7. Replace the front case half if any of the above conditions are found. 8. Inspect the sealing surfaces (1) for damage. 9. Repair small scratches or nicks with a soft stone. 10. Inspect the front case to transmission case mounting surface for damage. 11. Inspect the case threaded bolt holes (2) for damage. 12. Repair any damaged threads. 13. Inspect the transmission to transfer case studs for damage. 14. Replace any damaged studs. Refer to Transfer Case Disassemble and Transfer Case Assemble . 15. Inspect the location pins (3) for being loose or missing. 16. Repair or replace any damaged location pins. 17. Inspect the front output shaft front bearing and the input shaft bearing for the following conditions: z Roughness z Brinelling z Pitting 18. Replace the bearings if any of the above conditions are found. Refer to Transfer Case Disassemble and Transfer Case Assemble . Rear Case Half 1. Clean the rear case half in cleaning solvent and air dry.
2004 Hummer H2 2004 DRIVELINE/AXLE Transfer Case - Overhaul - BW 4482-NR4
|
