Infiniti Q60 (2018 year). Manual

2-60

Instruments and controls

PROGRAMMING HomeLink

If you have any questions or are having
difficulty programming your HomeLink

buttons, refer to the HomeLink

web site

at: www.homelink.com or call 1-800-355-
3515.

NOTE:
It is also recommended that a new battery
be placed in the hand-held transmitter of
t h e d e v i c e b e i n g p r o g r a m m e d t o
HomeLink

for quicker programming and

accurate transmission of the radio-fre-
quency.
1. Position the end of your hand-held

transmitter 1-3 in (26-76 mm) away
from the HomeLink

surface, keeping

the HomeLink

indicator light

in view.

JVI0428X

2. Using both hands, simultaneously press

and hold the desired HomeLink

button

and handheld transmitter button. DO
NOT release until the HomeLink

indi-

cator light

flashes slowly and then

rapidly. When the indicator light flashes
rapidly, both buttons may be released.
(The rapid flashing indicates successful
programming.)

NOTE:
Some devices to be programmed may
require you to replace Step 2 with the
cycling procedure noted in the “Pro-
gramming HomeLink

for Canadian cus-

tomers and gate openers” (P.2-61).

JVI0429X

3. Press and hold the programmed

HomeLink

button and observe the in-

dicator light.

If the indicator light

is solid/con-

tinuous, programming is complete
and your device should activate when
the HomeLink

button is pressed and

released.

If the indicator light

blinks rapidly

for two seconds and then turns to a
solid/continuous light, continue with
Steps 4-6 for a rolling code device. A
second person may make the follow-
ing steps easier. Use a ladder or other
device. Do not stand on your vehicle
to perform the next steps.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4. At the receiver located on the garage

door opener motor in the garage, locate
the “learn” or “smart” button (the name
and color of the button may vary by
manufacturer but it is usually located
near where the hanging antenna wire is
attached to the unit). If there is difficulty
locating the button, reference the garage
door opener’s manual.

5. Press and release the “learn” or “smart”

button.

NOTE:
Once the button is pressed, you have
approximately 30 seconds to initiate the
next step.

6. Return to the vehicle and firmly press

and hold the programmed HomeLink

button for two seconds and release.
Repeat the “press/hold/release” se-
quence up to 3 times to complete the
programming process. HomeLink

should now activate your rolling code
equipped device.

7. If you have any questions or are having

difficulty programming your HomeLink

buttons, refer to the HomeLink

web

site at: www.homelink.com or call 1-
800-355-3515.

PROGRAMMING HomeLink

FOR

CANADIAN CUSTOMERS AND
GATE OPENERS

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission –
which may not be long enough for
HomeLink

to pick up the signal during

programming. Similar to this Canadian law,
some U.S. gate operators are designed to
“time-out” in the same manner.
If you live in Canada or you are having
difficulties programming a gate operator or
garage door opener by using the “Program-
ming HomeLink

” procedures, replace “Pro-

gramming HomeLink

” Step 2 with the

following:

NOTE:
When programming a garage door opener,
etc., unplug the device during the “cycling”
process to prevent possible damage to the
garage door opener components.
Step 2: Using both hands, simultaneously
press and hold the desired HomeLink

button and the hand-held transmitter but-
ton. During programming, your hand-held
transmitter may automatically stop trans-
mitting. Continue to press and hold the
desired HomeLink

button while you press

and re-press (“cycle”) your hand-held trans-

mitter every two seconds until the frequency
signal has been learned. The HomeLink

indicator light will flash slowly and then
rapidly after several seconds upon success-
ful programming. DO NOT release until the
HomeLink

indicator light flashes slowly and

then rapidly. When the indicator light flashes
rapidly, both buttons may be released. The
rapid flashing indicates successful program-
ming.
Proceed with “Programming HomeLink

”

step 3 to complete.
Remember to plug the device back in when
programming is completed.

