Hyundai Elantra (2017 year). Instruction - part 24
In manual shift mode, moving the
(Continued)
shift lever backwards and forwards
•
If the driver presses the lever to
will allow you to select the desired
+ (Up) or - (Down) position, the
range of gears for the current driving
transmission may not make the
conditions.
requested gear change if the next
+ (Up) : Push the lever forward once
gear is outside of the allowable
+ (UP)
to shift up one gear.
engine rpm range. The driver must
execute upshifts in accordance with
- (Down) : Pull the lever backwards
road conditions, taking care to keep
once to shift down one
- (DOWN)
the engine rpms below the red zone.
gear.
•
When driving on a slippery road,
OAD055006
push the shift lever forward into the
i
Information
Manual shift mode
+ (Up) position. This causes the
• Only the six forward gears can be
transmission to shift into the
2nd
Whether the vehicle is stationary or
5
selected. To reverse or park the
gear which is better for smooth driv-
in motion, manual shift mode is
vehicle, move the shift lever to the R
ing on a slippery road. Push the shift
selected by pushing the shift lever
(Reverse) or P (Park) position as
lever to the - (Down) side to shift
from the D (Drive) position into the
required.
back to the 1st gear.
manual gate. To return to D (Drive)
range operation, push the shift lever
• Downshifts are made automatically
•
When driving in manual shift mode,
back into the main gate.
when the vehicle slows down. When
slow down before shifting to a lower
the vehicle stops, 1st gear is automat-
gear. Otherwise, the lower gear may
ically selected.
not be engaged if the engine rpms
• When the engine rpm approaches
are outside of the allowable range.
the red zone the transmission will
upshift automatically.
(Continued)
5-27
Driving your vehicle
Shift-lock system
■ Type A
■ Type B
For your safety, the automatic trans-
mission has a shift-lock system
which prevents shifting the transmis-
sion from P (Park) into R (Reverse)
unless the brake pedal is depressed.
To shift the transmission from P
(Park) into R (Reverse):
1. Depress and hold the brake pedal.
2. Start the engine or place the igni-
tion switch in the ON position.
OAD055007
OAD055084L
3. Move the shift lever.
1. Place the ignition switch in the
1. Place the ignition switch in the
LOCK/OFF position.
LOCK/OFF position.
Shift-lock release
2. Apply the parking brake.
2. Apply the parking brake.
If the shift lever cannot be moved
3. Push the shift-lock release button.
3. Carefully remove the cap (1) cov-
from the P (Park) position into R
ering the shift-lock access hole.
4. Move the shift lever while pushing
(Reverse) position with the brake
the shift-lock release button.
4. Insert a tool (e.g. flathead screw-
pedal depressed, continue depress-
driver) into the access hole and
5. Stop pushing the shift-lock release
ing the brake, and then do the follow-
press down on the tool.
button.
ing:
5. Move the shift lever while holding
6. Depress the brake pedal, and then
down the screwdriver.
restart the engine.
6. Remove the tool from the shiftlock
release access hole then install
If you need to use the shift-lock
the cap.
release, we recommend that the sys-
tem be inspected by an authorized
7. Depress the brake pedal, and then
restart the engine.
HYUNDAI dealer immediately.
5-28
If you need to use the shift-lock
Parking
Good driving practices
release, we recommend that the sys-
Always come to a complete stop and
•
Never move the shift lever from P
tem be inspected by an authorized
continue to depress the brake pedal.
(Park) or N (Neutral) to any other
HYUNDAI dealer immediately.
Move the shift lever into the P (Park)
position with the accelerator pedal
position, apply the parking brake,
depressed.
Ignition key interlock system
and place the ignition switch in the
•
Never move the shift lever into P
(if equipped)
LOCK/OFF position. Take the Key
(Park) when the vehicle is in
with you when exiting the vehicle.
The ignition key cannot be removed
motion.
unless the shift lever is in the P
Be sure the vehicle is completely
(Park) position.
