05

NOTICE

USB Charger

To prevent damage to the Power

Outlets:

ś

Use the power outlet only when the

engine is running and remove the

accessory plug after use. Using the

accessory plug for prolonged periods

of time with the engine off could

cause the battery to discharge.

ś

Only use 12V electric accessories

which are less than 180 W in electric

capacity.

OCN7050069

ś

Adjust the air-conditioner or heater

Insert the USB charger into the USB port,

to the lowest operating level when

and re-charge a smart phone or a tablet

using the power outlet.

PC.

ś

Close the cover when not in use.

ś A charging status/charging

ś

Some electronic devices can

completion message is displayed on

cause electronic interference

a screen of a smart phone or a tablet

when plugged into a vehicle’s

PC.

power outlet. These devices may

ś A smart phone or a tablet PC may

cause excessive audio static and

get warmer during the re-charging

malfunctions in other electronic

process. It does not indicate any

systems or devices used in your

malfunction with the charging system.

vehicle.

ś A smart phone or a tablet PC, which

ś

Push the plug in as far as it will go. If

adopts a different re-charging

good contact is not made, the plug

method, may not be properly re-

may overheat and the fuse may open.

charged. In this case, use an exclusive

ś

Plug in battery equipped electrical/

charger of your device.

electronic devices with reverse

ś The charging terminal is only to

current protection. The current

recharge a device. Do not use the

from the battery may flow into the

charging terminal either to turn ON

vehicle’s electrical/electronic system

an audio or to play media on the

and cause system malfunction.

infotainment system.

5-113

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features

Wireless Cellular Phone

To charge a cellular phone

Charging System (if equipped)

The wireless cellular phone charging

system charges only the Qi-enabled

cellular phones. Read the label on the

cellular phone accessory cover or visit

your cellular phone manufacturer’s

website to check whether your cellular

phone supports the Qi technology.

The wireless charging process starts

when you put a Qi-enabled cellular

phone on the wireless charging unit.

1. Remove other items, including the

smart key, from the wireless charging

OCN7050070

unit. If not, the wireless charging

[A] : Charging pad

process may be interrupted. Place the

cellular phone on the center of the

There is a wireless cellular phone charger

charging pad (

).

inside the front console.

2. When charging starts, a charging

The system is available when all doors

icon is displayed on the infotainment

are closed, and when the ignition switch

system screen. However, depending

is in the ON position.

on the infotainment system screen,

the wireless charging icon may not be

displayed. See the infotainment web

manual for details.

3. You can turn ON or OFF the wireless

charging function in the user settings

mode on the instrument cluster. For

further information, refer to the “LCD

Display Modes” in this chapter.

The system warns you with a message

on the LCD display if the cellular phone

is still on the wireless charging unit after

the engine is turned OFF and the front

door is opened.

5-114

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05

ś

:KHQ FKDUJLQJ VRPH FHOOXODU SKRQHV

Information

with a self-protection feature,

For some manufacturers’ cellular phones,

the wireless charging speed may

the system may not warn you even though

decrease and the wireless charging

the cellular phone is left on the wireless

may stop.

charging unit. This is due to the particular

ś

,I WKH FHOOXODU SKRQH KDV D WKLFN

characteristic of the cellular phone and

cover, the wireless charging may not

not a malfunction of the wireless charging.

be possible.

ś

,I WKH FHOOXODU SKRQH LV QRW

NOTICE

completely contacting the charging

ś

7KH ZLUHOHVV FHOOXODU SKRQH FKDUJLQJ

pad, wireless charging may not

system may not support certain

operate properly.

cellular phones, which are not

ś

6RPH PDJQHWLF LWHPV OLNH FUHGLW

verified for the Qi specification (

).

cards, phone cards or rail tickets may

ś

:KHQ SODFLQJ \RXU FHOOXODU SKRQH

be damaged if left with the cellular

on the charging mat, position the

phone during the charging process.

phone in the middle of the mat for

ś

:KHQ DQ\ FHOOXODU SKRQH ZLWKRXW

optimal charging performance. If

a wireless charging function or a

your cellular phone is off to the side,

metallic object is placed on the

the charging rate may be less and in

charging pad, a small noise may

some cases the cellular phone may

sound. This small sound is due to the

experience higher heat conduction.

vehicle discerning compatibility of

ś

,Q VRPH FDVHV WKH ZLUHOHVV FKDUJLQJ

the object placed on the charging

may stop temporarily when the

pad. It does not affect your vehicle or

Remote Key or Smart Key is used,

the cellular phone in any way.

either when starting the vehicle or

locking/unlocking the doors, etc.

