YOUR VEHICLE AT A GLANCE
B250A01TB-GAT
INSTRUMENTS AND CONTROLS (LEFT-HAND DRIVE)
B250A01TB
F8
YOUR VEHICLE AT A GLANCE
1. Headlight Leveling Switch (If installed)
12.Hood Release Lever
2. Front Fog Light Switch (If installed)
13.Fuse Box
3. Multi-Function Light Switch
14.Audio Remote Control Switch (If installed)
4. Instrument Cluster
15.Heating/Air Conditioning Control Panel
5. Horn and Driver's Airbag (If installed)
(If installed)
6. Windshield Wiper/Washer Switch
16.Cigarette Lighter
7. Digital Clock
17.Ashtray
8. Hazard Warning Light
18.Front Drink Holder
9. Audio System (If installed)
19.Shift Lever (If installed)
10.Passenger's Airbag (If installed)
20.Parking Brake Lever
11.Glove Box
21.Rear Drink Holder
!
CAUTION:
When installing a container of liquid air freshener inside a vehicle, do not place it near the instrument cluster nor
on the instrument panel pad surface. If there is any leakage from the air freshener onto these areas (instrument
cluster, instrument panel pad or air ventilator), it may damage these parts.If the liquid from the air freshener does
leak onto these areas, wash them with water immediately.
F9
YOUR VEHICLE AT A GLANCE
B250B01TB-GAT
INSTRUMENTS AND CONTROLS (RIGHT-HAND DRIVE)
B250B01TB
F10
YOUR VEHICLE AT A GLANCE
1. Glove Box
12. Parking Brake Lever
2. Passenger's Airbag (If installed)
13. Shift Lever (If installed)
3. Audio System (If installed)
14. Front Drink Holder
4. Hazard Warning Light
15. Ashtray
5. Digital Clock
16. Power Outlet (If installed)
6. Windshield Wiper/Washer Switch
17. Heating/Air Conditioning Control Panel
7. Horn and Driver's Airbag (If installed)
(If installed)
8. Instrument Cluster
18. Audio Remote Control Switch (If installed)
9. Multi-Function Light Switch
19. Fuse Box
10. Headlight Leveling Switch (If installed)
20. Hood Release Lever
11. Rear Drink Holder
!
CAUTION:
When installing a container of liquid air freshener inside a vehicle, do not place it near the instrument cluster nor
on the instrument panel pad surface. If there is any leakage from the air freshener onto these areas (instrument
cluster, instrument panel pad or air ventilator), it may damage these parts. If the liquid from the air freshener does
leak onto these areas, wash them with water immediately.
F11
YOUR VEHICLE AT A GLANCE
B255A01TB-GAT
INDICATOR SYMBOLS ON THE INSTRUMENT PANEL
SRS (Airbag) Service Reminder
Door Ajar Warning Light and Chime
Indicator
Passenger's Front Airbag OFF
Low Fuel Level Warning Light
Indicator Light (If Installed)
ABS Service Reminder Indicator
Malfunction Indicator Light
O/D OFF Indicator
Seat Belt Warning Light
(Automatic transaxle only)
Electric Power Steering System (EPS)
Turn Signal Indicator Lights
Warning Light
Electronic Stability Program Indicator
High Beam Indicator Light
Lights (If Installed)
Low Oil Pressure Warning Light
Immobilizer Warning Light
Parking Brake/Brake Fluid Level
Diesel Pre-heat Indicator Light (Diesel only)
Warning Light
Charging System Warning Light
Fuel Filter Warning Light (Diesel only)
Tail Gate Open Warning Light
Engine Coolant Temperature Indicator
F12
* A detail explanations of these items will be found on page 1-50
1. FEATURES OF YOUR HYUNDAI
Fuel Recommendations
1-2
Breaking in Your New Hyundai
1-4
1
key (Immobilizer system)
1-6
Theft-alarm system
1-11
Power windows
1-15
Seat
1-16
Seat Belt
1-23
Child restraint system
1-30
Supplemental restraint (AIRBAG) system
1-38
Instrument cluster and indicator lights
1-46
Warning Light and Indicator
1-50
Trip computer
1-59
Multi-Function Light Switch
1-61
Windshield wiper/Washer Switch
1-63
Sunroof
1-71
Mirror
1-74
Hood Release
1-78
How to use luggage Room
1-82
Heating and cooling control
1-88
Stereo sound system
1-97
Audio system
1-99
Antenna
1-130
1- 2 FEATURES OF YOUR HYUNDAI
B010A02TB-GAT
Except Europe - Unleaded gasoline
Diesel fuel
FUEL RECOMMENDATIONS
with a Pump Octane Rating of 87 (Re-
Diesel engine must be operated only on
Use Unleaded Gasoline
search Octane Number 91) or higher
commercially available diesel fuel that
must be used in Hyundai vehicle.
