When the ECO mode is activated:

Limitation of the ECO mode oper-

SPORT mode

ation:

• The acceleration response may be

SPORT mode manages

slightly reduced as the accelerator

If the following conditions occur while

the driving dynamics by

pedal is depressed moderately.

the ECO mode is operating, the sys-

automatically adjusting the

tem operation is limited even though

steering effort, the engine

• The air conditioner performance

there is no change in the ECO indi-

and transmission control logic for

may be limited.

cator.

enhanced driver performance.

• The shift pattern of the automatic

transmission may change.

•

When the coolant temperature is

•

When SPORT mode is selected by

low:

pressing the DRIVE MODE button,

• The engine noise may get louder.

The system will be limited until

the SPORT indicator

(orange

color) will illuminate.

engine performance becomes nor-

The above situations are normal

mal.

•

Whenever the engine is restarted,

conditions when the ECO mode is

the Drive Mode will revert back to

•

When driving up a hill:

activated to improve fuel efficiency.

NORMAL mode. If SPORT mode is

5

The system will be limited to gain

desired, re-select SPORT mode

power when driving uphill because

from the DRIVE MODE button.

engine torque is restricted.

•

When SPORT mode is activated:

•

When driving the vehicle with the

- The engine rpm will tend to

automatic transmission or the dual

clutch transmission gear shift lever

remain raised over a certain

length of time even after releas-

in manual shift mode:

ing the accelerator

The system will be limited accord-

- Upshifts are delayed when accel-

ing to the shift location.

erating

•

When the accelerator pedal is

deeply depressed for a few sec-

onds:

i

Information

The system will be limited, judging

In SPORT mode, the fuel efficiency

that the driver wants to speed up.

may decrease.

5-61

Driving your vehicle

BLIND SPOT DETECTION SYSTEM (BSD) (IF EQUIPPED)

(1) BSD (Blind Spot Detection)

WARNING

The blind spot detection range

varies relative to vehicle speed.

•

Always be aware of road con-

Blind spot area

Note that if your vehicle is travel-

ditions while driving and be

ing much faster than the vehicles

alert for unexpected situations

around you, the warning will not

even though the Blind Spot

occur.

Detection System is operat-

(2) LCA (Lane Change Assist)

ing.

Closing at high speed

The Lane Change Assist feature

•

The Blind Spot Detection

will alert you when a vehicle is

System (BSD) is a supplemen-

approaching in an adjacent lane

tal system to assist you. Do

at a high rate of speed. If the driv-

not entirely rely on the sys-

er activates the turn signal when

tem. Always pay attention,

the system detects an oncoming

while driving, for your safety.

vehicle, the system sounds an

•

The Blind Spot Detection

audible alert.

System (BSD) is not a substi-

(3) RCTA (Rear Cross Traffic Alert)

tute for proper and safe driving.

OTL055139

The Rear Cross Traffic Alert fea-

Always drive safely and use

The Blind Spot Detection System

ture monitors approaching cross

caution when changing lanes

(BSD) uses radar sensors in the rear

traffic from the left and right side

or backing up the vehicle. The

bumper to monitor and warn the driv-

of the vehicle when your vehicle is

Blind Spot Detection System

er of an approaching vehicle in the

in reverse. The feature will operate

(BSD) may not detect every

driver's blind spot area.

when the vehicle is moving in

object alongside the vehicle.

The system monitors the rear area of

reverse below about 10 km/h (6

the vehicle and provides information

mph). If oncoming cross traffic is

to the driver with an audible alert and

detected a warning chime will

a indicator on the outside side view

sound.

mirrors.

5-62

BSD (Blind Spot Detection) /

To operate:

Operating conditions

LCA (Lane Change Assist)

Press the BSD switch with the

The system will activate when:

Ignition switch in the ON position.

Operating conditions

1. The system is on.

■ Left-hand drive

The indicator on the BSD switch will

2. The vehicle speed is above about

illuminate. When the vehicle speed

30 km/h (20 mph).

exceeds 30 km/h (20 mph), the sys-

3.

An oncoming vehicle is detected

tem will be activated.

in the blind spot area.

To cancel:

Press the BSD switch again. The

indicator on the switch will go off.

When the system is not used, turn the

OAD055027

system off by turning off the switch.