Information

ś

7KH ZLUHOHVV FKDUJLQJ SURFHVV PD\

If the ignition switch is in the LOCK/ OFF

temporarily stop, when temperature

position, the charging also stops.

abnormally increases inside the

wireless cellular phone charging

system. Stop the charging cellular

Information

phone and wait until temperature

falls to a certain level.

This device complies with part 15 of the

FCC Rules.

ś

7KH ZLUHOHVV FKDUJLQJ SURFHVV PD\

temporarily stop when there is

Operation is subject to the following two

any metallic item, such as a coin,

conditions:

between the wireless cellular phone

1. This device may not cause harmful

charging system and the cellular

interference, and

phone.

2. This device must accept any

interference received, including

interference that may cause undesired

operation.

5-115

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features

Clock

Clothes Hanger

WARNING

Do not attempt to adjust the clock

while driving. Doing so may result in

distracted driving which may lead to

an accident involving personal injury or

death.

For more information, please refer to

the manual that was supplied with your

vehicle.

OTM048095

These hangers are not designed to hold

large or heavy items.

WARNING

OCN7050071

Do not hang other objects such

as hangers or hard objects except

clothes. Also, do not put heavy, sharp

or breakable objects in the clothes

pockets. In an accident or when the

curtain air bag is inflated, it may cause

vehicle damage or personal injury.

5-116

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05

,1)27$,10(17 6<67(0

NOTICE

USB Port

ś

If you install an aftermarket HID

headlight, your vehicle’s audio and

electronic devices may not function

properly.

ś

Prevent chemicals such as perfume,

cosmetic oil, sunscreen, hand

cleaner, and air freshener from

contacting the interior parts

because they may cause damage or

discoloration.

OCN7050074

You can use an USB port to plug in an

USB.

Information

When using a portable audio device

connected to the power outlet, noise may

occur during playback. If this happens,

use the power source of the portable audio

device.

5-117

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features

Antenna

WARNING

ś

Do not clean the inside of the rear

window glass with a cleaner or

scraper to remove foreign deposits

as this may cause damage to the

antenna elements.

ś

To prevent damage to the rear

glass antenna, never use sharp

instruments or window cleaner

containing abrasives to clean the

window. Clean the inside surface of

the rear glass window with a piece of

OCN7050072

soft cloth.

Shark fin antenna (1, if equipped)

ś

Avoid adding metallic coatings such

The shark fin antenna receives data

as Nickel, Cadmium, etc. These can

transmitted from base stations and

degrade the receiving AM and FM

satelliltes (for example: GPS, Sirus XM,

broadcast signals.

LTE) and also transmits to base stations

ś

When putting a sticker on the inside

(for example: LTE).

surface of the rear window, be

careful not to damage the rear glass

Glass antenna (2)

antenna.

Your vehicle uses a glass antenna to

ś

Do not put sharp instruments nearby

receive both AM and FM signals.

the rear glass antenna.

ś

Tinted rear window may affect the

proper functioning of the antenna.

5-118

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05

Steering Wheel Audio Control

ś RADIO mode

It will function as the AUTO SEEK

select switch. It will SEEK until you

release the switch.

ś MEDIA mode

It will function as the FF/REW switch.

If the SEEK/PRESET toggle switch is

moved up or down, it will function in

the following modes.

ś RADIO mode

It will function as the PRESET STATION

OCN7050073L

UP/DOWN switch.

The steering wheel audio control

ś MEDIA mode

switches are installed for your

It will function as the TRACK UP/

convenience.

DOWN switch.

NOTICE

MODE (

)(3)

Do not operate audio remote control

Press the MODE button to select Radio.

buttons simultaneously.

Voice recognition button (

) (4)

VOLUME (VOL + / VOL -) (1)

ś Start or end voice recognition of a

connected smartphone via phone

ś Move the VOLUME toggle switch up

projection. (The button’s operation

to increase volume.

may vary depending on smartphone

ś Move the VOLUME toggle switch

specifications.)

down to decrease volume.

SEEK/PRESET (

/

) (2)

Information

If the SEEK/PRESET toggle switch is

Detailed information for audio control

moved up or down and held for 0.8

buttons are described in the following

second or more, it will function in the

pages in this chapter.

following modes.

5-119

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features

Infotainment System (if equipped)

Bluetooth® Wireless Technology

If your vehicle is equipped with

Hands-free (if equipped)

additional navigation, please refer to the

infotainment system manual separately

supplied.

