Hyundai Santa Fe (2019 year). Instruction - part 5

•

To help provide protection, the air

You can take steps to reduce the risk

■ Driver’s front air bag (1)

bags must inflate rapidly. The speed

of being injured by an inflating air

of air bag inflation is a consequence

bag. The greatest risk is sitting too

of extremely short time in which to

close to the air bag. An air bag needs

inflate the air bag between the

space to inflate. It is recommended

2

occupant and the vehicle structures

that drivers sit as far as possible

before the occupant impacts those

between the centre of the steering

structures. This speed of inflation

wheel and the chest whilst still main-

reduces the risk of serious or life-

taining control of the vehicle.

threatening injuries and is thus a

necessary part of air bag design.

However, the rapid air bag inflation

OLMB033054

can also cause injuries which can

When the SRSCM detects a suffi-

include facial abrasions, bruises

ciently severe impact to the front of

and broken bones because the

the vehicle, it will automatically

inflation speed also causes the air

deploy the front air bags.

bags to expand with a great deal of

force.

•

There are even circumstances

under which contact with the air

bag can cause fatal injuries, espe-

cially if the occupant is positioned

excessively close to the air bag.

2-61

Safety system of your vehicle

■ Driver’s front air bag (2)

■ Driver’s front air bag (3)

WARNING

To prevent objects from becom-

ing dangerous projectiles when

the passenger's air bag inflates:

• Do not install or place any

objects (drink holder, CD hold-

er, stickers, etc.) on the front

passenger's panel above the

glove box where the passen-

ger's air bag is located.

OLMB033055

OLMB033056

■ Passenger’s front air bag

• Do not install a container of

Upon deployment, tear seams mold-

liquid air freshener near the

ed directly into the pad covers will

instrument cluster or on the

separate under pressure from the

instrument panel surface.

expansion of the air bags. Further

opening of the covers allows full

inflation of the air bags.

What to expect after an air bag

A fully inflated air bag, in combina-

inflates

tion with a properly worn seat belt,

slows the driver's or the front pas-

After a frontal or side air bag inflates,

senger's forward motion, reducing

it will deflate very quickly. Air bag

the risk of head and chest injury.

inflation will not prevent the driver

OLMB033057

from seeing out of the windscreen or

After complete inflation, the air bag

being able to steer. Curtain air bags

immediately starts deflating, enabling

may remain partially inflated for

the driver to maintain forward visibili-

some time after they deploy.

ty and the ability to steer or operate

other controls.

2-62

Noise and smoke from inflating

Do not install a Child Restraint

WARNING

air bag

System on the front passenger

seat

When the air bags inflate, they make

After an air bag inflates, take

a loud noise and may produce smoke

the following precautions:

■ Type A

2

and powder in the air inside of the

•

Open your windows and doors

vehicle. This is normal and is a result

as soon as possible after

of the ignition of the air bag inflator.

impact to reduce prolonged

After the air bag inflates, you may feel

exposure to the smoke and

substantial discomfort in breathing

powder released by the inflat-

because of the contact of your chest

ing air bag.

with both the seat belt and the air

•

Do not touch the air bag stor-

bag, as well as from breathing the

age area’s internal compo-

smoke and powder. The powder may

nents immediately after an air

aggravate asthma for some people. If

bag has inflated. The parts

you experience breathing problems

that come into contact with an

after an air bag deployment, seek

OYDESA2042

inflating air bag may be very

medical attention immediately.

hot.

Never install a Child Restraint System

Though the smoke and powder are

in the front passenger seat.

•

Always wash exposed skin

nontoxic, they may cause irritation to

areas thoroughly with cold

the skin, eyes, nose, throat, etc. If this

water and mild soap.

is the case, wash and rinse with cold

WARNING

•

We recommend that a

water immediately and seek medical

HYUNDAI authorised repairer

attention if the symptoms persist.

NEVER use a rearward facing

Child Restraint on a seat pro-

replace the air bag immediately

tected by an ACTIVE AIRBAG in

after deployment. Air bags are

front of it, DEATH or SERIOUS

designed to be used only once.

INJURY to the CHILD can occur.

