FL -6
FUEL SYSTEM
SERVICE STANDARD
EA925EF7
Neutral,N,P-range
790 ± 100 rpm
A/C OFF
D-range
790 ± 100 rpm
Neutral,N,P-range
790 ± 100 rpm
Basic Idle rpm(After
warm up)
A/C ON
D-range
790 ± 100 rpm
TIGHTENING TORQUES
E3562770
ENGINE CONTROL SYSTEM
Item
N·m
Kgf·m
lbf·ft
ECM bracket installation bolts
7.8 ~ 11.8
0.8 ~ 1.2
5.8 ~ 8.7
Boost pressure sensor installation bolts
7.8 ~ 11.8
0.8 ~ 1.2
5.8 ~ 8.7
Engine coolant temperature sensor installation
19.6 ~ 39.2
2.0 ~ 4.0
14.5 ~ 28.9
Crankshaft position sensor installation bolt
3.9 ~ 5.9
0.4 ~ 0.6
2.9 ~ 4.3
Camshaft position sensor installation bolt
3.9 ~ 5.9
0.4 ~ 0.6
2.9 ~ 4.3
Electric EGR control valve installation bolts
19.6 ~ 26.5
2.0 ~ 2.7
14.5 ~ 19.5
Variable swirl control actuator installation bolts
9.8 ~ 11.8
1.0 ~ 1.2
7.2 ~ 8.7
Throttle body installation bolts
9.8 ~ 11.8
1.0 ~ 1.2
7.2 ~ 8.7
Oil pressure switch installation
14.7 ~ 21.6
1.5 ~ 2.2
10.9 ~ 15.9
FUEL DELIVERY SYSTEM
Item
N·m
Kgf·m
lbf·ft
Injector clamp installation bolt
24.5 ~ 28.4
2.5 ~ 2.9
18.1 ~ 21.0
Common rail installation bolts
19.6 ~ 26.5
2.0 ~ 2.7
14.5 ~ 19.5
High pressure fuel pump installation bolts
24.5 ~ 34.3
2.5 ~ 3.5
18.0 ~ 25.3
High pressure pipe (Injector
↔
Common Rail) installation nuts
24.5 ~ 28.4
2.5 ~ 2.9
18.1 ~ 21.0
High pressure pipe (Common RaiI
↔
High Pressure
Fuel Pump) installation nuts
24.5 ~ 28.4
2.5 ~ 2.9
18.1 ~ 21.0
Fuel tank band installation bolts
39.2 ~ 54.0
4.0 ~ 5.5
28.9 ~ 39.8
Accelerator pedal installation bolts
16.6 ~ 25.5
1.7 ~ 2.6
12.3 ~ 18.8
Fuel pump / Sender plate cover tightening
5.9 ~ 6.9
0.6 ~ 0.7
4.3 ~ 5.1
