Hyundai Kona (2024 year). Manual in english

5-101

if equipped

Auto dehumidify

To increase cabin air quality and reduce

windshield misting, recirculation mode

switches off automatically after about 5

to 30 minutes, depending on the outside

temperature, and the air intake changes

to fresh mode.

Turning Auto dehumidify on or off

Climate control system

To turn the Auto dehumidify feature on or
off, select Face level ( ) mode and press

the air intake control (

) button at least

5 times within 3 seconds while pressing

the A/C button. When Auto dehumidify is

turned on, the air intake control button

indicator blinks 6 times. When turned off,

the indicator blinks 3 times.

Infotainment system

Auto dehumidify can be turned on and off

by selecting

Setup

Vehicle

Climate

Automatic Ventilation

Automatic

Dehumidify

from the infotainment

system.

Sunroof inside air

if equipped

recirculation

When the sunroof is opened, the fresh

mode is automatically selected. If you

press the air intake control button, the

recirculation mode is selected but

changes back to the fresh mode after 3

minutes. When the sunroof is closed, the

air intake position returns to the previous

position.

Recirculating air when washer

if equipped

fluid is used

Recirculation mode automatically

activates to reduce the scent of the

washer fluid entering the cabin when the

windshield washer is used.
When it is shifted to the recirculation

mode, the unpleasant scent may flow into

the vehicle.
However, in cold weather to prevent the

windshield from fogging up, the

recirculation mode may not be selected.

Turning Activation on a washer fluid

use on or off

Climate control system

To turn the Activate on washer fluid use

feature on or off, select Floor level ( )

mode, and then press the air intake

control (

) button 5 times within 3

seconds while pressing the A/C button.
When Activate on washer fluid use is

turned on, the air intake control button

indicator blinks 6 times. When turned off,

the indicator blinks 3 times.

Infotainment system

Activate on washer fluid use can be

turned on and off by selecting

Setup

Vehicle

Climate

Recirculate Air

Activate upon Washer Fluid Use

from the

infotainment system.

Convenience Features

5-102

Recirculating air when

if equipped

entering a tunnel

• To prevent the inflow of polluted air

into the vehicle when passing through a

tunnel, this function automatically

closes the windows and switches the

climate control system to Recirculation

mode for about 7 seconds before

entering a tunnel based on the map

information of the navigation and the

speed of the vehicle.

• The windows automatically closes

before entering a tunnel and area

requiring air recirculation. The windows

open to the previous position after

passing the area. If the power window

switch is operated before the window

opens, the window does not open to

the previous position.

• To use this feature, it must be enabled

from the Settings menu in the

infotainment system. Select:
-

Setup

Vehicle

Climate

Recirculate Air

Activate upon

Entering Tunnels

Scheduled ventilation control

The Scheduled Ventilation Control

releases hot air in the vehicle to lower

cabin temperature before getting in the

vehicle.
Depending on the outside ambient

temperature, the blower is operated for 5

to 15 minutes while the vehicle is parked.

Turning Schedule Ventilation

Control On or Off

The Schedule Ventilation Control can be

turned on and off by selecting ‘

Setup

Vehicle

Climate

Automatic

Ventilation

Scheduled Ventilation

Control

’ from the infotainment screen.

Also, the starting time can be set within

24 hours. Schedule Ventilation Control

operates only once when the feature is

set.

5-103

Storage Compartment

WARNING

Never store cigarette lighters, propane

cylinders, or other flammable/explosive

materials in the vehicle. These items may

catch fire and/or explode if the vehicle is

exposed to hot temperatures for

extended periods.

WARNING

ALWAYS keep the storage compartment

covers closed securely while driving.

Items inside your vehicle are moving as

fast as the vehicle. If you have to stop or

turn quickly, or if there is a collision, the

items may fly out of the compartment and

may cause an injury if they strike the

driver or a passenger.

NOTICE

To avoid possible theft, do not leave

valuables in the storage compartments.

Center console storage

2C_CenterConsoleBox

To open:
Press the button.

Removable partition

2C_PartitionCenterConsole

The removable partition (1) can be

removed to expand the storage

compartment.

Convenience Features

5-104

Glove box

2C_GloveBox

To open:
Pull the lever (1).

WARNING

ALWAYS close the glove box door after

use.
An open glove box door may cause

serious injury to a passenger in a collision,

even if the passenger is wearing a seat

belt.

Passenger seat open tray

2C_OpenTray

You can use this space to store small

items etc.

WARNING

Do not put any sharp object in the open

tray. It may seriously injure you in the

event of a sudden stop or a collision.

Interior Features

Cup holder

Cups or small beverages cups can be

placed in the cup holders.

Front seat - Type A

2C_CupHolderCenterConsole

Front seat - Type B

2C_CupHolderCenterConsole_2

Push the button. The cup supporter

protrudes from the front console.
Push in the cup supporter after use.

5-105

Rear seat armrest

2C_RearSeatCupHolder

Pull the armrest down to use the cup

holders.

WARNING

• Avoid abrupt starting and braking when

the cup holder is used to prevent

spilling your drink. If hot liquid spills,

you may be burned. Such a burn to the

driver may cause loss of vehicle control

resulting in a collision.

• Only use soft cups in the cup holders.

