TOWING RECOMMENDED BY INFINITI

Two-Wheel Drive (2WD) models

INFINITI recommends that your vehicle be towed
with the driving (rear) wheels off the ground or
place the vehicle on a flat bed truck as illus-
trated.

CAUTION

● Never tow automatic transmission models

with the rear wheels on the ground or four
wheels on the ground (forward or backward),
as this may cause serious and expensive
damage to the transmission. If it is neces-
sary to tow the vehicle with the front wheels
raised, always use towing dollies under the
rear wheels.

● When towing rear wheel drive models with

the front wheels on the ground or on towing
dollies: Push the ignition switch to the ACC
or ON position, and secure the steering
wheel in a straight-ahead position with a
rope or similar device. Never secure the
steering wheel by selecting the LOCK posi-
tion. This may damage the steering lock
mechanism.

Two-wheel drive models

SCE0788

In case of emergency

6-13

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Intelligent All-Wheel Drive (AWD)
models

INFINITI recommends that towing dollies be
used when towing your vehicle or the vehicle be
placed on a flat bed truck as illustrated.

CAUTION

Never tow Intelligent AWD models with any of
the wheels on the ground as this may cause
serious

and

expensive

damage

the

powertrain.

All-wheel drive models

SCE0488

SCE0885

6-14

In case of emergency

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

VEHICLE RECOVERY (freeing a stuck
vehicle)

WARNING

● Stand clear of a stuck vehicle.
● Do not spin your tires at high speed. This

could cause them to explode and result in
serious injury. Parts of your vehicle could
also overheat and be damaged.

Pulling a stuck vehicle

If your vehicle is stuck in sand, snow, mud, etc.,
use a tow strap or other device designed spe-
cifically for vehicle recovery. Always follow the
manufacturer’s instructions for the recovery de-
vice.

Front:

1. Remove the cover with a suitable tool.

2. Securely install the vehicle recovery hook

䊊

stored with jacking tools as illustrated.

Attach the tow strap to the recovery hook.

Make sure that the hook is properly secured
in the original place after use.

Rear :

Do not use the tie down hook

䊊

for towing or

vehicle recovery.

CAUTION

● Tow chains or cables must be attached only

to the vehicle recovery hooks or main struc-
tural members of the vehicle. Otherwise, the
vehicle body will be damaged.

● Do not use the vehicle tie downs to free a

vehicle stuck in sand, snow, mud, etc.

● Never tow a vehicle using the vehicle tie

downs or recovery hooks.

● Always pull the cable straight out from the

front of the vehicle. Never pull on the vehicle
at an angle.

● Pulling devices should be routed so they do

not touch any part of the suspension, steer-
ing, brake or cooling systems.

● Pulling devices such as ropes or canvas

straps are not recommended for use in ve-
hicle towing or recovery.

Rocking a stuck vehicle

If your vehicle is stuck in sand, snow, mud, etc.,
use the following procedure:

1. Turn off the Vehicle Dynamic Control (VDC)

system.

2. Make sure the area in front and behind

the vehicle is clear of obstructions.

3. Turn the steering wheel right and left to

clear an area around the front tires.

4. Slowly rock the vehicle forward and back-

ward.

● Shift back and forth between R (reverse)

and D (drive).

● Apply the accelerator as little as possible

to maintain the rocking motion.

● Release the accelerator pedal before

shifting between R and D.

● Do not spin the tires above 35 MPH

(55 km/h).

5. If the vehicle cannot be freed after a few

tries, contact a professional towing ser-
vice to remove the vehicle.

In case of emergency

6-15

췽

—

—
01/13/10—tbrooks

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In order to maintain the appearance of your
vehicle, it is important to take proper care of it.

To protect the paint surface, wash your vehicle
as soon as you can:

● after a rainfall to prevent possible damage

from acid rain

● after driving on coastal roads
● when contaminants such as soot, bird drop-

pings, tree sap, metal particles or bugs get
on the paint surface

● when dust or mud builds up on the surface

Whenever possible, store or park your vehicle
inside a garage or in a covered area.

