Hyundai ix35 (2016 year). Instruction

Features of your vehicle

System cancellation whilst park-

Be sure to check the front and rear view

ing

before releasing the brake pedal. Stop

the vehicle when the speed of your vehi-

Push the smart parking assist system or

cle is high and stop immediately by

turn the steering wheel left side or right

depressing the brake pedal if necessary.

side.

WARNING

Whilst parking the vehicle, unex-

pected vehicles or pedestrians may

be close to vehicle, be careful for

OLM043434E/OLM043435E

the accident.

OLM043422E

5-1. Gear shifting whilst control-

ling the steering wheel

By parking circumstance, if the buzzer

beep sounds with warning messages,

shift the transaxle to desired gear on

cluster, park the vehicle with using brake.

4 95

Features of your vehicle

CAUTION

Park the vehicle by yourself as fol-

lowing because the system will be

cancelled;

1. Whilst searching for the parking

space

- When the ABS/ESC is operated

- When the vehicle speed is over

40km/h

- When you click the smart parking

assist system button

OLM043427E

OLM043425E/OLM043423E

(The front and rear parking assist

6. Smart parking assist system

Additional introductions

system is normally operated)

completion

When the smart parking assist system

- When you shift the transaxle to R

Even if the vehicle is parked by smart

operated, the message may indicate on

2. Whilst controlling the steering

parking assist system, the driver needs

cluster regardless information sequence.

wheel

to control the brake pedal by himself.

Other messages may indicate on cluster

- When the ABS/ESC is operated

According to message on cluster, finish

by circumstance.

- When the vehicle speed is over

the parking the vehicle. By surrounding

When the system operated, control the

7km/h

circumstance, finish the parking the vehi-

vehicle with the notice. Regarding safety

- When you click the smart parking

cle with using the steering wheel.

action, the driver needs to be careful.

assist system button

After finishing the smart parking assist

(The front and rear parking assist

system, check the front and rear distance

system is normally operated.)

from front and rear vehicle and control

- When you shift the transaxle to D

your vehicle.

before entering the parking

space

- When you grab the steering

strongly

4 96

Features of your vehicle

REARVIEW CAMERA (IF EQUIPPED)

HAZARD WARNING FLASHER

The rearview camera will activate when

the back-up light is ON with the ignition

switch ON and the shift lever in the R

(Reverse) position.

This system is a supplemental system

that shows behind the vehicle through the

rearview display mirror whilst backing-up.

Type B

The rearview camera may be turned off

OEL043081

■ Type A

by pressing the ON/OFF button when the

rearview camera is activated.

To turn the camera on again, press the

OLM049084

ON/OFF button again when the ignition

The hazard warning flasher should be

switch is on and the shift lever in R

used whenever you find it necessary to

(Reverse). Also, the camera will turn on

Rear view display

stop the car in a hazardous location.

automatically whenever the ignition

When you must make such an emer-

switch is turned off and on again.

gency stop, always pull off the road as far

as possible.

WARNING

The hazard warning lights are turned on

• This system is a supplementary

by pushing in the hazard switch. This

OEL049082R

■ Type B

function only. It is the responsibil-

causes all turn signal lights to blink. The

Rear view display

ity of the driver to always check

hazard warning lights will operate even

the inside/outside rearview mirror

though the key is not in the ignition

and the area behind the vehicle

switch.

before and whilst backing up

To turn the hazard warning lights off,

because there is a dead zone that

push the switch a second time.

can't see through the camera.

• Always keep the camera lens

clean. If lens is covered with for-

eign matter, the camera may not

operate normally.

OEL049083R

Features of your vehicle

LIGHTING

Battery saver function

Headlight escort function

Headlight welcome function

(if equipped)

•

The purpose of this feature is to pre-

vent the battery from being dis-

IThe headlights (and/or taillights) remain

When the headlight switch is in the ON or

charged. The system automatically

on for approximately 5 minutes after the

AUTO position and all doors (and tail-

turns off the parking lights when the

ignition key is removed or turned to the

gate) are closed and locked, if you press

driver removes the ignition key and

ACC or LOCK position. However, if the

the door unlock button on the transmitter

opens the driver- side door.

driver’s door is opened and closed, the

(or smart key), the headlights will come

•

With this feature, the parking lights will

headlights are turned off after 15 sec-

on for about 15 seconds.

onds.

be turned off automatically if the driver

If the headlight switch is in the AUTO

parks on the side of road at night.