5

■ Right-hand drive

i

Information

• If the engine is turned off then on

again, the BSD system returns to the

previous state.

• When the system is turned on, the

warning light will illuminate for 3

seconds on the outside rearview

mirror.

OAD055027R

5-63

Driving your vehicle

■ Left side

■ Left side

■ Right side

■ Right side

OAD055028

OAD055029

OAD055030

First stage alert

Second stage alert

If a vehicle is detected within the

A warning chime to alert the driver will activate when:

boundary of the system, a warning

1. A vehicle has been detected in the blind spot area by the radar system

light will illuminate on the outside

(the warning light will illuminate on the outside rearview mirror) AND

rearview mirror.

2. The turn signal is applied (same side as where the vehicle is being

Once the detected vehicle is no

detected).

longer within the blind spot area, the

When this alert is activated, the warning light on the outside rearview mir-

warning will turn off according to the

ror will also blink.

driving conditions of the vehicle.

If you turn off the turn signal indicator, the warning chime will be deacti-

vated.

5-64

• The second stage alarm may be

Detecting sensor

Warning message

deactivated.

■ Type A

■ Type B

- To activate the warning chime:

Go to the User Settings Mode →

Sound and select "BSD" on the

LCD display.

- To deactivate the warning chime:

Go to the User Settings Mode →

Sound and deselect "BSD" on the

LCD display.

i

Information

OAD055031

OAD055090L/OLF054217N

The warning chime function helps

5

alert the driver. Deactivate this func-

The sensors are located inside the

BSD canceled

tion only when it is necessary

rear bumper.

• This warning message may appear

Always keep the rear bumper clean

when :

for proper operation of the system.

- One or both of the sensors on the

rear bumper is blocked by dirt or

snow or a foreign object.

- Driving in rural areas where the

BSD sensor does not detect

another vehicle for an extended

period of time.

- When there is inclement weather

such as heavy snow or rain.

If any of these conditions occur, the

light on the BSD switch and the sys-

tem will turn off automatically.

5-65

Driving your vehicle

When the BSD canceled warning

■ Type A

■ Type B

RCTA (Rear Cross Traffic Alert)

message is displayed in the cluster,

(if equipped)

check to make sure that the rear

The Rear Cross Traffic Alert feature

bumper is free from any dirt or snow

monitors approaching cross traffic

in the areas where the sensor is

from the left and right side of the

located. Remove any dirt, snow, or

vehicle when your vehicle is in

foreign material that could interfere

reverse.

with the radar sensors.

After any dirt or debris is removed,

the BSD system should operate nor-

mally after about 10 minutes of driv-

ing the vehicle.

OAD055091L/OTLE055040

If the system still does not operate

Check BSD system

normally have your vehicle inspected

If there is a problem with the BSD

by an authorized HYUNDAI dealer.

system, a warning message will

appear and the light on the switch

will turn off. The system will turn off

automatically. We recommend that

you have your vehicle inspected by

an authorized HYUNDAI dealer.

5-66

Operating conditions

Warning type

i

Information

■ Type A

■ Type B

The Rear Cross Traffic Alert (RCTA)

■ Left

• Type A

• Type B

detecting range is approximately

0.5 m

~ 20 m (1 ft

~ 65 ft). An

approaching vehicle will be detected if

their vehicle speed is within 4 km/h ~

36 km/h (2.5 ~ 22.5 mph ).

Note that the detecting range may

vary under certain conditions. As

always, use caution and pay close

attention to your surroundings when

OAD055046L/OAD055048L

backing up your vehicle.

■ Right

OAD055092L/OAD055093L

• Type A

• Type B

5

To operate:

Go to the User Settings mode

(Driving Assist) and select Rear

Cross Traffic Alert on the LCD dis-

play

(For more details, refer to

"LCD Display" in chapter 3.). The

system will turn on and standby to

activate. The system will activate

when vehicle speed is below 10 km/h

OAD055047L/OAD055049L

(6.2 mph) and with the shift lever in R

If the vehicle detected by the sensors

(Reverse).

approaches your vehicle, the warn-

ing chime will sound, the warning

light on the outside rearview mirror

will blink and a message will appear

on the LCD display.