2-63

Safety system of your vehicle

Why didn't my air bag go off in

Air bag collision sensors

•

Place the ignition switch to

a collision?

the LOCK/OFF or ACC posi-

There are certain types of accidents

WARNING

tion, when the vehicle is being

in which the air bag would not be

towed to prevent inadvertent

To reduce the risk of an air bag

expected to provide additional protec-

air bag deployment.

tion. These include rear impacts, sec-

deploying unexpectedly and

•

We recommend that all air bag

causing serious injury or death:

ond or third collisions in multiple

repairs are conducted by a

impact accidents, as well as low

•

Do not hit or allow any objects

HYUNDAI authorised repairer.

speed impacts. Damage to the vehicle

to impact the locations where

indicates a collision energy absorp-

air bags or sensors are

tion, and is not an indicator of whether

installed.

or not an air bag should have inflated.

•

Do not perform maintenance

on or around the air bag sen-

sors. If the location or angle of

the sensors is altered, the air

bags may deploy when they

should not or may not deploy

when they should.

•

Do not install bumper guards

or replace the bumper with a

non-genuine part. This may

adversely affect the collision

and air bag deployment per-

formance.

2-64

1. SRS control module/Rollover sensor

2. Front impact sensor

3. Side pressure sensor (front)

2

4. Side impact sensor

5. Side impact sensor

OTM038060R/OTM038061R/OTM038062R/OTM038063R/OTM038064/OTM038065

2-65

Safety system of your vehicle

Air bag inflation conditions

Although the driver’s and front pas-

senger’s air bags are designed to

inflate in frontal collisions, they also

may inflate in other types of colli-

sions if the front impact sensors

detect a sufficient impact. Side and

curtain air bags are designed to

inflate in side impact collisions, but

they may inflate in other collisions if

the side impact sensors detect a suf-

ficient impact.

OTM038067

Also, the side and curtain air bags

are designed to inflate when a

OTM038066

rollover is detected by a rollover sen-

Front air bags

sor.

Front air bags are designed to inflate

If the vehicle chassis is impacted by

in a frontal collision depending on

bumps or objects on unimproved

the severity, speed or angles of

roads, the air bags may deploy. Drive

impact of the front collision.

carefully on unimproved roads or on

surfaces not designed for vehicle

traffic to prevent unintended air bag

deployment.

OTM038068

Side and curtain air bags

Side and curtain air bags are

designed to inflate when an impact is

detected by side collision sensors

depending on the severity, speed or

angles of impact resulting from a

side impact collision.

2-66

Air bag non-inflation conditions

2

OTM038070

OTM038071

Front air bags are not designed to

Front air bags may not inflate in side

OTM038069

inflate in rear collisions, because

impact collisions, because occupants

In certain low-speed collisions the air

occupants are moved backward by

move in the direction of the collision,

bags may not deploy. The air bags

the force of the impact. In this case,

and thus in side impacts, front air bag

are designed not to deploy in such

inflated air bags would not provide

deployment would not provide addi-

cases because they may not provide

any additional benefit.

tional occupant protection.

benefits beyond the protection of the

However, side and curtain air bags

seat belts.

may inflate depending on the severity,

vehicle speed and angles of impact.

2-67

Safety system of your vehicle

OTL035069

OTM038072

OTL035068

In an angled collision, the force of

Just before impact, drivers often

Front air bags may not inflate in

impact may direct the occupants in a

brake heavily. Such heavy braking

rollover accidents because front air

direction where the air bags would

lowers the front portion of the vehicle

bag deployment would not provide

not be able to provide any additional

causing it to “ride” under a vehicle

additional occupant protection.

benefit, and thus the sensors may

with a higher ground clearance. Air

not deploy any air bags.

bags may not inflate in this "under-

i

Information

ride" situation because deceleration

forces that are detected by sensors

The side and curtain air bags may

may be significantly reduced by such

inflate in a rollover situation, when it

“underride” collisions.

is detected by the rollover sensor.

2-68

SRS care

•

Do not place objects over or

The SRS is virtually maintenance-

near the air bag modules on

free and there are no parts you can

the steering wheel, instrument

safely service by yourself. If the SRS

panel, and the front passen-

2

air bag warning light does not illumi-

ger's panel above the glove

nate when the ignition switch is in the

box.

