1. Push and hold the desired HomeLink

姞

button.

Do not release the button until

step 4 has been completed.

2. When the indicator light begins to flash

slowly (after 20 seconds), position the
hand-held transmitter 2 to 5 in (50 to 127
mm) away from the HomeLink

姞 surface.

3. Push and hold the hand-held transmitter

button.

4. The HomeLink

姞 indicator light will flash,

first slowly and then rapidly. When the
indicator light begins to flash rapidly,
release both buttons.

The HomeLink

姞 Universal Transceiver button

has now been reprogrammed. The new device
can be activated by pushing the HomeLink

姞

button that was just programmed. This proce-
dure will not affect any other programmed
HomeLink

姞 buttons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change the
codes of any non-rolling code device that has
been programmed into HomeLink

姞. Consult the

Owner’s Manual of each device or call the
manufacturer or retailer of those devices for
additional information.

When your vehicle is recovered, you will need to
reprogram the HomeLink

姞 Universal Transceiver

with your new transmitter information.

FCC Notice:

This device complies with Part 15 of FCC Rules
and RSS-Gen of IC Rules. Operation is subject to
the following two conditions: (1) this device may
not cause interference, and (2) this device must
accept any interference, including interference
that may cause undesired operation of this de-
vice.

2-60

Instruments and controls

췽

—

—
07/15/10—tbrooks

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

A key number plate is supplied with your keys.
Record the key number and keep it in a safe
place (such as your wallet), not in the vehicle. If
you lose your keys, see an INFINITI retailer for
duplicates by using the key number. INFINITI
does not record any key numbers so it is very
important to keep track of your key number
plate.

A key number is only necessary when you have
lost all keys and do not have one to duplicate
from. If you still have a key, this key can be
duplicated by an INFINITI retailer.

1. Intelligent Keys (2 sets)

2. Mechanical keys (inside the Keys) (2 sets)

3. Key number plate (1 set)

INTELLIGENT KEY

Your vehicle can only be driven with the Intelli-
gent Keys which are registered to your vehicle’s
Intelligent Key system components and INFINITI
Vehicle Immobilizer System components. As
many as 4 Intelligent Keys can be registered
and used with one vehicle. The new keys must
be registered by an INFINITI retailer prior to use
with the Intelligent Key system and INFINITI
Vehicle Immobilizer System of your vehicle.
Since the registration process requires erasing
all memory in the Intelligent Key components

when registering new keys, be sure to take all
Intelligent Keys that you have to the INFINITI
retailer.

It is possible that the Intelligent Key functions
become canceled. Contact an INFINITI retailer.

CAUTION

● Be sure to carry the Intelligent Key with you

when driving. The Intelligent Key is a preci-
sion device with a built-in transmitter. To
avoid

damaging

it,

please

note

the

following.

– The Intelligent Key is water resistant;

however, wetting may damage the Intelli-
gent Key. If the Intelligent Key gets wet,
immediately wipe until it is completely
dry.

– Do not bend, drop or strike it against an-

other object.

– Do not place the Intelligent Key for an

extended period in a place where tem-
peratures exceed 140°F (60°C).

– Do not change or modify the Intelligent

Key.

– Do not use a magnet key holder.

SPA2222

KEYS

3-2

Pre-driving checks and adjustments

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

– Do not place the Intelligent Key near an

electric appliance such as a television set
or personal computer.

– Do not allow the Intelligent Key to come

into contact with water or salt water, and
do not wash it in a washing machine. This
could affect the system function.

● If an Intelligent Key is lost or stolen, INFINITI

recommends erasing the ID code of that In-
telligent Key. This will prevent the Intelli-
gent Key from unauthorized use to unlock
the vehicle. For information regarding the
erasing

procedure,

please

contact

INFINITI retailer.

Mechanical key

To remove the mechanical key, release the lock
knob at the back of the Intelligent Key.

To install the mechanical key, firmly insert it
into the Intelligent Key until the lock knob
returns to the lock position.

Use the mechanical key to lock or unlock the
doors, glove box and trunk pass-through lid, if
they are equipped with a key cylinder.

See “DOORS” later in this section and “TRUNK
LID” later in this section, “STORAGE” in the “2.
Instruments and controls” section and “SEATS”
in the “1. Safety — Seats, seat belts and supple-
mental restraint system” section.

CAUTION

Always carry the mechanical key installed in
the key.

VALET HAND-OFF

When you have to leave a key with a valet, give
them the Intelligent Key itself and keep the
mechanical key with you to protect your belong-
ings.

