Hyundai Santa Fe (2019 year). Instruction - part 13
AUTO (Automatic) control
i
Information
WARNING
(if equipped)
If there is heavy accumulation of snow
The rain sensor located on the upper
or ice on the windscreen, defrost the
To avoid personal injury from the
end of the windscreen glass senses
windscreen for about 10 minutes, or
windscreen wipers, when the
the amount of rainfall and controls
until the snow and/or ice is removed
engine is running and the wind-
the wiping cycle for the proper inter-
screen wiper switch is placed in
before using the windscreen wipers to
val. The wiper operation time will be
the AUTO mode:
ensure proper operation.
automatically controlled depends on
3
• Do not touch the upper end of
If you do not remove the snow and/or
rainfall.
the windscreen glass facing
ice before using the wiper and washer,
When the rain stops, the wiper stops.
the rain sensor.
it may damage the wiper and washer
To vary the sensitivity setting, turn
• Do not wipe the upper end of
system.
the sensitivity control knob.
the windscreen glass with a
damp or wet cloth.
If the wiper switch is set in AUTO
mode when the ignition switch is in
• Do not put pressure on the
windscreen glass.
the ON position, the wiper will oper-
ate once to perform a self-check of
• Set the wiper switch to the O
the system.
(OFF) position when the wiper
is not in use.
3-127
Convenient features of your vehicle
NOTICE
Windscreen washers
WARNING
•
When washing the vehicle, set
the wiper switch in the O (OFF)
When the outside temperature
position to stop the auto wiper
is below freezing, ALWAYS
operation. The wiper may oper-
warm the windscreen using the
ate and be damaged if the switch
defroster to prevent the washer
is set in the AUTO mode whilst
fluid from freezing on the wind-
washing the vehicle.
screen and obscuring your
vision which could result in an
•
Do not remove the sensor cover
accident and serious injury or
located on the upper end of the
death.
passenger side windscreen
glass. Damage to system parts
could occur and may not be cov-
OTM048451
ered by your vehicle warranty.
In the O (OFF) position, pull the lever
•
Because of using a photo sen-
gently toward you to spray washer
sor, temporary malfunction
fluid on the windscreen and to run
could occur according to sud-
the wipers 1-3 cycles.
den ambient light change made
The spray and wiper operation will
by stone and dust whilst driving.
continue until you release the lever.
If the washer does not work, you may
need to add washer fluid to the
washer fluid reservoir.
3-128
Rear window wiper and wash-
CAUTION
er switch (if equipped)
•
To prevent possible damage
to the washer pump, do not
operate the washer when the
fluid reservoir is empty.
•
To prevent possible damage
3
to the wipers or windscreen,
do not operate the wipers
when the windscreen is dry.
•
To prevent damage to the
OTM048454L
wiper arms and other compo-
Push the lever away from you to
nents, do not attempt to move
spray rear washer fluid and to run the
OTM048453L
the wipers manually.
rear wiper 1~3 cycles. The spray and
•
To prevent possible damage
The rear window wiper and washer
wiper operation will continue until you
to the wipers and washer sys-
switch is located at the end of the
release the lever. (if equipped)
tem, use anti-freezing washer
wiper and washer switch lever.
fluids in the winter season or
Turn the switch to the desired posi-
Auto rear wiper (if equipped)
cold weather.
tion to operate the rear wiper and
The rear wiper will operate whilst the
washer.
vehicle is in reverse with the front
2 - High wiper speed
wipers ON by selecting the function
1 - Low wiper speed
on the LCD display.
O - Off
Go to ‘User settings → Convenience
→ Auto rear wiper (reverse)’.
3-129
Convenient features of your vehicle
DRIVER ASSIST SYSTEM
Rear view monitor (Type A)
This is a supplemental system that
WARNING
(if equipped)
shows behind the vehicle through
the mirror or navigation display whilst
backing-up.
•
Never rely solely on the rear
camera display when backing-
up.
WARNING
•
ALWAYS look around your
The Rear view monitor is not a
vehicle to make sure there are
safety device. It only serves to
no objects or obstacles
assist the driver in identifying
before moving the vehicle in
objects directly behind the mid-
any direction to prevent a col-
dle of the vehicle. The camera
lision.
does NOT cover the complete
•
Always pay close attention
area behind the vehicle.
when the vehicle is driven
OTM048049
close to objects, particularly
pedestrians, and especially
children.
