Hyundai Accent (2019 year). Instruction - part 20

What to do in an emergency

Jack label

■ Example

OHYK065011

The actual Jack label in the vehicle may differ from the illustration.

For more detailed specifications, refer to the label attached to the jack.

1. Model Name

8. Shift into Reverse gear on vehicles

with manual transmission or move

2. Maximum allowable load

the shift lever to the P (Park) posi-

3. When using the jack, set your

tion on vehicles with automatic

parking brake.

transmission.

4. When using the jack, stop the

9. The jack should be used on firm

engine.

level ground.

5. Do not get under a vehicle that is

10. Jack manufacture

supported by a jack.

11. Production date

6. The designated locations under

the frame

12. Representative company and

address

7. When supporting the vehicle, the

base plate of jack must be vertical

under the lifting point.

6-20

TOWING

Towing Service

It is acceptable to tow the vehicle

CAUTION

with the rear wheels on the ground

(without dollies) and the front wheels

•

Do not tow the vehicle with the

off the ground. If any of the loaded

wheels or suspension components

front wheels on the ground as

this may cause damage to the

are damaged or the vehicle is being

towed with the front wheels on the

vehicle.

ground, use a towing dolly under the

front wheels.

When being towed by a commercial

tow truck and wheel dollies are not

dolly

used, the front of the vehicle should

always be lifted, not the rear.

OHCA067019

•

Do not tow with sling-type

equipment. Use a wheel lift or

dolly

flatbed equipment.

OYC066010

If emergency towing is necessary,

we recommend having it done by an

authorized HYUNDAI dealer or a

commercial tow-truck service.

Proper lifting and towing procedures

are necessary to prevent damage to

OYC066012

the vehicle. The use of wheel dollies

or flatbed is recommended.

6-21

What to do in an emergency

Removable Towing Hook

WARNING

If your vehicle is equipped with

a rollover sensor, place the igni-

tion switch in the LOCK/OFF or

ACC position when the vehicle

is being towed. The side impact

and curtain air bag may deploy

if the sensor detects the situa-

tion as a rollover.

OHCR066018

When towing your vehicle in an

2. Remove the hole cover pressing

OYC066013

emergency without wheel dollies:

the lower part of the cover on the

1. Open the trunk, and remove the

front or rear bumper.

1. Place the ignition switch in the

towing hook from the tool case.

ACC position.

3. Install the towing hook by turning it

clockwise into the hole until it is

2. Place the shift lever in N (Neutral).

fully secured.

3. Release the parking brake.

4. Remove the towing hook and

install the cover after use.

CAUTION

Failure to place the shift lever in

N (Neutral) when being towed

with the front wheels on the

ground can cause internal dam-

age to the transmission.

6-22

Emergency Towing

If a towing service is not available in

Always follow these emergency tow-

an emergency, your vehicle may be

ing precautions:

■ Front

temporarily towed using a cable or

•

Place the ignition switch in the

chain secured to the emergency tow-

ACC position so the steering

ing hook at the front (or rear) of the

wheel is not locked. (if equipped)

vehicle.

•

Place the shift lever in N (Neutral).

Use extreme caution when towing

•

Release the parking brake.

the vehicle with a cable or chain. A

driver must be in the vehicle to steer

•

Depress the brake pedal with more

it and operate the brakes.

force than normal since you will

have reduced braking perform-

Towing in this manner may be done

ance.

OHCR066019

only on hard-surfaced roads for a

■ Rear

short distance and at low speeds.

•

More steering effort will be

Also, the wheels, axles, power train,

required because the power steer-

steering and brakes must all be in

ing system will be disabled.

good condition.

•

Use a vehicle heavier than your

own to tow your vehicle.

•

The drivers of both vehicles should

communicate with each other fre-

quently.

•

Before emergency towing, check

that the hook is not broken or dam-

OHCR066017

aged.

If towing is necessary, we recom-

•

Fasten the towing cable or chain

mend you have it done by an author-

securely to the hook.

ized HYUNDAI dealer or a commer-

cial tow truck service.