OPERATING THE HomeLink

UNIVERSAL TRANSCEIVER

The HomeLink

Universal Transceiver, after

it is programmed, can be used to activate the
programmed device. To operate, simply
press and release the appropriate pro-
grammed HomeLink

Universal Transceiver

button. The amber indicator light will illumi-
nate while the signal is being transmitted.
For convenience, the hand-held transmitter
of the device may also be used at any time.

Instruments and controls

2-61

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-62

Instruments and controls

PROGRAMMING TROUBLE-
SHOOTING

If the HomeLink

does not quickly learn the

hand-held transmitter information:
. replace the hand-held transmitter bat-

teries with new batteries.

. position the hand-held transmitter with

its battery area facing away from the
HomeLink

surface.

. press and hold both the HomeLink

and

hand-held transmitter buttons without
interruption.

. position the hand-held transmitter 1-3 in

(26-76 mm) away from the HomeLink

surface. Hold the transmitter in that
position for up to 15 seconds. If
HomeLink

is not programmed within

that time, try holding the transmitter in
another position - keeping the indicator
light in view at all times.

If you have any questions or are having
difficulty programming your HomeLink

buttons, refer to the HomeLink

web site

at: www.homelink.com or 1-800-355-
3515.

CLEARING THE PROGRAMMED
INFORMATION

The following procedure clears the pro-
grammed information from both buttons.
Individual buttons cannot be cleared. How-
ever, individual buttons can be repro-
grammed, see “Reprogramming a single
HomeLink

button” (P.2-62).

To clear all programming

1. Press and hold the two outer HomeLink

buttons until the indicator light begins to
flash in approximately 10 seconds. Do
not hold for longer than 20 seconds.

2. Release both buttons.
HomeLink

is now in the programming mode

and can be programmed at any time begin-
ning with “Programming HomeLink

” - Step

REPROGRAMMING A SINGLE
HomeLink

BUTTON

To reprogram a HomeLink

Universal Trans-

ceiver button, complete the following.
1. Press and hold the desired HomeLink

button. Do not release the button.

2. The indicator light will begin to flash

after 20 seconds. Without releasing the
HomeLink

button, proceed with “Pro-

gramming HomeLink

” - Step 1.

For questions or comments, contact
HomeLink

at: www.homelink.com or 1-

800-355-3515.
The HomeLink

Universal Transceiver but-

ton has now been reprogrammed. The new
device can be activated by pushing the
HomeLink

button that was just pro-

grammed. This procedure will not affect
any other programmed HomeLink

buttons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change
the codes of any non-rolling code device that
has been programmed into HomeLink

Consult the Owner’s Manual of each device
or call the manufacturer or retailer of those
devices for additional information.
When your vehicle is recovered, you will
need to reprogram the HomeLink

Univer-

sal Transceiver with your new transmitter
information.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-2

Pre-driving checks and adjustments

A key number plate is supplied with your
keys. Record the key number and keep it in a
safe place (such as your wallet), not in the
vehicle. If you lose your keys, it is recom-
mended you visit an INFINITI retailer for
duplicates by using the key number. INFINITI
does not record any key numbers so it is very
important to keep track of your key number
plate.
A key number is only necessary when you
have lost all keys and do not have one to
duplicate from. If you still have a key, it can
be duplicated without knowing the key
number.

SPA2865

Type A (if so equipped)

JVP0414X

Type B (if so equipped)

Intelligent Keys (2)

Mechanical keys (inside the Keys) (2)

Key number plate (1)

INTELLIGENT KEY

Your vehicle can only be driven with the
Intelligent Keys which are registered to your
vehicle’s Intelligent Key system components
and INFINITI Vehicle Immobilizer System
components. As many as 4 Intelligent Keys
can be registered and used with one vehicle.
The new keys must be registered by an
INFINITI retailer prior to use with the
Intelligent Key system and INFINITI Vehicle
Immobilizer System of your vehicle. Since the
registration process requires erasing all
memory in the Intelligent Key components
when registering new keys, be sure to take
all Intelligent Keys that you have to the
INFINITI retailer.
It is possible that the Intelligent Key func-
tions become canceled. Contact an INFINITI
retailer.