complies with EN 590 or comparable
If leaded gasoline is used, it will cause
standard. (EN stands for "European
the catalytic converter to become inef-
Norm"). Do not use marine diesel fuel,
fective and the emission control sys-
heating oils, or non-approved fuel addi-
tem to malfunction. This can also result
tives, as this will increase wear and
in increased maintenance expense.
cause damage to the engine and fuel
To avoid accidental use of leaded fuel,
system.
the large nozzle used with leaded gaso-
The use of non-approved fuels and / or
line at service stations can not be
fuel additives will result in a limitation of
inserted into fuel tank opening of Hyundai
your warranty rights.
vehicle.
Diesel fuel of above cetane 52 is used
B010A01TB
in Hyundai vehicle. If two types of
For Europe - For the optimal vehicle
NOTE:
diesel fuel are available, use summer or
performance, we recommend you to
o For some countries, Hyundai ve-
winter fuel properly according to the
use unleaded gasoline with an octane
hicles are designed to use leaded
following temperature conditions.
rating of RON (Research Octane Num-
gasoline. When you are going to
ber) 95 /AKI (Anti Knock Index) 91 or
use leaded gasoline, ask to
o Above -5°C (23°F) ... Summer type
higher.
Hyundai dealer whether leaded
diesel fuel.
You may use unleaded gasoline with an
gasoline in your vehicle is avail-
o Below -5°C (23°F) ... Winter type
octane rating of RON 91~94/AKI 87~90
able or not.
diesel fuel.
but it may result in slight performance
o Octane Rating of leaded gaso-
Watch the fuel level in the tank very
reduction of the vehicle.
line is same with unleaded one.
carefully : If the engine stops through
fuel failure, the circuits must be com-
pletely purged to permit restarting.
FEATURES OF YOUR HYUNDAI 1- 3
B010B01A-AAT
Biodiesel
What About Gasohol?
!
Commercially supplied Diesel blends
CAUTION:
Gasohol (a mixture of 90% unleaded
of no more than 7% biodiesel, com-
o Do not let any gasoline or water
gasoline and 10% ethanol or grain
monly known as "B7 Diesel" may be
enter the tank. This would make it
used in your vehicle if Biodiesel meets
alcohol) may be used in your Hyundai.
necessary to drain it out and to
However, if your engine develops
EN 14214 or equivalent specifications.
bleed the lines to avoid jamming
driveability problems, the use of 100%
(EN stands for "European Norm"). The
the injection pump and damaging
use of biofuels exceeding 7% made
unleaded gasoline is recommended.
the engine.
Fuels with unspecified quantities of
from rapeseed methyl ester (RME),
o In winter, in order to cut down
alcohol, or alcohols other than ethanol,
fatty acid methyl ester (FAME), veg-
incidents due to freezing, paraffin
should not be used.
etable oil methyl ester (VME) etc. or
oil may be added to the fuel if the
mixing diesel exceeding
7% with
temperature drops to below
biodiesel will cause increased wear or
-10°C. Never use more than 20%
damage to the engine and fuel system.
paraffin oil.