•

Do not jerk the hook. Apply steady

and even force.

6-23

What to do in an emergency

Tie-down Hook

CAUTION

WARNING

To avoid damage to your vehicle

and vehicle components when

Do not use the tie-down hook(s)

towing:

for towing purposes. If the tie-

•

Always pull straight ahead

down hook(s) are used for tow-

when using the towing hooks.

ing, the tie-down hook(s) or

Do not pull from the side or at

bumper will be damaged and

a vertical angle.

this could lead to serious injury.

•

Do not use the towing hooks to

OHCA067029

pull a vehicle out of mud, sand

or other conditions from which

•

Use a towing cable or chain less

the vehicle cannot be driven

than 16 feet (5 m) long. Attach a

out under its own power.

white or red cloth (about 12 inch

(30 cm) wide) in the middle of the

•

Limit the vehicle speed to

cable or chain for easy visibility.

10 mph (15 km/h) and drive

less than 1 mile (1.5 km) when

•

Drive carefully so the towing cable

towing to avoid serious dam-

or chain remains tight during tow-

age to the automatic transmis-

ing.

sion.

•

Before towing, check the automat-

ic transmission for fluid leaks under

your vehicle. If the automatic trans-

mission fluid is leaking, flatbed

equipment or a towing dolly must

be used.

6-24

Maintenance

Engine compartment

7-3

Brake/clutch fluid

7-21

Maintenance services

7-4

Checking the Brake/Clutch Fluid Level

7-21

Owner's Responsibility

7-4

Washer fluid

7-22

Owner Maintenance Precautions

7-4

Checking the Washer Fluid Level

7-22

Owner maintenance

7-5

Parking brake

7-22

Owner Maintenance Schedule

7-6

Checking the Parking Brake

7-22

Scheduled maintenance services

7-7

Air cleaner

7-23

Normal Maintenance Schedule (Gamma 1.6 GDI)

7-8

Filter Replacement

7-23

Maintenance Under Severe Usage Conditions

Climate control air filter

7-24

(Gamma 1.6 GDI)

7-11

Filter Inspection

7-24

Explanation of scheduled maintenance items.7-13

Wiper blades

7-26

Engine oil

7-16

Blade Inspection

7-26

Checking the Engine Oil Level

7-16

Blade Replacement

7-26

Checking the Engine Oil and Filter

7-17

Battery

7-28

Engine coolant

7-18

For Best Battery Service

7-29

Checking the Engine Coolant Level

7-18

Battery Recharging

7-29

Changing Engine Coolant

7-20

Reset Features

7-30

Tires and wheels

7-31

Fuses

7-46

Tire Care

7-31

Instrument Panel Fuse Replacement

7-47

Recommended Cold Tire Inflation Pressures

7-32

Fuse/Relay Panel Description

7-50

Check Tire Inflation Pressure

7-33

Light bulbs

7-61

Tire Rotation

7-33

Headlamp, Position lamp, Fog lamp, Daytime Running

Wheel Alignment and Tire Balance

7-34

Light, Turn Signal Lamp and Side Marker

7-61

Tire Replacement

7-35

Side Repeater Lamp Replacement

7-67

Wheel Replacement

7-36

Rear Combination Light Bulb Replacement

7-67

Tire Traction

7-36

High Mounted Stop Lamp Replacement

7-70

Tire Maintenance

7-36

License Plate Light Bulb Replacement

7-70

Tire Sidewall Labeling

7-36

Appearance care

7-72

Tire Terminology and Definitions

7-40

Exterior Care

7-72

All Season Tires

7-43

Interior Care

7-76

Summer Tires

7-43

Emission control system

7-79

Snow Tires

7-44

Crankcase Emission Control System

7-79

Radial-Ply Tires

7-44

Evaporative Emission Control System Including

Low Aspect Ratio Tires

7-44

Onboard Refueling Vapor Recovery (ORVR)

7-79

Exhaust Emission Control System

7-80

California perchlorate notice

7-83

ENGINE COMPARTMENT

■ Gamma 1.6 GDI

1. Engine oil filler cap

2. Engine oil dipstick

3. Brake/Clutch fluid reservoir

4. Battery

5. Fuse box

6. Air cleaner

7. Engine coolant reservoir

8. Windshield washer fluid reservoir

9. Radiator cap

The actual engine compartment in the

vehicle may differ from the illustration.