ON position, or continuously remains

•

Clean the air bag pad covers

on, we recommend that the system

with a soft cloth moistened

be immediately inspected by a

with plain water. Solvents or

HYUNDAI authorised repairer.

cleaners could adversely affect

We recommend any work on the SRS

the air bag covers and proper

OTM038073

system, such as removing, installing,

deployment of the system.

Air bags may not inflate if the vehicle

repairing, or any work on the steering

•

We recommend that inflated

collides with objects such as utility

wheel, the front passenger's panel,

air bags be replaced by a

poles or trees, where the point of

front seats and roof rails be performed

HYUNDAI authorised repairer.

impact is concentrated and the colli-

by a HYUNDAI authorised repairer.

•

If components of the air bag

sion energy is absorbed by the vehi-

Improper handling of the SRS system

cle structure.

may result in serious personal injury.

system must be discarded, or

if

the vehicle must be

scrapped, certain safety pre-

WARNING

cautions must be observed.

Consult a HYUNDAI autho-

To reduce the risk of serious

rised repairer for the neces-

injury or death take the follow-

sary information. Failure to

ing precautions:

follow these precautions

• Do not attempt to modify or

could increase the risk of per-

disconnect the SRS compo-

sonal injury.

nents or wiring, including the

addition of any kind of badges

to the pad covers or modifica-

tions to the body structure.

2-69

Safety system of your vehicle

Additional safety precautions

Adding equipment to or modify-

Air bag warning labels

ing your air bag equipped vehicle

Passengers should not move out of

or change seats whilst the vehicle

If you modify your vehicle by changing

is moving. A passenger who is not

your vehicle's frame, bumper system,

wearing a seat belt during a crash or

front end or side sheet metal or ride

emergency stop can be thrown

height, this may affect the operation of

against the inside of the vehicle,

your vehicle's air bag system.

against other occupants, or be ejected

from the vehicle.

Do not use any accessories on seat

belts. Devices claiming to improve

occupant comfort or reposition the

seat belt can reduce the protection

OTM038075R

provided by the seat belt and increase

Air bag warning labels are attached

the chance of serious injury in a crash.

to alert the passengers of potential

Do not modify the front seats.

risks of the air bag system.

Modification of the front seats could

Be sure to read all of the information

interfere with the operation of the sup-

about the air bags that are installed on

plemental restraint system sensing

your vehicle in this Owner’s Manual.

components or side air bags.

Do not place items under the front

seats. Placing items under the front

seats could interfere with the opera-

tion of the supplemental restraint sys-

tem sensing components and wiring

harnesses.

Do not cause impact to the doors.

Impact to the doors when the ignition

switch is in the ON position may cause

the air bags to inflate.

2-70

Convenient features of your vehicle

ACCESSING YOUR VEHICLE

Remote key (if equipped)

3. The doors will lock. The hazard

2. The doors will unlock. The hazard

warning lights will blink. Also, the

warning lights will blink two times.

outside rearview mirror will fold, if

Also, the outside rearview mirror

'Convenience

→ Welcome

will unfold, if 'Convenience

→

mirror/light → On door unlock' is

Welcome mirror/light → On door

selected from the User Settings

unlock' is selected from the User

mode on the LCD display. For

Settings mode on the LCD display.

more details, refer to "LCD

For more details, refer to "LCD

Display" in this chapter.

Display" in this chapter.

4. Make sure the doors are locked by

checking the position of the door

i

Information

lock button inside the vehicle.

After unlocking the doors, the doors

OPDE046001

will lock automatically after 30 sec-

WARNING

onds unless a door is opened.

Your HYUNDAI uses a remote key,

which you can use to lock or unlock

Do not leave the keys in your

a door (and tailgate) and even start

vehicle with unsupervised chil-

Tailgate unlocking

the engine.

dren. Unattended children

To unlock:

1. Door Lock

could place the key in the igni-

1. Press the Tailgate Unlock button

tion switch and may operate

2. Door Unlock

(3) on the remote key for more

power windows or other con-

than one second.

3. Tailgate Unlock

trols, or even make the vehicle

2. The hazard warning lights will

move, which could result in

blink two times.

serious injury or death.

Locking

To lock :

i

Information

1. Close all doors, engine bonnet

Unlocking

The word "HOLD" is written on the

and tailgate.