Voice Recognition (if equipped)

OCN7050075

OCN7050081

A wide range of infotainment functions

can be commanded with voice

recognition.

If your vehicle is equipped with

additional navigation, please refer

to the infotainment system manual

OCN7050076

separately supplied.

You can use the phone wirelessly

by using the Bluetooth® Wireless

Technology.

(1) Call / Answer button

(2) Call end button

(3) LHD Microphone

(4) RHD Microphone

ś Audio : For detailed information, refer

to “AUDIO” in this chapter.

ś Navigation : Detailed information for

the Bluetooth® Wireless Technology

hands-free is described in the manual

supplied separately

5-120

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05

How Vehicle Radio Works

AM (MW, LW) reception

FM reception

OJF045309L

OJF045308L

AM broadcasts can be received at

greater distances than FM broadcasts.

AM and FM radio signals are broadcast

This is because AM radio waves are

from transmitter towers located around

transmitted at low frequencies. These

your city. They are intercepted by the

long, low frequency radio waves can

radio antenna on your vehicle. This signal

follow the curvature of the earth rather

is then received by the radio and sent to

than travelling straight out into the

your vehicle speakers.

atmosphere. In addition, they curve

When a strong radio signal has reached

around obstructions so that they can

your vehicle, the precise engineering

provide better signal coverage.

of your audio system ensures the best

possible quality reproduction. However,

in some cases the signal coming to your

vehicle may not be strong and clear.

This can be due to factors, such as

the distance from the radio station,

closeness of other strong radio stations

or the presence of buildings, bridges or

other large obstructions in the area.

5-121

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features

FM radio station

These can result in certain listening

conditions which might lead you to

believe a problem exists with your radio.

The following conditions are normal and

do not indicate radio trouble :

OJF045310L

FM broadcasts are transmitted at high

frequencies and do not bend to follow

the earth’s surface. Because of this, FM

JBM004

broadcasts generally begin to fade at

short distances from the station. Also, FM

ś Fading as your vehicle moves away

signals are easily affected by buildings,

from the radio station, the signal will

mountains, or other obstructions.

weaken and sound will begin to fade.

When this occurs, we suggest that you

select another stronger station.

ś Flutter/Static Weak FM signals or

large obstructions between the

transmitter and your radio can disturb

the signal causing static or fluttering

noises to occur. Reducing the treble

level may lessen this effect until the

disturbance clears.

5-122

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05

Using a cellular phone or a twoway

radio

When a cellular phone is used inside

the vehicle, noise may be produced

from the audio system. This does not

mean that something is wrong with the

audio equipment. In such a case, use

the cellular phone at a place as far as

possible from the audio equipment.

NOTICE

OJF045311L

ś

Station Swapping As a FM signal

When using a communication system

weakens, another more powerful

such as a cellular phone or a radio set

signal near the same frequency may

inside the vehicle, a separate external

begin to play. This is because your

antenna must be fitted. When a cellular

radio is designed to lock onto the

phone or a radio set is used with an

clearest signal. If this occurs, select

internal antenna alone, it may interfere

another station with a stronger signal.

with the vehicle’s electrical system and

adversely affect safe operation of the

ś

Multi-Path Cancellation Radio

vehicle.

signals being received from several

directions can cause distortion or

fluttering. This can be caused by a

WARNING

direct and reflected signal from the

Do not use a cellular phone while

same station, or by signals from two

stations with close frequencies. If this

driving. Stop at a safe location to use a

cellular phone.

occurs, select another station until the

condition has passed.

5-123

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06

IGNITION SWITCH

Key Ignition Switch (if equipped)

WARNING

NEVER turn the ignition switch to the

WARNING

LOCK or ACC position while the vehicle

is in motion except in an emergency.

To reduce the risk of SERIOUS INJURY or

This will result in the engine turning

DEATH, take the following precautions:

off and loss of power assist for the

ś NEVER allow children or any person

steering and brake systems. This may

who is unfamiliar with the vehicle to

lead to loss of directional control and

touch the ignition switch or related

braking function, which could cause an

parts. Unexpected and sudden

accident.

vehicle movement can occur.

Before leaving the driver's seat, always

ś NEVER reach through the steering

make sure the shift button is in P (Park)

wheel for the ignition switch, or any

position, apply the parking brake,

other control, while the vehicle is in

and turn ignition switch to the LOCK

motion. The presence of your hand

position.

or arm in this area may cause a loss

Unexpected vehicle movement may

of vehicle control resulting in an

occur if these precautions are not

accident.

followed.