To prevent the glove box and the trunk from
being opened during valet hand-off, follow the
procedures below.

1. Push the trunk release power cancel

switch to the CANCEL side.

2. Remove the mechanical key from the In-

telligent Key.

3. Lock the glove box and the trunk pass-

through with the mechanical key.

4. Hand the Intelligent Key to the valet,

keeping the mechanical key in your
pocket or bag for insertion into the Intel-
ligent Key when you retrieve your vehicle.

See “TRUNK LID” later in this section, “STOR-
AGE” in the “2. Instruments and controls” sec-
tion and “SEATS” in the “1. Safety — Seats, seat
belts and supplemental restraint system” sec-
tion.

SPA2033

Pre-driving checks and adjustments

3-3

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

● Always have the doors locked while driving.

Along with the use of seat belts, this pro-
vides greater safety in the event of an acci-
dent by helping to prevent persons from be-
ing thrown from the vehicle. This also helps
keep children and others from unintention-
ally opening the doors, and will help keep
out intruders.

● Before opening any door, always look for and

avoid oncoming traffic.

● Do not leave children unattended inside the

vehicle. They could unknowingly activate
switches or controls. Unattended children
could become involved in serious accidents.

LOCKING WITH MECHANICAL KEY

The power door lock system allows you to lock
or unlock all doors simultaneously using the
mechanical key.

● Turning the driver’s door key cylinder to the

front of the vehicle

䊊

will lock all doors.

● Turning the driver’s door key cylinder once

to the rear of the vehicle

䊊

will unlock the

driver’s door. After returning the key to the
neutral position

䊊

, turning it to the rear

again within 60 seconds will unlock all
doors.

● You can switch the lock system to the mode

that allows you to open all the doors when
the key is turned once. (See “HOW TO USE
SETTING BUTTON” in the “4. Monitor, cli-
mate, audio, phone and voice recognition
systems” section.)

OPENING AND CLOSING WINDOWS
WITH THE MECHANICAL KEY

The driver’s door key operation also allows you
to open and close the window that is equipped
with the automatic open/close function. (See
“POWER WINDOWS” in the “2. Instruments and
controls” section).

To open the window, turn the driver’s door key
cylinder to the rear of the vehicle for

longer than

1 second . The door is unlocked and the window
keeps opening while turning the key.

This function can also be performed by pushing
and holding the door UNLOCK button of the
Intelligent Key. (See “REMOTE KEYLESS ENTRY
SYSTEM” later in this section.)

To close the window, turn the driver’s door key
cylinder to the front of the vehicle for

longer

than 1 second . The door is locked and the
window keeps closing while turning the key.

SPA2527

DOORS

3-4

Pre-driving checks and adjustments

췽

—

—
01/13/10—tbrooks

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKING WITH INSIDE LOCK KNOB

To lock the door individually, move the inside
lock knob to the lock position

䊊

then close the

door.

To unlock, move the inside lock knob to the
unlock position

䊊

When locking the door without an Intelligent
Key, be sure not to leave the Intelligent Key
inside the vehicle.

LOCKING WITH POWER DOOR LOCK
SWITCH

Operating the power door lock switch will lock
or unlock all the doors. The switches are lo-
cated on the driver’s and front passenger’s door
armrests.

To lock the doors, push the power door lock
switch to the lock position

䊊

with the driver’s

or front passenger’s door open, then close the
door.

When locking the door this way, be certain not to
leave the Intelligent Key inside the vehicle.

To unlock the doors including the fuel-filler
door, push the power door lock switch to the
unlock position

䊊

Lockout protection

When the power door lock switch is moved to
the lock position and any door open, all doors
will lock and unlock automatically. With the
Intelligent Key left in the vehicle and any door
open, all doors will unlock automatically and a
chime will sound after the door is closed.

These functions help to prevent the Intelligent
Key from being accidentally locked inside the
vehicle.

AUTOMATIC DOOR LOCKS

● All doors lock automatically when the ve-

hicle speed reaches 15 MPH (24 km/h).

● All doors unlock automatically when the

ignition switch is placed in the OFF position.

The automatic unlock function can be deacti-
vated or activated. To deactivate or activate the
automatic door unlock system, perform the
following procedure:

1. Close all doors.

2. Place the ignition switch in the ON posi-

tion.

3. Within 20 seconds of performing Step 2,

push and hold the power door lock switch

to the

position (UNLOCK) for more

than 5 seconds.

