FL -66
FUEL SYSTEM
RAIL PRESSURE SENSOR (RPS)
INSPECTION
E0734AD3
FUNCTION AND OPERATION PRINCIPLE
Rail Pressure Sensor (RPS) is installed at the end of the
common rail and measures the instantaneous fuel pres-
sure in the common rail by using its diaphragm. Its sens-
ing element (semiconductor device) mounted on the di-
aphragm converts the fuel pressure to an electric signal.
RPS
EFQG017A
SPECIFICATION
Test Condition
Rail pressure (bar)
Output Voltage (V)
Idle
220 ~ 320
Below 1.7
Fully depressed
About 1,800
Approx. 4.5
CIRCUIT DIAGRAM
RPS
C203
1
2
ECM C230-A (43)
Reference Voltage (+5V)
RPS Signal
ECM C230-A (28)
3
Sensor Signal
ECM C230-A (8)
ECM (C230-A)
RPS (C203)
P
2
1
3
8 - GND
28 - Reference Voltage (+5V)
43 - RPS Signal
[CIRCUIT DIAGRAM]
[HARNESS CONNECTORS]
[CONNECTION INFORMATION]
Terminal
Connected to
Function
ECM
C230-A
C230-K
1
2
4
3
6
5
8 7
12
13
16
17
18
23 22
20
21
19
27 26 25 24
28
29
30
14
9
10
11
15
33 32 31
34
37
41
42
40 39 38
35
36
43
44
47 46
49 48
50
53
56
58 57
54
51
52
55
59
60
45
1
30 29
31
32
38
39
36
37
35
33
34
40
42 41
46 45 44 43
48 47
50 49
2
3
4
6
5
8
7
12 11 10 9
13
14
15
18 17
19
16
22
25
27 26
23
20
21
24
28
51
75 74
53 52
73
79 78 77 76
80
81
83 82
84
86 85
87
89 88
90
92 91
93
94
57
69 68
70
71
64
54
55
56
61
58
59
60
63 62
65
66
67
72
SCMFL6124L