NOTICE

• Keep your drinks sealed while driving to

prevent spilling. If liquid spills, it may

get into the vehicle’s

electrical/electronic system and

damage electrical/electronic parts.

• When cleaning spilled liquids do not

use hot air to blow out or dry the cup

holder. This may damage the interior.

• Keep cans or bottles out of direct sun

light and do not put them in a hot

vehicle. Otherwise, they may explode.

Sunvisor

2C_Sunvisor

To use the sunvisor, pull it downward.
To use the sunvisor to block the sun from

the side window, pull it rearward, release

it from the bracket (1) and swing it to the

side (2) toward the window.
To use the vanity mirror, pull down the

sunvisor and slide the mirror cover (3).
Adjust the sunvisor forward or backward

(4) as needed (if equipped). Use the ticket

holder (5) to hold tickets.
Close the vanity mirror cover securely and

return the sunvisor to its original position

after use.

WARNING

Do not block your view or the roadway

when using the sunvisor.

NOTICE

The tab (5) adjacent to the vanity mirror

on the sunvisor can be used for toll road

tickets or self parking tickets. Use caution

when inserting tickets into the ticket

holder to avoid damage. Refrain from

putting several tickets in the ticket holder

as this could also damage the retaining

tab.

Convenience Features

5-106

Power outlet

Center console storage (inside)

2C_PowerOutlet

The power outlet is designed to provide

power for mobile phones or other devices

designed to operate with vehicle

electrical systems.
The devices should draw less than 180 W

with the engine running.

WARNING

Avoid electrical shocks. Do not place your

fingers or foreign objects (pin, etc.) into a

power outlet or touch the power outlet

with a wet hand.

NOTICE

To prevent damage to the power outlets:
• Use the power outlet only when the

engine is running and remove the

accessory plug after use. Using the

accessory plug for an extended period

of time with the engine off could cause

the battery to discharge.

• Only use 12 V electric accessories that

are less than 180 W in electric capacity.

• Adjust the air conditioner or heater to

the lowest operating level when using

the power outlet.

• Close the cover when not used.
• Some electronic devices may cause

electronic interference when plugged

into a vehicle’s power outlet.

• Push the plug in as far as it goes. The

plug may overheat and the fuse may

open.

• Only connect devices with reverse

current protection or the current from

the device battery may cause the

vehicle’s electrical/electronic system

to malfunction.

USB charger

The USB charger is designed to recharge

batteries of small size electronic devices

using a USB cable.

Front

2C_ChargingOutlet

Rear

2C_USBChargePortCenterConsoleBox

The USB charger is designed to recharge

batteries of small size electronic devices

using a USB cable.
Electronic devices can be charged when

the engine is running.

5-107

Information

• The battery charging state may be

monitored on the electronic device.

• Disconnect the USB cable from the USB

port after use.

• A smartphone or a tablet PC may get

warmer during the recharging process.

It does not indicate any malfunction

with the charging system.

• A smartphone or a tablet PC that does

not use a USB cable to charge should be

charged using its own charger.

• Do not attempt to use the charging

terminal either to turn on an audio or to

play media with the infotainment

system.

• Charging may not be possible when

using a Type-C to A converter sold by a

mobile phone manufacturer or

commercially available.

NOTICE

• Use the USB charger when the engine is

running. Using the USB charger for

prolonged periods of time with the

Engine Start/Stop button in the ON

position (engine off) may cause the

battery to discharge.

• To prevent damage to the USB charger:

- Do not insert foreign objects or spill

liquid into the outlet. The USB

charging terminal may be damaged.

- Do not use devices with working

current exceeding 3,000 mA (3.0 A).

• When charging an electrical device by

using an USB converting adapter (C to A

type), use a genuine adapter specified

for your vehicle. A commonly used

adapter is not equipped with any

measures to prevent over current and

maintain stability.
Using an unspecified cable may

damage the vehicle’s USB charger or

the connected devices. Contact an

authorized HYUNDAI dealer for more

information on accessories for

HYUNDAI vehicles.

• The use of non-genuine parts may

damage the USB port and infotainment

system. Damage cannot be covered by

your vehicle warranty.

Convenience Features

5-108

Wireless smartphone

if equipped

charging system

2C_WirelessSmartPhoneChargingSystem

[A] Indicator light

[B] Charging pad

Charging your smartphone

The wireless smartphone charging

system charges only the Qi-enabled
smartphones ( ). Visit your smartphone

manufacturer’s website to check whether

your smartphone supports the Qi

technology.
The wireless charging process starts

when you put a Qi-enabled smartphone

on the wireless charging with the screen

facing up.
1. The wireless smartphone charger is

available when all doors are closed, and

when the Engine Start/Stop button is in

the ON or START position.

2. Turn on the wireless charging function

from the Settings menu in the

infotainment system.
• Select:

Setup

Vehicle

Convenience

Wireless Charging

System for Mobile Devices

3. Place the smartphone on the center of

the wireless charging pad. The

indicator light is orange when the

smartphone is charging and turns blue

when phone charging is complete.

Information

• Remove other items, including the

smart key from the wireless charging

pad.

• For flip type smartphones, when using

wireless charging, place the

smartphone folded with the device’s

back placed on the center of the

wireless charging unit.

If your smartphone is not charging:
• Move the smartphone on the charging

pad.