To unlock:

button to inform you that you must

2. Press the Door Lock button (1) on

press and hold the button for more

1. Press the Door Unlock button (2)

the remote key.

on the remote key.

than one second.

3-4

Start-up

Mechanical key

Remote key precautions

For detailed information refer to “Key

The remote key will not work if any of

Ignition Switch” in chapter 5.

the following occur:

• The key is in the ignition switch.

NOTICE

• You exceed the operating distance

limit (about 10 m [30 feet]).

To prevent damaging the remote

key:

• The remote key battery is weak.

3

•

Keep the remote key away from

• Other vehicles or objects may be

water or any liquid and fire. If the

blocking the signal.

inside of the smart key gets

• The weather is extremely cold.

damp (due to drinks or mois-

• The remote key is close to a radio

ture), or is heated, internal cir-

OPDE046003

transmitter such as a radio station

cuit may malfunction and may

or an airport which can interfere

void the vehicle warranty.

If the remote key does not operate

with normal operation of the remote

•

Avoid dropping or throwing the

normally, you can lock or unlock the

key.

door by using the mechanical key.

remote key.

If the remote key does not work cor-

To unfold the key, press the release

•

Protect the remote key from

rectly, open and close the door with

button then the key will unfold auto-

extreme temperatures.

the mechanical key. If you have a

matically.

problem with the remote key, it is rec-

To fold the key, fold the key manually

ommended that you contact a

whilst pressing the release button.

HYUNDAI authorised repairer.

If the remote key is in close proximity

NOTICE

to your mobile phone, the signal could

be blocked by your mobile phone’s

Do not fold the key without press-

normal operational signals.

ing the release button. This may

damage the key.

3-5

Convenient features of your vehicle

This is specifically relevant when the

Battery replacement

If you suspect your remote key might

phone is active such as making and

have sustained some damage, or

receiving calls, text messaging,

you feel your remote key is not work-

and/or sending/receiving emails.

ing correctly, it is recommended that

you contact a HYUNDAI authorised

Avoid placing the remote key and

your mobile phone in the same loca-

repairer.

tion and always try to maintain an

adequate distance between the two

i

Information

devices.

An inappropriately disposed

battery can be harmful to the

i

Information

environment and human

health. Dispose of the battery

Changes or modifications not express-

OPD046002

according to your local law(s)

ly approved by the party responsible

or regulations.

for compliance could void the user’s

If the remote key is not working prop-

authority to operate the equipment. If

erly, try replacing the battery with a

the keyless entry system is inoperative

new one.

due to changes or modifications not

Battery Type: CR2032

expressly approved by the party

To replace the battery:

responsible for compliance, it will not

1. Insert a slim tool into the slot and

be covered by your manufacturer’s

gently pry open the cover.

vehicle warranty.

2. Using a screw driver, remove the

NOTICE

battery cover.

3. Remove the old battery and insert

Keep the remote key away from

a new battery. Make sure the bat-

electromagnetic materials that

tery position is correct.

block electromagnetic waves to

4. Reinstall the battery cover and key

the key surface.

cover in the reverse order of

removal.

3-6

Smart key (if equipped)

Locking

4. Make sure the doors are locked by

checking the position of the door

lock button inside the vehicle.

i

Information

The door handle button will only

operate when the smart key is within

3

0.7~1 m (28~40 in.) from the outside

door handle.

Even though you press the outside

door handle button, the doors will not

OPDE046044

OTM048000R

lock and the chime will sound for

To lock :

three seconds if any of the following

Your HYUNDAI uses a Smart Key,

occur:

which you can use to lock or unlock

1. Close all doors, engine bonnet

a door (and tailgate) and even start

and tailgate.

• The Smart Key is in the vehicle.

the engine.

• The Engine Start/Stop button is in

2. Either press the door handle but-

1. Door Lock

ton or press the Door Lock button

ACC or ON position.

2. Door Unlock

(1) on the smart key.

• Any door except the tailgate is

open.

3. Tailgate Unlock

3. The hazard warning lights will

blink. Also, the outside rearview

mirror will fold, if 'Convenience →

Welcome mirror/light → On door

unlock or On driver approach' is

selected from the User Settings

mode on the LCD display. For

more details, refer to "LCD

Display" in this chapter.

3-7

Content   ..  3  4  5  6   ..