When it is necessary to park outside, park in a
shady area or protect the vehicle with a body
cover.

Be careful not to scratch the paint surface when
putting on or removing the body cover.

WASHING

Wash dirt off the vehicle with a wet sponge and
plenty of water. Clean the vehicle thoroughly
using a mild soap, a special vehicle soap or
general purpose dishwashing liquid mixed with
clean, lukewarm (never hot) water.

CAUTION

● Do not use car washes that use acid in the

detergent. Some car washes, especially
brushless ones, use some acid for cleaning.
The acid may react with some plastic vehicle
components, causing them to crack. This
could affect their appearance, and also could
cause them not to function properly. Always
check with your car wash to confirm that acid
is not used.

● Do not wash the vehicle with strong house-

hold soap, strong chemical detergents,
gasoline or solvents.

● Do not wash the vehicle in direct sunlight or

while the vehicle body is hot, as the surface
may become water-spotted.

● Avoid using tight-napped or rough cloths,

such as washing mitts. Care must be taken
when removing caked-on dirt or other for-
eign substances so the paint surface is not
scratched or damaged.

Rinse the vehicle again with plenty of clean
water.

Inside flanges, seams and folds on the doors,
hatches and hood are particularly vulnerable to
the effects of road salt. Therefore, these areas
must be regularly cleaned. Make sure that the

drain holes in the lower edge of the door are
open. Spray water under the body and in the
wheel wells to loosen the dirt and wash away
road salt.

Avoid leaving water spots on the paint surface
by using a damp chamois to dry the vehicle.

WAXING

Regular waxing protects the paint surface and
helps retain new vehicle appearance. Polishing
is recommended to remove built-up wax residue
and to avoid a weathered appearance before
reapplying wax.

An INFINITI retailer can assist you in choosing
the proper product.

● Wax your vehicle only after a thorough wash-

ing. Follow the instructions supplied with
the wax.

● Do not use a wax containing any abrasives,

cutting compounds or cleaners that may
damage the vehicle finish.

Machine compound or aggressive polishing on
a base coat/clear coat paint finish may dull the
finish or leave swirl marks.

CLEANING EXTERIOR

7-2

Appearance and care

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

REMOVING SPOTS

Remove tar and oil spots, industrial dust, in-
sects, and tree sap as quickly as possible from
the paint surface to avoid lasting damage or
staining. Special cleaning products are avail-
able at an INFINITI retailer or any automotive
accessory stores.

UNDERBODY

In areas where road salt is used in winter, the
underbody must be cleaned regularly. This will
prevent dirt and salt from building up and
causing the acceleration of corrosion on the
underbody and suspension. Before the winter
period and again in the spring, the underseal
must be checked and, if necessary, re-treated.

GLASS

Use glass cleaner to remove smoke and dust
film from the glass surfaces. It is normal for
glass to become coated with a film after the
vehicle is parked in the hot sun. Glass cleaner
and a soft cloth will easily remove this film.

CAUTION

When cleaning the inside of the windows, do
not use sharp-edged tools, abrasive cleaners or
chlorine-based disinfectant cleaners. They
could damage the electrical conductors, radio
antenna elements or rear window defroster
elements.

WHEELS

Wash the wheels when washing the vehicle to
maintain their appearance.

● Clean the inner side of the wheels when the

wheel is changed or the underside of the
vehicle is washed.

● Inspect wheel rims regularly for dents or

corrosion. Such damage may cause loss of
pressure or poor seal at the tire bead.

● INFINITI recommends that the road wheels

be waxed to protect against road salt in
areas where it is used during winter.

CAUTION

Do not use abrasive cleaners when washing the
wheels.

Aluminum alloy wheels

Wash regularly with a sponge dampened in a
mild soap solution, especially during winter
months in areas where road salt is used. Salt
could discolor the wheels if not removed.

