system
additives are not necessary.

•

Never remove the radiator or coolant
reservoir cap when the engine is hot.
Wait until the engine and radiator cool
down. Serious burns could be caused by
high-pressure fluid escaping from the
radiator. For additional information on
precautions, refer to "If your vehicle
overheats" in the "6. In case of emer-
gency" section

•

The engine coolant reservoir tank is
equipped with a pressure type cap. To
prevent engine damage, use only a
genuine INFINITI pressure cap.

CAUTION

•

Never use any cooling system additives
such as radiator sealer. Additives may
clog the cooling system and cause dam-
age to the engine, transmission and/or
cooling system.

NIC2833

ENGINE COMPARTMENT CHECK
LOCATIONS

ENGINE COOLING SYSTEM

Do-it-yourself

8-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

•

When adding or replacing coolant, be
sure to use only INFINITI Genuine En-
gine Coolant, BASF Glysantin G40 or
equivalent in its quality. The use of other
types of engine coolant may damage the
engine cooling system.

CHECKING ENGINE COOLANT
LEVEL

NOTE
The coolant level must only be checked and
corrected when the engine is cold.

1. Park the vehicle on a level surface.

Only check the coolant level if the vehicle
is on a level surface and the engine is cold.

2. Slowly turn cap

䊊

half a turn counter-

clockwise to allow excess pressure to es-
cape.

3. Turn cap

䊊

further counter-clockwise

and remove it.

If the coolant is at the level of marker bar

䊊

in the filler neck when cold, there is

enough coolant in coolant expansion tank

䊊

4. If necessary, top up with INFINITI Genu-

ine Engine Coolant, BASF Glysantin G40
or equivalent in its quality.

5. Replace cap

䊊

and turn it clockwise as

far as it will go.

If the cooling system frequently requires
coolant, have it checked. It is recommended
that you visit an INFINITI retailer for this
service.

CHANGING ENGINE COOLANT

An INFINITI retailer can change the engine
coolant.

Improper servicing can result in reduced
heater performance and engine overheating.

WARNING

•

To avoid being scalded, never change
the coolant when the engine is hot.

•

Never remove the radiator cap when the
engine is hot. Serious burns could be
caused by high pressure fluid escaping
from the radiator.

•

Avoid direct skin contact with used
coolant. If skin contact is made, wash
thoroughly with soap or hand cleaner as
soon as possible.

•

Keep coolant out of reach of children
and pets.

Engine coolant must be disposed of properly.
Check your local regulations.

NDI1602

8-4

Do-it-yourself

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CHECKING ENGINE OIL LEVEL

1. Park the vehicle on a level surface and

apply the parking brake.

2. Start the engine and let it idle until it

reaches the normal operating tempera-
ture.

3. Turn off the engine. Wait more than 10

minutes for the oil to drain back into the oil
pan.

4. Remove the dipstick

䊊

and wipe it clean.

Reinsert it all the way.

5. Remove the dipstick and check the oil

level. It should be within the range

䊊

and

䊊

If the oil level is below

䊊

, remove the oil

filler cap and pour the recommended oil
into the opening. Do not overfill

䊊

It is normal to add some oil between oil main-
tenance intervals or during the break-in pe-
riod, depending on the severity of operating
conditions.

CAUTION

The oil level should be checked regularly.
Operating the engine with an insufficient
amount of oil can damage the engine, and
such damage is not covered by the
warranty.

CHANGING ENGINE OIL

WARNING

•

Prolonged and repeated contact with
used engine oil may cause skin cancer.

•

Try to avoid direct skin contact with
used oil. If skin contact is made, wash
thoroughly with soap or hand cleaner
and plenty of water as soon as possible.

•

Keep used engine oil out of reach of
children.

CAUTION

Be careful not to burn yourself. The engine
oil may be hot.

NDI1596

2.0L gasoline engine

ENGINE OIL

Do-it-yourself

8-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti QX30 (2018 year). Manual - part 28