CAUTION

. Be sure to carry the Intelligent Key

with you when driving. The Intelli-
gent Key is a precision device with a
built-in transmitter. To avoid dama-
ging it, please note the following.

KEYS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

— The Intelligent Key is water re-

sistant; however, wetting may
damage the Intelligent Key. If the
Intelligent Key gets wet, immedi-
ately wipe until it is completely
dry.

— Do not bend, drop or strike it

against another object.

— If the outside temperature is

below 14°F (−10°C), the battery
of the Intelligent Key may not
function properly.

— Do not place the Intelligent Key

for an extended period in a place
where temperatures exceed
140°F (60°C).

— Do not change or modify the

Intelligent Key.

— Do not use a magnet key holder.

— Do not place the Intelligent Key

near an electric appliance such as
a television set or personal com-
puter.

— Do not allow the Intelligent Key

to come into contact with water
or salt water, and do not wash it
in a washing machine. This could
affect the system function.

. If an Intelligent Key is lost or stolen,

INFINITI recommends erasing the ID
code of that Intelligent Key. This will
prevent the Intelligent Key from un-
authorized use to unlock the vehicle.
For information regarding the eras-
ing procedure, it is recommended you
visit an INFINITI retailer.

SPA2033

Mechanical key

To remove the mechanical key, release the
lock knob at the back of the Intelligent Key.
To install the mechanical key, firmly insert it
into the Intelligent Key until the lock knob
returns to the lock position.
Use the mechanical key to lock or unlock the
doors and glove box, if they are equipped
with a key cylinder.
See “Doors” (P.3-4) and “Glove box” (P.2-
50).

Pre-driving checks and adjustments

3-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-4

Pre-driving checks and adjustments

CAUTION

Always carry the mechanical key in-
stalled in the key.

VALET HAND-OFF

When you have to leave a key with a valet,
give them the Intelligent Key itself and keep
the mechanical key with you to protect your
belongings.
To prevent the glove box and the trunk from
being opened during valet hand-off, follow
the procedures below.
1. Push the trunk release power cancel

switch to the OFF (cancel) side.

2. Remove the mechanical key from the

Intelligent Key.

3. Lock the glove box with the mechanical

key.

4. Hand the Intelligent Key to the valet,

keeping the mechanical key in your
pocket or bag for insertion into the
Intelligent Key when you retrieve your
vehicle.

See “Trunk lid” (P.3-22) and “Glove box”
(P.2-50).

WARNING

. Always have the doors locked while

driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from unintention-
ally opening the doors, and will help
keep out intruders.

. Before opening any door, always look

for and avoid oncoming traffic.

. To help avoid risk of injury or death

through unintended operation of the
vehicle and or its systems, including
entrapment in windows or inadver-
tent door lock activation, do not
leave children, people who require
the assistance of others or pets
unattended in your vehicle. Addition-
ally, the temperature inside a closed
vehicle on a warm day can quickly
become high enough to cause a sig-
nificant risk of injury or death to
people and pets.

JVP0231X

LOCKING WITH MECHANICAL
KEY

The power door lock system allows you to
lock or unlock all doors, trunk lid simulta-
neously using the mechanical key.
. Turning the driver’s door key cylinder to

the front of the vehicle

will lock all

doors and trunk lid.

. Turning the driver’s door key cylinder

once to the rear of the vehicle

will

unlock the driver’s door. After returning
the key to the neutral position

, turning

it to the rear again within 60 seconds will
unlock all doors and trunk lid.

DOORS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

. You can switch the lock system to the

mode that allows you to open all the
doors when the key is turned once. (See
the Infiniti InTouch Owner’s Manual for
details.)