ACC

ON

START

LOCK

OAE056172L

Whenever the front door is opened, the

ignition switch will illuminate, provided

the ignition switch is not in the ON

position. The light will go off immediately

when the ignition switch is turned on or

go off after about 30 seconds when the

door is closed. (if equipped)

6-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle

Key ignition switch positions

Switch

Action

Notice

Position

To turn the ignition switch to the

LOCK position, put the key in at

the ACC position and turn the key

LOCK

towards the LOCK position.

The ignition key can be removed in

the LOCK position.

Electrical accessories are usable.

ACC

The steering wheel unlocks.

This is the normal key position when

Do not leave the ignition switch in

the engine has started.

the ON position when the engine is

All features and accessories are

not running in order to prevent the

ON

usable.

battery from discharging.

The warning lights can be checked

when you turn the ignition switch

from ACC to ON.

To start the engine, turn the ignition

The engine will crank until you

switch to the START position. The

release the key.

START

switch returns to the ON position

when you let go of the key.

6-6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06

Starting the engine

Information

ś It is best to maintain a moderate engine

WARNING

speed until the vehicle engine comes

Always wear appropriate shoes when

up to normal operating temperature.

operating your vehicle.

Avoid harsh or abrupt acceleration or

Unsuitable shoes, such as high heels,

deceleration while the engine is still

ski boots, sandals, flip-flops, etc., may

cold.

interfere with your ability to use the

ś Whether the engine is cold or warm,

brake and accelerator pedals.

always start the vehicle with your foot

on the brake pedal. Do not depress the

Vehicle with manual transmission:

accelerator while starting the vehicle.

Do not rev the engine while warming

1. Make sure the parking brake is

it up.

applied.

2. Make sure the shift lever is in neutral.

NOTICE

3. Depress the clutch and brake pedals.

To prevent damage to the vehicle:

4. Turn the ignition switch to the START

position. Hold the key (maximum of

ś Do not hold the ignition key in the

10 seconds) until the engine starts and

START position for more than 10

release it.

seconds. Wait 5 to 10 seconds before

trying again.

ś Do not push or tow your vehicle to

Information

start the engine.

Depress the brake pedal and clutch pedal

until the engine starts.

Turning off the engine

1. Stop the vehicle and depress the

Vehicle with intelligent variable

transmission:

brake pedal fully.

2. Shift the gear to P (Park).

1. Make sure the parking brake is

applied.

3. Turn the ignition switch to the off

position and apply the parking brake.

2. Make sure the shift lever is in P (Park).

3. Depress the brake pedal.

4. Turn the ignition switch to the START

position. Hold the key (maximum of

10 seconds) until the engine starts and

release it.

6-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle

Engine Start/Stop Button

WARNING

(if equipped)

ś

NEVER press the Engine Start/Stop

button while the vehicle is in motion

except in an emergency. This will

result in the engine turning off and

loss of power assist for the steering

and brake systems.

This may lead to loss of directional

control and braking function, which

could cause an accident.

ś

Before leaving the driver's seat,

always make sure the shift button

is in the P (Park) position, set the

OCN7060003

parking brake, press the Engine

Whenever the front door is opened, the

Start/Stop button to the OFF

Engine Start/Stop button will illuminate

position, and take the Smart Key with

and will go off 30 seconds after the door

you. Unexpected vehicle movement

is closed. (if equipped)

may occur if these precautions are

not followed.

WARNING

ś

NEVER reach through the steering

wheel for the Engine Start/Stop

To reduce risk of serious injury or death,

button or any other control while the

NEVER allow children or any person

vehicle is in motion. The presence

who is unfamiliar with the vehicle to

of your hand or arm in this area

touch the Engine Start/Stop button or

may cause a loss of vehicle control

related parts. Unexpected and sudden

resulting in an accident.

vehicle movement can occur.

WARNING

To turn the engine off in an emergency:

Press and hold the Engine Start/Stop

button for more than two seconds OR

rapidly press and release the Engine

Start/Stop button three times (within

three seconds).

If the vehicle is still moving, you can

restart the engine without depressing

the brake pedal by pressing the Engine

Start/Stop button with the shift button

in the N (Neutral) position.

6-8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06

Engine Stop/Start button positions

Button

Action

Notice

Position

To turn off the engine, press the

Engine Start/Stop button with shift

button in P (Park).