B010D01S-AAT
Repair or replacement of worn or dam-
Do not Use Methanol
aged components due to the use of non
approved fuels will not be covered by
Fuels containing methanol (wood al-
!
the manufactures warranty.
cohol) should not be used in your
CAUTION: Diesel Fuel
Hyundai. This type of fuel can reduce
It is recommended to use the regu-
vehicle performance and damage com-
lated automotive diesel fuel for die-
!
ponents of the fuel system.
CAUTION:
sel vehicle equipped with the DPF
o Never use any fuel, whether diesel
system.
or B7 biodiesel or otherwise that
!
If you use diesel fuel including high
CAUTION:
fails to meet the latest petroleum
sulfur (more than 50 ppm sulfur) and
Your Hyundai's New Vehicle Lim-
industry specification.
unspecified additives, it can cause
ited Warranty may not cover dam-
o Never use any fuel additives or
the DPF system to be damaged and
age to the fuel system and perfor-
treatments that are not recom-
white smoke can be emitted.
mance problems that are caused by
mended or approved by the ve-
the use of methanol or fuels con-
hicle manufacturer.
taining methanol.
1- 4 FEATURES OF YOUR HYUNDAI
B010E01A-AAT
B020A01S-GAT
o
Don't let the engine idle longer than 3
Gasolines for Cleaner Air
BREAKING IN YOUR NEW
minutes at one time.
HYUNDAI
o
Don't tow a trailer during the first
To help contribute to cleaner air,
Hyundai recommends that you use
During the First 2,000 Km (1,200
2,000 km (1,200 miles) of operation.
gasolines treated with detergent addi-
Miles) (Gasoline Engine)
tives, which help prevent deposit for-
No formal "break-in" procedure is re-
mation in the engine. These gasolines
quired with your new Hyundai. How-
will help the engine run cleaner and the
ever, you can contribute to the eco-
Emission Control System performance.
nomical operation and durability of your
Hyundai by observing the following
recommendations during the first 2,000
km (1,200 miles).
B010F01A-AAT
Operation in Foreign Countries
o Don't drive faster than 88 km/h (55
mph).
If you are going to drive your Hyundai
o While driving, keep your engine
in another country, be sure to:
speed (rpm, or revolutions per
minute) between 2,000 rpm and
o Observe all regulations regarding
4,000 rpm.
registration and insurance.
o Use moderate acceleration. Don't
o Determine that acceptable fuel is
start, depress the accelerator pedal
available.
fully.
o For the first 300 km (200 miles), try
to avoid hard stops.
o Don't lug the engine (in other words,
don't drive so slowly in toohigh a
gear that the engine "bucks": shift to
a lower gear).
o Whether going fast or slow, vary your
speed from time to time.
FEATURES OF YOUR HYUNDAI 1- 5
B020B01FC-GAT
B030A01A-AAT
B030B01A-AAT
BREAKING IN YOUR NEW
KEYS
Record Your Key Number
HYUNDAI
During the First 1,000 Km (600
Miles) (Diesel Engine)
No formal "break-in" procedure is re-
quired with your new Hyundai. However,
you can contribute to the economical
operation and durability of your Hyundai
by observing the following recommenda-
tions during the first 1,000 km (600 miles).
o While driving, keep your engine speed
B030A01E
B030B01E
(rpm, or revolutions per minute) within
3,000 rpm.
For greater convenience, the same key
A code number is stamped on the
o While driving, keep under three quar-
operates all the locks in your Hyundai.
number plate that came with the keys
ters of maximum speed.
However, because the doors can be
to your Hyundai. This key number
o Use moderate acceleration. Don't start,
locked without a key, carrying a spare
plate should not be left with the keys
depress the accelerator pedal fully.
key is recommended in case you acci-
but kept in a safe place, not in the
o For the first 300 km (200 miles), try to
dentally lock one key inside the car.
vehicle. The key number should also
avoid hard stops.
be recorded in a place where it can be
o Don't lug the engine (in other words,
found in an emergency.
don't drive so slowly in too-high a gear
that the engine "bucks": shift to a lower
If you need additional keys, or if you
gear).
should lose your keys, your authorized
o Whether going fast or slow, vary your
Hyundai dealer can make new keys if
speed from time to time.
you can supply the key number.
o Don't let the engine idle longer than 3
minutes at one time.
o Don't tow a trailer during the first 1,000
km (600 miles) of operation.