OTM048050R
The Rear view monitor will activate
when the engine is running and the
shift lever is in the R (Reverse) posi-
tion.
3-130
NOTICE
Rear view monitor (Type B)
The system is activated when:
(if equipped)
• The engine is ON
• Do not spray the camera or its
• The shift lever is in D (Drive) or N
surrounding area directly with a
(Neutral) and you press the button
high pressure washer. Shock
(1)
applied from high pressure
water may cause the device to
not operate normally.
The system is deactivated when:
3
• Do not use any cleanser con-
• You press the button (1) again
taining acid or alkaline deter-
• You press the audio or AVN system
gents when cleaning the lens.
button (2)
Use only a mild soap or neutral
detergent, and rinse thoroughly
with water.
When the vehicle is reversing the
OTM048432R
screen switches to rear parking
assist screen.
i
Information
Always keep the camera lens clean.
Warning indicator in the screen is
The camera may not work normally if
indicated when:
the lens is covered with dirt, water or
• The tailgate is open
snow.
• The driver/passenger’s door is open
OTM048056L
The Rear View Monitor system
assists you to drive safely by allow-
ing you to check the rear view
through the screen whilst driving.
3-131
Convenient features of your vehicle
Parking Distance Warning
WARNING
WARNING
(Reverse) system (if equipped)
•
The Rear View Monitor system
•
ALWAYS look around your vehi-
is a supplementary driving
cle to make sure there are not
assist system. Make sure to
any objects or obstacles before
check the rear view directly
moving the vehicle in any direc-
for safety. What you see on the
tion to prevent a collision.
screen may differ from the
•
Always pay close attention
actual vehicle’s location.
when the vehicle is driven close
•
The camera may not operate
to objects, particularly pedestri-
properly if any foreign sub-
ans, and especially children.
stance is on the rear camera
•
Be aware that some objects
lens. Always keep the lens
may not be visible on the
clean.
OTM048045
screen or be detected by the
[B] : Sensor
•
When the rear view is dis-
sensors, due to the objects
played whilst driving, an icon
distance, size or material, all of
The Parking Distance Warning
(
) is indicated on the upper
which can limit the effective-
(Reverse) system assists the driver
ness of the sensor.
during reverse movement of the vehi-
right side of the screen.
cle by chiming if any object is sensed
within the distance of 120 cm (50
inches) behind the vehicle.
This system is a supplemental sys-
tem that senses objects within the
range and location of the sensors, it
cannot detect objects in other areas
where sensors are not installed.
3-132
Operation of the Parking
Types of warning sound and indicator
Distance Warning (Reverse)
Types of warning sound
Indicator
system
Operating condition
When an object is 120 cm to 60 cm (47 in. to 24 in.) from the rear
• This system will activate when
bumper : Buzzer beeps intermittently.
backing up with the ignition switch
in the ON position. However, if vehi-
3
cle speed exceeds 3 mph (5 km/h),
When an object is 60 cm to 30 cm (24 in. to 12 in.) from the rear
the system may not detect objects.
bumper : Buzzer beeps more frequently.
• If vehicle speed exceeds 6 mph (10
km/h), the system will not warn you
even though objects are detected.
When an object is within 30 cm (12 in.) of the rear bumper :
• When more than two objects are
Buzzer beeps continuously.
sensed at the same time, the clos-
est one will be recognised first.
3-133
Convenient features of your vehicle
NOTICE
To turn off the Parking Distance
Non-operational conditions of
Warning (Reverse) system
Parking Distance Warning
•
The indicator may differ from the
(if equipped)
(Reverse) system
illustration
depending on
The Parking Distance Warning
objects or sensors status. If the
■ Type A
(Reverse) system may not operate
indicator blinks, we recommend
normally when:
that you have your vehicle
checked by a HYUNDAI autho-
• Moisture is frozen to the sensor.
rised repairer.
• Sensor is covered with foreign mat-
•
If the audible warning does not
ter, such as snow or water, or the
sound or if the buzzer sounds
sensor cover is blocked.
intermittently when shifting into
R (Reverse) position, this may
indicate a malfunction with
Parking Distance Warning
(Reverse) system. If this occurs,
OTM048433R
we recommend that you have
■ Type B
your vehicle checked by a
HYUNDAI authorised repairer as
soon as possible.