When you press the Engine Start/

OFF

Stop button without the shift

button in P (Park), the Engine Start/

Stop button does not turn to the

OFF position, but turns to the ACC

position.

Press the Engine Start/Stop button

If you leave the Engine Start/Stop

when the button is in the OFF

button in the ACC position for more

ACC

position without depressing the

than one hour, the battery power will

brake pedal.

turn off automatically to prevent the

Electrical accessories are usable.

battery from discharging.

Press the Engine Start/Stop button

Do not leave the Engine Start/Stop

while it is in the ACC position

button in the ON position when the

ON

without depressing the brake pedal.

engine is not running to prevent the

The warning lights can be checked

battery from discharging.

before the engine is started.

To start the engine, depress the

If you press the Engine Start/Stop

brake pedal and press the Engine

button without depressing the brake

Start/Stop button with the shift

pedal, the engine does not start

button in the P (Park) or in the N

and the Engine Start/Stop button

(Neutral) position.

changes as follows:

START

For your safety, start the engine

2)) Ɵ $&& Ɵ 21 Ɵ 2)) RU $&&

with the shift button in the P (Park)

However, the engine may start if you

position.

depress the brake pedal within 0.5

second after pressing the Engine

Start/Stop button from the OFF

position.

6-9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle

Starting the engine

Vehicle with manual transmission:

1. Always carry the smart key with you.

2. Make sure the parking brake is

WARNING

applied.

ś

Always wear appropriate shoes when

3. Make sure the shift lever is in neutral.

operating your vehicle.

4. Depress the clutch and brake pedals.

Unsuitable shoes, such as high heels,

ski boots, sandals, flip-flops, etc.,

5. Press the Engine Start/Stop button.

may interfere with your ability to use

the brake and accelerator pedals.

Information

ś

Do not start the vehicle with the

accelerator pedal depressed. The

Depress the brake pedal and clutch pedal

vehicle can move and lead to an

until the engine starts.

accident.

Vehicle with intelligent variable

ś

Wait until the engine rpm is normal.

transmission:

The vehicle may suddenly move if

the brake pedal is released when the

1. Always carry the smart key with you.

rpm is high.

2. Make sure the parking brake is

applied.

Information

3. Make sure the shift lever is in P (Park).

4. Depress the brake pedal.

ś

The engine will start by pressing the

Engine Start/Stop button, only when

5. Press the Engine Start/Stop button.

the smart key is in the vehicle.

ś

Even if the smart key is in the vehicle,

Information

if it is far away from the driver, the

engine may not start.

ś Do not wait for the engine to warm up

while the vehicle remains stationary.

ś

When the Engine Start/Stop button

Start driving at moderate engine

is in the ACC or ON position, if any

speeds. (Aggressive accelerating and

door is open, the system checks for the

decelerating should be avoided.)

smart key. If the smart key is not in the

vehicle, the “

” indicator will blink

ś Always start the vehicle with your foot

and the warning "Key not in vehicle"

on the brake pedal. Do not depress the

will come on and if all doors are closed,

accelerator while starting the vehicle.

the chime will also sound for about

Do not rev the engine while warming

5 seconds. Keep the smart key in the

it up.

vehicle when using the ACC position or

if the vehicle engine is ON.

6-10

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06

NOTICE

To prevent damage to the vehicle:

ś If the engine stalls while you are in

motion, do not attempt to move the

shift button to the P (Park) position.

If traffic and road conditions permit,

you may put the shift button in the N

(Neutral) position while the vehicle

is still moving and press the Engine

Start/Stop button in an attempt to

restart the engine.

OCN7060004L

ś Do not push or tow your vehicle to

start the engine.

Information

If the smart key battery is weak or the

NOTICE

smart key does not work correctly, you

To prevent damage to the vehicle:

can start the engine by pressing the Engine

When the stop lamp switch fuse is

Start/Stop button with the smart key in

blown, you can't start the engine

the direction of the picture above.

normally. Replace the fuse with a new

one. If you are not able to replace

the fuse, you can start the engine by

pressing and holding the Engine Start/

Stop button for 10 seconds with the

Engine Start/Stop button in the ACC

position.

Do not press the Engine Start/Stop

button for more than 10 seconds except

when the stop lamp switch fuse is

blown.

For your safety always depress the

brake pedal before starting the engine.

6-11

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle

9(+,&/( $872ǘ6+87 2)) ǣ,) (48,33('Ǥ

If your vehicle is parked and the engine

System Operation

is left on for a long period of time, the

engine will turn off automatically to help

reduce fuel consumption and prevent

accidents caused by carbon dioxide

poisoning.

