Hyundai Veracruz (2012 year). Instruction - part 11
Features of your vehicle
Recirculated air position
With the recirculated air
WARNING
position selected, air from
•
Continued use of the climate con-
the passenger compart-
trol system operation in the recir-
ment will be drawn through
culated air position may allow
the heating system and
humidity to increase inside the
heated or cooled according
vehicle which may fog the glass
to the function selected.
and obscure visibility.
•
Do not sleep in a vehicle with the
air conditioning or heating system
Outside (fresh) air position
on. It may cause serious harm or
With the outside (fresh) air
death due to a drop in the oxygen
OEN046128N
position selected, air enters
level and/or body temperature.
D240204AEN
the vehicle from outside and
•
Continued use of the climate con-
is heated or cooled accord-
trol system operation in the recir-
Air quality control (if equipped)
ing to the function selected.
culated air position can cause
The air inflow from outside the vehicle
drowsiness or sleepiness, and loss
can be automatically controlled. Press
of vehicle control. Set the air intake
the button to activate the air quality con-
control to the outside (fresh) air
trol system.
position as much as possible while
When using AQS mode, AQS(Air Quality
driving.
Control System) automatically senses
✽ NOTICE
outdoor air pollutants and minimizes
Prolonged operation of the heater in the
them from entering the vehicle, however,
recirculated air position
(without air
unpleasant or foul odors that might be
conditioning selected) may cause fog-
present may still be noticeable within the
ging of the windshield and side windows
vehicle.
and the air within the passenger com-
partment may become stale.
In addition, prolonged use of the air con-
ditioning with the recirculated air posi-
tion selected will result in excessively dry
air in the passenger compartment.
4 101
Features of your vehicle
Exhaust gas cutoff mode :
Air enters the vehicle from the outside.
If exhaust gas enters the vehicle from the
outside, the exhaust gas cutoff mode is
automatically converted from the outside
air position to the recirculated air position
to prevent exhaust gas from entering the
vehicle.
✽ NOTICE
It should be noted that prolonged oper-
ation of the heating system in recircula-
OEN046127
OEN046129
tion mode will give rise to misting of the
D240205AUN
D240206AUN
windshield and side windows and the air
Fan speed control
Air conditioning
within the passenger compartment will
The fan speed can be set to the desired
Push the A/C button to turn the air condi-
become stale. In addition, prolonged use
speed by turning the fan speed control
tioning system on (indicator light will illu-
of the air conditioning with the recircu-
knob.
minate).
lation mode selected may result in the
air within the passenger compartment
The higher the fan speed is, the more air
Push the button again to turn the air con-
becoming excessively dry.
is delivered.
ditioning system off.
Pressing the OFF button turns off the
fan.
CAUTION
If the windows fog up with the
Recirculation or A.Q.S mode select-
ed, set the air intake control to the
fresh air position or A.Q.S control
to OFF.
4 102
Features of your vehicle
D240300AEN
Rear heating and air conditioning
When the rear climate control selection
button is not pressed (the indicator light
is not illuminated), the temperature, fan
speed and mode of the rear climate con-
trol system is controlled automatically
according to the front climate control sys-
tem operation.
• Rear temperature and fan speed con-
trol: same as the front climate control
• Rear mode control
OEN046130
OEN046180
- Front mode control is
D240208AUN
The temperature, fan speed and mode of
: Rear mode control is
OFF mode
the rear climate control system can be
- Front mode control is
Push the OFF button to turn off the air cli-
controlled independently regardless of
: Rear mode control is
mate control system. However, you can
the front climate control system opera-
- Front mode control is
,
,
still operate the mode and air intake but-
tion.
: Rear mode control is
tons as long as the ignition switch is in
Press the rear climate control selection
the ON position.
button (the indicator light is illuminated)
To turn off the rear fan during the front cli-
and set the rear temperature, fan speed
mate control operation, press the rear cli-
and mode to the desired position.
mate control selection button (the indica-
However, the front climate control system
tor light is illuminated) and set the rear
should be operated together for rear air
fan speed control knob to the OFF posi-
conditioning;
tion.