OTM048047R
Push the button to turn off the
Parking Distance Warning (Reverse)
system. The indicator light on the
3-134
button will turn on.
There is a possibility of the Parking
Detecting range may decrease when:
The following objects may not be
Distance Warning (Reverse) system
recognised by the sensor:
•
Outside air temperature is extreme-
malfunction when:
ly hot or cold.
• Sharp or slim objects such as
•
Driving on uneven road surfaces
ropes, chains or small poles.
•
Undetectable objects smaller than
such as unpaved roads, gravel,
1 m (40 inches) and narrower than
• Objects, which tend to absorb sen-
bumps, or gradient.
14 cm (6 inches) in diameter.
sor frequency such as clothes,
•
Objects generating excessive noise
spongy material or snow.
such as vehicle horns, loud motor-
3
cycle engines, or truck air brakes
can interfere with the sensor.
WARNING
•
Heavy rain or water spray is present.
Your new vehicle warranty does
•
Wireless transmitters or mobile
not cover any accidents or dam-
phones are present near the sensor.
age to the vehicle or injuries to
•
The sensor is covered with snow.
its occupants related to a
Parking Distance Warning
•
Any non-factory equipment or acces-
(Reverse) system. Always drive
sories have been installed, or if the
safely and cautiously.
vehicle bumper height or sensor
installation has been modified.
3-135
Convenient features of your vehicle
Parking Distance Warning
•
Do not spray the sensors or its sur-
Parking Distance Warning
(Reverse) system precautions
rounding area directly with a high
(Reverse/Forward) system
pressure washer. Shock applied
(if equipped)
•
The Parking Distance Warning
from high pressure water may cause
(Reverse) system may not sound
the device to not operate normally.
■ Front sensor
consistently depending on the speed
and shapes of the objects detected.
•
The Parking Distance Warning
(Reverse) system may malfunction if
the vehicle bumper height or sensor
installation has been modified or
damaged. Any non-factory installed
equipment or accessories may also
interfere with the sensor perform-
ance.
•
The sensor may not recognise
OTM048046
objects less than 30 cm (11 in.) from
■ Rear sensor
the sensor, or it may sense an incor-
rect distance. Use caution.
•
When the sensor is frozen or stained
with snow, dirt, or water, the sensor
may be inoperative until the stains
are removed using a soft cloth.
•
Do not push, scratch or strike the
sensor with any hard objects that
could damage the surface of the
sensor. Sensor damage could occur.
OTM048045
[A] : Front sensor, [B] : Rear sensor
3-136
The Parking Distance Warning
Operation of the Parking
■ Type C
(Reverse/Forward) system assists
Distance Warning
the driver during movement of the
(Reverse/Forward) system
vehicle by chiming if any object is
■ Type A
sensed within the distance of 100 cm
(39 inches) in front and 120 cm (47
inches) behind the vehicle.
This system is a supplemental sys-
3
tem that senses objects within the
range and location of the sensors, it
cannot detect objects in other areas
where sensors are not installed.
OTM048175R
Operating condition
WARNING
•
This system will activate when the
OTM048449R
Parking
Distance
Warning
•
ALWAYS look around your vehi-
■ Type B
(Reverse/ Forward) system button
cle to make sure there are no
is pressed with the engine running.
objects or obstacles before
moving the vehicle in any direc-
tion to prevent a collision.
•
Always pay close attention
when the vehicle is driven close
to objects, particularly pedestri-
ans, and especially children.
•
Be aware that some objects
may not be visible on the
screen or be detected by the
OTM048462R
sensors, due to the objects
distance, size or material, all of
which can limit the effective-
ness of the sensor.
3-137
Convenient features of your vehicle
•
The Parking Distance Warning
Types of warning sound and indicator
cm (in)
(Reverse/Forward) system button
turns on automatically and acti-
Warning indicator
Distance
vates the Parking Distance
When driving
When driving
Warning sound
from object
Warning
(Reverse/Forward) sys-
forward
rearward
tem when you move the shift lever
61 ~ 100
Buzzer beeps
to the R
(Reverse) position.