1- 6 FEATURES OF YOUR HYUNDAI
B880A01A-GAT
B880C02A-GAT
IMMOBILIZER SYSTEM
Key Numbers
!
(If Installed)
WARNING:
In order to prevent theft of your ve-
The immobilizer system is an anti-theft
hicle, do not leave spare keys any-
device, designed to deter automobile theft.
where in your vehicle. Your immobi-
B880B06A-AAT
lizer password is a customer unique
Keys
password and should be kept confi-
dential. Do not leave this number
anywhere in your vehicle.
OTB028003
!
CAUTION:
The vehicle key number is recorded
o When starting the engine, do not
upon a metal tag attached to the keys
use the key with other immobi-
when the vehicle is first delivered to
lizer keys in close proximity. Oth-
you.
erwise, the engine may not start or
The key number should be recorded
OTB028002
may stop soon after it starts.
and kept in a safe place in case the
Keep each keys separately not to
need to order further keys arises. New
All of the locks fitted to the vehicle are
have any malfunction after you
keys are available from any Hyundai
operated by the same key. However,
receive your new vehicle.
dealer by quoting the relevant key num-
since it is possible to lock the doors
o Do not put metal accessories near
ber.
without the use of the key, care should
the key or ignition switch.
In the interest of security, the metal tag
be exercised to ensure that the key
The engine may not start for the
attached to the keys which bears the
does not become locked inside the
metal accessories may interrupt
key number should be removed from
vehicle by mistake.
the transponder signal from nor-
the key ring after you receive your new
NOTE:
mally transmitting.
vehicle. In addition, key numbers can-
If you make your own duplicate key,
not be provided by Hyundai for security
you will not be able to cancel the
reasons.
system or start the engine.
FEATURES OF YOUR HYUNDAI 1- 7
B880D02A-GAT
If you need additional keys or if you
NOTE:
Limp home procedures
should lose your keys, your authorized
You can get the limp home pass-
Hyundai dealer can make new keys.
word when the vehicle is first deliv-
ered to you. If you do not have the
password, consult your authorized
Hyundai dealer.
1. To set the password you may turn
the ignition key "ON" and then turn
it "OFF" according to the digit num-
bers, then the immobilizer indicator
will blink along with the operation of
the ignition key. For example, turn
HNF2011
the ignition key once for digit num-
In case the immobilizer warning indica-
ber "1", and twice for "2", and so on.
tor blinks for five seconds when the
However, for the digit number "0",
ignition key is turned to "ON" position,
you must turn the ignition key for 10
this indicates that the immobilizer sys-
times.
tem is out of order. And you cannot
2. Wait for 3~10 seconds.
start the engine without the limp home
3. You may set the remaining number
procedures with ignition key.
of digits by following the same pro-
The following procedure is how to start
cedures 1 and 2.
the engine with the function of the limp
4. If all of four digits have been tried
home. (0, 1, 2, 3 as a sample pass-
successfully, turn the ignition key
word).
"ON" and check that the immobilizer
indicator illuminates. From this time,
you have to start your engine within
30 seconds. If you start your engine
after 30 seconds, your engine will not
start.
1- 8 FEATURES OF YOUR HYUNDAI
B040A02Y-AAT
B040B01A-AAT
NOTE:
DOOR LOCKS
Locking and Unlocking Front
If the engine dies while driving after
Doors With a Key
limp home procedure, you can start
your engine within 8 seconds with-
!
WARNING:
UNLOCK
out limp home procedure again.
o Unlocked doors can be danger-
LOCK
ous. Before you drive away (es-
5. If the immobilizer indicator blinks for
pecially if there are children in
five seconds, you have to try the
the car), be sure that all the doors
limp home procedure again from the
are securely closed and locked
beginning.
so that the doors cannot be inad-
vertently opened from the inside.
After doing the limp home procedure,
This helps ensure that doors will
you have to consult with your autho-
not be opened accidentally. Also,
rized Hyundai dealer as soon as pos-
when combined with the proper
sible.