The headlights can be turned off by

position, the function can only operate at

If necessary, to keep the lights on

pressing the lock button on the transmit-

night.

when the ignition key is removed, per-

ter (or smart key) twice or turning off the

At this time, if you press the door unlock

form the following :

light switch from the headlight or Auto

button again or door lock button on the

light position.

1) Open the driver-side door.

transmitter (or smart key), the headlights

2) Turn the parking lights OFF and ON

will turn off immediately.

again using the light switch on the

CAUTION

steering column.

If the driver gets out of the vehicle

through other doors

(except dri-

ver’s door), the battery saver func-

tion does not operate and the head-

light escort function does not turn

off automatically. Therefore, it caus-

es the battery to be discharged. In

this case, make sure to turn off the

lamp before getting out of the vehi-

cle.

4 99

Features of your vehicle

OBK049045N

OBK049046N

OBK049047N

Lighting control

Parking light position (

)

Headlight position (

)

The light switch has a Headlight and a

When the light switch is in the parking

When the light switch is in the headlight

Parking light position.

light position, the tail, position, license

position the head, tail, position, license

To operate the lights, turn the knob at the

and instrument panel lights are ON.

end of the control lever to one of the fol-

lowing positions:

✽ NOTICE

(1) OFF position

The ignition switch must be in the ON

(2) Parking light position

position to turn on the headlights.

(3) Headlight position

(4) Auto light position (if equipped)

4 100

Features of your vehicle

CAUTION

•

Never place anything over the

sensor (1) located on the instru-

ment panel, this will ensure better

auto-light system control.

•

Don’t clean the sensor using a

window cleaner, the cleaner may

leave a light film which could

interfere with sensor operation.

•

If your vehicle has window tint or

other types of coating on the

OBK049048N

front windscreen, the Auto light

OBK049050N

Auto light position (if equipped)

system may not work properly.

High - beam operation

When the light switch is in the AUTO light

To turn on the high beam headlights,

position, the taillights and headlights will

push the lever away from you. Pull it back

be turned ON or OFF automatically

for low beams.

depending on the amount of light outside

The high-beam indicator will light when

the vehicle.

the headlight high beams are switched

on.

To prevent the battery from being dis-

charged, do not leave the lights on for a

prolonged time whilst the engine is not

running.

WARNING

Do not use high beam when there

are other vehicles. Using high

beam could obstruct the other dri-

ver's vision.

4 101

Features of your vehicle

If an indicator stays on and does not

flash or if it flashes abnormally, one of the

turn signal bulbs may be burned out and

will require replacement.

One-touch lane change function

(if equipped)

To activate an one-touch lane change

function, move the turn signal lever

slightly and then release it. The lane

change signals will blink 3 times.

OBK049049N

OBK049051N

✽ NOTICE

Flashing headlights

Turn signals and lane change sig-

If an indicator flash is abnormally quick

To flash the headlights, pull the lever

nals

or slow, bulb may be burned out or have

towards you. It will return to the normal

The ignition switch must be on for the

a poor electrical connection in the cir-

(low-beam) position when released. The

turn signals to function. To turn on the

cuit.

headlight switch does not need to be on

turn signals, move the lever up or down

to use this flashing feature.

(A). Green arrow indicators on the instru-

ment panel indicate which turn signal is

operating.

They will self-cancel after a turn is com-

pleted. If the indicator continues to flash

after a turn, manually return the lever to

the OFF position.

To signal a lane change, move the turn

signal lever slightly and hold it in position

(B). The lever will return to the OFF posi-

tion when released.

4 102

Features of your vehicle

■ Type A

The rear fog lights turn on when the rear

fog light switch is turned on after the front

fog light switch (if equipped) is turned on

and the headlight switch is in the park-

light position.

To turn the rear fog lights off, turn the rear

fog light switch to the on position again or

turn the headlight switch off or front fog

light switch off.

✽ NOTICE

OAM049046L

■ Type B

To turn on the rear fog light switch, the

OBK049052N

ignition switch must be in the ON position.

Front fog light (if equipped)

Fog lights are used to provide improved

visibility when visibility is poor due to fog,

rain or snow, etc. The fog lights will turn

on when the fog light switch (1) is turned

on after the parklight is turned on.

To turn off the fog lights, turn the fog light

switch (1) to the OFF position.

OED040806

CAUTION

Rear fog light (if equipped)

When in operation, the fog lights

To turn the rear fog lights on, turn the

consume large amounts of vehicle

headlight switch to the headlight on posi-

electrical power. Only use the fog

tion and turn the rear fog light switch (1)

lights when visibility is poor.

to the on position.

