Hyundai H-100 Truck (2012 year). Instruction

1 FEATURES OF YOUR HYUNDAI

DAY/NIGHT INSIDE

PARKING BRAKE

REARVIEW MIRROR

B510C01A-AAT

B520A01A-AAT

B530A02A-AAT

Folding the Outside Rearview

Mirrors

HHR2057

HHR3033

Your Hyundai is equipped with a day/

Applying the parking brake

HHR2136

night inside rearview mirror. The "night"

To engage the parking brake, first apply

position is selected by flipping the tab

To fold the outside rearview mirrors,

the foot brake and then without press-

at the bottom of the mirror toward you.

push them towards the rear.

ing the release button in, pull the park-

In the "night" position, the glare of

The outside rearview mirrors can be

ing brake lever up as far as possible. In

headlights of cars behind you is re-

folded rearward for parking in narrow

addition it is recommended that when

duced.

areas.

parking the vehicle on a gradient, the

shift lever should be positioned in the

appropriate low gear on manual transaxle

WARNING:

vehicles or in the P (Park) position on

Do not adjust or fold the outside

Do not modify the inside mirror and

automatic transaxle vehicles.

rearview mirrors while the vehicle

don’t install a wide mirror. It could

is moving. This could result in loss

result in injury, during an accident

of control, and an accident which

or deployment of the air bag.

could cause death, serious injury

or property damage.

FEATURES OF YOUR HYUNDAI

HOOD RELEASE

B570A01HR-GAT

CAUTION:

o Driving with the parking brake ap-

plied will cause excessive brake

pad (or lining) and brake rotor

wear.

o Do not operate the parking brake

while the vehicle is moving except

in an emergency situation. It could

damage the vehicle system and

B570B01HR

make endanger driving safety.

B570A01HR

2. Push the secondary latch lever to

1. Pull the release knob to unlatch the

the left and lower the hood.

Releasing the parking brake

hood.

To release the parking brake, first apply

To close the hood, lift up it and hit the

the foot brake and pull the parking brake

center of the hood with your hand. Make

WARNING:

lever slightly. Secondly, depress the

sure that it locks into place.

Open the hood after turning off the

release button and lower the parking

engine on a flat surface, shifting the

brake lever while holding the button.

NOTE:

shift lever to the 1st(First) gear or

If the hood will not open because ice

R(Reverse) for manual transaxle, and

has formed around it, tap lightly or

setting the parking brake.

push on the hood to break the ice

and release the hood. Do not pry on

the hood. If necessary, spray around

the hood with an approved de-icer

fluid (do not use radiator anti-freeze)

or move the vehicle to a warm place

and allow the ice to melt.

1 FEATURES OF YOUR HYUNDAI

FUEL TANK CAP

B560A03HR-GAT

WARNING:

o Always double check to be sure

o Make sure to refuel your vehicle

that the hood is firmly latched

according to the "Fuel require-

before driving away.

ments" suggested in section 1.

o Do not press excessively or step

o Fuel vapors are dangerous. Be-

on the hood. This can cause the

fore refueling, always stop the

hood to fall and result in serious

engine and never allow sparks or

injury.

open flames near the tank area. If

you need to replace the tank cap,

use a genuine Hyundai replace-

HHR2036

ment part.

The fuel tank cap is located at the left

If you open the fuel tank cap dur-

side of the vehicle body.

ing high ambient temperatures, a

The fuel tank cap can be unlocked by

slight "pressure sound" may be

turning the key counterclockwise.

heard. This is normal and not a

To lock the fuel tank cap, turn it clock-

cause for concern. Whenever you

wise until it locks into place.

open the fuel tank cap, turn it

slowly.

NOTE:

o Automotive fuels are flammable/

If the fuel tank cap will not open

explosive materials. When refuel-

because ice has formed around it,

ing, please note the following

tap lightly on the cap to break the ice

guidelines carefully.

and release the cap. If necessary,

Before touching the fuel nozzle or

spray around the cap with an ap-

fuel tank cap, have one's hands in

proved de-icer fluid (do not use ra-

contact with metal parts away from

diator anti-freeze) or move the ve-

the tank neck to discharge static

hicle to a warm place and allow the

electricity.

ice to melt.