The actual engine compartment in the vehicle may differ from the illustration.

OHCA077001

7-3

Maintenance

MAINTENANCE SERVICES

You should exercise the utmost care

Detailed warranty information is pro-

Certain modifications may also be in

to prevent damage to your vehicle

vided in your Owner's Handbook &

violation of regulations established by

and injury to yourself whenever per-

Warranty Information booklet.

the U.S. Department of Transportation

forming any maintenance or inspec-

and other federal or state agencies.

Repairs and adjustments required as

tion procedures.

a result of improper maintenance or

We recommend you have your vehi-

a lack of required maintenance are

NOTICE

cle maintained and repaired by an

not covered.

Improper owner maintenance dur-

authorized HYUNDAI dealer. An

authorized HYUNDAI dealer meets

ing the warranty period may affect

Owner Maintenance

warranty coverage. For details, read

HYUNDAI's high service quality

Precautions

the separate Owner's Handbook &

standards and receives technical

Warranty Information booklet pro-

support from HYUNDAI in order to

Inadequate, incomplete or insuffi-

provide you with a high level of serv-

cient servicing may result in opera-

vided with the vehicle. If you're

unsure about any service or mainte-

ice satisfaction.

tional problems with your vehicle that

nance procedure, have it done by an

could lead to vehicle damage, an

authorized HYUNDAI dealer.

accident, or personal injury. This

Owner's Responsibility

chapter provides instructions only for

Maintenance service and record

the maintenance items that are easy

retention are the owner's responsibil-

to perform. Several procedures can

ity.

be done only by an authorized

You should retain documents that

HYUNDAI dealer with special tools.

show proper maintenance has been

Your vehicle should not be modified

performed on your vehicle in accor-

in any way. Such modifications may

dance with the scheduled mainte-

adversely affect the performance,

nance service charts shown on the

safety or durability of your vehicle

following pages. You need this infor-

and may, in addition, violate condi-

mation to establish your compliance

tions of the limited warranties cover-

with the servicing and maintenance

ing the vehicle.

requirements of your vehicle war-

ranties.

7-4

OWNER MAINTENANCE

The following lists are vehicle checks

WARNING

(Continued)

and inspections that should be per-

•

Block the tires

(front and

formed by the owner or an author-

Performing maintenance work

back) to prevent the vehicle

ized HYUNDAI dealer at the frequen-

on a vehicle can be dangerous.

from moving.

cies indicated to help ensure safe,

If you lack sufficient knowledge

Remove loose clothing or jew-

dependable operation of your vehi-

and experience or the proper

elry that can become entan-

cle.

tools and equipment to do the

gled in moving parts.

Any adverse conditions should be

work, have it done by an author-

•

If you must run the engine

brought to the attention of your deal-

ized HYUNDAI dealer.

during maintenance, do so

er as soon as possible.

ALWAYS follow these precau-

out doors or in an area with

These Owner Maintenance vehicle

tions for performing mainte-

plenty of ventilation.

checks are generally not covered by

nance work:

•

Keep flames, sparks, or smok-

warranties and you may be charged

• Park your vehicle on level

ing materials away from the

for labor, parts and lubricants used.

ground, move the shift lever

battery and fuel-related parts.

into the P (Park, for automatic

transmission vehicle) position

or neutral (for manual trans-

mission vehicle), apply the

parking brake, place the igni-

tion switch in the LOCK/OFF

position.

(Continued)

7-5

Maintenance

Owner Maintenance Schedule

While operating your vehicle:

• Check the parking brake.

When you stop for fuel:

•

Note any changes in the sound of

• Check for fluid leaks under your

the exhaust or any smell of

vehicle (water dripping from the air

• Check the engine oil level.

exhaust fumes in the vehicle.

conditioning system during or after

• Check the coolant level in the

use is normal).