1. Set the front fan speed to the desired
position.
2. Push the air conditioning button.
3. Push the rear climate control selection
button.
4. Set the rear temperature, fan speed
and mode to the desired position.
4
103
Features of your vehicle
OEN046111
OEN046134
OEN046114
D240301AEN
Rear vents
Rear mode selection
The vent can be adjusted by rotating the
The rear mode is selected by pushing the
blade.
rear mode selection button on the rear
control panel as follows:
✽ NOTICE
If all the vents are closed, it may cause
some noise. Always open
2 vents or
OEN046112
more.
•
: Rear air blows from the upper
vents on the rear ceiling.
•
: Rear air blows from the upper
vents on the rear ceiling and the
lower vents on the right rear trim.
•
: Rear air blows from the lower
vents on the right rear trim.
4 104
Features of your vehicle
D240500AEN
❈ For information on “Cool box”, “System
operation”, “Climate control air filter”,
etc., refer to “Manual climate control
system” in this section.
OEN046133
OEN046132
D240302AEN
D240303AEN
Rear temperature control
Rear fan speed control
To change the air temperature in the rear
To change the fan speed, turn the knob
passenger compartment, turn the knob
to the right for higher speed or left for
to the right for warm and hot air or left for
lower speed.
cooler air.
To turn off the fan, turn the knob to the
OFF position.
4 105
Features of your vehicle
WINDSHIELD DEFROSTING AND DEFOGGING
D250000AEN
•
For maximum defrosting, set the tem-
perature control to the extreme
right/hot position and the fan speed
WARNING - Windshield
control to the highest speed.
heating
•
If warm air to the floor is desired while
Do not use the
or
position
defrosting or defogging, set the mode
during cooling operation in
to the floor-defrost position.
extremely humid weather. The dif-
•
Before driving, clear all snow and ice
ference between the temperature of
from the windshield, rear window, out-
the outside air and that of the wind-
side rear view mirrors, and all side win-
shield could cause the outer sur-
face of the windshield to fog up,
dows.
causing loss of visibility. In this
•
Clear all snow and ice from the hood
OEN046137N
case, set the mode selection knob
and air inlet in the cowl grill to improve
or button to the
position and
heater and defroster efficiency and to
Manual climate control system
fan speed control knob or button to
reduce the probability of fogging up the
D250101AEN-EU
a lower speed.
inside of the windshield.
To defog inside windshield
1. Select desired fan speed.
2. Select desired temperature.
3. Set the mode to the
or
posi-
tion.
4. The outside (fresh) air will be selected
automatically.
If the outside (fresh) air position is not
selected automatically, press the corre-
sponding button manually.
If the
position is selected, lower fan
speed is adjusted to a higher fan speed.
4 106
Features of your vehicle
OEN046138N
OEN046139N
OEN046140N
D250102AEN-EU
Automatic climate control system
D250202AEN-EU
To defrost outside windshield
To defrost outside windshield
D250201AEN-EU
1. Set the fan speed to the highest
1. Set the fan speed to the highest
To defog inside windshield
(extreme right) position.
(extreme right) position.
1. Select desired fan speed.
2. Set the temperature to the extreme hot
2. Set the temperature to the extreme hot
2. Select desired temperature.
position.
(HI) position.
3. Press the defrost button (
).
3. Set the mode to the
position.
3. Press the defrost button (
).
4. The outside (fresh) air position will be
4. The outside (fresh) air will be selected
4. The outside (fresh) air position will be
selected automatically.
automatically.
selected automatically.
If the outside (fresh) air position is not
If the
position is selected, lower fan
If the
position is selected, lower fan
selected automatically, adjust the corre-
speed is adjusted to a higher fan speed.
speed is adjusted to a higher fan speed.
sponding button manually.
