8-36

Maintenance and do-it-yourself

SDI1949

Checking the tire pressure

1. Remove the valve stem cap from

the tire.

2. P r e s s t h e p r e s s u r e g a u g e

squarely onto the valve stem. Do
not press too hard or force the
valve stem sideways, or air will
escape. If the hissing sound of air
escaping from the tire is heard
while checking the pressure, re-
position the gauge to eliminate
this leakage.

3. Remove the gauge.
4. Read the tire pressure on the

gauge stem and compare it to
the specification shown on the
Tire and Loading Information la-
bel.

5. Add air to the tire as needed. If

too much air is added, press the
core of the valve stem briefly with
the tip of the gauge stem to
release pressure. Recheck the
pressure and add or release air
as needed.

6. Install the valve stem cap.
7. Check the pressure of all other

tires, including the spare.

Sedan:

SIZE

COLD TIRE

INFLATION

PRESSURE

FRONT

ORIGINAL

TIRE

P225/55R17 95V

230 kPa,
33 PSI

P225/50R18 94V

230 kPa,
33 PSI

225/50R18 95W

230 kPa,
33 PSI

REAR ORI-

GINAL TIRE

P225/55R17 95V

230 kPa,
33 PSI

P225/50R18 94V

230 kPa,
33 PSI

245/45R18 96W

230 kPa,
33 PSI

SPARE TIRE

T145/80D17
107M

420 kPa,
60 PSI

T145/70R18
107M

420 kPa,
60 PSI

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (441,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

Coupe:

SIZE

COLD TIRE

INFLATION

PRESSURE

FRONT

ORIGINAL

TIRE

P225/50R18 94V

230 kPa,
33 PSI

P225/45R19 92V

240 kPa,
35 PSI

225/45R19 92W

240 kPa,
35 PSI

REAR ORI-

GINAL TIRE

P225/50R18 94V

230 kPa,
33 PSI

P225/45R19 92V

240 kPa,
35 PSI

245/40R19 94W

240 kPa,
35 PSI

SPARE TIRE

T145/80D17
107M

420 kPa,
60 PSI

T145/70R18
107M

420 kPa,
60 PSI

SDI1575

Example

TIRE LABELING

Federal law requires tire manufac-
turers to place standardized informa-
tion on the sidewall of all tires. This
information identifies and describes
the fundamental characteristics of
the tire and also provides the tire
identification number (TIN) for safety
standard certification. The TIN can be
used to identify the tire in case of a
recall.

SDI1606

Example

1 Tire size (example: P215/60R16

94H)

1. P: The “P” indicates the tire is

designed for passenger vehicles.
(Not all tires have this informa-
tion.)

2. Three-digit number (215): This

number gives the width in milli-
meters of the tire from sidewall
edge to sidewall edge.

3. Two-digit number (60): This num-

ber, known as the aspect ratio,

Maintenance and do-it-yourself

8-37

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (442,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

8-38

Maintenance and do-it-yourself

gives the tire’s ratio of height to
width.

4. R: The “R” stands for radial.
5. Two-digit number (16): This num-

ber is the wheel or rim diameter in
inches.

6. Two- or three-digit number (94):

This number is the tire’s load
index. It is a measurement of
how much weight each tire can
support. You may not find this
information on all tires because it
is not required by law.

7. H: Tire speed rating. You should

not drive the vehicle faster than
the tire speed rating.

SDI1607

Example

2 TIN (Tire Identification Number)

for a new tire (example: DOT XX
XX XXX XXXX)

1. DOT: Abbreviation for the “Depart-

ment of Transportation”. The sym-
bol can be placed above, below or
to the left or right of the Tire
Identification Number.

2. Two-digit code: Manufacturer’s

identification mark

3. Two-digit code: Tire size

4. Three-digit code: Tire type code

(Optional)

5. Three-digit code: Date of Manu-

facture

6. Four numbers represent the week

and year the tire was built. For
example, the numbers 3103
means the 31st week of 2003. If
these numbers are missing, then
look on the other sidewall of the
tire.

3 Tire ply composition and materi-

al
The number of layers or plies of
rubber-coated fabric in the tire.
Tire manufacturers also must
indicate the materials in the tire,
which include steel, nylon,
polyester, and others.