5-67

Driving your vehicle

i

Information

(Continued)

WARNING

•

The warning chime will turn off

•

The Blind Spot Detection

when the detected vehicle moves out

•

The warning light on the out-

System (BSD) and Rear Cross

of the sensing area or if your vehicle

side rearview mirror will illu-

Traffic Alert (RCTA) are not a

is moved away from the detected

minate whenever a vehicle is

substitute for proper and safe

vehicle.

detected at the rear side by

driving practices. Always

the system.

drive safely and use caution

•

The system may not operate proper-

when changing lanes or back-

ly due to other factors or circum-

To avoid accidents, do not

stances. Always pay attention to

focus only on the warning

ing up your vehicle. The Blind

Spot Detection System (BSD)

your surrounding.

light and neglect to see the

surrounding of the vehicle.

may not detect every object

•

If the sensing area near the rear

alongside the vehicle.

bumper is blocked by either a wall

•

Drive safely even though the

or barrier or by a parked vehicle,

vehicle is equipped with a

the system sensing area may be

Blind Spot Detection System

reduced.

(BSD) and Rear Cross Traffic

Alert

(RCTA). Do not solely

rely on the system but check

your surrounding before

changing lanes or backing the

vehicle up.

The system may not alert the

driver in some conditions so

always check your surround-

ings while driving.

(Continued)

5-68

NOTICE

Non-operating condition

Limitations of the system

The BSD indicator on the outer side

The driver must be cautious in the

•

The system may not work prop-

view mirror may not illuminate

below situations, because the sys-

erly when the bumper has been

properly when:

tem may not detect other vehicles or

damaged, or if the rear bumper

-

The outside rearview mirror hous-

objects in certain circumstances.

has been replaced or repaired.

ing is damaged.

•

The sensing range differs some-

-

The mirror is covered with dirt,

what according to the width of

- The vehicle drives on a curved road

the road. When the road is nar-

snow, or debris.

or through a tollgate.

row, the system may detect

-

The window is covered with dirt,

- The sensor is polluted with rain,

other vehicles in the next lane.

snow, or debris.

snow, mud, etc.

•

The system may turn off due to

-

The window is tinted.

- The rear bumper where the sensor

strong electromagnetic waves.

is located is covered with a foreign

object such as a bumper sticker, a

5

bumper guard, a bike stand, etc.

- The rear bumper is damaged, or

the sensor is out of the original

default position.

- The vehicle height gets lower or

higher due to heavy loading in a

trunk, abnormal tire pressure, etc.

- The vehicle drives in inclement

weather such as heavy rain or

snow.

- There is a fixed object near the

vehicle, such as a guardrail.

- A big vehicle is near such as a bus

or truck.

5-69

CRUISE CONTROL (IF EQUIPPED)

Cruise Control operation

The Cruise Control system allows you

(Continued)

to drive at speeds above 30 km/h

■ Type A

(20 mph) without depressing the

• Do not use the Cruise Control

accelerator pedal.

when it may be unsafe to keep

the vehicle at a constant

speed:

WARNING

- When driving in heavy traffic

or when traffic conditions

Take the following precautions:

make it difficult to drive at a

•

If the Cruise Control is left on,

constant speed

(CRUISE indicator light in the

- When driving on rainy, icy, or

instrument cluster is illumi-

snow-covered roads

OAD055035

nated) the Cruise Control can

■ Type B

- When driving on hilly or

be activated unintentionally.

windy roads

Keep the Cruise Control sys-

5

tem off

(CRUISE indicator

- When driving in windy areas

light OFF) when the Cruise

Control is not in use, to avoid

NOTICE

inadvertently setting a speed.

•

Use the Cruise Control system

During cruise-speed driving of a

only when traveling on open

manual transmission vehicle, do

highways in good weather.

not shift into neutral without

depressing the clutch pedal, since

OAD055085L

(Continued)

the engine will be overrevved. If

1. CRUISE indicator

this happens, depress the clutch

2. SET indicator

pedal or press the cruise control

ON / OFF button.

5-71

Driving your vehicle

■ Type A

To set Cruise Control speed

i

Information

■ Type A

• During normal cruise control opera-

tion, when the SET switch is activat-

ed or reactivated after applying the

brakes, the cruise control will ener-

gize after approximately 3 seconds.

This delay is normal.

