GENERAL

GI -5

WARNING / CAUTION LABEL LOCATIONS

SIDE AIRBAG INFORMATION

ATTENTION

SRS VEHICLE
THIS CAR IS EQUIPPED WITH A SUPPLEMENTAL
RESTRAINT SYSTEM. TO PROVIDE CONTINED RELIABLITY,
CERTAIN ELEMENTS OF THE SUPPLEMENTAL RESTRAINT
SYSTEM SHALL BE SERVICED OR REPLACED BY AUTHORIZED
DEALER TEN YEARS AFTER VEHICLE LABEL. FOR FURTHER INFORMATION.
SEE OWNER'S MANUAL.

SIDE AIR BAG
THIS CAR IS EQUIPPED WITH A SIDE AIRBAG SYSTEM.
TO PROVIDE CONTINUED RELIABILITY, CERTAIN ELEMENTS
OF THE SIDE AIRBAG SYSTEM  SHALL BE SERVICED OR
VEHICLE MANUFACTURE DATE SHOWN ON CERTIFICATION LABEL.
FOR FURTHER INFORMATION
SEE OWNER'S MANUAL.

RADIATOR CAP CAUTION

FAN CAUTION

BATTERY CAUTION

AIRDUCT WARNING

SCMGI6005L

GI -6

GENERAL INFORMATION

AIR BAG WARNING / CAUTION LABEL

CAUTION
AIR BAG : Handing is limited to trained personnel.
To be used only in prescribed vehicles. If not propely
installed, device may become a dangerous projectile.
See serivce manual instruction

DRIVE MODULE CAUTION

Caution
Don't open, remove or transfer  to another
vehicle. Risk of malfunction and bodily
injury!
This unit is to be installed and/or dismantled
by trained personnel only. This item contains
an explosive to be installed igniter.

EAKE002A

GENERAL

GI -7

AIR BAG WARING / CAUTION LABEL (CONT’D)

C

D

B

A

SCMGI6006D

GI -8

GENERAL INFORMATION

WARNING / CAUTION LABEL (CONT’D)

A : WARNING
SEE OWNER’S MANUAL.
This car is equipped a side airbag for each front seat.

• Do not use any accessory seat covers.
• Use of other seat covers could reduce the

effect of the system.

• Do not install any accessories on the side

or near the side airbag.

• Do not use excessive force on the side of the seal.
• For further information, see the owner’s manual.

B : CAUTION
AIRBAG ESPE UNIT

Detach connector before unmounting. Assemble
strictly according to manual instructions.

C : PASSENGER MODULE CAUTION

CAUTION
Don’t open, remove or transfer to another vehicle.
Risk of malfunction and bodily injury!
This unit is to be installed and/or dismantled by
trained personnel only. This item contains an
explosive to be installed igniter.

D : SUPPLEMENTAL RESTRAINT SYSTEM
(AIRBAG) INFORMATION

• The airbag is a Supplement Restraint

System (SRS).
You must always wear the seat belts.

• The airbag system condition is normal

when the "SRS" lamp in the cluster flashes
approximately 6 times after the ignition key
is turned on and then goes off.

• If any of the following condition occur, the

system must be serviced.

• "SRS" lamp does not light up when

the key is turned on.

• "SRS" lamp stays lit or flashes continuously.
• The airbag has inflated.

• The airbag system must be inspected by an

authorized dealer ten years after the vehicle
manufacture date shown on the certification label,
located on left front door opening area.

WARNING
Failure to the above instructions may result in injury
to you or other occupants in the vehicle

• See the "SRS" section in Owner’s Manual for

more information about airbags.