• Make sure the indicator light is orange.
The indicator light blinks orange for 10

seconds if there is a malfunction in the

wireless charging system.
The system warns you with a message on

the cluster display if the smartphone is

still on the wireless charging pad after the

vehicle is turned OFF and the front door is

opened.

NOTICE

• The wireless smartphone charging

system may not support certain

smartphones, that do not meet for the
Qi specification ( ).

• When placing your smartphone on the

charging pad, position the phone in the

middle of the mat for optimal charging

performance. If your smartphone is off

to the side, the charging rate may be

less and in some cases the smartphone

may experience higher heat

conduction.

• Wireless charging may stop temporarily

when the smart key is used, either

when starting the vehicle or

locking/unlocking the doors, etc.

• When charging certain smartphones,

the charging indicator may not change

to blue when the smartphone is fully

charged.

5-109

• The wireless charging process may

temporarily stop, when temperature

abnormally increases inside the

wireless smartphone charging system.

The wireless charging process does not

restart, until the temperature falls.

• The wireless charging process may

temporarily stop when there is any

metallic item, such as a coin, between

the wireless smartphone charging

system and smartphone.

• For some manufacturer’s smart

phones, the system may not warn you

even though the smart phone is left on

the wireless charging unit. This is due to

the particular characteristic of the

smart phone and not a malfunction of

the wireless charging.

• When charging some smartphones

with a self-protection feature, the

wireless charging speed may decrease

and the wireless charging may stop.

• If the smartphone has a thick case, it

may not charge.

• Some magnetic items such as credit

cards, phone cards, or transit cards may

be damaged if left with the smartphone

during the charging process.

• If the smartphone is not completely

contacting the charging pad, wireless

charging may not operate properly.

• If the Engine Start/Stop button is in the

OFF position, the charging also stops.

• When any smartphone without a

wireless charging function or a metallic

object is placed on the charging pad, a

small noise may sound. This small

sound because the vehicle discerns

compatibility of the object placed on

the charging pad. It does not affect

your vehicle or the smartphone.

• Some smartphones may not be able to

charge depending on the internal

structure of the smartphone. If this

occurs, try charging the smartphone by

moving it to the left or right side of the

wireless charging pad. However, for

some fold-able smartphones that have

magnets inside the smartphone, try

charging the smartphone while holding

it close to the left side of the wireless

charging pad.

NOTICE

Some magnetic items like credit cards,

phone cards or rail tickets may be

damaged if left with the smartphone

during the charging process.

Information

This device complies with Part 15 of the

FCC rules.
Operation is subject to the following three

conditions:
1. This device may not cause harmful

interference.

2. This device must accept any

interference received, including

interference that may cause undesired

operation.

3. Changes or modifications not expressly

approved by the party responsible for

compliance could void the user’s

authority to operate the device.

Clock

The clock can be set from the

infotainment system.

WARNING

Do not attempt to adjust the clock while

driving.

Convenience Features

5-110

Coat hook

Rear

2C_CoatHook

This hook is not designed to hold large or

heavy items.

WARNING

Only hang soft clothing without heavy,

sharp or breakable objects in the clothes

pockets. In a collision or when the curtain

airbag is inflated, the objects could move

and cause serious injury.

2C_CoatHookWarning

Floor mat anchor(s)

ALWAYS use the floor mat anchors to

attach the front floor mats to the vehicle.

The anchors on the front floor carpet keep

the floor mats from sliding forward.

WARNING

To prevent serious injury or death from a

floor mat interfering with the brake or

accelerator pedals:
• Remove any protective film on the

carpet before installing a floor mat.

• Check floor mats are securely attached

to the vehicle’s floor mat anchors

before driving.

• Do not use ANY floor mat that cannot

be firmly attached to the vehicle’s floor

mat anchors.

• Do not stack floor mats on top of one

another (e.g. all-weather rubber mat on

top of a carpeted floor mat). Only a

single floor mat must be installed in

each position.

WARNING

To avoid any interference with pedal

operation, install the HYUNDAI floor mat

designed for your vehicle.

5-111

if equipped

Cargo net holder

2C_CargoFixingNet

To keep items from shifting in the cargo

area, use the 4 holders located in the

cargo area side trim to attach the cargo

net.
Make sure the cargo net is securely

attached to the holders in the cargo

board.
If necessary, contact your authorized

HYUNDAI dealer to purchase a genuine

accessory cargo net.

WARNING

• Avoid eye injury. Do not overstretch the

cargo net. Always keep your face and

body out of the cargo net’s recoil path.

Do not use the cargo net when the strap

has visible signs of wear or damage.

• Use the cargo net to keep only light

items from shifting in the cargo area.

Cargo area cover

2C_CargoShelf

Use the cargo area cover to hide items

stored in the cargo area.
• If the cargo area cover is connected to

the liftgate, the cover lifts with the

liftgate when opening the liftgate.

• If you do not want the cargo area cover

to lift with the liftgate, disconnect the

strap (1) from the strap holder of the

liftgate.

Removing cargo area cover

To remove the cargo area cover:
1. Disconnect the strap (1) from the strap

holder of the liftgate.

2. Lift the cover diagonally and pull it out

(2).

To reinstall, follow the reverse order.

CAUTION

• When the cargo area cover is removed,

you can secure the cover to the rear

seatback not to distract you while

driving.

• Since the cargo area cover also lifts

when opening the liftgate, move the

items placed on top of the cover to a

safe place so they do not fall.