FEATURES OF YOUR HYUNDAI

REAR GATE

B191A01HR-GAT

2. Lower the rear gate slowly with it

Do not get back in the vehicle

To open the rear gate

received on both arms.

while refueling. Do not operate

anything that can produce static

electricity. Static electricity dis-

charge can ignite fuel vapors re-

WARNING:

sulting in an explosion.

When the rear combination lamps

When using a portable fuel con-

are hidden, other road users should

tainer, be sure to place the con-

be warned by means of warning tri-

tainer on the ground while refuel-

angle or other devices.

ing. Static electricity discharge

from the container can ignite fuel

vapors causing a fire. While start-

To close the rear gate

ing refueling, contact should be

HHR2025

maintained until the filling is com-

1. Lift up the rear gate handle, push it

plete.

inside and pull it toward you.

Do not use cellular phones around

a gas station. The electric current

or electronic interference from cel-

lular phones can ignite fuel va-

pors causing a fire.

When refueling, always turn the

engine off. Sparks by engine com-

partment electrical equipment can

ignite fuel vapors causing a fire.

HHR2031

After refueling, check to make sure

Lift the rear gate up and lock the rear

the fuel tank cap is securely closed,

gate handle in place.

and then start the engine.

OHR028106

Do not smoke or try to light ciga-

rettes around a gas station. Auto-

motive fuels are flammable.

1 FEATURES OF YOUR HYUNDAI

SIDE GATE

B191B01HR-GAT

To close the side gate

To open the side gate

Support bar

OHR028117

2. Remove the side gate handle from

OHR028118

HHR2026

the hook after pulling it up.

1. Lift the side gate up and lock the side

1. With the rear gate opened, pull up the

3. Lower the side gate slowly with it

gate handle in place.

knob to release the support bar down.

received on both arms.

WARNING:

When locking the side gate handle,

be careful not to get your fingers into

the chink in the handle.

FEATURES OF YOUR HYUNDAI

EXTERIOR TOOL BOX

SUN VISOR

B650A02HR-GAT

B580A01HR-GAT

(If Installed)

(1)

OHR028119

OHR028107

2. Push the knob down to lock the side

OHR048100

Your Hyundai is equipped with sun

gates.

The exterior tool box is located behind

visors to give the driver and front pas-

the rear tire on left side to store jack and

senger either frontal or sideward shade.

tool.

To reduce glare or to shut out direct

To open it, pull up the clamp lever (1)

rays of the sun, turn the sun visor down.

and unhook the clamp.

Ticket holders are provided on the back

of the sun visor for the driver and front

passenger.

1 FEATURES OF YOUR HYUNDAI

STEERING WHEEL TILT

HORN

LEVER

B600A01HR-AAT

B610B01A-GAT

(If Installed)

WARNING:

o Do not place the sun visor in such

a manner that it obscures visibil-

ity of the roadway, traffic or other

objects.

o For your safety, do not obstruct

your vision when using the

sunvisor.

B610B01HR

OHR028108

Press the center hub of the steering

To Adjust the Steering Wheel:

wheel to sound the horn.

1. Push the lever and hold it to unlock.

2. Raise or lower the steering wheel to

the desired position.

3. After adjustment, release the lever.

WARNING:

Do not attempt to adjust the steering

wheel while driving as this may re-

sult in loss of control of the vehicle

which may cause serious injury or

death.

FEATURES OF YOUR HYUNDAI

HEATING AND COOLING CONTROL

B710A01TB-GAT

B710B01S-AAT

(If Installed)

CENTER VENTILATOR

The center ventilators are located in the

middle of the dashboard. The direction

of air flow from the vents in the center

of the dashboard is adjustable.

To control the direction of the air flow,

move the knob in the center of the vent

up-and-down and side-to-side.