CAUTION

Follow the directions below to avoid staining or
discoloring the wheels:

● Do not use a cleaner that uses strong acid or

alkali contents to clean the wheels.

● Do not apply wheel cleaners to the wheels

when they are hot. The wheel temperature
should be the same as ambient temperature.

● Rinse the wheel to completely remove the

cleaner within 15 minutes after the cleaner is
applied.

CHROME PARTS

Clean chrome parts regularly with a non- abra-
sive chrome polish to maintain the finish.

Appearance and care

7-3

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

TIRE DRESSING

INFINITI does not recommend the use of tire
dressings. Tire manufacturers apply a coating
to the tires to help reduce discoloration of the
rubber. If a tire dressing is applied to the tires,
it may react with the coating and form a com-
pound. This compound may come off the tire
while driving and stain the vehicle paint.

If you choose to use a tire dressing, take the
following precautions:

● Use a water-based tire dressing. The coating

on the tire dissolves more easily with an
oil-based tire dressing.

● Apply a light coat of tire dressing to help

prevent

from

entering

the

tire

tread/grooves (where it would be difficult to
remove).

● Wipe off excess tire dressing using a dry

towel. Make sure the tire dressing is com-
pletely removed from the tire tread/grooves.

● Allow the tire dressing to dry as recom-

mended by tire dressing manufacturer.

Occasionally remove loose dust from the inte-
rior trim, plastic parts and seats using a vacuum
cleaner or soft bristled brush. Wipe the vinyl
and leather surfaces with a clean, soft cloth
dampened in mild soap solution, then wipe
clean with a dry soft cloth.

Regular care and cleaning is required in order to
maintain the appearance of the leather.

Before using any fabric protector, read the
manufacturer’s recommendations. Some fabric
protectors contain chemicals that may stain or
bleach the seat material.

Use a cloth dampened only with water, to clean
the meter and gauge lens.

WARNING

Do not use water or acidic cleaners (hot steam
cleaners) on the seat. This can damage the seat
or occupant classification sensors. This can
also affect the operation of the air bag system
and result in serious personal injury.

CAUTION

● Never use benzine, thinner, or any similar

material.

● Small dirt particles can be abrasive and dam-

aging to the leather surfaces and should be
removed promptly. Do not use saddle soap,
car waxes, polishes, oils, cleaning fluids,
solvents, detergents or ammonia-based
cleaners as they may damage the leather’s
natural finish.

● Only use fabric protectors approved by

INFINITI.

● Do not use glass or plastic cleaner on meter

or gauge lens covers. It may damage the lens
cover.

AIR FRESHENERS

Most air fresheners use a solvent that could
affect the vehicle interior. If you use an air
freshener, take the following precautions:

● Hanging-type air fresheners can cause per-

manent discoloration when they contact ve-
hicle interior surfaces. Place the air fresh-
ener in a location that allows it to hang free
and not contact an interior surface.

● Liquid-type air fresheners typically clip on

the vents. These products can cause imme-
diate

damage

and

discoloration

when

spilled on interior surfaces.

CLEANING INTERIOR

7-4

Appearance and care

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Carefully read and follow the manufacturer’s
instructions before using air fresheners.

MOONROOF SUNSHADE (if so
equipped)

The moonroof sunshade is made from a suede
material.

Clean the sunshade material as follows:

CAUTION

To help prevent damaging the sunshade while
cleaning:
● Do not rub the material with a cloth. Doing so

can damage the surface of the material or
cause a stain to spread.

● Never use benzine, thinner or any similar

chemical to clean the suede. This may dis-
color the sunshade and damage the surface.

● Clean water based stains by patting the sur-

face with a clean soft cloth dampened in
warm water. Press a clean dry cloth onto the
surface to remove as much dampness as
possible and then let air dry.