•

Check for vibrations in the steering

engine coolant reservoir.

wheel. Notice if there is any

• Check the windshield washer fluid

increased steering effort or loose-

At least monthly:

level.

ness in the steering wheel, or

•

Check coolant level in the engine

• Check the for low or under-inflated

change in its straight-ahead posi-

coolant reservoir.

tires.

tion.

•

Check the operation of all exterior

•

Notice if your vehicle constantly

lights, including the brake lights,

turns slightly or "pulls" to one side

WARNING

turn signals and hazard warning

when traveling on smooth, level

flashers.

Be careful when checking your

road.

•

Check the inflation pressures of all

engine coolant level when the

•

When stopping, listen and check

tires including the spare for tires

engine is hot. This may result in

for unusual sounds, pulling to one

that are worn, show uneven wear,

coolant being blown out of the

side, increased brake pedal travel

or are damaged.

opening and cause serious

or "hard-to-push" brake pedal.

burns and other injuries.

•

Check for loose wheel lug nuts.

•

If any slipping or changes in the

operation of your transmission

occurs, check the transmission

fluid level.

•

Check the automatic transmission

P (Park) function.

7-6

SCHEDULED MAINTENANCE

At least twice a year:

At least once a year:

SERVICES

(i.e., every Spring and Autumn)

•

Clean body and door drain holes.

Follow Normal Maintenance Schedule

•

Check radiator, heater and air con-

•

Lubricate door hinges and hood

if the vehicle is usually operated where

ditioning hoses for leaks or dam-

hinges.

none of the following conditions apply.

age.

•

Lubricate door and hood locks and

If any of the following conditions apply,

•

Check windshield washer spray

you must follow the Maintenance

latches.

and wiper operation. Clean wiper

Under Severe Usage Conditions.

•

Lubricate door rubber weather

blades with a clean cloth damp-

strips.

•

Repeated short distance driving.

ened with washer a fluid.

•

Lubricate door checker.

•

Driving in dusty conditions or

•

Check headlamp alignment.

sandy areas.

•

Check the air conditioning system.

•

Check muffler, exhaust pipes,

•

Extensive use of brakes.

shields and clamps.

•

Inspect and lubricate automatic

transmission linkage and controls.

•

Driving in areas where salt or other

•

Check the seat belts for wear and

corrosive materials are used.

•

Clean the battery and terminals.

function.

•

Driving on rough or muddy roads.

•

Check the brake fluid level.

•

Driving in mountainous areas.

•

Extended periods of idling or low

speed operation.

•

Driving for a prolonged period in

cold temperatures and/or extreme-

ly humid climates.

•

More than 50% driving in heavy

city traffic during hot weather

above 90°F (32°C).

For additional information or assis-

tance see your authorized HYUNDAI

dealer.

7-7

Maintenance

Normal Maintenance Schedule (Gamma 1.6 GDI)

MAINTENANCE

Months

108

120

132

144

156

168

180

INTERVALS

Miles×1,000

7.5

22.5

37.5

52.5

67.5

82.5

97.5

105

112.5

MAINTENANCE

ITEM

Km×1,000

108

120

132

144

156

168

180

Rotate tires

Rotate tires every 7,500 miles

Engine oil and engine oil filter

Fuel additives *1

Add fuel additives every 7,500 miles or 12 months

Air cleaner filter

At first, inspect at 60,000 miles or 72 months.

Drive belts *2

Thereafter, inspect every 15,000 miles or 24 months

Spark plugs

Replace every 97,500 miles

Vapor hose, fuel filler cap and fuel tank

Vacuum hose

Fuel tank air filter *3

Fuel filter *3

: Inspect : Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

*1 : If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your

authorized HYUNDAI dealer along with information on how to use them. Do not mix other additives.

*2 : The drive belt should be replaced when cracks occur or tension is reduced excessively.

