Various status of cassette tape will be
displayed on the screen while listening
to the tape such as "PLAY" while play-
ing the tape, the direction of play " or
", "FF" and "REW" for fast forward
and rewind, "METAL" for playing metal
tapes as well as "DOLBY" and "RPT."
!
CAUTION:
o Do not insert anything like coins
into the player slot as damage to
the unit may occur.
o Do not place beverages close to
the audio system. The playback
mechanism may be damaged if
you spill them.
o Do not strike or allow anything to
impact the audio system, damage
to the system mechanisms could
occur.
FEATURES OF YOUR HYUNDAI
1
113
H280E01GK-GAT
COMPACT DISC PLAYER OPERATION (H280) (If installed)
1
1. CD Deck
3
2. CD Indicator
2
3. CD EJECT
4. CD Selection Button
5. Fast Backward
4
6. Fast Forward
10
16
7. Automatic Previous Track Selec-
tion Button
8. Automatic Next Track Selection
Button
14
9. Section Repeat Button
10. Information Display Screen (LCD)
8
11. BOOKMARK Button
12. RDM (Random) Button
15
7
13. SCROLL Button
5
6
9
12
1113
14. FILE Search Knob
15. Directory Search Button
16. SCAN Button
GK_280_UR
1 FEATURES OF YOUR HYUNDAI
114
H280F01GK-GAT
4. CD Selection Button
NOTE:
1. CD Deck
If you press this button when the
Press this button while the disk is
Make sure the printed side of the disk
power is off and CD is inside the
inside the CDP deck to listen to the CD
faces upward when you insert the disk.
deck, the power will be automati-
even if the radio or tape was on or if CD
If you insert the disk when the ignition
cally turned on.
changer was in action. If you press [CD/
switch of the automobile is set to ACC
MP3] button when the disk is ejected
(1st notch) or ON (2nd notch), the CD
7. Automatic Previous Track Se-
and hanging in the opening, the system
Deck will automatically play CD even if
lection Button
will automatically insert the disk and
the power was off. This CD Deck can
play the CD.
Press [TRACK
] button to go to the
play both 12cm and 8cm audio disks. If
beginning of the song you are listening
you insert video CD, then the screen
5. Fast Backward (REW)
to while playing the CD. Press the
will display "ERROR DISC" and eject
button again to go to the beginning of
the disk.
Press and hold [REW] button while
the song before the song you were
playing CD then the player will play the
listening to. When you press this button
2. CD Indicator
disk backwards 5 times the regular
while listening to the first track of the
speed for first 5 seconds and 15 times
This indicator light will be on if the CD is
CD then the system will move to the
faster after that. The sound will be
inside the CDP deck whether the audio
beginning of the last track of the CD.
reduced by 12dB while you are holding
system is on or not. This light will go off
the button.
when the CD is ejected.
8. Automatic Next Track Selec-
6. Fast Forward (FF)
tion Button
3. CD Eject Button
Press and hold [FF] button while play-
Press [SEEK
] button to go to the
Press [
] button to eject the disk while
beginning of the song next to the song
ing CD then the player will play the disk
playing the disk. This will eject the CD
you are listening to while playing the
forward 5 times the regular speed for
whether or not the ignition switch is on
CD.
first 5 seconds and 15 times faster after
or off.
that. The sound will be reduced by 12dB
while you are holding the button.
9. Section Repeat Button (RPT)
Press [RPT] button to repeat the song
you are listening to. Press this button
again to cancel repetition.
FEATURES OF YOUR HYUNDAI
1
115
10. Information Display Screen
14. FILE Search Knob
(LCD)
Turn this knob to the left and right while
!
CAUTION:
Various status of the CD will be dis-
listening to CD to change track number.
o Do not insert warped or poor qual-
played on the screen while listening to
If you press the button within 5 seconds
ity discs into the CD player as
the CD such as "CD" while playing the
then the selected track will be played. If
damage to the unit may occur.