● Clean oil based stains by patting the surface

with a clean soft cloth dampened in warm
water. Press a clean dry cloth onto the sur-
face to remove as much dampness as pos-
sible and then let air dry.

WARNING

To avoid potential pedal interference that may
result in a collision or injury:

● NEVER place a floor mat on top of another

floor mat in the driver front position.

● Use only NISSAN Genuine Floor Mats specifi-

cally designed for use in your vehicle model.
See your NISSAN dealer.

● Properly position the mats in the floorwell

using the floor mat positioning aid. See
“Floor mat positioning aid” in this section.

FLOOR MATS

The use of INFINITI floor mats can extend the life
of your vehicle carpet and make it easier to
clean the interior. Mats should be maintained
with regular cleaning and replaced if they be-
come excessively worn.

Floor mat positioning aid

This model includes front floor mat brackets to
act as floor mat positioning aid. INFINITI floor
mats have been specially designed for your
vehicle model. The front floor mats have grom-
met holes in them. To install, simply position
the mat by placing the floor mat bracket
through the floor mat grommet hole while cen-
tering the mat in the floor pan contour.
Periodically check to make certain that the mats
are properly positioned.

Front (example)

SAI0050

Appearance and care

7-5

췽

—

—
03/10/10—tbrooks

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The illustration shows the location of the floor
mat brackets.

SEAT BELTS

The seat belts can be cleaned by wiping them
with a sponge dampened in a mild soap solu-
tion. Allow the belts to dry completely before
using them.

See “SEAT BELTS” in the “1. Safety — Seats,
seat belts and supplemental restraint system”
section.

WARNING

Do not allow wet seat belts to roll up in the
retractor. NEVER use bleach, dye, or chemical
solvents to clean the seat belts, since these
materials may severely weaken the seat belt
webbing.

MOST COMMON FACTORS
CONTRIBUTING TO VEHICLE
CORROSION

● The accumulation of moisture-retaining dirt

and debris in body panel sections, cavities,
and other areas.

● Damage to paint and other protective coat-

ings caused by gravel and stone chips or
minor traffic accidents.

ENVIRONMENTAL FACTORS INFLUENCE
THE RATE OF CORROSION

Moisture

Accumulation of sand, dirt and water on the
vehicle body underside can accelerate corro-
sion. Wet floor coverings will not dry completely
inside the vehicle, and should be removed for
drying to avoid floor panel corrosion.

Relative humidity

Corrosion will be accelerated in areas of high
relative humidity, especially those areas where
the temperatures stay above freezing where
atmospheric pollution exists, or where road salt
is used.

Bracket positions

SAI0051

CORROSION PROTECTION

7-6

Appearance and care

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Temperature

A temperature increase will accelerate the rate
of corrosion to those parts which are not well
ventilated.

Air pollution

Industrial pollution, the presence of salt in the
air in coastal areas, or heavy road salt use will
accelerate the corrosion process. Road salt will
also accelerate the disintegration of paint sur-
faces.

TO PROTECT YOUR VEHICLE FROM
CORROSION

● Wash and wax your vehicle often to keep the

vehicle clean.

● Always check for minor damage to the paint

and repair it as soon as possible.

● Keep drain holes at the bottom of the doors

open to avoid water accumulation.

● Check the underbody for accumulation of

sand, dirt or salt. If present, wash with water
as soon as possible.

CAUTION

● NEVER remove dirt, sand or other debris from

the passenger compartment by washing it
out with a hose. Remove dirt with a vacuum
cleaner.

● Never allow water or other liquids to come in

contact with electronic components inside
the vehicle as this may damage them.

Chemicals used for road surface deicing are
extremely corrosive. They accelerate corrosion
and deterioration of underbody components
such as the exhaust system, fuel and brake
lines, brake cables, floor pan and fenders.

In winter, the underbody must be cleaned peri-
odically.

For additional protection against rust and cor-
rosion, which may be required in some areas,
consult an INFINITI retailer.