• Do not put excessive pressure or

weight on the cargo area cover. The

cargo area cover may be damaged.

Convenience Features

5-112

Increasing cargo area volume

To increase cargo area volume:
1. Open the liftgate and remove the cover

according to “Removing cargo area

cover”.

2. Push the cargo area cover in to reach

the lower fixing part (A).
• Be careful not to get the cover caught

in the cargo.

2C_CargoShelf_Volume1

3. Insert the cargo area cover to the lower

fixing part (A) on both sides.

4. Lift the rear part of the cargo area cover

and secure it with the stopper (B).

2C_CargoShelf_Volume2

• To release the cargo area cover, press

the stopper (B), lower the cover, and

pull out the cover diagonally.

CAUTION

When securing cover, be careful not to

get the cover caught on the upper fixing

part. The cargo area cover may be

damaged.

if equipped

Cargo tray

2C_CargoCompartment

Use the cargo tray to organize and store

small items such as tools. To use the tray,

lift the luggage floor by the handle.

CAUTION

• When storing small or easily movable

items, they may cause noise while

driving.

• Do not store fragile items in the cargo

tray.

5-113

Increasing cargo area volume

(Lower position)

To increase the cargo area volume:
1. Lift the luggage floor by its handle and

remove the cargo tray.

2C_CargoBoard

2. Remove the luggage floor and insert

the luggage floor into the lower

position. It may take a good push to

fully seat it so it lays flat at the rear.

2C_CargoBoard_2

3. Unfold the top board.

Exterior Features

if equipped

Roof side rails

2C_RoofRack

Your vehicle may come equipped with

roof side rails. If your vehicle is equipped

with roof rack rails, you can add roof rack

crossbars as an accessory (not shown).

Information

• If the vehicle is equipped with a

sunroof, do not position the cargo onto

the roof side rails in such a way that it

may interfere with sunroof operation.

• Always take precautions to make sure

the cargo does not damage the roof.

• When carrying large objects on the roof

side rails, make sure they do not exceed

the overall roof length or width.

• When carrying cargo on the roof side

rails, take necessary precautions to

make sure the cargo does not damage

the roof of the vehicle.
When carrying large objects on the roof

side rails, make sure they do not exceed

the overall roof length or width.

Convenience Features

5-114

WARNING

• Loading cargo or luggage in excess of

the specified weight limit on the roof

side rails may damage your vehicle.

• Avoid sudden starts, braking, sharp

turns, abrupt maneuvers, or high

speeds that may result in loss of vehicle

control or rollover resulting in a

collision. The vehicle center of gravity is

higher when items are loaded onto the

roof side rails.

• Always drive slowly and turn corners

carefully when carrying items on the

roof side rails. Severe wind updrafts

caused by passing vehicles or natural

causes, can cause sudden upward

pressure on items loaded on the roof

side rails. This is especially true when

carrying large, flat items such as wood

panels or mattresses. This may cause

the items to fall off the roof side rails

and cause damage to your vehicle or

others around you.

• To prevent damage or loss of cargo

while driving, check frequently before

or while driving to make sure the items

on the roof side rails are securely

fastened.

Hitch mounted accessories

The maximum load for a hitch mounted

accessory, with the weigh of the

accessory and the load, is 220 lbs. (100

kg). This would include bicycle racks,

wheel chair racks, etc. The center of the

weight must be within 19 inches (0.5 m) of

the bumper. If the weight is further away,

the capacity is reduced up to 10% per

inch.
• The weight of the rack and load must be

reduced from the vehicle carrying

capacity. For more information, refer to

the “Vehicle Load Limit” section in

chapter 6.

ROOF SIDE

RAILS

200 lbs. (100 kg)

EVENLY DISTRIBUTED

5-115

Infotainment System

NOTICE

• Do not install an aftermarket HID

headlight. Your vehicle’s audio and

electronic devices may not function

properly.

• Prevent chemicals such as perfume,

cosmetic oil, sun cream, hand cleaner,

and air freshener from contacting the

interior parts because they may cause

damage or discoloration.

USB Port

2C_USBPort

Press the USB port selection button while

the engine is running. Press the upper

portion of the button (1) to charge an

electronic device. Press the lower portion

of the button (2) to charge and listen to

music with a media storage device. The

USB port can be used after either

indicator light turns on.
• You can use an USB cable to connect

audio devices to the vehicle USB port.

• After connecting a media storage

device such as a MP3 or USB to the USB

port, you can listen to music through

the vehicle's speakers or play it on the

infotainment system.

• Small electronic devices can be

charged.

• Use the USB position to connect to

wired Android Auto or Apple Car Play.

Information

• Some devices may not be charged

through USB port.

• When using a portable audio device

connected to the power outlet, and the

USB port at the same time, noise may

occur during playback. If this happens,

disconnect the power cable from the

power outlet and use the portable

audio device's power source.

NOTICE

• When connecting a Type-A USB or a

memory device to a vehicle, use a

genuine converting adapter (C to A

type) specified for your vehicle. A

commonly used adapter is not

equipped with any measures to reduce

noise, prevent overcurrent and

maintain stability. Connecting an

unspecified cable may damage the

vehicle’s USB port or the connected

devices. Contact an authorized

HYUNDAI dealer for more information

on accessories for HYUNDAI vehicles.