CD, the track title and number, RPT,
you do not press the button within 5
o Do not insert anything like coins
RDM and MARK.
seconds then it will display the cur-
into the player slot as damage to
rently played track.
the unit may occur.
11. BOOKMARK Button
o Do not place beverages close to
This button lets you select the songs
15. Directory Search Button
the audio system. The playback
you want to listen to in the CD. Move to
In case the MP3/WMA CD contains
mechanism may be damaged if
the track and press [MARK] for more
more than 2 folders, press this button
you spill them.
than 1 second then the screen will
up and down to search each directory.
o Do not strike or allow anything to
display "M" and select the track. Press
You can move to the directory and turn
impact the audio system, damage
the button less than 1 second to play
the search knob to search through the
to the system mechanisms could
the songs you selected and the system
tracks. If you do not press the knob
occur.
will display "M"
within 5 seconds after you select a
o Off-road or rough surface driving
track then the system will automati-
may cause the compact disc to
12. RDM (Random) Button
cally return to the current track.
skip. Do not use the compact disc
Press [RDM] button to play the songs in
when driving in such conditions
random order.
16. SCAN Button
as damage to the compact disc
If you press this button, the player will
face could occur.
play 10 seconds of each track. Press it
o Do not attempt to grab or pull the
13. SCROLL Button
again to cancel scanning.
compact disc out while the disc is
If the title of MP3 or WMA file is too
being pulled into the audio unit by
long, press this button to scroll the
the self-loading mechanism. Dam-
entire song title on the LCD screen.
age to the audio unit and compact
disc could occur.
o Avoid using recorded compact
discs in your audio unit. Original
compact discs are recommended.
1 FEATURES OF YOUR HYUNDAI
116
H265A01GK-GAT
STEREO RADIO OPERATION (H265) (If installed)
1. Power Button and Volume Control
(Power On / Volume)
2
2. Radio Band Selection Button
7
3. Automatic Channel Selection
8
Button(SEEK)
4. Manual Channel Selection Control
(TUNE)
6
5. Preset Button
1
6. Information Display Screen (LCD)
7. BSM Button (Best Station
4
Memory)
5
3
8. AUDIO Select Button
GK_265_UR
FEATURES OF YOUR HYUNDAI
1
117
H265B01GK-GAT
3. Automatic Channel Selection
5. Preset Button (1~6)
1. Power Button and Volume
Button (SEEK)
Press this button but do not hold for no
Control (POWER ON/ VOL-
Press and hold the [
] button for more
more than 2 seconds to listen to the
UME)
than 0.5 seconds until you hear the beep
channels memorized to each button. If
Press this button when the ignition
to automatically increase frequency and
you want to memorize the current chan-
switch of the automobile is set to ACC
press and hold the [
] button for more
nel to the preset button when you are
(1st notch) or ON (2nd notch) to turn on
than 0.5 seconds until you hear the beep
listening to channel not memorized to
the power of the audio system. When
to automatically decrease frequency to
any of the preset buttons, press the
the power is turned on, turn the volume
select and play the next available chan-
button and hold for more than 2 sec-
control clockwise to increase volume
nel. If the received channel is memo-
onds then the channel will be memo-
and counterclockwise to reduce. Press
rized in the preset buttons then the
rized to the button with the beep.
once again when the audio system is on
screen will display the memorized chan-
to turn off the power.
nel.
6. Information Display Screen
(LCD)
2. Radio Band Selection Button
4. Manual Channel Selection
A variety of information will be dis-
(FM/AM)
Control (TUNE)
played on the screen including the radio
North American Standard
Press and hold [
] button for less than
bands (FM1/FM2/AM) while listening to
o Press this button to listen to either
0.5 seconds to increase frequency by 1
the radio, frequency of each channel,
FM or AM.
step and [
] to decrease.
the number of preset channel and "ST"
o The radio will be set to each mode
Press and hold [
] or [
] button for
for FM stereo broadcasting.
each time you press the button in a
more than 0.5 seconds even after you
loop; FM1➟FM2➟AM➟FM1 and
hear the beep then the frequency will
soon.
increase or decrease quickly. When
you release the button, the system will
European Standard
turn to the automatic selection mode.
o Press this button to listen to either
FM or AM.
o The radio will be set to each mode
each time you press the button in a
loop; FM1➟FM2➟MW➟LW➟FM1
and soon.