4 103

Features of your vehicle

Daytime running light

Listed below are the examples of proper

(if equipped)

switch settings. For loading conditions

other than those listed below, adjust the

Daytime Running Lights (DRL) can make

switch position so that the beam level

it easier for others to see the front of your

may be the nearest as the condition

vehicle during the day. DRL can be help-

obtained according to the list.

ful in many different driving conditions,

and it is especially helpful after dawn and

Loading condition

Switch position

before sunset.

Driver only

The DRL system will make the head-

Driver + Front passenger

lights turn OFF when:

1. The parklight switch is ON.

Full passengers

(including driver)

2. Engine stops.

OLM049211R

Full passengers (including

Headlight levelling device

driver) + Maximum permis-

(if equipped)

sible loading

To adjust the headlight beam level

Driver + Maximum permis-

according to the number of the passen-

sible loading

gers and the loading weight in the lug-

gage area, turn the beam levelling switch.

The higher the number of the switch

position, the lower the headlight beam

level. Always keep the headlight beam at

the proper levelling position, or head-

lights may dazzle other road users.

4 104

Features of your vehicle

Automatic type

It automatically adjusts the headlight

beam level according to the number of

passengers and loading weight in the

luggage area.

And it offers proper headlight beam

under various conditions.

WARNING

If it does not work properly even

though your car is inclined back-

ward according to passenger's

posture, or the headlight beam is

irradiated to the high or low posi-

tion, we recommend that you have

your vehicle inspected by a

HYUNDAI authorised repairer.

Do not attempt to inspect or

replace the wiring yourself.

4 105

Features of your vehicle

WIPERS AND WASHERS

A : Wiper speed control (front)

Windscreen wiper/washer

Rear window wiper/washer

- Single wipe

· O - Off

· --- - Intermittent wipe

AUTO* - Auto control wipe

· 1 - Low wiper speed

· 2 - High wiper speed

B : Intermittent control wipe time

adjustment

C : Wash with brief wipes (front)*

D : Rear wiper/washer control*

OXM049230L/OAM049048L

- Continuous wipe

· --- - Intermittent wipe

(if equipped)

· O - Off

E : Wash with brief wipes* (rear)

* : if equipped

4 106

Features of your vehicle

Windscreen wipers

To vary the speed setting, turn the speed

control knob (1).

Operates as follows when the ignition

switch is turned ON.

If the wiper switch is set in AUTO mode

when the ignition switch is ON, the wiper

: For a single wiping cycle, move the

will operate once to perform a self-check

lever to this position and release it.

of the system. Set the wiper to OFF posi-

The wipers will operate continuous-

tion when the wiper is not in use.

ly if the lever is held in this position.

O : Wiper is not in operation

--- : Wiper operates intermittently at the

CAUTION

same wiping intervals. Use this mode

When the ignition switch is ON and

Rain sensor

in light rain or mist. To vary the speed

the windscreen wiper switch is

setting, turn the speed control knob.

placed in the AUTO mode, use cau-

OEL049900

1 : Normal wiper speed

tion in the following situations to

Auto control (if equipped)

2 : Fast wiper speed

avoid any injury to the hands or

The rain sensor located on the upper end

other parts of the body:

of the windscreen glass senses the

• Do not touch the upper end of the

✽ NOTICE

amount of rainfall and controls the wiping

windscreen glass facing the rain

If there is heavy accumulation of snow

cycle for the proper interval. The more it

sensor.

or ice on the windscreen, defrost the

rains, the faster the wiper operates. When

• Do not wipe the upper end of the

windscreen for about

10 minutes, or

the rain stops, the wiper stops.

windscreen glass with a damp or

until the snow and/or ice is removed

wet cloth.

before using the windscreen wipers to

• Do not put pressure on the wind-

ensure proper operation.

If you do not remove the snow and/or ice

screen glass.

before using the wiper and washer, it

may damage the wiper and washer sys-

tem.

4 107

Features of your vehicle

CAUTION

When washing the vehicle, set the

To prevent possible damage to the

wiper switch in the OFF position to

washer pump, do not operate the

stop the auto wiper operation.

washer when the fluid reservoir is

The wiper may operate and be dam-

empty.

aged if the switch is set in the AUTO

mode whilst washing the vehicle.

Do not remove the sensor cover

WARNING

located on the upper end of the

Do not use the washer in freezing

driver side windscreen glass.

temperatures without first warming

Damage to system parts could

the windscreen with the defrosters;

occur and may not be covered by

OXM049048E

the washer solution could freeze on

your vehicle warranty.