Front
-
(24 ~39)
intermittently
However, if vehicle speed exceeds
6 mph (10 km/h), the system will
61 ~ 120
Buzzer beeps
Rear
-
not warn you even though objects
(24 ~47)
intermittently
are detected, and if vehicle speed
Buzzer beeps
exceeds 12 mph (20 km/h), the
Front
31 ~ 60
frequently
system will turn off automatically.
To turn on the system, press the
(12 ~24)
Buzzer beeps
Rear
-
Parking
Distance
Warning
frequently
(Reverse/Forward) system button.
Buzzer sounds
Front
•
When more than two objects are
continuously
30
sensed at the same time, the clos-
(12)
Buzzer sounds
est one will be recognised first.
Rear
-
continuously
NOTICE
• The indicator may differ from the illustration depending on objects or
sensors status. If the indicator blinks, we recommend that the system
be checked by a HYUNDAI authorised repairer.
• If the audible warning does not sound or if the buzzer sounds inter-
mittently when shifting into R (Reverse) position, this may indicate a
malfunction with the Parking Distance Warning (Reverse/Forward)
system. If this occurs, we recommend that you have your vehicle
checked by a HYUNDAI authorised repairer as soon as possible.
3-138
Non-operational conditions of
Detecting range may decrease when:
Parking Distance Warning
Parking Distance Warning
• Outside air temperature is
(Reverse/Forward) system
(Reverse/Forward) system
extremely hot or cold.
precautions
Parking Distance Warning
• Undetectable objects smaller than
•
The Parking Distance Warning
(Reverse/Forward) system may not
1 m and narrower than 14 cm in
(Reverse/Forward) system may not
operate normally when:
diameter.
sound consistently depending on the
speed and shapes of the objects
• Moisture is frozen to the sensor.
detected.
3
• Sensor is covered with foreign mat-
The following objects may not be
ter, such as snow or water, or the
•
The Parking Distance Warning
recognised by the sensor:
(Reverse/Forward) system may mal-
sensor cover is blocked.
• Sharp or slim objects such as
function if the vehicle bumper height
There is a possibility of Parking
ropes, chains or small poles.
or sensor installation has been mod-
Distance Warning (Reverse/Forward)
• Objects, which tend to absorb sen-
ified or damaged. Any non-factory
system malfunction when:
sor frequency such as clothes,
installed equipment or accessories
spongy material or snow.
may also interfere with the sensor
•
Driving on uneven road surfaces
such as unpaved roads, gravel,
performance.
bumps, or gradient.
WARNING
•
The sensor may not recognise
•
Objects generating excessive noise
objects less than 30 cm (11 in.) from
such as vehicle horns, loud motor-
Your new vehicle warranty does
the sensor, or it may sense an incor-
cycle engines, or truck air brakes
not cover any accidents or dam-
rect distance. Use caution.
can interfere with the sensor.
age to the vehicle or injuries to
•
When the sensor is frozen or stained
its occupants related to a
with snow, dirt, or water, the sensor
•
Heavy rain or water spray is present.
Parking Distance Warning
may be inoperative until the stains
•
Wireless transmitters or mobile
(Reverse/Forward) system.
are removed using a soft cloth.
phones are present near the sensor.
Always drive safely and cau-
•
Do not push, scratch or strike the
•
The sensor is covered with snow.
tiously.
sensor. Sensor damage could occur.
•
Any non-factory equipment or
accessories have been installed, or
if the vehicle bumper height or sen-
sor installation has been modified.
3-139
Convenient features of your vehicle
•
Do not spray the sensors or its sur-
Surround view monitor
i
Information
rounding area directly with a high
(if equipped)
pressure washer. Shock applied
•
When vehicle speed is over 15km/h,
from high pressure water may
the system will turn off. The system
cause the device to not operate
will not automatically turn on again,
normally.
even though vehicle speed gets
below 9 mph (15 km/h). Push the
button (1, indicator ON) again, to
turn on the system.
•
When the vehicle is backing up, the
system will turn ON regardless of
vehicle speed or button status.
However, if vehicle speed is over 15
km/h when driving forward, the
OTM048452R
SVM system will turn off.
The Surround View Monitor system
•
A warning appears on the system
can assist in parking by allowing the
when:
driver to see around the vehicle.
