Average Vehicle Speed (2)

Elapsed Time (3)

Auto stop time (if equipped)

• The average vehicle speed is cal-

• The elapsed time is the total driv-

■ Type A

■ Type B

culated by the total driving dis-

ing time since the last elapsed time

tance and driving time since the

reset.

last average vehicle speed reset.

- Time range (hh:mm):

- Speed range:

00:00 ~ 99:59

0~240 km/h or 0~160 MPH

• To reset the elapsed time, press the

3

• To reset the average vehicle speed,

[OK] button on the steering wheel

press the [OK] button on the steer-

for more than 1 second when the

ing wheel for more than 1 second

elapsed time is displayed.

when the average vehicle speed is

displayed.

i

Information

OTL045191L/OAD045175N

The elapsed time will continue to be

i

Information

This mode displays the elapsed time of

counted while the engine is still run-

Auto stop for "Idle stop and go system".

• The average vehicle speed is not dis-

ning (for example, when the vehicle is

played if the driving distance is less

in traffic or stopped at a stop light.)

For more details, refer to the "Idle

than 300 meters (0.19 miles) or the

stop and go system" in chapter 5.

driving time is less than 10 seconds

since the ignition switch or the Engine

Start/Stop button is turned to ON.

• The average vehicle speed will con-

tinue to be calculated and will start

to decrease if the vehicle is stopped

while the engine is still running (for

example, when the vehicle is in traf-

fic or stopped at a stop light.)

3-97

Convenient features of your vehicle

Digital speedometer

Driving Info display

If the estimated remaining vehicle

range is below 1 km (1 mi.), the dis-

■ Type A

■ Type B

■ Type A

■ Type B

tance to empty will display as "----"

and a "Low Fuel" warning message

(4) will be displayed.

i

Information

If sunroof open warning is displayed

in the cluster, the Driving Info mes-

sage will not be displayed.

OTL045193/OTL045194

OAD045164L/OAD045163L

This message shows the speed of

At the end of each driving cycle, the

the vehicle (km/h, MPH).

Driving Info message is displayed.

This display shows the trip distance

(1), the average fuel economy (2),

and the remaining distance to empty

(3).

This information is displayed for a few

seconds when you turn off the igni-

tion, and then goes off automatically.

The information is calculated for each

ignition cycle.

3-98

LIGHT

Exterior lights

(1) OFF (O) position

■ Left-hand drive

Lighting control

(2) AUTO light position (if equipped)

■ Left-hand drive

(3) Parking lamp position

(4) Headlamp position

3

OAD045436L

■ Right-hand drive

OTL045251L

■ Right-hand drive

OAD045436R

AUTO light position (if equipped)

OTL045251R

When the light switch is in the AUTO

position, the parking lamp and head-

To operate the lights, turn the knob at

lamp will be turned ON or OFF auto-

the end of the control lever to one of

matically depending on the amount

the following positions:

of light outside the vehicle.

3-99

Convenient features of your vehicle

Even with the AUTO light feature in

■ Left-hand drive

■ Left-hand drive

operation, it is recommended to

manually turn ON the lamps when

driving at night or in a fog, or when

you enter dark areas, such as tun-

nels and parking facilities.

NOTICE

•

Do not cover or spill anything on

the sensor (1) located on the

OTL045253L

OTL045252L

instrument panel.

■ Right-hand drive

■ Right-hand drive

•

Do not clean the sensor using a

window cleaner, the cleanser

may leave a light film which

could interfere with sensor oper-

ation.

•

If your vehicle has window tint

or other types of metallic coat-

ing on the front windshield, the

AUTO light system may not work

OTL045253R

OTL045252R

properly.

Parking lamp position (

)

Headlamp position (

)

The parking lamp, license plate lamp

The headlamp, parking lamp, license

and instrument panel lamp are turned

plate lamp and instrument panel

ON.

lamp are turned ON.

i

Information

The ignition switch button must be in

the ON position to turn on the head-

lamp.

3-100

High beam operation

To turn off the high beam headlamp,

■ Left-hand drive

pull the lever towards you. The low

■ Left-hand drive

beams will turn on.