4 Maximum permissible inflation

pressure
This number is the greatest
amount of air pressure that
should be put in the tire. Do
not exceed the maximum per-

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (443,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

missible inflation pressure.

5 Maximum load rating

This number indicates the max-
imum load in kilograms and
pounds that can be carried by
the tire. When replacing the tires
on the vehicle, always use a tire
that has the same load rating as
the factory installed tire.

6 Term of “tubeless” or “tube

type”
Indicates whether the tire re-
quires an inner tube (“tube
type”) or not (“tubeless”).

7 The word “radial”

The word “radial” is shown, if
the tire has radial structure.

8 Manufacturer or brand name

Manufacturer or brand name is
shown.

Other tire-related terminology:
In addition to the many terms that
are defined throughout this section,
Intended Outboard Sidewall is (1) the
sidewall that contains a whitewall,

bears white lettering or bears manu-
facturer, brand and/or model name
molding that is higher or deeper than
the same molding on the other side-
wall of the tire, or (2) the outward
facing sidewall of an asymmetrical
tire that has a particular side that
must always face outward when
mounted on a vehicle.

TYPES OF TIRES

WARNING

When changing or replacing tires, be
sure all four tires are of the same type
(Example: Summer, All Season or Snow)
and construction. An INFINITI retailer
may be able to help you with information
about tire type, size, speed rating and
availability.

Replacement tires may have a lower
speed rating than the factory equipped
tires, and may not match the potential
maximum vehicle speed. Never exceed
the maximum speed rating of the tire.

Replacing tires with those not originally

specified by INFINITI could affect the
proper operation of the TPMS.

For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety Infor-
mation” (Canada) in the Warranty Infor-
mation Booklet.

All season tires

INFINITI specifies all season tires on some
models to provide good performance all
year, including snowy and icy road condi-
tions. All Season tires are identified by ALL
SEASON and/or M&S (Mud and Snow) on
the tire sidewall. Snow tires have better
snow traction than All Season tires and
may be more appropriate in some areas.

Summer tires

INFINITI specifies summer tires on some
models to provide superior performance on
dry roads. Summer tire performance is
substantially reduced in snow and ice.
Summer tires do not have the tire traction
rating M&S on the tire sidewall.

If you plan to operate your vehicle in snowy
or icy conditions, INFINITI recommends the
use of SNOW tires or ALL SEASON tires on

Maintenance and do-it-yourself

8-39

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (444,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

8-40

Maintenance and do-it-yourself

all four wheels.

Snow tires

If snow tires are needed, it is necessary to
select tires equivalent in size and load
rating to the original equipment tires. If
you do not, it can adversely affect the
safety and handling of your vehicle.

Generally, snow tires will have lower speed
ratings than factory equipped tires and
may not match the potential maximum
vehicle speed. Never exceed the maximum
speed rating of the tire.

If you install snow tires, they must be the
same size, brand, construction and tread
pattern on all four wheels.

For additional traction on icy roads,
studded tires may be used. However, some
U.S. states and Canadian provinces prohi-
bit their use. Check local, state and
provincial laws before installing studded
tires. Skid and traction capabilities of
studded snow tires, on wet or dry surfaces,
may be poorer than that of non-studded
snow tires.

TIRE CHAINS

Use of tire chains may be prohibited
according to location. Check the local laws
before installing tire chains. When instal-
ling tire chains, make sure they are the
proper size for the tires on your vehicle and
are installed according to the chain man-
ufacturer’s suggestions. Use only SAE
Class S chains. Class “S” chains are used
on vehicles with restricted tire to vehicle
clearance. Vehicles that can use Class “S”
chains are designed to meet the SAE
standard minimum clearances between
the tire and the closest vehicle suspension
or body component required to accommo-
date the use of a winter traction device (tire
chains or cables). The minimum clearances
are determined using the factory equipped
tire size. Other types may damage your
vehicle. Use chain tensioners when recom-
mended by the tire chain manufacturer to
ensure a tight fit. Loose end links of the
tire chain must be secured or removed to
prevent the possibility of whipping action
damage to the fenders or underbody. If
possible, avoid fully loading your vehicle
when using tire chains. In addition, drive at
a reduced speed. Otherwise, your vehicle
may be damaged and/or vehicle handling

and performance may be adversely af-
fected.

