J 29710

Differential Side Bearing Installer

J 29713

Axle Seal Installer (9.5 in Axle)

J 34925

Pinion Setting Gauge and Components

J 36597

Side Bearing Puller Pilot - 9.25 in Axle

J 36614



2004 Hummer H2

2004 DRIVELINE/AXLE Rear Drive Axle - Hummer H2



Inner Pinion Bearing Installer (9.5 in Axle)

J 38125-B

Terminal Repair Kit

J 44685

Rear Axle Seal and Bearing Remover

J 45766

Differential Side Bearing Remover



2004 Hummer H2

2004 DRIVELINE/AXLE Rear Drive Axle - Hummer H2



2004 DRIVELINE/AXLE

Drive Axle - Locking/Limited Slip - Hummer H2

SPECIFICATIONS

FASTENER TIGHTENING SPECIFICATIONS

Fastener Tightening Specifications

SCHEMATIC AND ROUTING DIAGRAMS

DIFFERENTIAL LOCK SCHEMATICS

Fig. 1: Differential Lock Schematics
Courtesy of GENERAL MOTORS CORP.

COMPONENT LOCATOR

Application

Specification

Metric

English

Pinion Shaft Lock Bolt

36 N.m

27 lb ft



2004 Hummer H2

2004 DRIVELINE/AXLE Drive Axle - Locking/Limited Slip - Hummer H2





2004 Hummer H2

2004 DRIVELINE/AXLE Drive Axle - Locking/Limited Slip - Hummer H2



REAR AXLE COMPONENT VIEWS

Fig. 2: Rear Differential Lock Actuator Component Views
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 2

REAR AXLE CONNECTOR END VIEWS

Rear Differential Lock Terminal Identification Actuator

Callout

Component Name

1

Rear Axle

2

Rear Differential Lock Actuator