B710C02HP-AAT

SIDE VENTILATOR

The side ventilators are located on

each side of dashboard. To change the

direction of the air flow, move the knob

in the center of the vent up-and-down

and side-to-side.

The vents are opened when the vent

knob is moved to " " position. The

vents are closed when the vent knob is

moved to " ". Keep these vents clear

of any obstructions.

1. Side Defrost Nozzle

2. Side Ventilator

3. Windshield Defrost Nozzle

OHR028110

4. Center Ventilator

1 FEATURES OF YOUR HYUNDAI

HEATING AND VENTILATION

B670A01HR-GAT

B670D01HR-GAT

(If Installed)

Air Flow Control

OHR028111

HHR2080

Face-Level

Selecting the "Face" mode will cause

This is used to direct the flow of air. Air

air to be discharged through the face

can be directed to the floor, dashboard

level vents.

outlets, or windshield. Five symbols

are used to represent Face, Bi-Level,

Floor, Floor-Defrost and Defrost air

position.

HHR2017

1. Air flow control switch

2. Fan speed control switch

3. Temperature control switch

4. Air intake control switch

5. Air conditioning switch

FEATURES OF YOUR HYUNDAI

OHR028112

OHR028113

OHR028114

Bi-Level

Floor-Level

Floor-Defrost Level

Air is discharged through the face vents

Air is discharged through the floor

Air is discharged through the wind-

and the floor vents. This makes it

vents, windshield defroster nozzle, side

shield defroster nozzle, the floor vents,

possible to have cooler air from the

defroster nozzle, side ventilator.

side defroster nozzle, side ventilator.

dashboard vents and warmer air from

the floor outlets at the same time.

1 FEATURES OF YOUR HYUNDAI

B670B01A-AAT

B670E02A-AAT

Fan Speed Control

Temperature Control

(Blower Control)

OHR028115

Cool

Warm

Defrost-Level

HHR2087

Air is discharged through the wind-

HHR2086

This control is used to adjust the degree

shield defroster nozzle, side defroster

This is used to turn the blower fan on or

of heating or cooling desired.

nozzle, side ventilator.

off and to select the fan speed.

This blower fan speed, and therefore

the volume of air delivered from the

system, may be controlled manually

by setting the blower control between

the "1" and "4" positions.

FEATURES OF YOUR HYUNDAI

HEATING CONTROLS

B670C01E-AAT

With the "Fresh" mode selected, air

B690A01HR-GAT

Air Intake Control

enters the vehicle from the outside and

is heated or cooled according to the

function selected.

With the "Recirculation" mode selected,

air from within the passenger compart-

ment will be drawn through the heating

system and heated or cooled according

to the function selected.

NOTE:

It should be noted that prolonged

OHR028116

operation of the heating in "Recircu-

This is used to select fresh outside air

lation" mode (

) will give rise to

or recirculating inside air.

fogging of the windshield and side

To change the air intake control mode

windows and the air within the pas-

(Fresh mode, Recirculation mode), push

senger compartment will become

the control button.

stale. In addition, prolonged use of

the air conditioning with the "Recir-

FRESH MODE (

) : The indicator

culation" mode (

) selected may

light on the button goes off when the air

result in the air within the passenger

intake control is fresh mode.

compartment becoming excessively

dry.

HHR2091

RECIRCULATION MODE (

): The

For normal heating operation, set the air

indicator light on the button is illumi-

intake control to the fresh air (

)

nated when the air intake control is

position and the air flow control to the

recirculation mode.

floor (

) position.

1 FEATURES OF YOUR HYUNDAI

BI-LEVEL HEATING

For faster heating, the air intake control

B700A01A-AAT

Your Hyundai is equipped with bi-level

should be set in the recirculate (

)

heating controls. This makes it pos-

position.

sible to have cooler air from the dash-

board vents and warmer air from the

If the windows fog up, set the air flow

floor outlets at the same time. To use

control to the defrost (

) position and

this feature:

the air intake control to the fresh air (

)

o Set the air intake control to the fresh

position.

air (

) position.

o Set the air flow control at the bi-level

For maximum heat, move the tempera-

(

) position.

ture control to "Warm".

o Set the temperature control between

"Cool" and "Warm".