Tire chains must be installed only on the
rear wheels and not on the front wheels.

Never install tire chains on a TEMPORARY
USE ONLY spare tire.

Do not use tire chains on dry roads. Driving
with tire chains in such conditions can
cause damage to the various mechanisms
of the vehicle due to some overstress.

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (445,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

SDI1662

CHANGING WHEELS AND TIRES

Tire rotation (Models equipped with
same size tires on all wheels)

INFINITI recommends rotating the
tires every 7,500 miles (12,000 km).
(See “Flat tire” (P.6-3) for tire repla-
cing procedures.)
As soon as possible, tighten the
wheel nuts to the specified torque
with a torque wrench.

Wheel nut tightening torque:

80 ft-lb (108 N·m)

The wheel nuts must be kept tigh-
tened to the specification at all
times. It is recommended that wheel
nuts be tightened to the specifica-
tion at each tire rotation interval.

WARNING

. After rotating the tires, check and

adjust the tire pressure.

. Retighten the wheel nuts when

the vehicle has been driven for
600 miles (1,000 km) (also in
cases of a flat tire, etc.).

. Do not include the T-type spare

tire or any other small size spare
tire in the tire rotation.

. For additional information regard-

ing tires, refer to “Important Tire
Safety Information” (US) or “Tire
Safety Information” (Canada) in
the Warranty Information Booklet.

Tire rotation (Models equipped with
different size tires on front and
rear)

Tires cannot be rotated on this
vehicle, as front tires are a different
size from rear tires.
A pin is on the front brake rotor to
prevent the rear wheels from being
installed in place of the front wheels.
The spare tire can be installed in
place of the front and rear wheels.
When installing the spare tire in the
front wheel, the hole in the spare tire
wheel must be aligned with the pin
on the brake rotor.

WARNING

. Retighten the wheel nuts when

the vehicle has been driven for
600 miles (1,000 km) (also in
cases of a flat tire, etc.).

. For additional information regard-

ing tires, refer to “Important Tire
Safety Information” (US) or “Tire

Maintenance and do-it-yourself

8-41

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (446,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

8-42

Maintenance and do-it-yourself

Safety Information” (Canada) in
the Warranty Information Booklet.

SDI1663

Wear indicator

Wear indicator location mark

Tire wear and damage

WARNING

. Tires should be periodically in-

spected for wear, cracking, bul-
ging or objects caught in the
tread. If excessive wear, cracks,
bulging or deep cuts are found,
the tire(s) should be replaced.

. The original tires have built-in

tread wear indicators. When wear
indicators are visible, the tire(s)
should be replaced.

. Tires degrade with age and use.

Have tires, including the spare,
over 6 years old checked by a
qualified technician, because
some tire damage may not be
obvious. Replace the tires as
necessary to prevent tire failure
and possible personal injury.

. Improper service of the spare tire

may result in serious personal
injury. If it is necessary to repair
the spare tire, contact an INFINITI
retailer.

. For additional information regard-

ing tires, refer to “Important Tire
Safety Information” (US) or “Tire
Safety Information” (Canada) in
the Warranty Information Booklet.

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (447,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

Replacing wheels and tires

When replacing a tire, use the same size,
tread design, speed rating and load carry-
ing capacity as originally equipped. (See
“Specifications” (P.9-8) for recommended
types and sizes of tires and wheels.)

WARNING

The use of tires other than those
recommended or the mixed use of tires
of different brands, construction (bias,
bias-belted or radial), or tread patterns
can adversely affect the ride, braking,
handling, ground clearance, body-to-tire
clearance, tire chain clearance, speed-
ometer calibration, headlight aim and
bumper height. Some of these effects
may lead to accidents and could result in
serious personal injury.

For Two-Wheel Drive (2WD) models, if
your vehicle was originally equipped
with 4 tires that were the same size
and you are only replacing 2 of the 4
tires, install the new tires on the rear
axle. Placing new tires on the front axle
may cause loss of vehicle control in
some driving conditions and cause an

accident and personal injury.