WARNING
stopped before you attempt to shift
into R (Reverse) or D (Drive).
When you stay in the vehicle
•
Do not move the shift lever to N
with the engine running, be
(Neutral) when driving. Doing so
careful not to depress the accel-
may result in an accident because
5
erator pedal for a long period of
of a loss of engine braking and the
time. The engine or exhaust
transmission could be damaged.
system may overheat and start
•
Do not drive with your foot resting
a fire.
on the brake pedal. Even light, but
The exhaust gas and the
consistent pedal pressure can
exhaust system are very hot.
result in the brakes overheating,
Keep away from the exhaust
brake wear and possibly even
system components.
brake failure.
Do not stop or park over flam-
mable materials, such as dry
grass, paper or leaves. They
may ignite and cause a fire.
5-29
Driving your vehicle
•
Always apply the parking brake
WARNING
(Continued)
when leaving the vehicle. Do not
depend on placing the transmis-
•
In the event your vehicle
To reduce the risk of SERIOUS
leaves the roadway, do not
sion in P (Park) to keep the vehicle
INJURY or DEATH:
steer sharply. Instead, slow
from moving.
•
ALWAYS wear your seatbelt.
down before pulling back into
•
Exercise extreme caution when
In a collision, an unbelted
the travel lanes.
driving on a slippery surface. Be
occupant is significantly more
•
HYUNDAI recommends you
especially careful when braking,
likely to be seriously injured
follow all posted speed limits.
accelerating or shifting gears. On a
or killed than a properly belt-
slippery surface, an abrupt change
ed occupant.
in vehicle speed can cause the
drive wheels to lose traction and
•
Avoid high speeds when cor-
may cause loss of vehicle control
nering or turning.
resulting in an accident
•
Do not make quick steering
•
Optimum vehicle performance and
wheel movements, such as
economy is obtained by smoothly
sharp lane changes or fast,
depressing and releasing the
sharp turns.
accelerator.
•
The risk of rollover is greatly
increased if you lose control
of your vehicle at highway
speeds.
•
Loss of control often occurs if
two or more wheels drop off
the roadway and the driver
over steers to reenter the
roadway.
(Continued)
5-30
DUAL CLUTCH TRANSMISSION (IF EQUIPPED)
■ Left-hand drive
■ Right-hand drive
Manual shift mode
Manual shift mode
5
Depress the brake pedal and press the shift button while moving the shift lever.
Press the shift button while moving the shift lever.
The shift lever can freely operate.
OAD055005/OAD055005R
Dual clutch transmission operation
The dual clutch transmission has seven forward speeds and one reverse speed.
The individual speeds are selected automatically in the D (Drive) position.
5-31
Driving your vehicle
•
The dual clutch transmission incor-
WARNING
(Continued)
porates a dry-type dual clutch
• Do not use the engine brake
mechanism, which allows for better
To reduce the risk of serious
(shifting from a high gear to
acceleration performance and
injury or death:
lower gear) rapidly on slip-
increased fuel efficiency while driv-
•
ALWAYS check the surround-
pery roads. The vehicle may
ing. But it differs from a conven-
ing areas near your vehicle for
slip causing an accident.
tional automatic transmission in
people, especially children,
that it does not incorporate a
before shifting a vehicle into
torque converter. Instead, the tran-
D (Drive) or R (Reverse).
•
The dual clutch transmission gives
sition from one gear to the next is
the driving feel of a manual trans-
managed by clutch slip, especially
•
Before leaving the driver's
mission, yet provides the ease of a
at lower speeds. As a result, shifts
seat, always make sure the
fully automatic transmission. Unlike
are sometimes more noticeable,
shift lever is in the P (Park)
a traditional automatic transmis-
and a light vibration can be felt as
position, then set the parking
sion, the gear shifting can some-
the transmission shaft speed is
brake, and place the ignition
times be felt and heard on the dual
matched with the engine shaft
switch in the LOCK/OFF posi-
clutch transmission, as the actua-
speed. This is a normal condition of
tion. Unexpected and sudden
tors engage the clutch and the
the dual clutch transmission.
vehicle movement can occur
gear is selected.
if these precautions are not
•
The dry-type clutch transfers
followed.