• The use of non-genuine parts may

damage the USB port and infotainment

system. Damage cannot be covered by

your vehicle warranty.

Convenience Features

5-116

Antenna

2C_SharkAntenna

The shark fin antenna receives

transmitted data (for example, AM/FM,

SXM).

Steering wheel remote

controls

2C_AudioButtonOverview

NOTICE

Do not operate multiple audio remote

control buttons simultaneously.

SEEK/PRESET ( / )

If the SEEK/PRESET switch is pushed up

or down and held for 0.8 seconds or

more, it functions in the following modes:
• RADIO mode

It functions as the AUTO SEEK select

button. It seeks until you release the

button.

• MEDIA mode

It functions as the FF/RW button.

If the SEEK/PRESET switch is pushed up

or down, it functions in the following

modes:
• RADIO mode

It functions as the PRESET STATION

UP/DOWN button.

• MEDIA mode

It functions as the TRACK UP/ DOWN

button.

VOLUME (VOL + / VOL -)

Roll the knob up or down to adjust the

volume.

MODE

Press the MODE button to toggle through

Radio mode.

MUTE ( )

Press the MUTE ( ) button to mute or

activate the sound.

5-117

Infotainment system

2C_AVNOverview

For more information, refer to the

separately supplied infotainment system

manual.

Voice recognition

2C_SteeringWheelVoiceRecognitionButton

See additional information in supplied

Infotainment Manual.

Bluetooth® wireless

technology

2C_SteeringWheelCallButton

2C_Microphone

(1) Call/Answer/Call end button
(2) Microphone
For more information, refer to the

separately supplied infotainment system

manual.

CAUTION

To prevent driver distractions, minimize

your use of these features while driving.

Distraction may cause a collision,

resulting in serious injury or death.

6-3

Before Driving

WARNING

Carbon monoxide (CO) gas is toxic. Breathing CO may cause unconsciousness and

death.

Engine exhaust contains carbon monoxide that cannot be seen or smelled.

Do not inhale engine exhaust.

If at any time you smell engine exhaust inside the vehicle, open the windows

immediately. Exposure to CO may cause unconsciousness and death by asphyxiation.

Make sure the exhaust system does not leak.

Be sure to check the exhaust system whenever the vehicle is raised to change the oil or

for any other purposes. If you hear a change in the sound of the exhaust or drive over

something that strikes the underneath side of the vehicle, have the exhaust system

inspected as soon as possible by an authorized HYUNDAI dealer.

Do not run the engine in an enclosed area.

Letting the engine idle in your garage, even with the garage door open, is a hazardous

practice. Run the engine only long enough to start the engine and to move the vehicle

out of the garage.

Avoid idling the engine for an extended period of time with people inside the vehicle.

If it is necessary to idle the engine for a long time with people inside the vehicle, be sure

to do so only in an open area with the air intake set at “Fresh” and fan control set to high

so fresh air is drawn into the interior.

Keep the air intakes clear.

To ensure proper operation of the ventilation system, keep the ventilation air intakes

located in front of the windshield clear of snow, ice, leaves, or other obstructions.

If you must drive with the liftgate open:

Close all windows.
Open instrument panel air vents.
Set the air intake control at “Fresh”, the air flow control at “Floor” or “Face”, and the fan

control set to high.

WARNING

CALIFORNIA PROPOSITION 65 WARNING
Engine exhaust and a wide variety of automobile components including components

found in the interior furnishings in a vehicle, contain or emit harmful chemicals known to

the State of California to cause cancer and birth defects and reproductive harm. In

addition, certain fluids contained in vehicles and certain products of components contain

or emit chemicals known to the State of California to cause cancer and birth defects or

other reproductive harm.

Driving Your Vehicle

6-4

Before entering the vehicle

• Make sure all windows, side view

mirror(s), and outside lights are clean

and unobstructed.

• Remove frost, snow, or ice.
• Visually check the tires for uneven wear

and damage.

• Check under the vehicle for any sign of

leaks.

• Make sure there are no obstacles

behind you if you intend to back up.

Before starting

Make sure the hood, the liftgate, and the

doors are securely closed and locked.
Adjust the position of the seat and

steering wheel.
Adjust the inside and side view mirrors.
Verify all the lights work.
Fasten your seat belt. Check that all

passengers have fastened their seat belts.
Check the gauges and indicators in the

instrument panel and the messages on

the cluster display when the Engine

Start/Stop button is in the ON position.
Check that any items you are carrying are

stored properly or fastened down

securely.
To reduce the risk of SERIOUS INJURY or

DEATH, take the following precautions:
ALWAYS wear your seat belt. All

passengers must be properly belted

whenever the vehicle is moving. For more

information, refer to the “Seat Belts”

section in chapter 3.

Always drive defensively. Do not assume

that the other drivers are seeing your

vehicle. They may not act as you expect.

Be prepared to react to avoid a possible

collision. Plan your movements

anticipating the “worst case” scenario.
Stay focused on driving. Driver distraction

may cause a collision.
Leave plenty of space between you and

the vehicle in front of you.
NEVER drink or take drugs while driving.
Drinking or taking drugs while driving is

dangerous and may result in a collision,

causing serious injury or death.
Drunk driving is the number one

contributor to the highway death toll each

year. Even a small amount of alcohol can

affect your reflexes, perceptions and

judgment. Just one drink may reduce

your ability to respond to changing

conditions and emergencies and your

reaction time gets worse with each

additional drink.
Driving while under the influence of drugs

is as dangerous or more dangerous than

driving under the influence of alcohol.
You are much more likely to have a

serious accident if you are drinking or

taking drugs, never drive. Do not ride with

a driver who has been drinking or taking

drugs. Choose a designated driver or call

a taxi.