If the
position is selected, lower fan
speed is adjusted to a higher fan speed.
4 107
Features of your vehicle
D250300AUN-EU
Defogging logic
To reduce the possibility of fogging up
the inside of the windshield, the air intake
is controlled automatically according to
certain conditions such as
or
position. To cancel or return the defog-
ging logic, perform the following steps.
OEN046141N
OEN046142N
D250301AUN
D250302AUN
Manual climate control system
Automatic climate control system
1. Turn the ignition switch to the ON posi-
1. Turn the ignition switch to the ON posi-
tion.
tion.
2. Turn the mode selection knob to the
2. Select the defrost position pressing
defrost position (
).
defrost button (
).
3. Push the air intake control button at
3. While holding the air conditioning but-
least 5 times within 3 seconds.
ton (A/C) pressed, press the air intake
The indicator light in the air intake control
control button at least 5 times within 3
button will blink 3 times with 0.5 second
seconds.
of interval. It indicates that the defogging
The A/C display blinks 3 times with 0.5
logic is canceled or returned to the pro-
second of interval. It indicates that the
grammed status.
defogging logic is canceled or returned to
the programmed status.
If the battery has been discharged or dis-
connected, the system resets to the pre-
If the battery has been discharged or dis-
programmed defogging logic.
connected, the system resets to the pre-
programmed defogging logic.
4 108
Features of your vehicle
STORAGE COMPARTMENT
D270000AUN
These compartments can be used to
store small items required by the driver
or passengers.
CAUTION
• To avoid possible theft, do not
leave valuables in the storage
compartment.
• Always keep the storage com-
partment covers closed while
driving. Do not attempt to place
OEN046143
OEN048144
so many items in the storage
D270100AEN
D270200AEN
compartment that the storage
Center console storage
Glove box
compartment cover cannot close
securely.
These compartments can be used to
The glove box can be locked and
store small items required by the driver
unlocked with a master key.
or front passenger.
To open the glove box, pull the handle
To open the center console storage, push
and the glove box will automatically
WARNING - Flammable
the button (1) or pull up the lever (2).
open. Close the glove box after use.
materials
Do not store cigarette lighters,
propane cylinders, or other flamma-
WARNING
ble/explosive materials in the vehi-
To reduce the risk of injury in an acci-
cle. These items may catch fire
dent or sudden stop, always keep the
and/or explode if the vehicle is
glove box door closed while driving.
exposed to hot temperatures for
extended periods.
WARNING
Do not keep food in the glove box
for a long time.
4 109
Features of your vehicle
Front
WARNING
•
Do not keep objects except sun-
glasses inside the sunglass hold-
er. Such objects can be thrown
from the holder in the event of a
sudden stop or an accident, pos-
(If equipped)
sibly injuring the passengers in
the vehicle.
•
Do not open the sunglass holder
while the vehicle is moving. The
OEN046151
rear view mirror of the vehicle
Center (if equipped)
OEN046145
can be blocked by an open sun-
D270300AUN
glass holder.
Sunglass holder
To open the sunglass holder, press the
cover and the holder will slowly open.
Place your sunglasses in the compart-
ment door with the lenses facing out.
Push to close.
OEN046173
D270400AEN
Multi box
Front/Center
To open the cover, press the button and
the cover will slowly open.
4 110
Features of your vehicle
OEN046147
OEN047148
OEN047149
Rear
D270500AEN
2. Pull out the support rod and hold the
To open the cover, lift the cover. It can be
cover open with the support rod by
Luggage box
used for storing small items.
inserting the free end of the rod into
You can place a first aid kit, a reflector tri-
the slot on the side of the box.
angle, tools, etc. in the box for easy
access.
1. Grasp the handle on the edge of the
cover and lift it.
4 111
Features of your vehicle
INTERIOR FEATURES
WARNING
• Do not hold the lighter in after it
is already heated because it will
overheat.