The dual clutch transmission can
torque more directly and provides
be thought of as an automatically
a direct-drive feeling which may
(Continued)
shifting manual transmission.
feel different from a conventional
When D (Drive) is selected, the
automatic transmission. This may
transmission will automatically shift
be more noticeable when launch-
through the gears similar to a con-
ing the vehicle from a stop or when
ventional automatic transmission.
traveling at low, stop-and-go vehi-
cle speeds.
5-32
•
When rapidly accelerating from a
•
When driving downhill, you may
NOTICE
lower vehicle speed, the engine
wish to move the gear shift lever to
rpm may increase dramatically as
Manual Shift mode and downshift
■ Type A
■ Type B
a result of clutch slip as the dual
to a lower gear in order to control
clutch transmission selects the cor-
your speed without using the brake
rect gear. This is a normal condi-
pedal excessively.
tion.
•
When you turn the engine on and
•
When accelerating from a stop on
off, you may hear clicking sounds
an incline, press the accelerator
as the system goes through a self
smoothly and gradually to avoid
test. This is a normal sound for the
any shudder feeling or jerkiness.
dual clutch transmission.
•
When traveling at a lower vehicle
speed, if you release the accelera-
OTLE055019/OTLE055018
tor pedal quickly, you may feel
5
engine braking before the trans-
•
To hold the vehicle on a hill use
mission changes gears. This
the foot brake or the parking
engine braking feeling is similar to
brake. If the vehicle is held by
operating a manual transmission at
applying the accelerator pedal
low speed.
on a hill the clutch and trans-
mission will be overheated
resulting in damage.
At this time, a warning message
will appear on the LCD display
and you may feel a vibration.
(Continued)
5-33
Driving your vehicle
(Continued)
(Continued)
(Continued)
•
If the clutch becomes overheat-
■ Type A
■ Type B
If the safe protection mode logic
ed by excessive use of the
is enabled, the gear position
clutch to hold on a hill, you may
indicator on the cluster blinks
notice a shudder feeling and a
with a chime sound. At this time,
blinking display on the instru-
a warning message will appear
ment cluster. When this occurs,
on the LCD display and driving
the clutch is disabled until the
may not be smooth.
clutch cools to normal tempera-
If you ignore this warning, the
tures. If this occurs, pull over to
driving condition may become
a safe location, shift into P
worse. To return the normal driv-
(Park) and apply the foot brake
OTLE055022/OTLE055023
ing condition, stop the vehicle
for a few minutes.
■ Type A
■ Type B
and apply the foot brake for a
•
If the LCD warning is active, the
few minutes before driving off.
foot brake must be applied.
•
Gear shifts may be more notice-
•
Ignoring the warnings can lead
able than a conventional auto-
to damage to the transmission.
matic transmission. This is a
normal characteristic of this
•
If the display continues to blink,
type of dual clutch transmis-
for your safety, we recommend
sion.
that you contact an authorized
HYUNDAI dealer and have the
(Continued)
system checked.
OTLE055026/OTLE055027
(Continued)
•
Under certain conditions, such
as repeated stop-and-go launch-
es on steep grades, the trans-
mission clutches may overheat.
When the clutches are overheat-
ed, the transmission safe pro-
tection mode logic is enabled.
(Continued)
5-34
(Continued)
Shift lever position
WARNING
•
During the first 1,500 km (1,000
The indicator in the instrument clus-
miles), you may feel that the
ter displays the shift lever position
•
Shifting into P (Park) while the
vehicle may not be smooth
when the ignition switch is in the ON
vehicle is in motion may
when accelerating at low speed.
position.
cause you to lose control of
During this break-in period, the
the vehicle.
shift quality and performance of
P (Park)
•
After the vehicle has stopped,
your new vehicle is continuous-
ly optimized.