1 FEATURES OF YOUR HYUNDAI
118
7. BSM Button(Best Station
BASS
Turn the TUNE Controller
Memory)
clockwise to increase bass
!
CAUTION:
tone and counterclockwise
Press this button once to automatically
o Do not place beverages close to
to decrease.
select well-received channels and
the audio system. The audio sys-
memorize them into the preset buttons
MIDDLE
Turn the TUNE Controller
tem mechanism may be damaged
(1~6) in the selected order and turn to
clockwise to increase
if you spill them.
the channel memorized in preset button
middle tone and counter-
o Do not strike or allow anything to
1. If no channel is received after acti-
clockwise to decrease.
impact the audio system, damage
vating BSM and no channel is memo-
to the system mechanisms could
TREBLE
Turn the TUNE Controller
rized, the system will turn to the previ-
occur.
clockwise to increase
ously received channel.
treble tone and counter-
clockwise to decrease.
8. AUDIO Select Button
BALANCE
Turn the TUNE Controller
o Press this button to change AUDIO
clockwise to increase right
function control mode.
speaker volume and coun-
Current State➟BASS➟MID➟TRE➟
terclockwise to increase left
FAD➟BAL
speaker volume.
o Select the audio control mode you
want and increase or decrease the
FADER
Turn the TUNE Controller
setting by ±10 from currently audio
clockwise to increase rear
control mode. If no actions are taken,
speaker volume and coun-
terclockwise to increase
the screen will return to the previous
front speaker volume.
display after 3 seconds.
FEATURES OF YOUR HYUNDAI
1
119
H265C01GK-GAT
COMPACT DISC PLAYER OPERATION (H265) (If installed)
1. CD DECK
2. CD INDICATOR
4
1
3. CD Disc EJECT Button
11
4. CD Selection Button
3
5. Fast Backward
2
6. Fast Forward
7. Automatic Previous Track Selec-
10
tion Button
8. Automatic Next Track Selection
Button
9. Section Repeat Button
9
7
5
6
8
10. Information Display Screen (LCD)
11. SCAN Button
GK_265_UR
1 FEATURES OF YOUR HYUNDAI
120
H265D01GK-GAT
4. CD Selection Button
7. Automatic Previous Track Se-
1. CD Deck
lection Button
Press this button while the disk is
Make sure the printed side of the disk
inside the CD DECK to listen to the CD.
Press [
] button to go to the beginning
faces upward when you insert the disk.
If the radio was on previously then it will
of the song you are listening to while
If you insert the disk when the ignition
be turned off and CD player will be
playing the CD. Press the button again
switch of the automobile is set to ACC
activated. If you press [CD] button
to go to the beginning of the song before
(1st notch) or ON (2nd notch), the CD
when the disk is ejected and hanging in
the song you were listening to. When
DECK will automatically play CD even
the opening the system will automati-
you press this button while listening to
if the power was off.
cally insert the disk and play the CD.
the first track of the CD then the system
This CD DECK can play both 12cm and
will move to the beginning of the last
8cm audio disks. If you insert video CD,
5. Fast Backward (REW)
track of the CD.
then the screen will display the status
of the CD but it will not play the video file
Press and hold [REW] button while
8. Automatic Next Track Selec-
and therefore there will be no sound.
playing CD then the player will play the
tion Button
disk backwards 5 times the regular
2. CD Indicator
speed for first 5 seconds and 15 times
Press [
] button to go to the beginning
faster after that. The sound will be
of the song next to the song you are
This indicator light will be on if the CD is
reduced by 12dB while you are holding
listening to while playing the CD. When
inside the CD DECK if the ignition
the button.