OPENING AND CLOSING WIN-
DOWS WITH MECHANICAL KEY

The driver’s door key operation also allows
you to open and close the window that is
equipped with the automatic open/close
function. (See “Power windows” (P.2-52).)
To open the window, turn the driver’s door
key cylinder to the rear of the vehicle for
longer than 1 second. The door is unlocked
and the window keeps opening while turning
the key.
This function can also be performed by
pushing and holding the UNLOCK button
on the Intelligent Key. (See “Remote keyless
entry system” (P.3-15).)
To close the window, turn the driver’s door
key cylinder to the front of the vehicle for
longer than 1 second. The door is locked and
the window keeps closing while turning the
key.

SPA2726

LOCKING WITH INSIDE LOCK
KNOB

To lock the door individually, move the inside
lock knob to the lock position

then close

the door.
To unlock, move the inside lock knob to the
unlock position

When locking the door without an Intelli-
gent Key, be sure not to leave the Intelligent
Key inside the vehicle.

JVP0319X

LOCKING WITH POWER DOOR
LOCK SWITCH

Operating the power door lock switch will
lock or unlock all the doors and trunk lid. The
switches are located on the driver’s and
front passenger’s door armrests.
To lock the doors and trunk lid, push the
power door lock switch to the lock position

with the driver’s or front passenger’s door

open, then close the door.
When locking the door this way, be certain
not to leave the Intelligent Key inside the
vehicle.
To unlock the doors including the fuel-filler
door and trunk lid, push the power door lock

Pre-driving checks and adjustments

3-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-6

Pre-driving checks and adjustments

switch to the unlock position

Lockout protection

When the power door lock switch is moved
to the lock position and any door open, all
doors will lock and unlock automatically.
With the Intelligent Key left in the vehicle
and any door open, all doors will unlock
automatically and a chime will sound after
the door is closed.
These functions help to prevent the Intelli-
gent Key from being accidentally locked
inside the vehicle.

AUTOMATIC DOOR LOCKS

. All doors and trunk lid lock automatically

when the vehicle speed reaches 15 MPH
(24 km/h).

. All doors and trunk lid unlock automati-

cally when the ignition switch is placed in
the OFF position or when the shift lever
is moved to the P (Park) position, if
selected.

The automatic unlock function can be
deactivated or activated. To deactivate or
activate the automatic door unlock system,
perform the following procedure:
1. Close all doors.
2. Place the ignition switch in the ON

position.

3. Within 20 seconds of performing Step 2,

push and hold the power door lock
switch to the

position (UNLOCK)

for more than 5 seconds.

4. When activated, the hazard indicator will

flash twice. When deactivated, the ha-
zard indicator will flash once.

5. The ignition switch must be placed in the

OFF and ON position again between
each setting change.

When the automatic door unlock system is
deactivated, the doors do not unlock when
the ignition switch is placed in the OFF
position. To unlock the door manually, use
the inside lock knob or the power door lock
switch (driver’s or front passenger’s side).
The automatic door unlock function can be
changed on the lower display. (See the
Infiniti InTouch Owner’s Manual.)

WARNING

. Radio waves could adversely affect

electric medical equipment. Those
who use a pacemaker should contact
the electric medical equipment man-
ufacturer for the possible influences
before use.

. The Intelligent Key transmits radio

waves when the buttons are pushed.
The FAA advises that the radio
waves may affect aircraft navigation
and communication systems. Do not
operate the Intelligent Key while on
an airplane. Make sure the buttons
are not operated unintentionally
when the unit is stored during a
flight.

The Intelligent Key system can operate all
the doors and the trunk lid using the remote
controller function, using one touch unlock
function or pushing the request switch on
the vehicle without taking the key out from a
pocket or purse. The operating environment
and/or conditions may affect the Intelligent
Key system operation.
Be sure to read the following before using
the Intelligent Key system.

INTELLIGENT KEY SYSTEM

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION

. Be sure to carry the Intelligent Key

with you when operating the vehicle.

. Never leave the Intelligent Key in the

vehicle when you leave the vehicle.

The Intelligent Key is always communicating
with the vehicle as it receives radio waves.
The Intelligent Key system transmits weak
radio waves. Environmental conditions may
interfere with the operation of the Intelligent
Key system under the following operating
conditions.
. When operating near a location where

strong radio waves are transmitted, such
as a TV tower, power station and broad-
casting station.