SPA2726

SPA2727

Pre-driving checks and adjustments

3-5

췽

—

—
03/02/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4. When activated, the hazard indicator will

flash twice. When deactivated, the hazard
indicator will flash once.

5. The ignition switch must be placed in the

OFF and ON position again between each
setting change.

When the automatic door unlock system is
deactivated, the doors do not unlock when the
ignition switch is placed in the OFF position. To
unlock the door manually, use the inside lock
knob or the power door lock switch (driver’s or
front passenger’s side).

CHILD SAFETY REAR DOOR LOCK

The child safety rear door lock helps prevent
doors from being opened accidentally, espe-
cially when small children are in the vehicle.

When the levers are in the lock position

䊊

, the

rear doors can be opened only from the outside.

To disengage, move the levers to the unlock
position

䊊

WARNING

● Radio waves could adversely affect electric

medical equipment. Those who use a pace-
maker should contact the electric medical
equipment manufacturer for the possible in-
fluences before use.

● The Intelligent Key transmits radio waves

when the buttons are pushed. The FAA ad-
vises that the radio waves may affect aircraft
navigation and communication systems. Do
not operate the Intelligent Key while on an
airplane. Make sure the buttons are not op-
erated unintentionally when the unit is
stored during a flight.

The Intelligent Key system can operate all the
doors and the trunk lid using the remote con-
troller function or pushing the request switch
on the vehicle without taking the key out from a
pocket or purse. The operating environment
and/or conditions may affect the Intelligent Key
system operation.

Be sure to read the following before using the
Intelligent Key system.

CAUTION

● Be sure to carry the Intelligent Key with you

when operating the vehicle.

SPA2728

INTELLIGENT KEY SYSTEM

3-6

Pre-driving checks and adjustments

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

● Never leave the Intelligent Key in the vehicle

when you leave the vehicle.

The Intelligent Key is always communicating
with the vehicle as it receives radio waves. The
Intelligent Key system transmits weak radio
waves. Environmental conditions may interfere
with the operation of the Intelligent Key system
under the following operating conditions.

● When operating near a location where strong

radio waves are transmitted, such as a TV
tower, power station and broadcasting sta-
tion.

● When in possession of wireless equipment,

such as a cellular telephone, transceiver,
and CB radio.

● When the Intelligent Key is in contact with or

covered by metallic materials.

● When any type of radio wave remote control

is used nearby.

● When the Intelligent Key is placed near an

electric appliance such as a personal com-
puter.

● When the vehicle is parked near a parking

meter.

In such cases, correct the operating conditions
before using the Intelligent Key function or use
the mechanical key.

Although the life of the battery varies depend-
ing on the operating conditions, the battery’s
life is approximately 2 years. If the battery is
discharged, replace it with a new one.

Since the Intelligent Key is continuously receiv-
ing radio waves, if the key is left near equip-
ment which transmits strong radio waves, such
as signals from a TV and personal computer, the
battery life may become shorter.

For information regarding replacement of a bat-
tery, see “INTELLIGENT KEY BATTERY REPLACE-
MENT” in the “8. Maintenance and do-it-
yourself” section.

Because the steering wheel is locked electri-
cally, unlocking the steering wheel with the
ignition switch in the LOCK position is impos-
sible when the vehicle battery is completely
discharged. Pay special attention that the ve-
hicle battery is not completely discharged.

As many as 4 Intelligent Keys can be registered
and used with one vehicle. For information
about the purchase and use of additional Intel-
ligent Keys, contact an INFINITI retailer.

CAUTION

● Do not allow the Intelligent Key, which con-

tains electrical components, to come into
contact with water or salt water. This could
affect the system function.

● Do not drop the Intelligent Key.
● Do not strike the Intelligent Key sharply

against another object.

● Do not change or modify the Intelligent Key.
● Wetting may damage the Intelligent Key. If

the Intelligent Key gets wet, immediately
wipe until it is completely dry.

● Do not place the Intelligent Key for an ex-

tended period in an area where tempera-
tures exceed 140°F (60°C).

● Do not attach the Intelligent Key with a key

holder that contains a magnet.

● Do not place the Intelligent Key near equip-

ment that produces a magnetic field, such as
a

TV,

audio

equipment

and

personal

computers.