WARNING

Do not use high beam when there

are other vehicles approaching

3

you. Using high beam could

obstruct the other driver's vision.

OTL045254L

■ Right-hand drive

OTL045255L

■ Right-hand drive

OTL045254R

To flash the high beam headlamp,

OTL045255R

pull the lever towards you, then

release the lever. The high beams

To turn on the high beam headlamp,

push the lever away from you. The

will remain ON as long as you hold

the lever towards you.

lever will return to its original position.

The high beam indicator will light

when the headlamp high beams are

switched on.

3-101

Convenient features of your vehicle

Turn signals and lane change

The lever will return to the OFF posi-

Front fog lamp (if equipped)

signals

tion when released or when the turn

■ Left-hand drive

is completed.

■ Left-hand drive

If an indicator stays on and does not

flash or if it flashes abnormally, one of

the turn signal bulbs may be burned

out and will require replacement.

One-touch turn signal function

To activate an one-touch turn signal

function, move the turn signal lever

OTL045258L

slightly and then release it. The lane

OTL045257L

■ Right-hand drive

change signals will blink 3, 5 or 7

■ Right-hand drive

times.

You can activate/deactivate the One

Touch Turn Signal function or choose

the number of blinking (3, 5, or 7)

from the User Settings Mode on the

LCD display. For more details, refer

to "LCD Display" in this chapter.

OTL045258R

OTL045257R

Fog lamps are used to provide

To signal a turn, push down on the

improved visibility when visibility is

lever for a left turn or up for a right

poor due to fog, rain or snow, etc. Use

turn in position (A). To signal a lane

the switch next to the headlamp switch

change, move the turn signal lever

to turn the fog lamps ON and OFF.

slightly and hold it in position (B).

3-102

1. Turn on the parking lamp.

Rear fog lamp (if equipped)

■ Left-hand drive

2. Turn the light switch (1) to the front

■ Left-hand drive

fog lamp position.

3. To turn off the front fog lamp, turn

the light switch to the front fog

lamp position again or turn off the

parking lamp.

3

NOTICE

OTLE045285

When in operation, the fog lamps

■ Right-hand drive

consume large amounts of vehicle

OTL045278L

electrical power. Only use the fog

■ Right-hand drive

lamps when visibility is poor.

OTL045278AU

Vehicle without front fog lamp

OTL045278R

To turn on the rear fog lamp:

Vehicle with front fog lamp

Position the light switch in the head-

To turn on the rear fog lamp:

lamp position, and then turn the light

Position the light switch in the park-

switch (1) to the rear fog lamp position.

ing lamp position, turn the light

switch to the front fog lamp position,

and then turn the lamp switch (1) to

the rear fog lamp position.

3-103

NOTICE

Daytime running light (DRL)

Headlight leveling device

(if equipped)

(if equipped)

If the driver gets out of the vehicle

The Daytime Running Lights (DRL)

through other doors (except dri-

■ Left-hand drive

can make it easier for others to see

ver's door), the battery saver func-

the front of your vehicle during the

tion does not operate and the

day, especially after dawn and before

headlamp delay function does not

sunset.

turn off automatically. Therefore, It

The DRL system will turn the dedi-

3

causes the battery to be dis-

charged. In this case, make sure to

cated lamp OFF when:

turn off the lamp before getting out

1. The headlights or front fog lights

of the vehicle.

are in the ON position.

2. The engine is turned off.

OAD045433

■ Right-hand drive

OAD045433R

Manual type

To adjust the headlight beam level

according to the number of the pas-

sengers and loading weight in the

luggage area, turn the beam leveling

switch.