6-5

Engine Start/Stop Button

2C_StartButton

Whenever the front door is opened, the

Engine Start/Stop button illuminates and

goes off for a few seconds after the door

is closed.

WARNING

To turn off the engine in an emergency:
Press and hold the Engine Start/Stop

button for more than 2 seconds. Or

rapidly press and release the Engine

Start/Stop button 3 times (within 3

seconds).
If the vehicle is still moving, you can

restart the vehicle without depressing the

brake pedal by pressing the Engine

Start/Stop button with the gear in the N

(Neutral) position.

WARNING

• Never press the Engine Start/Stop

button while the vehicle is in motion

except in an emergency. This may

result in the vehicle turning off and loss

of power assist for the steering and

brake systems. This may cause loss of

directional control and braking

function, which could cause a collision.

• Before leaving the driver’s seat, always

make sure the gear is in the P (Park)

position, apply the parking brake, press

the Engine Start/Stop button to the OFF

position, and take the smart key with

you. Unexpected vehicle movement

may occur if these precautions are not

followed.

• Never reach through the steering wheel

for the Engine Start/Stop button or any

other control while the vehicle is

moving. The presence of your hand or

arm in this area may cause a loss of

vehicle control resulting in a collision.

Driving Your Vehicle

6-6

Engine Start/Stop button positions

Button Position

Action

Notes

OFF

To turn off the engine, press the

Engine Start/Stop button with

gear in P (Park).
For rotary type shift gear vehicles,

if the Engine Start/Stop button is

pressed with the vehicle shifted to

D (Drive), R (Reverse), or N

(Neutral), the gear automatically

shifts to P (Park).
For lever type shift gear vehicles, if

the Engine Start/Stop button is

pressed with the gear shifted to D

(Drive), R (Reverse), or N (Neutral),

the Engine Start/Stop button

changes to the ACC position.

Always stop the vehicle before

pressing the Engine Start/Stop

button to the OFF position.

ACC

Press the Engine Start/Stop

button when the button is in the

OFF position without depressing

the brake pedal.
Some electrical accessories are

usable.

If you leave the Engine Start/Stop

button in the ACC position for more

than one hour, the battery power

turns off automatically to prevent

the battery from discharging.

Press the Engine Start/Stop

button while it is in the ACC

position without depressing the

brake pedal.
The warning lights can be checked

before the engine is started.

Do not leave the Engine Start/Stop

button in the ON position when the

engine is not running to prevent

the battery from discharging.

START

To start the engine, depress the

brake pedal and press the Engine

Start/Stop button with the gear in

the P (Park) or in the N (Neutral)

position.
For your safety, start the engine

with the gear in the P (Park)

position.

If you press the Engine Start/Stop

button without depressing the

brake pedal, the engine does not

start and the Engine Start/Stop

button changes as follows:

OFF

ACC

OFF

ACC

6-7

Starting the engine

WARNING

• Always wear appropriate shoes when

operating your vehicle. Unsuitable

shoes such as high heels, ski boots,

sandals, and flip-flops may interfere

with your ability to use the brake,

accelerator, and clutch pedals. Do not

drive barefoot.

• Do not start your vehicle with the

accelerator pedal depressed. Place

your foot firmly on the brake pedal

while starting your vehicle.

• Wait until the engine is at normal idle

before shifting gears and releasing the

brake. Your vehicle may move suddenly

if your vehicle is shifted while the

engine RPM is high. It may cause

damage to the transmission system.

Information

• The vehicle starts by pressing the

Engine Start/Stop button, only when

the smart key is in the vehicle.

• The vehicle may not start even if the

smart key is in the vehicle but it is not

near you (e.g. in the cargo area).

• When the Engine Start/Stop button is in

the ACC or ON position, if any door is

open, the system checks for the smart

key. When the smart key is not in the
vehicle, the

indicator blinks and the

warning “

Key not in vehicle

” appears.

When all doors are closed, the chime

sounds for a few seconds. Keep the

smart key in the vehicle.

1. Always carry the smart key with you.
2. Make sure the parking brake is applied.
3. Make sure the gear is in P(Park).
4. Depress the brake pedal.
5. Press the Engine Start/Stop button.

NOTICE

• Do not wait for the engine to warm up

or race the engine while the vehicle

remains stationary.

• Start driving at moderate engine

speeds. Do not rapidly accelerate and

decelerate while driving.

Information

To prevent damage to the vehicle:
• Do not press the Engine Start/Stop

button for more than 10 seconds except

when the brake switch fuse is blown.
When the brake switch fuse is blown, a

warning message appears on the

instrument cluster. In this case, start

the engine by pressing and holding the

Engine Start/Stop button for 10

seconds with the Engine Start/Stop

button in the ACC position.
Replace the fuse as soon as possible.

For more information, refer to the

"Fuses" section in chapter 9.