• If the lighter does not pop out
within 30 seconds, remove it to
prevent overheating.
CAUTION
OEN046153
Only a genuine HYUNDAI lighter
OEN046154
D280100AEN
should be used in the cigarette
D280200AEN
lighter socket. The use of plug-in
Cigarette lighter (if equipped)
Ashtray
accessories
(shavers, hand-held
For the cigarette lighter to work, the igni-
vacuums, and coffee pots, etc.) may
tion switch must be in the ACC position
WARNING - Ashtray use
damage the socket or cause electri-
or the ON position.
cal failure.
• Do not use the vehicle’s ashtrays
To open the cover, press the cover and it
as waste receptacles.
will slowly open.
• Putting lit cigarettes or matches
To use the cigarette lighter, push it all the
in an ashtray with other com-
way into its socket. When the element
bustible materials may cause a
has heated, the lighter will pop out to the
fire.
“ready” position.
If it is necessary to replace the cigarette
To open the cover, press the cover and it
lighter, use only a genuine HYUNDAI
will slowly open. To clean the ashtray, the
replacement or its approved equivalent.
plastic receptacle should be removed by
lifting the plastic ash receptacle upward
and pulling it out.
4 112
Features of your vehicle
D280300AEN
Front
Front
Cup holder
To open the cover, press the cover and it
will slowly open.
WARNING - Hot liquids
Center
• Do not place uncovered cups of
To open the cover, press the button and
hot liquid in the cup holder while
the vehicle is in motion. If the hot
the cover will slowly open.
liquid spills, you burn yourself.
Place a cup or small beverage can in the
Such a burn to the driver could
holder after pulling out the support (1).
OEN046155
lead to loss of control of the vehi-
Center
cle.
• To reduce the risk of personal
injury in the event of sudden stop
or collision, do not place uncov-
ered or unsecured bottles, glass-
es, cans, etc., in the cup holder
while the vehicle is in motion.
OEN036201
Rear
WARNING
Keep cans or bottles out of direct
sun light and do not put them in a
vehicle that is heated up. It may
explode.
OEN046156
Cups or small beverage cans may be
placed in the cup holders.
4 113
Features of your vehicle
Front
CAUTION - Vanity mirror
lamp
Close the vanity mirror cover
securely and return the sunvisor to
its original position after use. If the
vanity mirror is not closed securely,
the lamp will stay on and could
result in battery discharge and pos-
sible sunvisor damage.
OEN046158
Center (if equipped)
OEN046157
D280400AEN
Sunvisor
Use the sunvisor to shield direct light
through the front or side windows.
To use a sunvisor, pull it downward.
To use a sunvisor for a side window, pull
it downward, unsnap it from the bracket
(1) and swing it to the side (2).
To use the vanity mirror, pull down the
OEN046160
visor and slide the mirror cover (3).
D280500AEN
Adjust the sunvisor extension forward or
Power outlet
backward (4).
The power outlet is designed to provide
The ticket holder (5) is provided for hold-
power for mobile telephones or other
ing a tollgate ticket. (if equipped)
devices designed to operate with vehicle
electrical systems. The devices should
draw less than 10 amps with the engine
running.
4 114
Features of your vehicle
✽ NOTICE
CAUTION
When pushing the AC inverter switch,
•
Use the power outlet only when
the switch indicator illumination is
the engine is running and remove
delayed momentarily while the system
the accessory plug after use.
conducts a self-check.
Using the accessory plug for pro-
longed periods of time with the
engine off could cause the bat-
CAUTION
tery to discharge.
•
When not using the AC inverter,
•
Only use 12V electric accessories
make sure that the switch is
which are less than 10A in elec-
OEN046203N
turned off, and is closed the AC
tric capacity.
inverter cover.
•
Adjust the air-conditioner or
•
Only use when the engine is run-
heater to the lowest operating
ning, and remove the plug from the
level when using the power outlet.