Appearance and care

7-7

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Your new INFINITI has been designed to have
minimum maintenance requirements with long
service intervals to save you both time and
money. However, some day-to-day and regular
maintenance is essential to maintain your IN-
FINITI’s fine mechanical condition, as well as its
emission and engine performance.

It is the owner’s responsibility to make sure that
the scheduled maintenance, as well as general
maintenance, is performed.

As the vehicle owner, you are the only one who
can ensure that your vehicle receives the proper
maintenance care. You are a vital link in the
maintenance chain.

SCHEDULED MAINTENANCE

For your convenience, both required and op-
tional scheduled maintenance items are de-
scribed and listed in your “INFINITI Service and
Maintenance Guide”. You must refer to that
guide to ensure that necessary maintenance is
performed on your INFINITI at regular intervals.

GENERAL MAINTENANCE

General maintenance includes those items
which should be checked during normal day-to-
day operation. They are essential for proper

vehicle operation. It is your responsibility to
perform these procedures regularly as pre-
scribed.

Performing general maintenance checks re-
quires minimal mechanical skill and only a few
general automotive tools.

These checks or inspections can be done by
yourself, a qualified technician or, if you prefer,
an INFINITI retailer.

WHERE TO GO FOR SERVICE

If maintenance service is required or your ve-
hicle appears to malfunction, have the systems
checked and serviced by an INFINITI retailer.

INFINITI technicians are well-trained specialists
and are kept up to date with the latest service
information through technical bulletins, service
tips, and in-retailership information systems.
They are completely qualified to work on
INFINITI vehicles

before work begins.

You can be confident that an INFINITI retailer’s
service department performs the best job to
meet the maintenance requirements on your
vehicle — in a reliable and economical way.

During the normal day-to-day operation of the
vehicle, general maintenance should be per-
formed regularly as prescribed in this section. If
you detect any unusual sounds, vibrations or
smell, be sure to check for the cause or have an
INFINITI retailer do it promptly. In addition, you
should notify an INFINITI retailer if you think
that repairs are required.

When performing any checks or maintenance
work, see “MAINTENANCE PRECAUTIONS” later
in this section.

EXPLANATION OF MAINTENANCE
ITEMS

Additional information on the following items
with “*” is found later in this section.

Outside the vehicle

The maintenance items listed here should be
performed from time to time, unless otherwise
specified.

Doors and engine hood: Check that all doors
and the engine hood, operate properly. Also
ensure that all latches lock securely. Lubricate
hinges, latches, latch pins, rollers and links if
necessary. Make sure that the secondary latch
keeps the hood from opening when the primary
latch is released.

MAINTENANCE REQUIREMENT

GENERAL MAINTENANCE

8-2

Maintenance and do-it-yourself

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When driving in areas using road salt or other
corrosive

materials,

check

lubrication

fre-

quently.

Lights*: Clean the headlights on a regular
basis. Make sure that the headlights, stop
lights, tail lights, turn signal lights, and other
lights are all operating properly and installed
securely. Also check headlight aim.

Road wheel nuts (lug nuts)*: When checking the
tires, make sure no wheel nuts are missing, and
check for any loose wheel nuts. Tighten if
necessary.

Tire rotation*: Tires should be rotated every
7,500 miles (12,000 km). If your vehicle is
equipped with different sized tires in the front
and rear, tires cannot be rotated.

Tires*: Check the pressure with a gauge often
and always prior to long distance trips. If nec-
essary, adjust the pressure in all tires, includ-
ing the spare, to the pressure specified. Check
carefully for damage, cuts or excessive wear.

Tire Pressure Monitoring System (TPMS) trans-
mitter components: Replace the TPMS transmit-
ter grommet seal, valve core and cap when the
tires are replaced due to wear or age.

Tire, wheel alignment and balance: If the vehicle
should pull to either side while driving on a

straight and level road, or if you detect uneven
or abnormal tire wear, there may be a need for
wheel alignment.

