Fig. 67: Lamp Lens Assembly
Courtesy of GENERAL MOTORS CORP.

1. Remove the lamp lens assembly using a small screw driver.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Lighting Systems - Hummer H2



Fig. 68: Dome Lamp Assembly & Headliner
Courtesy of GENERAL MOTORS CORP.

2. Remove the dome lamp assembly from the headliner.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Lighting Systems - Hummer H2



Fig. 69: Electrical Connector & Bulb
Courtesy of GENERAL MOTORS CORP.

3. Disconnect the electrical connector.

4. Remove the bulb.

Installation Procedure

1. Install the bulb.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Lighting Systems - Hummer H2



Fig. 70: Electrical Connector & Bulb
Courtesy of GENERAL MOTORS CORP.

2. Connect the electrical connector.