• If the engine stalls while the vehicle is

moving, shift to N (Neutral) and use the

Engine Start/Stop button to attempt to

restart the engine.

• Do not push or tow your vehicle to start

the engine.

Driving Your Vehicle

6-8

Information

2C_StartVehicleWithPushingSmartKey

If the smart key battery is weak or the

smart key does not work correctly, press

the Engine Start/Stop button with the

smart key.

Turning off the engine

1. Stop the vehicle and depress the brake

pedal fully.

2. Make sure the gear is in P (Park).
3. Apply the parking brake.
4. Press the Engine Start/Stop button to

the OFF position.

5. Take the key with you when you leave

the vehicle.

Remotely starting the engine

2C_SmartKeyRemoteStartButton

You can start the vehicle using the
Remote Start button ( ) on the smart key.
To start the vehicle remotely:
1. Press the door lock button within 32 ft.

(10 m) from the vehicle.

2. Press and hold the remote start button

( ) for over 2 seconds within 4 seconds.

To turn off the engine:
Press the remote start button ( ) once.

Information

• The vehicle does not remotely start if

the hood or liftgate is open.

• The vehicle must be in P (Park).
• The engine turns off if you get in the

vehicle without a registered smart key

or you do not get in the vehicle within

10 minutes.

6-9

if equipped

Vehicle Auto-Shut Off

If your vehicle is parked and the engine is

left on for a long period of time, the

engine will turn off automatically to help

reduce fuel consumption and prevent

accidents caused by carbon dioxide

poisoning.

Operating conditions

Vehicle Auto-Shut Off timer operates

when all the following conditions are

satisfied:
• Vehicle speed is below 1.8 mph (3

km/h), and the gear is shifted to P (Park)

• The brake pedal and accelerator pedal

are not depressed

• The driver’s seat belt is unfastened
• The passenger seat is empty
• The infotainment system is being

updated

Deactivating conditions

Vehicle Auto-Shut Off timer turns off

when one of the situation occurs:
• Vehicle speed is above 1.8 mph (3

km/h)

• The gear is shifted to R (Reverse), D

(Drive) or N (Neutral)

• The brake pedal or accelerator pedal is

depressed

• The driver’s seat belt is fastened
• A passenger is in the passenger’s seat

System operation

2C_AutoShutOffInfo

When all the conditions are satisfied, the

Vehicle Auto-Shut Off operates and turns

the engine off automatically after 60

minutes.
A timer appears on the instrument cluster

30 minutes before vehicle shut off.

Resetting cluster timer

To reset the cluster timer, do one of

following:
• Release the accelerator pedal or brake

pedal after Vehicle Auto-Shut Off is

complete.

• Press the OK button on the steering

wheel while the timer appears on the

instrument cluster.

CAUTION

Do not leave a passenger or a pet in the

vehicle in hot weather since the air

conditioning system turns off when the

engine is off.

Driving Your Vehicle

6-10

if equipped

Automatic Transmission

2C_ShiftButtonOverview

[A] Rotary gear shift dial

[B] P button

Depress the brake pedal whenever

rotating the gear shift dial or shifting to P

(Park).

Automatic transmission

operation

The automatic transmission has eight

forward speeds and one reverse speed.
The individual speeds are selected

automatically in the D (Drive) position.

WARNING

The automatic transmission rotary gear

shift dial or interior parts might get hot

when a vehicle is parked outside during

hot weather. Always be careful when the

vehicle is hot.

The indicator on the instrument cluster

displays the shift position when the

Engine Start/Stop button is in the ON

position.

WARNING

To reduce the risk of serious injury or

death:
• ALWAYS check the surrounding areas

near your vehicle for people, especially

children, before shifting a vehicle into D

(Drive) or R (Reverse).

• Before leaving the driver's seat, always

make sure the vehicle is shifted to the P

(Park) position, then apply the parking

brake, then press the Engine Start/Stop

button to the OFF position. Unexpected

and sudden vehicle movement can

occur if these precautions are not

followed.

• When using the paddle shifter (manual

shift mode), do not use engine braking

(shifting from a high gear to lower gear)

rapidly on slippery roads. The vehicle

may slip causing an accident.

Transmission ranges

P (Park)

Always come to a complete stop before

shifting into P (Park).

2C_PressPButton

To shift the gear to P (Park), press the P

button while depressing the brake pedal.
If you turn the engine off in R (Reverse), N

(Neutral) or D (Drive), the gear

automatically shifts to P (Park).

6-11

WARNING

• Shifting into P (Park) while the vehicle is

in motion may cause you to lose control

of the vehicle.

• After the vehicle has stopped, always

make sure the vehicle is in P (Park),

apply the parking brake, and turn the

engine off.

• When parking on an incline, shift the

gear to P (Park) and apply the parking

brake to prevent the vehicle from

rolling downhill.

Automatic gear shift to P (Park)

The gear is shifted to P (Park)

automatically for safety reasons under

the following conditions:
• When the engine is turned off with the

gear in R (Reverse), D (Drive) or N

(Neutral).

• When the driver’s door is open with the

engine running, the gear in R (Reverse),

D (Drive) or N (Neutral) and the vehicle

at a standstill.

• When the driver’s door is open with the

gear in N (Neutral) and the vehicle is

off.

In situations in which the gear must be in

P (Park), always check if the gear is shifted

to P (Park) by checking the cluster.