Always come to a complete stop
always make sure the shift
before shifting into P (Park).
lever is in P (Park), apply the
•
Always come to a complete stop
parking brake, and turn the
before shifting into D (Drive) or
To shift from P
(Park), you must
engine off.
R (Reverse).
depress firmly on the brake pedal
and make sure your foot is off the
•
Do not use the P (Park) posi-
•
Do not put the shift lever in N
accelerator pedal.
tion in place of the parking
(Neutral) while driving.
5
brake.
If you have done all of the above
and still cannot shift the lever out
of P
(Park), see "Shift-Lock
Release" in this chapter.
The shift lever must be in P (Park)
before turning the engine off.
5-35
Driving your vehicle
R (Reverse)
D (Drive)
Use this position to drive the vehicle
This is the normal driving position.
backward.
The transmission will automatically
shift through a 7-gear sequence, pro-
NOTICE
viding the best fuel economy and
power.
Always come to a complete stop
+ (UP)
For extra power when passing anoth-
before shifting into or out of R
er vehicle or driving uphill, depress
(Reverse); you may damage the
the accelerator fully. The transmis-
transmission if you shift into R
- (DOWN)
sion will automatically downshift to
(Reverse) while the vehicle is in
the next lower gear
(or gears, as
motion.
OAD055006
appropriate).
The DRIVE MODE switch, located on
Manual shift mode
N (Neutral)
the shift lever console, allows the driv-
Whether the vehicle is stationary or
The wheels and transmission are not
er to switch from NORMAL mode to
in motion, manual shift mode is
engaged.
ECO or SPORT mode. (if equipped)
selected by pushing the shift lever
from the D (Drive) position into the
Use N (Neutral) if you need to restart
For more information, refer to
manual gate. To return to D (Drive)
a stalled engine, or if it is necessary
"Drive Mode Integrated Control
range operation, push the shift lever
to stop with the engine ON. Shift into
System" later in this chapter.
back into the main gate.
P (Park) if you need to leave your
vehicle for any reason.
In manual shift mode, moving the shift
Always depress the brake pedal
lever backwards and forwards will
when you are shifting from N
allow you to make gearshifts rapidly.
(Neutral) to another gear.
Up (+)
: Push the lever forward
once to shift up one gear.
Down (-) : Pull the lever backwards
once to shift down one
gear.
5-36
(Continued)
Shift-lock system
i
Information
•
When driving on a slippery road,
For your safety, the dual clutch trans-
•
Only the seven forward gears can be
push the shift lever forward into the
mission has a shift-lock system
selected. To reverse or park the
+ (Up) position. This causes the
which prevents shifting the transmis-
vehicle, move the shift lever to the R
transmission to shift into the
2nd
sion from P (Park) into R (Reverse)
(Reverse) or P (Park) position as
gear which is better for smooth driv-
unless the brake pedal is depressed.
required.
ing on a slippery road. Push the shift
To shift the transmission from P
•
Downshifts are made automatically
lever to the - (Down) side to shift
(Park) into R (Reverse):
when the vehicle slows down. When
back to the 1st gear.
1. Depress and hold the brake pedal.
the vehicle stops, 1st gear is automat-
•
When driving in manual shift mode,
ically selected.
2. Start the engine or place the igni-
slow down before shifting to a lower
tion switch in the ON position.
•
When the engine rpm approaches
gear. Otherwise, the lower gear may
the red zone the transmission will
not be engaged if the engine rpms
3. Move the shift lever.
upshift automatically.
are outside of the allowable range.
5
•
If the driver presses the lever to
Shift-lock release
+ (Up) or - (Down) position, the
If the shift lever cannot be moved
transmission may not make the
from the P (Park) position into R
requested gear change if the next
(Reverse) position with the brake
gear is outside of the allowable
pedal depressed, continue depress-
engine rpm range. The driver must
ing the brake, and then do the follow-
execute upshifts in accordance with
ing:
road conditions, taking care to keep
the engine rpms below the red zone.