Operating Conditions

Vehicle Auto-Shut Off timer operates

when all the following conditions are

satisfied:

ś Vehicle speed is below 1.8 mph (3

km/h), and the gear is shifted to P

OJK041087N

(Park)

When all the conditions are satisfied, the

ś The brake pedal and accelerator pedal

Vehicle Auto-Shut Off operates and turns

are not depressed

the engine off automatically after 60

minutes.

ś The driver’s seat belt is unfastened

A timer appears on the instrument

ś The passenger seat is empty

cluster 30 minutes before vehicle shut

ś The infotainment system is not being

off.

updated

Resetting cluster timer

Deactivating Conditions

To reset the cluster timer, do one of

Vehicle Auto-Shut Off timer turns off

following:

when one of the situation occur:

ś Release the accelerator pedal or brake

ś Vehicle speed is above 1.8 mph (3

pedal after Vehicle Auto-Shut Off is

km/h)

complete.

ś The gear is shifted to R (Reverse), D

ś Press the OK button on the steering

(Drive) or N (Neutral)

wheel while the timer appears on the

ś The brake pedal or accelerator pedal

instrument cluster.

is depressed

ś The driver’s seat belt is fastened

CAUTION

ś A passenger is in the passenger’s seat

Do not leave a passenger or a pet in

the vehicle in hot weather since the air

conditioning system turns off when the

engine is off.

6-12

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06

0$18

$/ 75$160,66,21 ǣ,) (48,33('Ǥ

„ Type A

Manual Transmission Operation

The manual transmission has 6

forward gears. The transmission is fully

synchronized in all forward gears so

shifting to either a higher or a lower gear

is easily accomplished.

WARNING

ś Before leaving the driver’s seat,

always make sure the shift lever is in

OCN7060009

1st gear when the vehicle is parked

„ Type B (N Line)

on a uphill and in R (Reverse) on

a downhill, set the parking brake,

and place the ignition switch in the

LOCK/OFF position. Unexpected

vehicle movement may occur if these

precautions are not followed.

ś When parking on an incline, block

the wheels to prevent the vehicle

from rolling down.

To shift to R (Reverse), make sure the

OCN7N060001

vehicle has completely stopped, and

The shift lever can be moved without

then move the shift lever to neutral

pressing the button (1).

before moving into R (Reverse).

The button (1) must be pressed while

moving the shift lever.

When you've come to a complete stop

and it's hard to shift into 1st gear or R

(Reverse):

1. Put the shift lever in neutral and

release the clutch pedal.

2. Depress the clutch pedal, and then

shift into first or R (Reverse) gear.

Information

During cold weather, shifting may be

difficult until the transmission lubricant

has warmed up.

6-13

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving Your Vehicle

,17(//,*(17 9

$5,$%/( 75$160,66,21 ǣ,) (48,33('Ǥ

„ Left-hand drive

„ Right-hand drive

OCN7060006

OCN7060006R

Depress the brake pedal and press the shift button while moving the shift lever.

Press the shift button while moving the shift lever.

The shift lever can freely operate.

Intelligent Variable Transmission Operation

The Intelligent Variable Transmission (IVT) automatically shifts depending on speed

and accelerate pedal position. The individual speeds are selected automatically,

depending on the position of the shift lever.

6-16

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

06

OCN7060007

OCN7060008

DS mode (Drive Sporty)

Manual shift mode

ś To shift into Ds mode, move the shift

Whether the vehicle is stationary or in

lever from D (Drive) to the center of

motion, manual shift mode is selected by

the manual shift mode. The engine

pushing the shift lever from the D (Drive)

and transmission control logic is

position into the manual gate. To return

automatically optimized for sporty

to D (Drive) range operation, push the

driving.

shift lever back into the main gate.

ś In Ds mode, if you move the shift

In manual shift mode, moving the shift

lever to + (up) or (down), the gear

lever backwards and forwards will allow

will change to manual shift mode.

you to select the desired range of gears

If the shift lever is moved back into

for the current driving conditions.

D (Drive), it will change to D (Drive).

+ (Up) : Push the lever forward once to

The vehicle will perform according to

shift up one gear.

the mode selected from drive mode

- (Down) : Pull the lever backwards

(NORMAL, SPORT, SMART).

once to shift down one gear.

6-19

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Content      ..     7      8      9      10     ..