Pre-driving checks and adjustments

3-7

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If an Intelligent Key is lost or stolen, INFINITI
recommends erasing the ID code of that Intelli-
gent Key from the vehicle. This may prevent the
unauthorized use of the Intelligent Key to oper-
ate the vehicle. For information regarding the
erasing procedure, contact an INFINITI retailer.

INTELLIGENT KEY OPERATING RANGE

The Intelligent Key functions can only be used
when the Intelligent Key is within the specified
operating range from the request switch

䊊

When the Intelligent Key battery is discharged
or strong radio waves are present near the
operating location, the Intelligent Key system’s

operating range becomes narrower, and the
Intelligent Key may not function properly.

The operating range is within 31.50 in (80 cm)
from each request switch

䊊

If the Intelligent Key is too close to the door
glass, handle or rear bumper the request
switches may not function.

When the Intelligent Key is within the operating
range, it is possible for anyone who does not
carry the Intelligent Key to push the request
switch to lock/unlock the doors and open the
trunk lid.

SPA2538

3-8

Pre-driving checks and adjustments

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DOOR LOCKS/UNLOCKS PRECAUTION

● Do not push the door handle request switch

with the Intelligent Key held in your hand as
illustrated. The close distance to the door
handle will cause the Intelligent Key system
to have difficulty recognizing that the Intel-
ligent Key is outside the vehicle.

● After locking with the door handle request

switch, verify the doors are securely locked
by testing them.

● To prevent the Intelligent Key from being left

inside the vehicle or the trunk, make sure
you carry the key with you and then lock the
doors or the trunk.

● Do not pull the door handle before pushing

the door handle request switch. The door
will be unlocked but will not open. Release
the door handle once and pull it again to
open the door.

● The Intelligent Key system (opening/closing

doors with the door handle request switch)
can be set to remain inactive. (See “VEHICLE
INFORMATION AND SETTINGS” in the “4.
Monitor, climate, audio, phone and voice
recognition systems” section.)

INTELLIGENT KEY OPERATION

You can lock or unlock the doors without taking
the key out from your pocket or bag.

SPA2407

SPA2729

Pre-driving checks and adjustments

3-9

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When you carry the Intelligent Key with you, you
can lock or unlock all doors by pushing the door
handle request switch (driver’s or front passen-
ger’s)

䊊

within the range of operation.

When you lock or unlock the doors or the trunk
lid, the hazard indicator will flash and the horn
(if so equipped) (or the outside chime) will
sound as a confirmation. For details, see “Set-
ting hazard indicator and horn mode” later in
this section.

Locking doors and fuel-filler door

1. Push the ignition switch to the OFF posi-

tion and make sure you carry the Intelli-
gent Key with you.*1

2. Close all the doors.*2

3. Push the door handle request switch

(driver’s or front passenger’s)

䊊

while

carrying the Intelligent Key with you.*3

4. All the doors and fuel-filler door will lock.

5. The hazard indicator flashes twice and the

outside chime sounds twice.

*1: Doors will lock with the Intelligent Key while

the ignition switch is in the ACC or ON
position.

*2: Doors will not lock with the Intelligent Key

while any door is open.

*3: Doors will not lock by pushing the door

handle request switch with the Intelligent
Key inside the vehicle. However, when an
Intelligent Key is inside the vehicle, doors
can be locked with another registered Intel-
ligent Key.

Unlocking doors and fuel-filler door

1. Push the door handle request switch (driv-

er’s or front passenger’s)

䊊

once while

carrying the Intelligent Key with you.

2. The hazard indicator flashes once and

outside chime sounds once. The corre-
sponding door and the fuel-filler door will
unlock.

The fuel-filler door will also unlock when the
driver’s door handle request switch is
pushed.

3. Push the door handle request switch

again within 1 minute.

4. The hazard indicator flashes once and

outside chime sounds once again. All the
doors will unlock.

All doors and the fuel-filler door will be locked
automatically unless one of the following opera-
tions is performed within 1 minute after pushing
the request switch while the doors are locked.

● Opening any door
● Pushing the ignition switch
During this 1-minute time period, if the UNLOCK

button on the Intelligent Key is pushed,

all doors will be locked automatically after
another 1 minute.

SPA2730

3-10

Pre-driving checks and adjustments

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening trunk lid

1. Push the trunk open request switch

䊊

for

more than 1 second.

2. The trunk will unlatch. An outside chime

will sound four times.

3. Raise the trunk lid to open the trunk.

Lockout protection :

To prevent the Intelligent Key from being acci-
dentally locked in the trunk, lockout protection
is equipped with the Intelligent Key system.