If the wheels are changed for any
reason, always replace with wheels
which have the same off-set dimension.
Wheels of a different off-set could cause
premature tire wear, degrade vehicle
handling characteristics and/or interfer-
ence with the brake discs/drums. Such
interference can lead to decreased brak-
ing efficiency and/or early brake pad/
shoe wear. See “Wheels and tires” (P.9-
9) of this manual for wheel off-set
dimensions.

When a spare tire is mounted or a wheel
is replaced, the TPMS will not function
and the low tire pressure warning light
will flash for approximately 1 minute.
The light will remain on after 1 minute.
Contact your INFINITI retailer as soon as
possible for tire replacement and/or
system resetting.

Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.

Do not install a damaged or deformed
wheel or tire even if it has been repaired.
Such wheels or tires could have struc-
tural damage and could fail without

warning.

The use of retread tire is not recom-
mended.

For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety Infor-
mation” (Canada) in the Warranty Infor-
mation Booklet.

All-Wheel Drive (AWD) models

CAUTION

Always use tires of the same type, size,
brand, construction (bias, bias-belted or
radial), and tread pattern on all four
wheels. Failure to do so may result in a
circumference difference between tires
on the front and rear axles which will
cause excessive tire wear and may
damage the transmission, transfer case
and differential gears.

ONLY use spare tires specified for the
AWD model.

If excessive tire wear is found, it is
recommended that all four tires be re-

Maintenance and do-it-yourself

8-43

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (448,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

8-44

Maintenance and do-it-yourself

placed with tires of the same size, brand,
construction and tread pattern. The tire
pressure and wheel alignment should also
be checked and corrected as necessary.
Contact an INFINITI retailer.

Wheel balance

Unbalanced wheels may affect vehicle
handling and tire life. Even with regular
use, wheels can get out of balance. There-
fore, they should be balanced as required.

Wheel balance service should be per-
formed with the wheels off the vehicle.
Spin balancing the wheels on the vehicle
could lead to mechanical damage.

For additional information regarding tires,
refer to “Important Tire Safety Information”
(US) or “Tire Safety Information” (Canada)
in the INFINITI Warranty Information Book-
let.

Care of wheels

See “Cleaning exterior” (P.7-2) for details
about care of the wheels.

Spare tire (TEMPORARY USE ONLY
(T-type) spare tire)

Observe the following precautions if the T-
type spare tire must be used, otherwise

your vehicle could be damaged or involved
in an accident.

WARNING

The T-type spare tire should be used for
emergency use. It should be replaced
with the standard tire at the first
opportunity to avoid possible tire or
differential damage.

Drive carefully while the TEMPORARY
USE ONLY spare tire is installed. Avoid
sharp turns and abrupt braking while
driving.

Periodically check spare tire inflation
pressure. Always keep the pressure of
the TEMPORARY USE ONLY spare tire at
60 psi (420 kPa, 4.2 bar). Always keep
the pressure of the full size spare tire (if
so equipped) at the recommended pres-
sure for standard tires, as indicated on
the Tire and Loading Information label.
For Tire and Loading Information label
location, see “Tire and Loading Informa-
tion label” in the index of this manual.

With the TEMPORARY USE ONLY spare
tire installed do not drive your vehicle at
speeds faster than 50 MPH (80 km/h).

When driving on roads covered with
snow or ice, the TEMPORARY USE ONLY
spare tire should be used on the front
wheels and original tire used on the rear
wheels (drive wheels). Use tire chains
only on the two rear original tires.

Tire tread of the TEMPORARY USE ONLY
spare tire will wear at a faster rate than
the standard tire. Replace the spare tire
as soon as the tread wear indicators
appear.

Do not use the spare tire on other
vehicles.

Do not use more than one spare tire at
the same time.

CAUTION

Do not use tire chains on a TEMPORARY
USE ONLY spare tire. Tire chains will not
fit properly and may cause damage to
the vehicle.

Because the TEMPORARY USE ONLY
spare tire is smaller than the original
tire, ground clearance is reduced. To
avoid damage to the vehicle, do not
drive over obstacles. Also do not drive

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (452,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

9-2

Technical and consumer information

The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the “8. Maintenance and do-it-yourself” section to determine the proper refill capacity.

Capacity (Approximate)

Recommended specifications

US measure

Imp measure

Liter

Fuel

20 gal

16-5/8 gal

See “Fuel information” (P.9-4).