*3 : Fuel filter & Fuel tank air filter are considered to be maintenance free but periodic inspection is recommended for this mainte-

nance schedule depends on fuel quality. If there are some important safety matters like fuel flow restriction, surging, loss of

power, hard starting problem, etc. replace the fuel filter immediately regardless of maintenance schedule and consult an

authorized HYUNDAI dealer for details.

7-8

Normal Maintenance Schedule (Gamma 1.6 GDI) (CONT)

MAINTENANCE

Months

108

120

132

144

156

168

180

INTERVALS

Miles×1,000

7.5

22.5

37.5

52.5

67.5

82.5

97.5

105

112.5

MAINTENANCE

ITEM

Km×1,000

108

120

132

144

156

168

180

Fuel lines, hoses and connections

Valve clearance *1

Inspect every 60,000 miles or 72 months

At first, replace at 120,000 miles or 10 years :

Engine coolant

Thereafter, replace every 30,000 miles or 24 months

Battery condition

Brake lines, hoses and connections

Parking brake

Brake/clutch (if equipped) fluid

Disc brakes and pads

Steering gear rack, linkage and boots

Driveshaft and boots

Suspension mounting bolts

Air conditioner refrigerant

Air conditioner compressor

Climate control air filter

: Inspect : Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

: Inspect for excessive valve noise and/or engine vibration and adjust if necessary. Have an authorized HYUNDAI dealer per-

form the operation.

7-9

Maintenance

Normal Maintenance Schedule (Gamma 1.6 GDI) (CONT)

MAINTENANCE

Months

108

120

132

144

156

168

180

INTERVALS

Miles×1,000

7.5

22.5

37.5

52.5

67.5

82.5

97.5

105

112.5

MAINTENANCE

ITEM

Km×1,000

108

120

132

144

156

168

180

Manual transmission fluid (if equipped)

Automatic transmission fluid

No check, No service required

(if equipped)

Exhaust pipe and muffler

: Inspect : Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

7-10

Maintenance Under Severe Usage Conditions (Gamma 1.6 GDI)

The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer

to the chart below for the appropriate maintenance intervals.

R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary

MAINTENANCE

DRIVING

MAINTENANCE ITEM

MAINTENANCE INTERVALS

OPERATION

CONDITION

A, B, C, D, E, F,

Engine oil and filter

Every 3,750 miles or 6 months

G, H, I, J, K

Air cleaner filter

More frequently

C, E

Spark plugs

More frequently

A, B, H, I, K

Automatic transmission fluid

Every 60,000 miles

A, C, E, F, G, I

(if equipped)

Manual transmission fluid

C, D, E, F,

Every 75,000 miles

(if equipped)

G, H, I, J

Front brake disc/pads, calipers

More frequently

C, D, G, H

Rear brake shoes or disc/pads

More frequently

C, D, G, F

7-11

Maintenance

MAINTENANCE

DRIVING

MAINTENANCE ITEM

MAINTENANCE INTERVALS

OPERATION

CONDITION

Parking brake

More frequently

C, D, G, H

Steering gear box, linkage & boots/

lower arm ball joint, upper arm ball

More frequently

C, D, E, F, G, H, I

joint

Drive shafts and boots

More frequently

C, D, E, F, G, H, I, J

Climate control air filter

More frequently

C, E

(for evaporator and blower unit)

Severe Driving Conditions

A-Repeatedly driving short distances of less than 5 miles

E-Driving in sandy areas

(8 km) in normal temperature or less than 10 miles (16 km)

F-Driving in heavy traffic area over 90°F (32°C)

in freezing temperature

G-Driving on uphill, downhill, or mountain road

B-Extensive engine idling or low speed driving for long dis-

H-Towing a Trailer, or using a camper, or roof rack

tances

- Driving as a patrol car, taxi, other commercial use or vehicle

C-Driving on rough, dusty, muddy, unpaved, graveled or salt-

towing

spread roads

J-Driving over 106 mph (170 km/h)

D-Driving in areas using salt or other corrosive materials or in

K-Frequently driving in stop-and-go conditions

very cold weather

7-12

Content .. 18 19 20 21 ..