AC inverter after using the acces-
sory. Using when the engine is not
•
Close the cover when not in use.
running or leaving the accessory
•
Some electronic devices can
plugged in for long time may cause
cause electronic interference
the battery to discharge.
when plugged into a vehicle’s
power outlet. These devices may
•
Do not use electric accessories
cause excessive audio static and
or equipment with maximum elec-
OEN048161N
tric power consumption greater
malfunctions in other electronic
D281300AEN
than 150W (115VAC).
systems or devices used in your
AC inverter (if equipped)
•
Some electronic devices can
vehicle.
These supply
115VAC/150W electric
cause electronic interference
power to operate electric accessories or
when plugged into the AC inverter.
equipment when the ignition switch is in
These devices may cause exces-
WARNING
the ON position or engine is running. The
sive audio noise and malfunctions
Do not put a finger or a foreign ele-
AC inverter is turned on by pushing in the
in other electronic systems or
ment (pin, etc.) into a power outlet
switch. To turn the AC inverter off, push
devices used in your vehicle.
and do not touch with a wet hand.
the switch a second time.
(Continued)
You may get an electric shock.
4 115
Features of your vehicle
D280601AUN
(Continued)
Hour (1)
• Do not use broken electric acces-
Pressing the H button with your finger, a
sories or equipment, as they may
pencil or similar object will advance the
damage the AC inverter and vehi-
time displayed by one hour.
cle's electrical system.
• Do not use two or more electric
D280602AUN
accessories or equipment at the
Minute (2)
same time.
Pressing the M button with your finger, a
• When input voltage is under 11V,
pencil or similar object will advance the
the outlet LED and indicator will
time displayed by one minute.
blink, and will automatically turn
off.
OEN046159N
D280603AUN
D280600AEN
Reset (3)
Digital clock
To clear away minutes, press the R but-
WARNING
ton with your finger, a pencil or similar
object. Then the clock will be set precise-
The AC inverter can be dangerous!
WARNING
ly on the hour.
When using the AC inverter, care-
Do not adjust the clock while driv-
For example, if the R button is pressed
fully observe the following precau-
ing. You may lose your steering
while the time is between 9:01 and 9:29,
tions to avoid serious injuries.
control and cause an accident that
the display will be reset to 9:00.
• Do not use heated electric prod-
results in severe personal injury or
9:01 ~ 9:29 display changed to 9:00
ucts
(coffeepot, toaster, heater,
death.
9:30 ~ 9:59 display changed to 10:00
iron, etc.).
• Do not insert foreign objects into
D280604AEN
or touch the AC inverter; you may
Whenever the battery terminals or relat-
get shocked.
ed fuses are disconnected, you must
Display conversion
reset the time.
To change the 12 hour format to the 24
• Do not let children operate or
hour format, press the R button until the
touch the AC inverter.
When the ignition switch is in the ACC or
display blinks.
ON position, the clock buttons operate as
• When not using the AC inverter,
For example, if the R button is pressed
close the cover.
follows:
while the time is 10:15 p.m., the display
will be changed to 22:15.
4 116
Features of your vehicle
• Temperature conversion
2nd row
If the battery has been discharged or
disconnected, the temperature mode
display will reset to Fahrenheit.
This is a normal condition. You can
switch the temperature mode between
Fahrenheit to Centigrade as follows;
While depressing the R button,
depress the H or M button. The display
will change from Fahrenheit to
Centigrade, or from Centigrade to
OEN046163
Fahrenheit.
3rd row (if equipped)
OEN046135N
D281200AEN
Outside thermometer
The current outside temperature is dis-
played in 1°F (1°C) increments. The tem-
perature range is between -30°F~140°F
(-30°C ~ 60°C).
• The outside temperature on the display
may not change immediately like a
general thermometer to prevent the
OEN049173L
driver from being inattentive.
D280800AEN
Clothes hanger (if equipped)
CAUTION
Do not hang heavy clothes, since
those may damage the hook.
4 117