HTB056
use of seat belts, locking the
o
The door can be locked or unlocked
doors helps keep occupants from
with a key.
being ejected from the car in case
!
o
Lock the door by turning the key
CAUTION:
of an accident.
toward the front of the vehicle and
o If you fail to try the limp home
o Before opening the door, always
unlock it by turning the key toward
procedure with the sequence of
look for and avoid oncoming traf-
the rear.
three times, you have to wait for
fic.
about one hour to do the limp
o In case of accident, the door is
home procedure again.
unlocked automatically (If In-
o If you cannot start your engine in
stalled).
spite of limp home procedure,
have your vehicle towed by an
authorized Hyundai dealer.
FEATURES OF YOUR HYUNDAI 1- 9
B040C01FC-GAT
B040D01FC-GAT
NOTE:
Locking From the Outside
Locking From the Inside
o When locking the door this way,
be careful not to lock the door
LOCK
with the ignition key left in the
UNLOCK
vehicle.
o To protect against theft, always
remove the ignition key, close all
windows, and lock all doors and
tail gate when leaving your ve-
hicle unattended.
HTB062
HTB057
The doors can be locked without a key.
To lock the doors from the inside, sim-
To lock the doors from the outside, first
ply close the door and push the lock
push the inside lock switch to the
switch to the "LOCK" position. When
"LOCK" position, so that the red mark
this is done, neither the outside nor the
on the switch is not visible, then close
inside door handle can be used.
the door.
NOTE:
The door will not lock if the key is left in
When the door is locked, the red
the ignition switch when the front doors
mark on the switch is not visible and
close. This is normal operation. (If in-
the character "LOCK" on the switch
stalled)
is visible.
1- 10 FEATURES OF YOUR HYUNDAI
B040E04A-AAT
B040G02FC-GAT
If you wish to be able to open the door
CHILD-PROTECTOR
Central Door Lock (If Installed)
from the outside, the outside door
REAR DOOR LOCK (5door only)
handle will function normally.
HTB212
HTB058
The central door locking is operated by
Your Hyundai is equipped with a "child-
pushing the driver's door lock switch
protector" rear door lock assembly.
toward the front or rear of the vehicle.
When the lock mechanism is engaged,
If the passenger and rear doors are
the rear door cannot be opened from
open when the switch is pushed, the
the inside. It's use is recommended
door will remain locked when closed.
whenever there are small children in
the rear seat.
NOTE:
To engage the child-protector feature
o When pushing the switch toward
so that the door cannot be opened from
the rear, all doors and tail gate
the inside, move the child-protector
will unlock.
lever to the " " position and close the
When pushing the switch toward
door. Move the lever to the " " posi-
the front, all doors and tail gate
tion when normal door operation is de-
will lock.
sired.
FEATURES OF YOUR HYUNDAI 1- 11
B070A01A-AAT
B070B01O-GAT
o When the door is unlocked, the
THEFT-ALARM SYSTEM
Armed Stage
red mark on the switch is visible
and the character "LOCK" on the
(If Installed)
switch is visible.
This system is designed to provide
o The central door locking is oper-
protection from unauthorized entry into
ated by turning the key (with theft-
the car. This system is operated in
alarm system: driver's door and
three stages: the first is the "Armed"
passenger's door, without theft-
stage, the second is the "Alarm" stage,
alarm system: driver's door only)
and the third is the "Disarmed" stage.
toward the front or rear of the
If triggered, the system provides an
vehicle.
audible alarm with blinking of the turn
o If the door is locked/unlocked mul-
signal lights.
tiple times in rapid succession
B070B01TB
with either the vehicle key or door
lock switch, the system may stop
Park the car and stop the engine. Arm
operating temporarily in order to
the system as described below.
protect the circuit and prevent
damage to system components.
1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine hood and
tail gate are locked.
3) Lock the doors using the transmitter
of the keyless entry system.
After completion of the steps above,
the turn signal lights will blink once to
indicate that the system is armed.
|
|
|