3-105

Convenient features of your vehicle

The higher the number of the switch

Welcome system (if equipped)

Headlamp and Parking lamp

position, the lower the headlight

Welcome light (if equipped)

When the headlamp (lamp switch in

beam level. Always keep the head-

the headlamp or AUTO position) is on

light beam at the proper leveling

and all doors (and trunk) are locked

position, or headlights may dazzle

and closed, the parking lamp and

other road users.

headlamp will come on for 15 seconds

Listed below are the examples of

if/or any of the below is performed.

proper switch settings. For loading

• When the door unlock button is

conditions other than those listed

pressed on the remote key or

below, adjust the switch position so

smart key.

that the beam level may be the near-

At this time, if you press the door lock

est as the condition obtained accord-

or unlock button, the parking lamp and

ing to the list.

headlamp will turn off immediately.

Switch

OAD045434L

Loading condition

position

You can activate or deactivate the

Door handle lamp (if equipped)

Driver only

0

Welcome Light from the User

When all the doors (and trunk) are

Settings Mode on the LCD display.

Driver + Front passenger

0

closed and locked, the door handle

For more details, refer to "LCD

Full passengers (including driver)

1

lamp will come on for about 15 sec-

Display" in this chapter.

onds if any of the below is performed.

Full passengers (including driver)

2

+ Maximum permissible loading

• When the door unlock button is

pressed on the remote key or

Driver + Maximum permissible

3

smart key.

loading

• When the button of the outside

door handle is pressed.

• When the vehicle is approached

with the smart key in possession.

3-106

Interior lamp

Interior lights

Interior lamp AUTO cut

When the interior lamp switch is in

NOTICE

The interior lamps will automatically

the DOOR position and all doors (and

go off approximately 20 minutes after

trunk) are closed and locked, the

Do not use the interior lights for

the engine is turned off and the

room lamp will come on for 30 sec-

extended periods when the engine

doors closed. If a door is opened, the

onds if any of the below is performed.

is turned off or the battery will dis-

lamp will go off 40 minutes after the

charge.

engine is turned off. If the doors are

• When the door unlock button is

locked by the smart key and the vehi-

3

pressed on the remote key or

smart key.

cle enters the armed stage of the

WARNING

theft alarm system, the lamps will go

• When the button of the outside

off five seconds later.

door handle is pressed.

If it does not work properly even

though your car is inclined

backward according to passen-

At this time, if you press the door lock

ger's posture, or the headlight

or unlock button, the room lamp will

beam is irradiated to the high or

turn off immediately.

low position, we recommend

that the system be inspected by

an authorized HYUNDAI dealer.

Do not attempt to inspect or

replace the wiring yourself.

3-107

Convenient features of your vehicle

Front lamps

Front Map Lamp :

Front room lamp

■ Type A

Press either of these lens to turn the

•

:

map lamp on or off. This light pro-

Press the button to turn ON the

duces a spot beam for convenient

room lamp for the front/rear seats.

use as a map lamp at night or as a

Re-press the button to turn OFF

personal lamp for the driver and the

the room lamp.

front passenger.

•

:

Front Door Lamp (

):

Press the button to turn OFF the

The front or rear room lamps come on

room lamp for the front/rear seats.

when the front or rear doors are

OAD045405

opened if the engine is running or not.

■ Type B

When doors are unlocked by the

remote key or smart key, the front and

rear lamps come on for approximate-

ly 30 seconds as long as any door is

not opened. The front and rear room

lamps go out gradually after approxi-

mately

30 seconds if the door is

closed. However, if the ignition switch

is in the ON position or all doors are

locked, the front and rear lamps will

OAD045406

turn off. If a door is opened with the

(1) Front Map Lamp

ignition switch in the ACC position or

(2) Front Door Lamp

the OFF position, the front and rear

lamps stay on for about 20 minutes.

(3) Front Room Lamp

3-108

Rear lamps

Trunk room lamp

Vanity mirror lamp

3

OAD045407

OAD045408

OAD045410

The trunk room lamp comes on

Push the switch to turn the light on or

Rear Room Lamp Switch (

):

when the trunk is opened.

off.

Press this button to turn the room

•

: The lamp will turn on if this

lamp on and off.

NOTICE

button is pressed.

•

: The lamp will turn off if this

The trunk lamp comes on as long

button is pressed.

