6 CHECK HEATED OXYGEN SENSOR 1 (FRONT) With CONSULT-II 1. Start engine and warm it up to normal operating temperature. SEF646Y 6. Check the following. I “HO2S1 MNTR (B1)/(B2)” in “DATA MONITOR” mode changes from “RICH” to “LEAN” to “RICH” 5 times in 10 seconds. SEF647Y I “HO2S1 (B1)/(B2)” voltage goes above 0.6V at least once. I “HO2S1 (B1)/(B2)” voltage goes below 0.3V at least once. I “HO2S1 (B1)/(B2)” voltage never exceeds 1.0V. SEF648Y CAUTION: Discard any heated oxygen sensor which has been dropped from a height of more than 0.5 m (19.7 in) onto a OK or NG OK © GO TO 9. NG © GO TO 8. GI MA EM LC FE AT AX SU BR ST RS BT HA SC EL IDX DTC P0132 (BANK 1), P0152 (BANK 2) HO2S1 (FRONT) (RICH SHIFT MONITORING) Diagnostic Procedure (Cont’d) EC-215 |