• Before activating the cruise control

function, the system will check to

verify that the brake switch is oper-

OAD055088L

■ Type B

ating normally. Depress the brake

OAD055019

pedal at least once after turning ON

■ Type B

the ignition or starting the engine.

OAD055089L

Cruise control switch

OAD055019L

CANCEL/O : Cancels cruise control

operation.

1. Press the CRUISE /

button on

CRUISE /

: Turns cruise control

the steering wheel to turn the sys-

system on or off.

tem on. The CRUISE indicator will

RES+: Resumes or increases cruise

illuminate.

control speed.

SET-: Sets or decreases cruise con-

trol speed.

5-72

2. Accelerate to the desired speed,

■ Type A

i

Information

which must be more than 30 km/h

(20 mph).

On a steep slope, the vehicle may

slightly slow down or speed up, while

driving uphill or downhill.

i

Information - Manual trans-

mission

For manual transmission vehicles, you

should depress the brake pedal at

least once to set the cruise control

after starting the engine.

OAD055020

■ Type B

5

OAD055020L

3. Push the toggle switch (1) down

(SET -), and release it. The SET

indicator light will illuminate.

4. Release the accelerator pedal.

5-73

Driving your vehicle

To increase Cruise Control

Release the toggle switch when

To decrease Cruise Control

speed

the desired speed is shown and

speed

the vehicle will accelerate to that

■ Type A

■ Type A

speed.

• Push the toggle switch

(1) up

(RES+) and release it immediately.

The cruising speed will increase

2.0 km/h (1.2 mph) each time the

toggle switch is operated in this

manner.

• Depress the accelerator pedal.

When the vehicle attains the

OAD055021

desired speed, push the toggle

OAD055020

■ Type B

switch (1) down (SET-).

■ Type B

OAD055021L

OAD055020L

• Push the toggle switch

(1) up

• Push the toggle switch (1) down

(RES+) and hold it, while monitor-

(SET-) and hold it. Your vehicle will

ing the SET speed on the instru-

gradually slow down. Release the

ment cluster.

toggle switch at the speed you

want to maintain.

5-74

• Push the toggle switch (1) down

To temporarily accelerate with

Cruise Control will be canceled

(SET-) and release it immediately.

the Cruise Control ON

when:

The cruising speed will decrease

Depress the accelerator pedal. When

■ Type A

2.0 km/h (1.2 mph) each time the

you take your foot off the accelerator,

toggle switch is operated in this

the vehicle will return to the previ-

manner.

ously set speed.

• Lightly tap the brake pedal. When

If you push the toggle switch down

the vehicle attains the desired

(SET-) at the increased speed, the

speed, push the toggle switch (1)

Cruise Control will maintain the

down (SET-).

increased speed.

OAD055022

■ Type B

5

OAD055022L

• Depressing the brake pedal.

• Depressing the clutch pedal.

(for manual transmission vehicle)

5-75

Driving your vehicle

•

Pressing the CANCEL / O button

To resume preset Cruising

i

Information

located on the steering wheel.

speed

Each of the above actions will cancel

•

Pressing the CRUISE /

button.

Cruise Control operation

(the SET

■ Type A

Both the CRUISE indicator and the

indicator light in the instrument clus-

SET indicator will turn OFF.

ter will go off), but only pressing the

•

Moving the shift lever into N

CRUISE button will turn the system

(Neutral). (for automatic transmis-

off. If you wish to resume Cruise

sion/dual clutch transmission)

Control operation, push the toggle

•

Decreasing the vehicle speed

switch up

(RES+) located on your

lower than the speed by 20 km/h

steering wheel. You will return to your

(12 mph).

previously preset speed, unless the sys-

tem was turned off using the CRUISE

•

Decreasing the vehicle speed to

button.

OAD055021

less than approximately 30 km/h

■ Type B

(20 mph).

•

The ESC

(Electronic Stability

Control) is operating.

•

Downshifting to 2nd gear when in

Manual Shift mode.

OAD055021L

Push the toggle switch

(1) up

(RES+). If the vehicle speed is over

30 km/h (20 mph), the vehicle will

resume the preset speed.

5-76

To turn Cruise Control off

■ Type A

OAD055019

■ Type B

5

OAD055019L

• Press the CRUISE /

button (the

CRUISE indicator light will go off).

• Turn the engine OFF.

5-77

Content   ..  24  25  26  27   ..