NOTICE

as the trunk lid is open. To prevent

Do not leave the lamp switches on

unnecessary charging system

NOTICE

for an extended period of time

drain, close the trunk lid securely

Always have the switch in the off

when the engine is turned off.

after using the trunk.

position when the vanity mirror

lamp is not in use. If the sunvisor

is closed without the lamp off, it

may discharge the battery or dam-

age the sunvisor.

3-109

Convenient features of your vehicle

WIPERS AND WASHERS

■ Left-hand drive

■ Right-hand drive

Windshield wipers

• Type A

Operates as follows when the igni-

tion switch is in the ON position.

MIST (V ) : For a single wiping cycle,

push the lever upward

and release. The wipers

will operate continuously

if the lever is held in this

position.

OFF (O) : Wiper is not in operation.

OAD045437L

OAD045437R

INT (---) : Wiper operates intermit-

• Type B

tently at the same wiping

A : Wiper speed control

intervals.To vary the speed

· MIST / V - Single wipe

setting, turn the speed

· O / OFF - Off

control knob (B).

· --- / INT - Intermittent wipe

AUTO : The rain sensor located on

AUTO* - Auto control wipe

the upper end of the wind-

shield glass senses the

· 1 / LO- Low wiper speed

amount of rainfall and con-

· 2 / HI - High wiper speed

trols the wiping cycle for the

proper interval. The more it

* : if equipped

rains, the faster the wiper

OAD045438L

operates. When the rain

B : Auto control wipe time adjust-

stops, the wiper stops.To

ment

vary the speed setting, turn

the speed control knob (B).

C : Wash with brief wipes

3-110

LO (1) : The wiper runs at a lower

AUTO (Automatic) control

If the wiper switch is set in AUTO

speed.

(if equipped)

mode when the ignition switch is in

the ON position, the wiper will oper-

HI (2) : The wiper runs at a higher

ate once to perform a self-check of

speed.

the system. Set the wiper to OFF

position when the wiper is not in use.

i

Information

If there is heavy accumulation of snow

WARNING

3

or ice on the windshield, defrost the

windshield for about 10 minutes, or

To avoid personal injury from

until the snow and/or ice is removed

the windshield wipers, when the

before using the windshield wipers to

engine is running and the wind-

ensure proper operation.

Sensor

shield wiper switch is placed in

If you do not remove the snow and/or

the AUTO mode:

OAD045441L

ice before using the wiper and washer,

• Do not touch the upper end of

it may damage the wiper and washer

The rain sensor located on the upper

the windshield glass facing

system.

end of the windshield glass senses

the rain sensor.

the amount of rainfall and controls

• Do not wipe the upper end of

the wiping cycle for the proper inter-

the windshield glass with a

val. The more it rains, the faster the

damp or wet cloth.

wiper operates.

• Do not put pressure on the

When the rain stops, the wiper stops.

windshield glass.

To vary the speed setting, turn the

speed control knob (1).

3-111

Convenient features of your vehicle

NOTICE

Windshield washers

If equipped with the Headlamp

Washer, washer fluid will be sprayed

•

When washing the vehicle, set

on the headlamp at the same time you

the wiper switch in the OFF (O)

operate the windshield washer when:

position to stop the auto wiper

1. The ignition switch is in the ON

operation. The wiper may oper-

position.

ate and be damaged if the switch

2. The light switch is in the headlamp

is set in the AUTO mode while

washing the vehicle.

position.

•

Do not remove the sensor cover

located on the upper end of the

WARNING

passenger side windshield

glass. Damage to system parts

When the outside temperature is

could occur and may not be cov-

OAD045404

below freezing, ALWAYS warm

ered by your vehicle warranty.

the windshield using the

In the OFF (O) position, pull the lever

defroster to prevent the washer

gently toward you to spray washer

fluid from freezing on the wind-

fluid on the windshield and to run the

shield and obscuring your vision

wipers

1-3 cycles. The spray and

which could result in an accident

wiper operation will continue until you

and serious injury or death.

release the lever. If the washer does

not work, you may need to add wash-

er fluid to the washer fluid reservoir.

3-112

Content   ..  9  10  11  12   ..