you press this button while listening to
switch of the automobile is set to ACC
the last track of the CD then the system
(1st notch) or ON (2nd notch) regard-
6. Fast Forward (FF)
will move to the beginning of the first
less of whether the audio system is on
track of the CD.
or off. This light will go off when the CD
Press and hold [FF] button while play-
is ejected.
ing CD then the player will play the disk
9. Section Repeat Button (RPT)
forward 5 times the regular speed for
3. CD Eject Button
first 5 seconds and 15 times faster after
Press [RPT] button to repeat the song
that. The sound will be reduced by 12dB
you are listening to. Press this button
Press [
] button to eject the disk while
while you are holding the button.
again to cancel repetition.
playing the disk. This will eject the CD
whether or not the ignition switch is on
or off.
FEATURES OF YOUR HYUNDAI
1
121
10. Information Display Screen
o Avoid using recorded compact
(LCD)
!
discs in your audio unit. Original
CAUTION:
compact discs are recommended.
Various status of the CD will be dis-
o Do not insert warped or poor qual-
played on the screen while listening to
ity discs into the CD player as
the CD such as "CD" while playing the
damage to the unit may occur.
CD, the track title and number and RPT.
o Do not insert anything like coins
into the player slot as damage to
11. SCAN Button
the unit may occur.
If you press this button, the player will
o Do not place beverages close to
play 10 seconds of each track. Press it
the audio system. The playback
again to cancel scanning.
mechanism may be damaged if
you spill them.
o Do not strike or allow anything to
impact the audio system, damage
to the system mechanisms could
occur.
o Off-road or rough surface driving
may cause the compact disc to
skip. Do not use the compact disc
when driving in such conditions
as damage to the compact disc
face could occur.
o Do not attempt to grab or pull the
compact disc out while the disc is
being pulled into the audio unit by
the self-loading mechanism. Dam-
age to the audio unit and compact
disc could occur.
1 FEATURES OF YOUR HYUNDAI
122
H465A01GK-GAT
STEREO RADIO OPERATION (H465) (If Installed)
8
1, 2. Power Button and Volume
Control
3. Radio Band Selection Button
4. Automatic Channel Selection
Memorization Button
3
4
5. Automatic Channel Selection
Button
9
6. Manual Channel Selection Control
(TUNE Control)
7. Preset Button
8. Information Display Screen (LCD)
1, 2
6
9. AUDIO Select Button
5
7
GK_465_UR
FEATURES OF YOUR HYUNDAI
1
123
H465B01GK-GAT
NOTE:
6. Manual Channel Selection
1. Power Button (POWER ON)
Push this button when the power is
Control (TUNE)
Press this button when the ignition
off to turn on the power automati-
Turn the TUNE control clockwise to
switch of the automobile is set to ACC
cally.
increase frequency and counterclock-
(1st notch) or ON (2nd notch) to turn on
wise to reduce frequency by 1 step for
the power and the audio system. Press
4. Automatic Channel Selection
each click.
once again when the audio system is on
Memorization Button (BSM:
to turn off the power.
Best Station Memory)
7. Preset Button (1~6)
Press this button once to automatically
2. Volume Control (VOLUME)
Press this button to listen to the chan-
select channels starting from the cur-
nels memorized to each button. If you
Turn the volume control clockwise to
rent channel and memorize into the
want to memorize the current channel
increase volume and counterclockwise
preset buttons (1~6) in the selected
to the preset button, press the button
to reduce. The volume level will be
order and turn to the channel memo-
for more than 1.5 seconds then the
displayed on the screen when you ad-
rized in preset button 1.
channel will be memorized to the button
just the volume.
with a beep.