Engine oil*1

. Engine oil with API Certification Mark*2*3
. Viscosity SAE 5W-30

Drain and refill

With oil filter change

5-1/8 qt

4-3/8 qt

4.9

Without oil filter change

4-7/8 qt

4 qt

4.6

Cooling system

Automatic transmission
model

With reservoir

9 qt

7-1/2 qt

8.5

Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent

Reservoir

7/8 qt

3/4 qt

0.8

Manual transmission model

With reservoir

9-1/2 qt

7-7/8 qt

9.0

Reservoir

7/8 qt

3/4 qt

0.8

Automatic transmission fluid

—

Genuine NISSAN Matic S ATF*4

Manual transmission gear oil

—

Genuine NISSAN Manual Transmission Fluid (MTF) HQ Multi 75W-85 or API GL-4,
Viscosity SAE 75W-85

Differential gear oil

—

For 7A/T 2WD models:
API GL-5 Synthetic Gear Oil Viscosity SAE 75W-90*5
All other models:
Genuine NISSAN Differential Oil Hypoid Super GL-5 80W-90 or API GL-5, Viscosity SAE
80W-90*6

Transfer fluid

—

Genuine NISSAN Matic J ATF*7

Power steering fluid (PSF)

Refill to the proper oil level according to the instructions in the “8.
Maintenance and do-it-yourself” section.

Genuine NISSAN PSF or equivalent*8

Brake and clutch fluid

Genuine NISSAN Super Heavy Duty Brake Fluid*9 or equivalent DOT 3

Multi-purpose grease

Without limited slip differential

—

NLGI No. 2 (Lithium soap base)

With limited slip differential

—

Air conditioning system refrigerant

—

HFC-134a (R-134a)*10

Air conditioning system lubricants

—

NISSAN A/C System Oil Type S or exact equivalent

Window washer fluid

—

Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent

*1: For additional information, see “Engine oil” (P.8-11) for changing engine oil.
*2: INFINITI recommends Genuine NISSAN Ester Engine Oil available at an INFINITI retailer.

CAPACITIES AND RECOMMENDED FUEL/
LUBRICANTS

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (453,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

*3: For additional information, see “Engine oil and oil filter recommendation” (P.9-6).
*4: Using automatic transmission fluid other than Genuine NISSAN Matic S ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic

transmission, which is not covered by the INFINITI new vehicle limited warranty.

*5: See an INFINITI retailer for service for synthetic oil.
*6: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 328F (08C).
*7: Using transfer fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and transfer durability, and may damage the transfer, which is not covered by the INFINITI new

vehicle limited warranty.

*8: DEXRON

VI type ATF may also be used.

*9: Available in mainland USA through an INFINITI retailer.
*10: For additional information, see “Vehicle identification” (P.9-11) for air conditioner specification label.

Technical and consumer information

9-3

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (454,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

9-4

Technical and consumer information

FUEL INFORMATION

VQ37VHR engine

Use unleaded premium gasoline with an
octane rating of at least 91 AKI (Anti-Knock
Index) number (Research octane number
96).

If premium gasoline is not available,
unleaded regular gasoline with an octane
rating of 87 AKI number (Research octane
number 91) may be temporarily used, but
only under the following precautions:

. Have the fuel tank filled only partially

with unleaded regular gasoline, and fill
up with unleaded premium gasoline as
soon as possible.

. Avoid full throttle driving and abrupt

acceleration.

Use unleaded premium gasoline for max-
imum vehicle performance.

CAUTION

Using a fuel other than that specified
could adversely affect the emission
control system, and may also affect
warranty coverage.

Under no circumstances should a leaded
gasoline be used, because this will
damage the three-way catalyst.

Do not use E-15 or E-85 fuel in your
vehicle. Your vehicle is not designed to
run on E-15 or E-85 fuel. Using E-15 or E-
85 fuel in a vehicle not specifically
designed for E-15 or E-85 fuel can
adversely affect the emission control
devices and systems of the vehicle.
Damage caused by such fuel is not
covered by the INFINITI new vehicle
limited warranty.

U.S. government regulations require
ethanol dispensing pumps to be identi-
fied by a small, square, orange and black
label with the common abbreviation or
the appropriate percentage for that
region.