. When in possession of wireless equip-

ment, such as a cellular telephone,
transceiver, and CB radio.

. When the Intelligent Key is in contact

with or covered by metallic materials.

. When any type of radio wave remote

control is used nearby.

. When the Intelligent Key is placed near

an electric appliance such as a personal
computer.

. When the vehicle is parked near a parking

meter.

In such cases, correct the operating condi-
tions before using the Intelligent Key func-
tion or use the mechanical key.
Although the life of the battery varies
depending on the operating conditions, the
battery’s life is approximately 2 years. If the
battery is discharged, replace it with a new
one.
When the Intelligent Key battery is almost
discharged, see “Intelligent Key battery dis-
charge” (P.5-14) to start the engine.
Since the Intelligent Key is continuously
receiving radio waves, if the key is left near
equipment which transmits strong radio
waves, such as signals from a TV and
personal computer, the battery life may
become shorter.
For information regarding replacement of a
battery, see “Intelligent Key battery replace-
ment” (P.8-26).
As many as 4 Intelligent Keys can be
registered and used with one vehicle. For
information about the purchase and use of
additional Intelligent Keys, contact an
INFINITI retailer.

CAUTION

. Do not allow the Intelligent Key,

which contains electrical compo-
nents, to come into contact with
water or salt water. This could affect
the system function.

. Do not drop the Intelligent Key.
. Do not strike the Intelligent Key

sharply against another object.

. Do not change or modify the Intelli-

gent Key.

. Wetting may damage the Intelligent

Key. If the Intelligent Key gets wet,
immediately wipe until it is comple-
tely dry.

. Do not place the Intelligent Key for

an extended period in an area where
temperatures exceed 140°F (60°C).

. If the outside temperature is below

14°F (−10°C), the battery of the
Intelligent Key may not function
properly.

. Do not attach the Intelligent Key

with a key holder that contains a
magnet.

. Do not place the Intelligent Key near

equipment that produces a magnetic
field, such as a TV, audio equipment

Pre-driving checks and adjustments

3-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-8

Pre-driving checks and adjustments

and personal computers.

If an Intelligent Key is lost or stolen, INFINITI
recommends erasing the ID code of that
Intelligent Key from the vehicle. This may
prevent the unauthorized use of the Intelli-
gent Key to operate the vehicle. For infor-
mation regarding the erasing procedure,
contact an INFINITI retailer.

JVP0453X

INTELLIGENT KEY OPERATING
RANGE

The Intelligent Key functions can only be
used when the Intelligent Key is within the
specified operating range from the one
touch unlock sensor/door request switch
and trunk open request switch

When the Intelligent Key battery is dis-
charged or strong radio waves are present
near the operating location, the Intelligent
Key system’s operating range becomes nar-
rower, and the Intelligent Key may not
function properly.
The operating range is within 31.50 in (80
cm) from each one touch unlock sensor/door

handle request switch

and trunk open

request switch

If the Intelligent Key is too close to the door
glass, handle or rear bumper, the one touch
unlock sensor and request switches may not
function.
When the Intelligent Key is within the
operating range, it is possible for anyone
who does not carry the Intelligent Key to use
the one touch unlock sensor or request
switches to lock or unlock the doors and
open the trunk lid.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SPA2407

DOOR LOCKS/UNLOCKS PRE-
CAUTION

. Do not push the door handle request

switch with the Intelligent Key held in
your hand as illustrated. The close dis-
tance to the door handle will cause the
Intelligent Key system to have difficulty
recognizing that the Intelligent Key is
outside the vehicle.

. Within 2 seconds after the door are

locked using the door handle request
switch, make sure that the doors have
been securely locked by operating the
door handles. If you keep holding the
door handle for more than 2 seconds
after locking the doors using the door

handle request switch, the door will be
unlocked.

