Description NHEC0081 NOTE: SEF594K COMPONENT DESCRIPTION NHEC0081S01 The engine coolant temperature sensor is used to detect the SEF012P <Reference data> Engine coolant temperature °C (°F) Voltage* V Resistance k Ω −10 (14) 4.4 9.2 20 (68) 3.5 2.1 - 2.9 50 (122) 2.2 0.68 - 1.00 90 (194) 0.9 0.236 - 0.260 *: These data are reference values and are measured between ECM terminal 70 CAUTION: Do not use ECM ground terminals when measuring input/ On Board Diagnosis Logic NHEC0082 Malfunction is detected when voltage sent to ECM from the sen- GI MA EM LC FE AT AX SU BR ST RS BT HA SC EL IDX DTC P0125 ENGINE COOLANT TEMPERATURE SENSOR (ECTS) Description EC-187 |