(Continued)
5-37
Driving your vehicle
■ Type A
■ Type B
If you need to use the shift-lock
release, we recommend that the sys-
tem be inspected by an authorized
HYUNDAI dealer immediately.
Ignition key interlock system
(if equipped)
The ignition key cannot be removed
unless the shift lever is in the P
(Park) position.
OAD055007
OAD055084L
1. Place the ignition switch in the
1. Place the ignition switch in the
LOCK/OFF position.
LOCK/OFF position.
2. Apply the parking brake.
2. Apply the parking brake.
3. Push the shift-lock release button.
3. Carefully remove the cap (1) cov-
ering the shift-lock access hole.
4. Move the shift lever while pushing
the shift-lock release button.
4. Insert a tool (e.g. flathead screw-
5. Stop pushing the shift-lock release
driver) into the access hole and
press down on the tool.
button.
5. Move the shift lever while holding
6. Depress the brake pedal, and then
down the screwdriver.
restart the engine.
6. Remove the tool from the shiftlock
release access hole then install
If you need to use the shift-lock
the cap.
release, we recommend that the sys-
tem be inspected by an authorized
7. Depress the brake pedal, and then
restart the engine.
HYUNDAI dealer immediately.
5-38
Parking
Good driving practices
•
Exercise extreme caution when
driving on a slippery surface. Be
Always come to a complete stop and
•
Never move the shift lever from P
especially careful when braking,
continue to depress the brake pedal.
(Park) or N (Neutral) to any other
accelerating or shifting gears. On a
Move the shift lever into the P (Park)
position with the accelerator pedal
slippery surface, an abrupt change
position, apply the parking brake,
depressed.
in vehicle speed can cause the
and place the ignition switch in the
•
Never move the shift lever into P
drive wheels to lose traction and
LOCK/OFF position. Take the Key
(Park) when the vehicle is in
may cause loss of vehicle control
with you when exiting the vehicle.
motion.
resulting in an accident
Be sure the vehicle is completely
•
Optimum vehicle performance and
WARNING
stopped before you attempt to shift
economy is obtained by smoothly
into R (Reverse) or D (Drive).
depressing and releasing the
When you stay in the vehicle
•
Do not move the shift lever to N
accelerator.
with the engine running, be
(Neutral) when driving. Doing so
careful not to depress the accel-
5
may result in an accident because
erator pedal for a long period of
of a loss of engine braking and the
time. The engine or exhaust
transmission could be damaged.
system may overheat and start
•
Do not drive with your foot resting
a fire.
on the brake pedal. Even light, but
The exhaust gas and the
consistent pedal pressure can
exhaust system are very hot.
result in the brakes overheating,
Keep away from the exhaust
brake wear and possibly even
system components.
brake failure.
Do not stop or park over flam-
•
Always apply the parking brake
mable materials, such as dry
when leaving the vehicle. Do not
grass, paper or leaves. They
depend on placing the transmis-
may ignite and cause a fire.
sion in P (Park) to keep the vehicle
from moving.
5-39
Driving your vehicle
WARNING
(Continued)
•
In the event your vehicle
To reduce the risk of SERIOUS
leaves the roadway, do not
INJURY or DEATH:
steer sharply. Instead, slow
•
ALWAYS wear your seatbelt.
down before pulling back into
In a collision, an unbelted
the travel lanes.
occupant is significantly more
•
HYUNDAI recommends you
likely to be seriously injured
follow all posted speed limits.
or killed than a properly belt-
ed occupant.
•
Avoid high speeds when cor-
nering or turning.
•
Do not make quick steering
wheel movements, such as
sharp lane changes or fast,
sharp turns.
•
The risk of rollover is greatly
increased if you lose control
of your vehicle at highway
speeds.