If the steering wheel or seat vibrates at normal
highway speeds, wheel balancing may be
needed.

For additional information regarding tires, refer
to “Important Tire Safety Information” (US) or
“Tire Safety Information” (Canada) in the
INFINITI Warranty Information Booklet.

Windshield: Clean the windshield on a regular
basis. Check the windshield at least every six
months for cracks or other damage. Have a
damaged windshield repaired by a qualified
repair facility.

Windshield wiper blades*: Check for cracks or
wear if they do not wipe properly.

Inside the vehicle

The maintenance items listed here should be
checked on a regular basis, such as when
performing periodic maintenance, cleaning the
vehicle, etc.

Accelerator pedal: Check the pedal for smooth
operation and make sure the pedal does not
catch or require uneven effort. Keep the floor
mat away from the pedal.

Automatic transmission P (Park) mechanism: On
a fairly steep hill, check that your vehicle is held
securely with the selector lever in the P (Park)
position without applying any brakes.

Brake pedal: Check the pedal for smooth opera-
tion. If the brake pedal suddenly goes down
further than normal, the pedal feels spongy or
the vehicle seems to take longer to stop, see an
INFINITI retailer immediately. Keep the floor mat
away from the pedal.

Brakes: Check that the brakes do not pull the
vehicle to one side when applied.

Parking brake: Check the parking brake opera-
tion regularly. The vehicle should be securely
held on a fairly steep hill with only the parking
brake applied. If the parking brake needs ad-
justed, see an INFINITI retailer.

Seat belts: Check that all parts of the seat belt
system (for example, buckles, anchors, adjuster
and retractors) operate properly and smoothly,
and are installed securely. Check the belt web-
bing for cuts, fraying, wear or damage.

Seats: Check seat position controls such as
seat adjusters, seatback recliner, etc. to ensure
they operate smoothly and that all latches lock
securely in every position. Check that the head

Maintenance and do-it-yourself

8-3

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

restraints move up and down smoothly and that
the locks (if so equipped) hold securely in all
latched positions.

Steering wheel: Check for changes in the steer-
ing conditions, such as excessive free play,
hard steering or strange noises.

Warning lights and chimes: Make sure that all
warning lights and chimes are operating prop-
erly.

Windshield defroster: Check that the air comes
out of the defroster outlets properly and in
sufficient quantity when operating the heater or
air conditioner.

Windshield wiper and washer*: Check that the
wipers and washer operate properly and that
the wipers do not streak.

Under the hood and vehicle

The maintenance items listed here should be
checked periodically (for example, each time
you check the engine oil or refuel).

Battery*: Check the fluid level in each cell. It
should be between the MAX and MIN lines.
Vehicles operated in high temperatures or un-
der severe condition require frequent checks of
the battery fluid level.

Brake fluid level*: Make sure that the brake
fluid level is between the MAX and MIN lines on
the reservoir.

Engine coolant level*: Check the coolant level
when the engine is cold.

Engine drive belts*: Make sure that no belt is
frayed, worn, cracked or oily.

Engine oil level*: Check the level after parking
the vehicle on a level spot and turning off the
engine. Wait more than 15 minutes for the oil to
drain back into the oil pan.

Exhaust system: Make sure there are no loose
supports, cracks or holes. If the sound of the
exhaust seems unusual or there is a smell of
exhaust fumes, immediately have the exhaust
system inspected by an INFINITI retailer. (See
“PRECAUTIONS WHEN STARTING AND DRIVING”
in the “5. Starting and driving” section for
exhaust gas (Carbon monoxide).)

Fluid leaks: Check under the vehicle for fuel, oil,
water or other fluid leaks after the vehicle has
been parked for a while. Water dripping from
the air conditioner after use is normal. If you
should notice any leaks or if gasoline fumes are
evident, check for the cause and have it cor-
rected immediately.