5. Automatic Channel Selection
3. Radio Band Selection Button
Button (SEEK)
8. Information Display Screen
(FM/AM)
(LCD)
Press the [SEEK
] button to auto-
o Press this button to listen to either
matically increase frequency and press
A variety of information will be dis-
FM or AM.
played on the screen including the radio
the
[TRACK
] button to automati-
o The radio will be set to each of the
bands (FM1/FM2/AM) while listening to
cally decrease frequency to select and
following modes each time you press
the radio, frequency of each channel,
play the next available channel. If the
the button.
the number of preset channel and "ST"
received channel is memorized in the
FM1 ➟ FM2 ➟ AM
for FM stereo broadcasting.
preset buttons then the screen will dis-
play the memorized channel.
1 FEATURES OF YOUR HYUNDAI
124
9. AUDIO Select Button
FADER
Turn the TUNE Controller
clockwise to increase rear
Press this button to control tone. Each
speaker volume and coun-
time you press the button, the mode will
terclockwise to increase
switch from BASS➟MIDDLE
front speaker volume.
➟TREBLE➟FADER➟BALANCE and
the mode will be displayed on the screen.
BASS
Turn the TUNE Controller
clockwise to increase bass
tone and counterclockwise
!
CAUTION:
to decrease.
o Do not place beverages close to
MIDDLE
Turn the TUNE Controller
the audio system. The audio sys-
clockwise to increase
tem mechanism may be damaged
middle tone and counter-
if you spill them.
clockwise to decrease.
o Do not strike or allow anything to
impact the audio system, damage
TREBLE
Turn the TUNE Controller
to the system mechanisms could
clockwise to increase
occur.
treble tone and counter-
clockwise to decrease.
BALANCE
Turn the TUNE Controller
clockwise to increase right
speaker volume and coun-
terclockwise to increase left
speaker volume.
FEATURES OF YOUR HYUNDAI
1
125
H465C01GK-GAT
COMPACT DISC PLAYER OPERATION (H465) (If installed)
1. CD Deck
6
1
2. CD Load
3. CD Eject
4. Information Display Screen (LCD)
3
2
5. CD Changer Selection Button
13
6. Disc Selection Button
7. Fast Backward
8. Fast Forward
12
9. Automatic Previous Track Selec-
tion Button
5
10. Automatic Next Track Selection
4
Button
11. Repeat Button
12. SCAN Button
16
13. EQ Button
14. MARK Button
10
15. RDM Button
18
9
16. File Search Knob
7
8
11
15
1417
17. Scroll Button
18. Directory Search Button
GK_465_UR
1 FEATURES OF YOUR HYUNDAI
126
H465D01GK-GAT
4. Information Display Screen
If you wish to listen to the previous CD,
1.CD Deck
(LCD)
then press [DISC
] button then the
The deck will open only when you press
previous disc will be played (If you
This shows the location of disk inside
[LOAD] button. Make sure the printed
press the button when you are listening
the CD Changer and the corresponding
side of the disk faces upward when you
to CD 2, the CD 1 will be played). If the
CD deck number will flicker when you
insert the disk. The CD changer can
CD Changer is not fully loaded, this will
load or eject the CD.
only play 12cm disks. If you insert
move to the next available deck. When
video CD or DATA CD, then the screen
the player moves from deck to deck,
5. CD Changer Selection Button
will display "ERROR DISC," eject the
the screen will display the selected
disk and return to the previous mode.
If the power was turned off when the CD
deck number.
is inside the CD changer or if you press
2. CD Load Button
"CD" button when radio was on, the
7. Fast Backward (REW)
system will play CD. If you press [CD]
Press and hold [REW] button while
When you press [LOAD] button, the
button when there is no CD in the
playing CD then the player will play the
empty lots of the CD Changer will be
changer then the system will display
disk backwards 5 times the regular
opened in the order of 1, 2, 3, 4, 5 and
"NO DISK" for 2 seconds and return to
speed for first 5 seconds and 15 times
6. When you insert CD, you can listen
the previous mode.
faster after that. The sound will be
to the corresponding CD. In this case,
reduced by 12dB while you are holding
the last CD you inserted will be played.