•
Loss of control often occurs if
two or more wheels drop off
the roadway and the driver
over steers to reenter the
roadway.
(Continued)
5-40
BRAKING SYSTEM
Power brakes
WARNING
(Continued)
Your vehicle has power-assisted
•
Wet brakes may impair the
brakes that adjust automatically
Take the following precautions:
vehicle's ability to safely slow
through normal usage.
•
Do not drive with your foot
down; the vehicle may also
If the engine is not running or is
pull to one side when the
resting on the brake pedal.
turned off while driving, the power
This will create abnormal high
brakes are applied. Applying
assist for the brakes will not work.
the brakes lightly will indicate
brake temperatures, exces-
You can still stop your vehicle by
sive brake lining and pad
whether they have been
applying greater force to the brake
affected in this way. Always
wear, and increased stopping
pedal than typical. The stopping dis-
distances.
test your brakes in this fash-
tance, however, will be longer than
ion after driving through deep
•
When descending down a
with power brakes.
water. To dry the brakes, light-
long or steep hill, move the
When the engine is not running, the
ly tap the brake pedal to heat
shift lever to Manual Shift
up the brakes while maintain-
reserve brake power is partially
mode and manually downshift
5
depleted each time the brake pedal
ing a safe forward speed until
to a lower gear in order to
brake performance returns to
is applied. Do not pump the brake
control your speed without
pedal when the power assist has
normal. Avoid driving at high
using the brake pedal exces-
speeds until the brakes func-
been interrupted.
sively. Applying the brakes
tion correctly.
Pump the brake pedal only when
continuously will cause the
necessary to maintain steering con-
brakes to overheat and could
trol on slippery surfaces.
result in a temporary loss of
braking performance.
(Continued)
5-41
Driving your vehicle
Disc brakes wear indicator
Rear drum brakes
Parking brake
(if equipped)
When your brake pads are worn and
Applying the parking brake
new pads are required, you will hear
Your rear drum brakes do not have
a high pitched warning sound from
wear indicators. Therefore, have the
your front or rear brakes. You may
rear brake linings inspected if you
hear this sound come and go or it
hear a rear brake rubbing noise. Also
may occur whenever you depress
have your rear brakes inspected
the brake pedal.
each time you change or rotate your
Note that some driving conditions or
tires and when you have the front
brakes replaced.
climates may cause a brake squeal
when you first apply (or lightly apply)
the brakes. This is normal and does
not indicate a problem with your
brakes.
OAD055008
NOTICE
Always set the parking brake before
leaving the vehicle, to apply:
To avoid costly brake repairs, do
Firmly depress the brake pedal.
not continue to drive with worn
Pull up the parking brake lever as far
brake pads.
as possible.
i
Information
Always replace brake pads as com-
plete front or rear axle sets.
5-42
Releasing the parking brake
WARNING
WARNING
To reduce the risk of SERIOUS
•
Whenever leaving the vehicle
INJURY or DEATH, do not oper-
or parking, always come to a
ate the parking brake while the
complete stop and continue to
vehicle is moving except in an
depress the brake pedal. Move
emergency situation. It could
the shift lever into the 1st gear
damage the brake system and
(for manual transmission vehi-
lead to an accident.
cle) or P (Park, for automatic
transmission/dual clutch trans-
mission vehicle) position, then
apply the parking brake, and
OAD055009
place the ignition switch in the
LOCK/OFF position.
5
To release:
Vehicles with the parking
Firmly depress the brake pedal.
brake not fully engaged are at
While pressing the release button
risk for moving inadvertently
(1), slightly pull up on the parking
and causing injury to yourself
brake lever then lower the parking
or others.
brake lever (2).
•
NEVER allow anyone who is
unfamiliar with the vehicle to
touch the parking brake. If the
parking brake is released
unintentionally, serious injury
may occur.
•
Only release the parking
brake when you are seated
inside the vehicle with your
foot firmly on the brake pedal.
5-43