When the trunk lid is closed with the Intelligent
Key inside the trunk, the outside chime will
sound and the trunk will open.

BATTERY SAVER SYSTEM

When all the following conditions are met for 60
minutes, the battery saver system will cut off
the power supply to prevent battery discharge.

● The ignition switch is in the ACC position,

and

● All doors are closed, and
● The selector lever is in the P (Park) position.

WARNING SIGNALS

To help prevent the vehicle from moving unex-
pectedly by erroneous operation of the Intelli-
gent Key listed on the following chart or to help
prevent the vehicle from being stolen, chime or
beep sounds inside and outside the vehicle and
a warning displays in the dot matrix liquid
crystal display.

When a chime or beep sounds or the warning
displays, be sure to check the vehicle and
Intelligent Key.

See “TROUBLESHOOTING GUIDE” later in this
section and “DOT MATRIX LIQUID CRYSTAL DIS-
PLAY” in the “2. Instruments and controls”
section.

SPA2731

SPA2732

Pre-driving checks and adjustments

3-11

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

TROUBLESHOOTING GUIDE

Symptom

Possible cause

Action to take

When pushing the ignition switch to
stop the engine

The SHIFT P warning appears on the
display and the inside warning chime
sounds continuously.

The selector lever is not in the P
(Park) position.

Shift the selector lever to the P
(Park) position.

When opening the driver’s door to
get out of the vehicle

The inside warning chime sounds
continuously.

The ignition switch is in the ACC
position.

Push the ignition switch to the OFF
position.

When closing the door after getting
out of the vehicle

The NO KEY warning appears on the
display, the outside chime sounds 3
times and the inside warning chime
sounds for a few seconds.

The ignition switch is in the ACC or
ON position.

Push the ignition switch to the OFF
position.

The SHIFT P warning appears on the
display and the outside chime
sounds continuously.

The ignition switch is in the ACC or
OFF position and the selector lever is
not in the P (Park) position.

Move the selector lever to the P
(Park) position and push the ignition
switch to the OFF position.

When closing the door with the in-
side lock knob turned to LOCK

The outside chime sounds for a few
seconds and all the doors unlock.

The Intelligent Key is inside the ve-
hicle or trunk.

Carry the Intelligent Key with you.

When pushing the request switch or
LOCK button on the Intelligent Key
to lock the door

The outside chime sounds for a few
seconds.

The Intelligent Key is inside the ve-
hicle or trunk.

Carry the Intelligent Key with you.

A door is not closed securely.

Close the door securely.

When closing the trunk lid

The outside chime sounds for ap-
proximately 10 seconds and the
trunk lid opens.

The Intelligent Key is inside the
trunk.

Carry the Intelligent Key with you.

3-12

Pre-driving checks and adjustments

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

The Intelligent Key transmits radio waves when
the buttons are pushed. The FAA advises that
the radio waves may affect aircraft navigation
and communication systems. Do not operate
the Intelligent Key while on an airplane. Make
sure the buttons are not operated unintention-
ally when the unit is stored during a flight.

It is possible to lock/unlock all doors, fuel-filler
door, activate the panic alarm and open the
windows by pushing the buttons on the Intelli-
gent Key from outside the vehicle.

Before locking the doors, make sure the Intelli-
gent Key is not left in the vehicle.

The LOCK/UNLOCK button on the Intelligent Key
can operate at a distance of approximately 33 ft
(10 m) from the vehicle. (The effective distance
depends upon the conditions around the ve-
hicle.)
As many as 4 Intelligent Keys can be used with
one vehicle. For information concerning the
purchase and use of additional Intelligent Keys,
contact an INFINITI retailer.

The lock and unlock buttons on the Intelligent
Key will not operate when:

● the distance between the Intelligent Key and

the vehicle is over 33 ft (10 m).

● the Intelligent Key battery is discharged.
After locking with the remote keyless entry
function, pull the door handle to make sure the
doors are securely locked.

The LOCK/UNLOCK operating range varies de-
pending on the environment. To securely oper-
ate the lock and unlock buttons, approach the
vehicle to about 3 ft (1 m) from the door.

1. LOCK button

2. UNLOCK button

3. TRUNK button

4. PANIC button

HOW TO USE REMOTE KEYLESS ENTRY
SYSTEM

When you lock or unlock the doors or the trunk
lid, the hazard indicator will flash and the horn
(or the outside chime) will sound as a confirma-
tion. For details, see “Setting hazard indicator
and horn mode” later in this section.