Windscreen washers

the windscreen and obscure your

When starting the vehicle in winter,

In the OFF position, pull the lever gently

vision.

set the wiper switch in the OFF

toward you to spray washer fluid on the

position. Otherwise, wipers may

windscreen and to run the wipers 1-3

operate and ice may damage the

cycles.

CAUTION

windscreen wiper blades. Always

Use this function when the windscreen is

remove all snow and ice and defrost

•

To prevent possible damage to

dirty.

the windscreen properly prior to

the wipers or windscreen, do not

The spray and wiper operation will con-

operating the windscreen wipers.

operate the wipers when the

tinue until you release the lever.

windscreen is dry.

If the washer does not work, check the

•

To prevent damage to the wiper

washer fluid level. If the fluid level is not

blades, do not use petrol,

sufficient, you will need to add appropri-

kerosene, paint thinner, or other

ate non-abrasive windscreen washer

solvents on or near them.

fluid to the washer reservoir.

•

To prevent damage to the wiper

The reservoir filler neck is located in the

arms and other components, do

front of the engine compartment on the

not attempt to move the wipers

driver side.

manually.

(Continued)

4 108

Features of your vehicle

(Continued)

• To prevent possible damage to

the wipers and washer system,

use anti-freezing washer fluids in

the winter season or cold weath-

er.

Headlight washer (if equipped)

If your vehicle is equipped with the head-

light washer it will operate at the same

time when you operate the windscreen

washer. It will operate when the headlight

OXM049103E

OXM049125L

low beam is turned on and the ignition

Rear window wiper and washer

Push the lever away from you to spray

switch or engine start/stop button is in

switch

rear washer fluid and to run the rear

the ON position.

wipers 1~3 cycles. The spray and wiper

The rear window wiper and washer

The washer fluid will be sprayed on to the

operation will continue until you release

switch is located at the end of the wiper

headlights.

and washer switch lever. Turn the switch

the lever. (if equipped)

to the desired position to operate the rear

wiper and washer.

✽ NOTICE

- Normal wiper operation

• Check the headlight washers periodi-

--- - Intermittent wiper operation

cally to confirm that the washer fluid

(if equipped)

is being sprayed properly onto the

headlight lenses.

O - Wiper is not in operation

• The headlight washer can be operated

15 minutes after being operated last

time.

4 109

Features of your vehicle

INTERIOR LIGHT

Also, the light

(with room lamp)

CAUTION

goes out gradually after approxi-

Do not use the interior lights for

mately

30 seconds if the door

extended periods when the engine

(except tailgate) is closed.

is not running.

However, if the ignition switch is

It may cause battery discharge.

ON or all doors (except tailgate)

are locked, the light will turn off

immediately.

If a door

(except tailgate) is

WARNING

opened with the ignition switch in

Do not use the interior lights when

the ACC or LOCK position, the

driving in the dark. Accidents could

light (with room lamp) stays on for

happen because the view may be

OEL049100

about 20 minutes. However, if a

obscured by interior lights.

door (except tailgate) is opened

Map lamp (if equipped)

with the ignition switch in the ON

Push the lens (1) to turn the map lamp on

position, the light (with room lamp)

or off.

stays on continuously.

•

: The light (with room lamp) stays

•

: The lights turn off even if a door is

on at all times.

opened.

•

: The light (with room lamp) comes

❈ When the lamp is turned ON by

on when any door (except tail-

pressing the lens (1), the lamp

gate) is opened regardless of the

does not turn off even if the

ignition switch position. When

switch (2) is in the OFF posi-

doors

(except tailgate) are

tion.

unlocked by the transmitter

(or

smart key), the light (with room

lamp) comes on for approximate-

ly 30 seconds as long as any door

(except tailgate) is not opened.

4 110

Features of your vehicle

OEL049101

OLM049105/H

OLM049103

Room lamp

Vanity mirror lamp (if equipped)

Luggage room lamp (if equipped)

Press the button to turn the light on or off.

•

: The lamp will turn on if this but-

The luggage room lamp comes on when

ton is pressed.

the boot lid is opened.

•

: The lamp will turn off if this but-

ton is pressed.

CAUTION - Vanity mirror

lamp (if equipped)

• Always have the switch in the off

position when the vanity mirror

lamp is not in use. If the sunvisor

is closed without the lamp off, it

may discharge the battery or

damage the sunvisor.

• Turn off the lamp before return

the sunvisor to its original posi-

tion.

4 111

Hyundai ix35 (2016 year). Instruction - part 11