R (Reverse)

Use this position to drive the vehicle

rearward.

2C_ShiftButtonRPosition

To shift the gear R (Reverse), rotate the

rotary gear shift dial to R (Reverse) while

depressing the brake pedal.
When the vehicle is stopped in the R

(Reverse) position, if you open the driver's

door with the seat belt unfastened, the

gear automatically shifts to P (Park).
However, if the vehicle is in motion, the

gear may not automatically shift to P

(Park) to prevent automatic transmission

damage.

NOTICE

Always come to a complete stop before

shifting into or out of R (Reverse) to

prevent damaging the transmission.

Driving Your Vehicle

6-12

N (Neutral)

The wheels and transmission are not

engaged.

2C_ShiftButtonNPosition

To shift the gear to N (Neutral), rotate the

rotary gear shift dial to N (Neutral) from R

(Reverse) or D (Drive) while depressing

the brake pedal.
Always depress the brake pedal when you

are shifting from N (Neutral) to another

gear.
If you turn the engine off in N (Neutral),

the gear automatically shifts to P (Park).
However, if you need to stay in N

(Neutral) with the engine off, refer to

“Automatic transmission operation” in

this section.

CAUTION

The engine can be started with the gear in

N (Neutral), but for your safety, be sure to

start the engine with the gear in P (Park).

To stay in N (Neutral) when vehicle is

OFF

2C_ToStayNPositionInfo

2C_SteeringWheelOkButton

If you want to stay in N (Neutral) after the

engine is OFF (in the ACC state), do the

following.
1. Turn off Auto Hold and apply the

parking brake when the engine is

running.

2. Rotate the shift dial to N (Neutral) while

depressing the brake pedal.

3. When you take your foot off the brake

pedal, the message “

Press and hold

the OK button on the steering wheel to

stay in Neutral

” appears on the cluster

display.

4. Press and hold the OK button [A] on the

steering wheel for more than 1 second.

6-13

5. When the message “

Vehicle will stay in

(N). Change gear to cancel.

” appears

on the cluster display, turn the vehicle

off while depressing the brake pedal.
If you wish to cancel, change gear to P

(Park), D (Drive) or R (Reverse).

Otherwise, N (Neutral) will stay

engaged when the vehicle is Off.
Also, if you open the driver's door, the

gear automatically shifts to P (Park) and

the Engine Start/Stop button changes

to the OFF position.

NOTICE

With the gear in N (Neutral) the Engine

Start/Stop button is in the ACC position.

In the ACC position, the doors cannot be

locked. The battery may discharge if left

in the ACC position for a long time.

D (Drive)

This is the normal driving position.
The transmission automatically shifts

through an 8 gear sequence, providing

the best fuel economy and power.
For extra power when passing another

vehicle or driving uphill, depress the

accelerator pedal further until you feel

the transmission downshift to a lower

gear.

2C_ShiftButtonDPosition

To shift the gear D (Drive), rotate the

rotary gear shift dial to D (Drive) while

depressing the brake pedal.

When the vehicle is stopped in the D

(Drive) position, if you open the driver's

door with the seat belt unfastened, the

gear automatically shifts to P (Park).
However, if the vehicle is in motion, the

gear may not automatically shift to P

(Park) to prevent automatic transmission

damage.

NOTICE

Always come to a complete stop before

shifting into D (Drive).

CAUTION

When you start after stopping on a steep

incline, even if the gear is in D (Drive), if

you do not depress the accelerator or

brake pedal, the vehicle may roll

backwards, which can cause an accident.

Shift-lock system

For your safety, the automatic

transmission has a shift-lock system

which prevents shifting the transmission

from P (Park) into R (Reverse) or D (Drive)

unless the brake pedal is depressed.
To shift from P (Park) or N (Neutral) into R

(Reverse) or D (Drive):
1. Depress and hold the brake pedal.
2. Start the engine.
3. Shift the gear while depressing the

brake pedal.

Driving Your Vehicle

6-14

When the battery is discharged

You cannot shift gears, when the battery

is discharged.
In emergencies, do the following to shift

the gear to N (Neutral) on a level ground.
1. Connect the battery cables from

another vehicle or from a another

battery to the jump-starting terminals

inside the engine compartment.
For more information, refer to the

“Jump Starting” section in chapter 8.

2. Apply the parking brake with the Engine

Start/Stop button in the ON position.

3. Shift the gear to the N (Neutral)

position. Refer to the “Automatic

transmission operation” in this chapter.

Information

In situations when the gear needs to be

shifted from P (Park) to N (Neutral) when

the vehicle off, refer to the “To stay in N

(Neutral) when vehicle is OFF” in this

chapter.

Parking

Always come to a complete stop and

continue to depress the brake pedal.
Shift the gear to P (Park), apply the

parking brake, and press the Engine

Start/Stop button to turn the vehicle off.
Take the smart key with you when leaving

the vehicle.

WARNING

• When you stay in the vehicle with the

engine running, be careful not to

depress the accelerator pedal for a long

period of time. The engine or exhaust

system may overheat and start a fire.

• The exhaust gas and the exhaust

system are very hot. Keep away from

the exhaust system components.

• Do not stop or park over flammable

materials, such as dry grass, paper or

leaves. They may ignite and cause a

fire.

Hyundai Kona (2024 year). Manual in english - page 8