SPA2100

REMOTE KEYLESS ENTRY SYSTEM

Pre-driving checks and adjustments

3-13

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking doors and fuel-filler door

1. Push the ignition switch to the OFF posi-

tion and make sure you carry the Intelli-
gent Key with you.*1

2. Close all the doors.*2

3. Push the LOCK

button

䊊

on the

Intelligent Key.

4. All the doors and fuel-filler door will lock.

5. The hazard indicator flashes twice and the

horn chirps once.

*1: Doors will lock with the Intelligent Key while

the ignition switch is in the ACC or ON
position.

*2: Doors will not lock with the Intelligent Key

while any door is open. Operate the door
handles to confirm that the doors have been
securely locked.

Unlocking doors and fuel-filler door

1. Push the UNLOCK

button

䊊

on the

Intelligent Key once.

2. The hazard indicator flashes once. The

driver’s door and fuel-filler door will un-
lock.

3. Push the UNLOCK

button on the

Intelligent Key again within 1 minute.

4. The hazard indicator flashes once again.

All the doors will unlock.

All doors will be locked automatically unless
one of the following operations is performed
within 1 minute after pushing the UNLOCK but-
ton on the Intelligent Key while the doors are
locked. If during this 1-minute time period, the
UNLOCK button on the Intelligent Key is
pushed, all doors will be locked automatically
after another 1 minute.

● Opening any door
● Pushing the ignition switch

Opening windows

The UNLOCK

button operation also al-

lows you to open the window that is equipped
with the automatic open/close function. (See
“POWER WINDOWS” in the “2. Instruments and
controls” section).

To open the window, push the door UNLOCK

button

䊊

on the Intelligent Key for

about 3 seconds after the door is unlocked.

To stop opening, release the UNLOCK
button.

If the window open operation is stopped in
mid-operation

while

pushing

the

UNLOCK

button, release and push the UNLOCK

button again until the window opens

completely.

Window cannot be closed using the Intelligent
Key.

The door window can also be operated by
turning the mechanical key in a door lock. (See
“DOORS” earlier in this section.)

Opening trunk lid

1. Push the TRUNK

button

䊊

on the

Intelligent Key for more than 1 second.

2. The trunk will unlatch.

3. Raise the trunk lid to open the trunk.

Using panic alarm

If you are near your vehicle and feel threatened,
you may activate the alarm to call attention as
follows:

1. Push the PANIC

button

䊊

on the

key for

more than 1 second.

2. The theft warning alarm and headlights

will stay on for 25 seconds.

3. The panic alarm stops when:

● It has run for 25 seconds, or

3-14

Pre-driving checks and adjustments

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

● Any of the buttons on the Intelligent Key

are pushed. (Note: Panic button should be
pushed for more than 1 second.)

Setting hazard indicator and horn
mode

This vehicle is set in hazard indicator and horn
mode when you first receive the vehicle.

In hazard indicator and horn mode, when the

LOCK

button

䊊

is pushed, the hazard

indicator flashes twice and the horn chirps

once. When the UNLOCK

button

䊊

pushed, the hazard indicator flashes once.

If horns are not necessary, the system can be
switched to the hazard indicator mode.

In hazard indicator mode, when the LOCK

button is pushed, the hazard indicator

flashes twice. When the UNLOCK

button

is pushed, neither the hazard indicator nor the
horn operates.

Hazard indicator and horn mode :

DOOR LOCK

DOOR UNLOCK

TRUNK UNLOCK

Intelligent Key system

(Using door handle or

trunk request switch)

HAZARD -

twice

OUTSIDE CHIME -
twice

HAZARD -

once

OUTSIDE CHIME -
once

HAZARD - none
OUTSIDE CHIME -
4 times

Remote keyless entry

system (Using

button)

HAZARD -

twice

HORN -

once

HAZARD -

once

HORN - none

HAZARD - none
HORN - none

Hazard indicator mode :

DOOR LOCK

DOOR UNLOCK

TRUNK UNLOCK

Intelligent Key system

(Using door handle or

trunk request switch)

HAZARD -

twice

OUTSIDE CHIME -
none

HAZARD - none
OUTSIDE CHIME -
none

Remote keyless entry

system (Using

button)

HAZARD -

twice

HORN - none

HAZARD - none
HORN - none

Pre-driving checks and adjustments

3-15

췽

—

—
01/12/10—pattie

墍

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti M37 (2011 year). Manual - part 9