HHR2092

FEATURES OF YOUR HYUNDAI

VENTILATION

DEFROSTING/DEFOGGING

B710A01S-AAT

To operate the ventilation system:

B720A01HR-GAT

o Set the air intake control to "Fresh"

mode (

o To direct all intake air to the dash-

board vents, set the air flow control

to "Face".

o Adjust the fan speed control to the

desired speed.

o Set the temperature control between

"Cool" and "Warm".

B710A01HR

B720B01HR

1 FEATURES OF YOUR HYUNDAI

Use the heating/ventilation system to

To remove the frost or exterior

o Set the air flow control to the defrost

defrost or defog the windshield:

(

) position.

fog on the windshield:

o If the vehicle is equipped with a air

To remove interior fog on the

conditioning system, turn on the air

conditioning switch.

windshield:

o Set the air intake control to the fresh

(

) position.

o Set the air flow control to the defrost

o Set the fan speed control to position

(

) position.

"3" or "4".

o If the vehicle is equipped with a air

o Set the temperature control to warm.

conditioning system, turn on the air

conditioning switch.

o Set the air intake control to the fresh

air (

) position.

NOTE:

o Set the fan speed control between

When the A/C is operated continu-

"1" and "4" position.

ously on the floor-defrost level (

)

o Set the temperature control to the

or defrost level (

), it may cause

desired position.

fog to form on the exterior wind-

shield. If this occurs, set the air

flow control to the face level posi-

tion (

) and fan speed control to

the low position.

B720B02HR

FEATURES OF YOUR HYUNDAI

AIR CONDITIONING SYSTEM

B730A01L-AAT

B740A01A-AAT

B740B02A-AAT

Operation Tips

Air Conditioning Switch

Air Conditioning Operation

(If Installed)

(Cooling)

To keep dust or unpleasant fumes

from entering the car through the

ventilation system, temporarily set

the air intake control at "Recircula-

tion (

)". Be sure to return the

control to "Fresh (

)" when the

irritation has passed to keep fresh air

in the vehicle. This will help keep the

driver alert and comfortable.

Air for the heating/cooling system is

drawn in through the grilles just

ahead of the windshield. Care should

OHR028109

be taken that these are not blocked

by leaves, snow, ice or other ob-

The air conditioning is turned on by

structions.

pushing the A/C button on the heating/

To prevent interior fog on the wind-

air conditioning control panel.

shield, set the air intake control to

the fresh air (

) position, fan speed

to the desired position, turn on the air

conditioning system, and adjust tem-

perature control to desired tempera-

ture.

B740B01HR

1 FEATURES OF YOUR HYUNDAI

To use the air conditioning to cool the

B740C01A-AAT

For dehumidified heating:

interior:

De-Humidified Heating

Turn on the fan control switch (2).

Turn on the air conditioning switch

o Turn on the fan control switch (2).

(5). The air conditioning indicator

o Turn on the air conditioning switch

light should come on at the same

(5) by pushing in on the switch.

time.

The air conditioning indicator light

Set the air intake control (4) to the

should come on at the same time.

fresh air (

) position.

o Set the air intake control (4) to the

Set the air flow control (1) to the face

position.

(

) position.

o Set the temperature control (3) to

Adjust the fan control (2) to the de-

"Cool". ("Cool" provides maximum

sired speed.

cooling. The temperature may be

For more rapid action, set the fan at

moderated by moving the control

one of the higher speeds.

toward "Warm".)

Adjust the temperature control (3) to

o Adjust the fan control (2) to the de-

provide the desired amount of

sired speed. For greater cooling, turn

warmth.

the fan control to one of the higher

speeds or temporarily select the

position on the air intake control.

B740C01HR

Hyundai H-100 Truck (2012 year). Instruction - part 4