Power steering fluid level* and lines: Check the
level when the fluid is cold, with the engine off.
Check the lines for proper attachment, leaks,
cracks, etc.

Radiator and hoses: Check the front of the
radiator and clean off any dirt, insects, leaves,
etc., that may have accumulated. Make sure the
hoses have no cracks, deformation, rot or loose
connections.

Underbody: The underbody is frequently ex-
posed to corrosive substances such as those
used on icy roads or to control dust. It is very
important to remove these substances, other-
wise rust will form on the floor pan, frame, fuel
lines and around the exhaust system. At the
end of winter, the underbody should be thor-
oughly flushed with plain water, being careful
to clean those areas where mud and dirt may
accumulate. For additional information, see
“CLEANING EXTERIOR” in the “7. Appearance
and care” section.

Windshield washer fluid*: Check that there is
adequate fluid in the reservoir.

8-4

Maintenance and do-it-yourself

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When performing any inspection or mainte-
nance work on your vehicle, always take care to
prevent serious accidental injury to yourself or
damage to the vehicle. The following are gen-
eral precautions which should be closely ob-
served.

WARNING

● Park the vehicle on a level surface, apply the

parking brake securely and block the wheels
to prevent the vehicle from moving. Move
the selector lever to P (Park).

● Be sure the ignition switch is in the OFF or

LOCK position when performing any parts
replacement or repairs.

● Never connect or disconnect the battery or

any transistorized component while the ig-
nition switch is in the ON position.

● Never leave the engine or automatic trans-

mission related component harnesses dis-
connected while the ignition switch is in the
ON position.

● If you must work with the engine running,

keep your hands, clothing, hair and tools
away from moving fans, belts and any other
moving parts.

● It is advisable to secure or remove any loose

clothing and remove any jewelry, such as
rings, watches, etc. before working on your
vehicle.

● Always wear eye protection whenever you

work on your vehicle.

● If you must run the engine in an enclosed

space such as a garage, be sure there is
proper ventilation for exhaust gases to
escape.

● Never get under the vehicle while it is sup-

ported only by a jack. If it is necessary to
work under the vehicle, support it with
safety stands.

● Keep smoking materials, flame and sparks

away from fuel tank and the battery.

● Your vehicle is equipped with an automatic

engine cooling fan. It may come on at any
time without warning, even if the ignition
key is in the OFF position and the engine is
not running. To avoid injury, always discon-
nect the negative battery cable before work-
ing near the fan.

● The fuel filter or fuel lines should be serviced

by an INFINITI retailer because the fuel lines
are under high pressure even when the en-
gine is off.

CAUTION

● Do not work under the hood while the engine

is hot. Turn the engine off and wait until it
cools down.

● Avoid direct contact with used engine oil and

coolant. Improperly disposed engine oil,
coolant, and/or other vehicle fluids can dam-
age the environment. Always conform to lo-
cal regulations for disposal of vehicle fluid.

This “8. Maintenance and do-it-yourself” sec-
tion gives instructions regarding only those
items which are relatively easy for an owner to
perform.

A genuine INFINITI Service Manual is also avail-
able.

(See

“OWNER’S

MANUAL/SERVICE

MANUAL ORDER INFORMATION” in the “9. Tech-
nical and consumer information” section.)

You should be aware that incomplete or im-
proper servicing may result in operating diffi-
culties or excessive emissions, and could affect
your warranty coverage.

If in doubt about any

servicing, we recommend that it be done by an
INFINITI retailer.

MAINTENANCE PRECAUTIONS

Maintenance and do-it-yourself

8-5

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

VK56VD ENGINE

To remove the engine compartment cover, un-
hook the clips

䊊

located as illustrated. Loosen

the bolts

䊊

and then pull the cover upward.

SDI2569

ENGINE COMPARTMENT CHECK
LOCATIONS

8-6

Maintenance and do-it-yourself

췽

—

—
01/13/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti M37 (2011 year). Manual - part 26