Gasoline specifications

INFINITI recommends using gasoline that
meets the World-Wide Fuel Charter (WWFC)
specifications where it is available. Many
of the automobile manufacturers devel-
oped this specification to improve emis-
sion system and vehicle performance. Ask
your service station manager if the gaso-

line meets the World-Wide Fuel Charter
(WWFC) specifications.

Reformulated gasoline

Some fuel suppliers are now producing
reformulated gasolines. These gasolines
are specially designed to reduce vehicle
emissions. INFINITI supports efforts to-
wards cleaner air and suggests that you
use reformulated gasoline when available.

Gasoline containing oxygenates

Some fuel suppliers sell gasoline contain-
ing oxygenates such as ethanol, MTBE and
methanol with or without advertising their
presence. INFINITI does not recommend the
use of fuels of which the oxygenate content
and the fuel compatibility for your INFINITI
cannot be readily determined. If in doubt,
ask your service station manager.

If you use oxygenate-blend gasoline,
please take the following precautions as
the usage of such fuels may cause vehicle
performance problems and/or fuel system
damage.

. The fuel should be unleaded and have

an octane rating no lower than that
recommended for unleaded gasoline.

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Black plate (455,1)

[ Edit: 2012/ 7/ 6 Model: V36-D ]

. If an oxygenate-blend, excepting a

methanol blend, is used, it should
contain no more than 10% oxygenate.
(MTBE may, however, be added up to
15%.)

. E-15 fuel contains more than 10%

oxygenate. E-15 fuel will adversely
affect the emission control devices
and systems of the vehicle and should
not be used. Damage caused by such
fuel is not covered by the INFINITI new
vehicle limited warranty.

. If a methanol blend is used, it should

contain no more than 5% methanol
(methyl alcohol, wood alcohol). It
should also contain a suitable amount
of appropriate cosolvents and corro-
sion inhibitors. If not properly formu-
lated with appropriate cosolvents and
corrosion inhibitors, such methanol
blends may cause fuel system damage
and/or vehicle performance problems.
At this time, sufficient data is not
available to ensure that all methanol
blends are suitable for use in INFINITI
vehicles.

If any undesirable driveability problems
such as engine stalling or hard hot starting
are experienced after using oxygenate-

blend fuels, immediately change to a
non-oxygenate fuel or a fuel with a low
blend of MTBE.

Take care not to spill gasoline during
refueling. Gasoline containing oxygenates
can cause paint damage.

E-15 fuel

E-15 fuel is a mixture of approximately
15% fuel ethanol and 85% unleaded
gasoline. E-15 can only be used in vehicles
designed to run on E-15 fuel. Do not use E-
15 in your vehicle. U.S. government
regulations require fuel ethanol dispensing
pumps to be identified with small, square,
orange and black label with the common
abbreviation or the appropriate percentage
for that region.

E-85 fuel

E-85 fuel is a mixture of approximately
85% fuel ethanol and 15% unleaded
gasoline. E-85 can only be used in a
Flexible Fuel Vehicle (FFV). Do not use E-
85 fuel in your vehicle. U.S. government
regulations require fuel ethanol dispensing
pumps to be identified by a small, square,
orange and black label with the common
abbreviation or the appropriate percentage
for that region.

Aftermarket fuel additives

INFINITI does not recommend the use of
any aftermarket fuel additives (Example:
fuel injector cleaner, octane booster, intake
valve deposit removers, etc.) which are
sold commercially. Many of these additives
intended for gum, varnish or deposit
removal may contain active solvent or
similar ingredients that can be harmful to
the fuel system and engine.

Octane rating tips

Using unleaded gasoline with an octane
rating lower than recommended above can
cause persistent, heavy spark knock.
(Spark knock is a metallic rapping noise.)
If severe, this can lead to engine damage.
If you detect a persistent heavy spark
knock even when using gasoline of the
stated octane rating, or if you hear steady
spark knock while holding a steady speed
on level roads, have an INFINITI retailer
correct the condition. Failure to correct the
condition is misuse of the vehicle, for
which INFINITI is not responsible.

Incorrect ignition timing will result in
knocking, after-run or overheating. This in
turn may cause excessive fuel consumption
or damage to the engine. If any of the

Technical and consumer information

9-5

Condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti G Sedan (2013 year). Manual - part 28