NOTE:
the button.
If you do not take any actions after
If you press this button when the
pressing (LOAD) then the (LOAD) will
power is off and CD is inside the
8. Fast Forward (FF)
be cancelled.
deck, the power will be automati-
cally turned on.
Press and hold [FF] button while play-
3. CD Eject Button
ing CD then the player will play the disk
forward 5 times the regular speed for
6. Disc Selection Button
When you press [
] button, the cur-
first 5 seconds and 15 times faster after
rently played CD will be ejected. If you
If you press [DISC
] button while
that. The sound will be reduced by 12dB
press the button for more than 2 sec-
using CD Changer, the next disc will be
while you are holding the button.
onds, you will be able to eject all CDs.
played (If you press the button when
If currently played CD is in the 3rd slot,
you are listening to CD 1, the CD 2 will
the ejection order will be 3, 4, 5, 6, 1 and
be played).
2.
FEATURES OF YOUR HYUNDAI
1
127
9. Automatic Previous Track Se-
13. EQ Button
16. FILE Search Knob
lection Button
Each time you press this button the
Turn this knob to the left and right while
Press [TRACK
] button to go to the
sound equalizer setting will switch from
listening to CD to change track number.
beginning of the song you are listening
POP➟JAZZ➟ROCK➟CLASSIC➟OFF
If you press the button within 5 seconds
to while playing the CD. Press the
(Not displayed).
then the selected track will be played. If
button again to go to the beginning of
you do not press the button within 5
the song before the song you were
14. BOOKMARK Button
seconds then it will display the cur-
listening to.
rently played track.
This button lets you select the songs
you want to listen to in the CD. Move to
10. Automatic Next Track Selec-
17. SCROLL Button
the track and press (MARK) for more
tion Button
than 1 second then the screen will
If the title of MP3 or WMA file is too
display " M " and select the track. Press
long, press this button to scroll the
Press [SEEK
] button to go to the
the button less than 1 second to play
entire song title on the LCD screen.
beginning of the song next to the song
the songs you selected and the system
you are listening to while playing the
will display " M "
18. Directory Search Button
CD.
In case the MP3/WMA CD contains
15. RDM (Random) Button
11. Section Repeat Button (RPT)
more than 2 folders, press this button
Press [RDM] button to play the songs in
up and down to search each directory.
Press [RPT] button to repeat the song
random order.
You can move to the directory and turn
you are listening to. Press this button
the search knob to search through the
again to cancel repetition.
NOTE:
tracks. If you do not press the knob
When you use CD-R or CD-RW, the
within 5 seconds after you select a
12. SCAN Button
CD may not be played due to the
track then the system will automati-
manufacturing method of CD mak-
If you press this button, the player will
cally return to the current track.
ers and the recording method of the
play 10 seconds of each track. Press it
user. In this case, change CD unless
again to cancel scanning.
the continuous use of such CDs may
cause damage to the system.
1 FEATURES OF YOUR HYUNDAI
128
o Avoid using recorded compact
!
CAUTION:
discs in your audio unit. Original
o Do not insert warped or poor qual-
compact discs are recommended.
ity discs into the CD player as
damage to the unit may occur.
o Do not insert anything like coins
into the player slot as damage to
the unit may occur.
o Do not place beverages close to
the audio system. The playback
mechanism may be damaged if
you spill them.
o Do not strike or allow anything to
impact the audio system, damage
to the system mechanisms could
occur.
o Off-road or rough surface driving
may cause the compact disc to
skip. Do not use the compact disc
when driving in such conditions
as damage to the compact disc
face could occur.
o Do not attempt to grab or pull the
compact disc out while the disc is
being pulled into the audio unit by
the self-loading mechanism. Dam-
age to the audio unit and compact
disc could occur.