. To prevent the Intelligent Key from being

left inside the vehicle or the trunk, make
sure you carry the key with you and then
lock the doors or the trunk.

. The Intelligent Key system (opening/

closing doors with the door handle
request switch or one touch unlock
sensor) can be set to remain inactive.
(See the Infiniti InTouch Owner’s Man-
ual.)

. The door cannot be unlocked using one

touch unlock operation after locking the
door within 2 seconds. To unlock the
door, release the one touch unlock
sensor once and touch it again.

. If a large amount of water runs down on

the door handle (for example, when
washing the vehicle or in a heavy rain),
the door may unlock if the Intelligent Key
is within the range of operation. To
prevent the door from being unlocked,
the Intelligent Key should be away from
the vehicle more than 7 ft (2 m).

. Do not hold and pull the door handle

quickly. The door will be unlocked but will
not open. Release the door handle once
and pull it again to open the door.

. If you pull the door handle with your

gloved hand, the one touch unlock
operation may not function.

JVP0415X

INTELLIGENT KEY OPERATION

You can lock or unlock the doors without
taking the key out from your pocket or bag.

Pre-driving checks and adjustments

3-9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-10

Pre-driving checks and adjustments

JVP0448X

When you carry the Intelligent Key with you,
you can lock all doors by pushing the door
handle request switch

(driver’s or front

passenger’s) within the range of operation.

JVP0449X

You can also unlock the corresponding door
by touching the one touch unlock sensor
(driver’s or front passenger’s) within the
range of operation, and can unlock the other
doors using the door handle request switch

When you lock or unlock the doors or the
trunk lid, the hazard indicator will flash and
the horn (or the outside chime) will sound as
a confirmation. For details, see “Setting
hazard indicator and horn mode” (P.3-18).

CAUTION

. After locking the doors using the

request switch, make sure that the
doors have been securely locked by
operating the door handles.

. When locking the doors using the

request switch, make sure to have the
Intelligent Key in your possession
before operating the request switch
to prevent the Intelligent Key from
being left in the vehicle.

. The request switch and one touch

unlock sensor are operational only
when the Intelligent Key has been
detected by the Intelligent Key sys-
tem.

Welcome light and farewell light
function

When you lock or unlock the doors and fuel-
filler door, front and rear side marker lights,
parking lights, emblem light (if so equipped),
tail lights and the license plate light will
illuminate for a period of time. The welcome
light and farewell light function can be
disabled. For information about disabling
the welcome light and farewell light func-
tion, see the Infiniti InTouch Owner’s Man-

-------------------------------------------------------------------------------------------------------------------------------------------------------------

ual.

Lockout protection

To prevent the Intelligent Key from being
accidentally locked in the vehicle, lockout
protection is equipped with the Intelligent
Key system.
When the driver’s side door is open, the
doors are locked, and then the Intelligent
Key is put inside the vehicle and all the doors
are closed; the lock will automatically unlock
and the door buzzer sounds.

NOTE:
The doors may not lock when the Intelligent
Key is in the same hand that is operating the
request switch to lock the door. Put the
Intelligent Key in a purse, pocket or your
other hand.

CAUTION

The lockout protection may not function
under the following conditions:
. When the Intelligent Key is placed on

top of the instrument panel.

. When the Intelligent Key is placed

inside the glove box or a storage bin.

. When the Intelligent Key is placed

inside the door pockets.

. When the Intelligent Key is placed

inside or near metallic materials.

JVP0448X

Locking doors, trunk lid and fuel-
filler door

1. Push the ignition switch to the OFF

position and make sure you carry the
Intelligent Key with you.*1

2. Close all the doors.*2
3. Push the door handle request switch

(driver’s or front passenger’s)

while

carrying the Intelligent Key with you.*3

4. All the doors, trunk lid and fuel-filler door

will lock.

5. The hazard indicator flashes twice and

the outside chime sounds twice.

*1: Doors will lock with the Intelligent Key

Pre-driving checks and adjustments

3-11

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti Q60 (2018 year). Manual - part 9