- The tailgate is opened
Push the button (1, indicator ON) to
- The driver's door is opened
operate the system. To cancel the
- The passenger's door is opened
system, push the button again (1,
indicator OFF).
- The outside rearview mirror is folded
•
If the system is not operating nor-
mally, we recommend that you take
Operating conditions
your vehicle to a HYUNDAI autho-
• When the Engine Start/Stop button
rised repairer and have the system
is in the ON position
checked.
• When the transmission is in D, N or
R
For more details, refer to the sep-
arately supplied manual with your
• When vehicle speed is under
9
vehicle.
mph (15km/h)
3-140
Rear view monitor (if equipped)
The system is activated when:
CAUTION
• The engine is ON
• The vehicle’s speed is over 9 mph
(15 km/h) and you press the SVM
(1) Front camera
button (1, indicator ON)
(2) Left/Right cam-
• The vehicle’s speed is under 9 mph
era
(15 km/h) and you press the
(3) Rear camera
3
(2) on the screen
The system is deactivated when:
ODH047435
• You press the SVM button (1, indi-
Surround View Monitor system
cator OFF) again
only serves to assist the driver
OTM048452R
• You press the
(2) on the
in parking. ALWAYS look around
screen again
your vehicle to make sure there
are no objects or obstacles
• You press the audio or AVN system
before moving the vehicle.
button (3)
NOTICE
i
Information
• If vehicle speed is over 9 mph (15
Always keep the camera lens
km/h)
clean. The camera may not work
normally if the lens is covered
- the rear image stays ON when the
with foreign material.
rear view was on the screen
- if other modes
(top, front wide,
OTM048053L
front right and front left) of SVM
You may check the rear view through
system was on the screen, the
the screen whilst driving.
screen changes to the screen of
rear view.
3-141
Convenient features of your vehicle
•
If the SVM system is ON and the
•
A warning appears on the SVM sys-
vehicle speed is under 9 mph (15
tem when
WARNING
km/h)
- the tailgate is opened
•
The Rear View Monitor system
- the rear image stays ON when the
- the driver/passenger’s door is
is a supplementary driving
rear view was on the screen
opened
assist system. Make sure to
- a pop-up for selecting the SVM
- the outside rearview mirror is folded
check the rear view directly
mode (top, front wide, front right
for safety. What you see on the
and front left) appears when press-
screen may differ from the
ing
(2) on the screen
actual vehicle’s location.
•
When the vehicle is backing up, the
•
The camera may not operate
rear image will be appear on the
properly if any foreign sub-
screen automatically regardless of
stance is on the rear camera
the vehicle speed or SVM button (1)
lens. Always keep the lens
status.
clean.
- If the rear image was ON, the
•
When the rear view is dis-
screen switches to the parking
played whilst driving, an icon
assist screen.
(
) is indicated on the upper
- If the screen (top, front wide, front
right and front left) of other modes
right side of the screen.
of SVM system was ON, the screen
for setting the initial rear view
mode appears.
- When the shift lever is moved from
R (Reverse) to D
(Drive), the
screen of the previous mode is dis-
played.
3-142
PARKING ASSIST (PARALLEL, PERPENDICULAR REVERSE) (IF EQUIPPED)
■ Parallel parking
■ Parallel exit
CAUTION
•
The vehicle will not stop for
pedestrians or objects that
may be in its path, so the driv-
er must monitor the manoeu-
vre.
3
•
Use the system only in park-
ing lots and places used for
parking.
OTM048057
OTM048059
•
The system does not work if
■ Reverse parking
there is no car parked in front
Parking Assist system helps drivers
of the parking space you are
park their vehicle by using sensors to
planning to park or if it is a
measure parking spaces, control the
diagonal parking space.
steering wheel to semi-automatically
park the vehicle and provide instruc-
•
After parking your vehicle
tion on the LCD display to help
using the system, the vehicle
through parking.
may not be parked at the
exact spot you have wished.
Additionally, the system provides
For example, the space
assistance when leaving
(parallel
between your vehicle and wall
exit) a parking space.
may not be the distance you
OTM048058
have desired.
•
Deactivate the system and
park your vehicle manually,
when the situation requires
parking manually.
3-143
